Assigned readings

1
Assigned readings
2
SIGNALSTORM NANOMETER DELAY CALCULATOR
CADENCE DATASHEET
3
Introduction

• The movement of VLSI chips to nanometer process
  geometries resulted
• to the domination of interconnect delays in
  total delay
• increased sensitivity to variations in power
  supply
• New Challenges for the delay calculators
• cant model the wires as single lumped effective
  capacitance
• cant use linear approximation techniques for IR
  Drop and ground bounce
• CAD tools need to develop new algorithms for
  nanometer delay modeling
• Signalstorm is a popular tool for performing
  timing characterizations for standard cell
  libraries.

4
Why Do We Need New Solution for Delay Prediction

• Multilevel design methodologies allow great
  variation in power supply voltage
  tools must model this variation in a nonlinear
  fashion
• Modeling input pin capacitance was inaccurate
  because it is based on fixed values rather than
  dynamic values
• Modeling dynamic current and capacitance
  characteristics should take into account of
  nonlinear IR Drop and wire loading effects.

Inadequate delay calculations lead design
failures, and lack of competitiveness in the
market because we might lose the advantages of
nanometer technology.
5
What Are Essential Capabilities for NDC?

• Estimating Ceff

Gate Delay f( Tin, Cload )
Gate Delay f( Tin, Cload, Rpi, C2 ) Requires
4-D table to achieve high accuracy
Single C value that can be replaced instead of
RC-Pi load
6
What Are Essential Capabilities for NDC?

• Timequantized Model of Ceff
• Traditional tool use single values for Ceff
  which results in up to 20 inaccurate slew values
• SignalStorm apply dynamic relationship between
  voltage, current and load capacitance to
  calculate slew and delay.
• SignalStorm computes over several time steps
  during signal ramp to more closely track the
  actual effective capacitance as it changes with
  signal voltage.

Gate Delay f( Tin, Cload )
7
What Are Essential Capabilities for NDC?

• Variable Source Current Modeling with ECMs

• Nonlinear current source fitting
• Input slew output load dependence
• Accurate calculations at multiple driver cells,
  clock meshes, long interconnects, modeling RC
  drop effects
• Most efficient current modeling because it can
  represent complex topologies more accurately

8
What Are Essential Capabilities for NDC?

• IR Drop and Ground Bounce Effects on Timing at
  130 nm
• IR Drop
• Describes the voltage drops caused by current
  flowing from power source through a resistive
  power network to the on-chip devices.
• Ground Bounce
• Describes voltage spikes caused by current
  flowing from on-chip devices through a resistive
  ground network to the ground pins
• IR Drop and Ground Bounce impact silicon
  performance
• Increased clock skew hold time
  violations
• Increased signal skew setup time
  violations

9
Change In Delay With IR is Nonlinear
10
SignalStorm NDC In The Design Flow
11
Synopsis Primetime (Brendan)

• Stand-alone full chip, gate-level static timing
  analyzer.
• It analyzes the timing of large, synchronous,
  digital ASICs.
• Pre-layout static timing analysis

12
Static Timing Analysis

• Setup and hold checks
• Recovery and removal checks
• Clock pulse width checks
• Clock gating checks

13
Design Analysis

• Unclocked registers
• Unconstrained timing endpoints
• Master-slave clock separation
• Multiple clocked registers
• Level-sensitive clocking
• Combinational feedback loops
• Design rule checks (maximum capacitance, maximum
  transition time, and maximum fanout)

14
Inputs -gt Outputs

• Design file
• Synopsys database files (.db)
• Verilog netlist files
• Electronic Data Interchange Format (EDIF) netlist
  files
• VHDL netlist files
• Set up the operating conditions, wireload models,
  port load, drive, and transition time.
• Define the clock period, waveform, uncertainty,
  and latency.
• Specify the input and output port delays.
• Set multicycle paths.
• Set false paths.
• Specify minimum and maximum delays, path
  segmentation, and disabled arcs.

• flip-flops with violations
• setup and hold violations
• timing paths
• rising edge input timing and falling edge input
  timing of all paths in the design
• critical path for each clock group
• timing report for each clock group
• electrical design rule violations

15
Benefits

• Tight integration with other Synopsis tools
• Standalone (lower memory usage than Design
  Compiler, better performance)
• Primetime SI cross talk aware analysis

16
Alternatives

• Dataquest (2004) Synopsis holds 93 of STA
  market share
• ViewLogic Motive
• Bought by Synopsis
• Spice
• More for validation
• Cadence Pearl
• Mentor Graphics SST Velocity

17
Further Information

• PrimeTime Tutorial 1. Introduction to PrimeTime
  and the Tutorial
• Primetime Tutorial
• Have I Really Met Timing? - Validating PrimeTime
  Timing Reports with Spice
• Tobias Thiel
• Proceedings of the Design, Automation and Test
  in Europe Conference and Exhibition Designers
  Forum (DATE04)

18
Statistical Timing Analysis for Intra-Die
Process Variationswith Spatial
CorrelationsAseem Agarwal, David Blaauw,
Vladimir ZolotovUniversity of Michigan, Ann
Arbor, MIMotorola, Inc., Austin, TX
19
Inter-die Intra die variablilty

• Gate length variability
• Intra-die variations
• Random variations
• (no dependence on location)
• Spatially correlated variations

20
Process variation model

• Ignoring all spatial correlations
• Gate length variations small with 3s values of
  less that 15 of Lnom
• The change in gate delay is linear with the
  change in gate length.

21
Correlations

• Reconvergence of circuit paths
• Arrival time of nodes B and C are both dependent
  on the arrival time at node A
• Can be ignored. Gives the upper bound.
• For proof see A. Agarwal et al Computation and
  Refinement of Statistical Bounds on Circuit
  Delay DAC 2003
• Spatial correlation
• Between gate delay and arrival times (complicates
  the propagation)
• Between gate delays (complicates the merging of
  arrival times)
• Ignoring does not give the upper bound. WHY?
• Spatial correlation makes the intra-die
  variability more similar to that of inter-die
  variability, which increases the delay of circuit
  paths.

22
Modeling spatial correlation

• Divide the die into 2lx2l squares
• random variable associated with each
  region (l,r)

23
Modeling spatial correlation
one of random variables in the model
for random variable associated with the
gate based on its position in the die. For all
other
24
sTA Method Propagation

• Arrival times propagated from input to output of
  gates.
• Add gate delay and input arrival time to get
  output arrival time.

25
sTA Method Merging

• a1, a2 arrival times both in the sum of
  components form.
• max(a1,a2) ?
• Expensive requires enumeration of the random
  variables Li
• Inaccurate result does not preserve the spatial
  information for further propagation.
• GOAL generate an output arrival time that is
  efficient and whose CDF is an upper bound on the
  exact arrival time.

26
sTA Method Merging
27
INCREMENTAL TIMING ANALYSISPatent Number
5,508,937Abato et al. Date of Patent Apr. 16,
1996
Presented by Cesare
28
INCREMENTAL TIMING ANALYSIS STA vs. ITA

• STA (static timing analysis) naïve approach
• For each node of the circuit, calculate its
  ltarrival_time, required_timegt couple.
• Observation what happens if some circuit
  parameter changes?
• STA NO PROBLEM ? Re-calculate the entire list of
  nodes (very inefficient solution..)
• Better Approach Incremental timing analysis

29
INCREMENTAL TIMING ANALYSIS Overview
X
W3

• Circuit as a set of sub-circuits
• Each sub circuit is delimited by leftmost nodes,
  and rightmost nodes
• What happens if we increment by 1 the rise/fall
  time of gate G1 ?
• ?The Arrival time for node Y changes
• ?Re-calculate the STA?

2/4
A
2/4
W1
G1
B
Y
W4
2/4 3/4
2/4
W2
C
Rightmost nodes X,Y
Leftmost nodes A,B,C
Sub Circuit_i
Required Time
Arrival Time
30
INCREMENTAL TIMING ANALYSIS Algorithm

• Basic Idea
• Subdivide the circuit in N sub-regions
• Define the frontier of change nodes (rightmost
  and leftmost nodes).
• Store the frontiers of change are stored into two
  separate lists (Arrival queue Required Queue).
• Order the lists according to the the sub-circuit
  level number
• If a node changes its timing propriety, discard
  the delay table of the respective sub-region
• DO NOT compute the STA for the sub-region until
  explicitly requested.

31
INCREMENTAL TIMING ANALYSIS Notes

• The frontiers of change move as recalculation
  progresses.
• The algorithm works recursively.
• Ordered lists ? for a fixed level, we can avoid
  to consider nodes with higher level.
• It is not needed to calculate the sub circuit STA
  every time a node changes!!

32
INCREMENTAL TIMING ANALYSIS

• ANY Questions??
• E
• N
• D
