Systolic Architectures: Why is RC fast

1
Systolic ArchitecturesWhy is RC fast?

• Greg Stitt
• ECE Department
• University of Florida

2
Why are microprocessors slow?

• Von Neumann architecture
• Stored-program machine
• Memory for instructions (and data)

3
Von Neumann architecture

• Summary
• 1) Fetch instruction
• 2) Decode instruction, fetch data
• 3) Execute
• 4) Store results
• 5) Repeat from 1 until end of program
• Problem
• Inherently sequential
• Only executes one instruction at a time
• Does not take into consideration parallelism of
  application

4
Von Neumann architecture

• Problem 2 Von Neumann bottleneck
• Constantly reading/writing data for every
  instruction requires high memory bandwidth
• Performance limited by bandwidth of memory

RAM
Bandwidth not sufficient - Von Neumann
bottleneck
Control
Datapath
5
Improvements

• Increase resources in datapath to execute
  multiple instructions in parallel
• VLIW - very long instruction word
• Compiler encodes parallelism into very-long
  instructions
• Superscalar
• Architecture determines parallelism at run time -
  out-of-order instruction execution
• Von Neumann bottleneck still problem

RAM
Control
Datapath
Datapath
. . .
Datapath
6
Why is RC fast?

• RC implements custom circuits for an application
• Circuits can exploit massive amount of
  parallelism
• VLIW/Superscalar Parallelism
• 5 ins/cycle in best case (rarely occurs)
• RC
• Potentially thousands
• As many ops as will fit in device
• Also, supports different types of parallelism

7
Types of Parallelism

• Bit-level

C Code for Bit Reversal
x (x gtgt16) (x ltlt16) x ((x
gtgt 8) 0x00ff00ff) ((x ltlt 8) 0xff00ff00) x
((x gtgt 4) 0x0f0f0f0f) ((x ltlt 4)
0xf0f0f0f0) x ((x gtgt 2) 0x33333333) ((x ltlt
2) 0xcccccccc) x ((x gtgt 1) 0x55555555)
((x ltlt 1) 0xaaaaaaaa)
8
Types of Parallelism

• Arithmetic-level Parallelism

C Code
Circuit
for (i0 i lt 128 i) y ci
xi .. .. ..
for (i0 i lt 128 i) yi ci
xi .. .. ..

• 7 cycles
• Speedup gt 100x for same clock

• 1000s of instructions
• Several thousand cycles

9
Types of Parallelism

• Pipeline Parallelism

for (j0 j lt n j) y aj x bj
for (i0 i lt 128 i) y ci xi
// output y y 0
for (i0 i lt 128 i) yi ci
xi .. .. ..
Start new inner loop every cycle
After filling up pipeline, performs 128 mults
127 adds every cycle
10
Types of Parallelism

• Task-level Parallelism
• e.g. MPEG-2
• Execute each task
• in parallel

11
How to exploit parallelism?

• General Idea
• Identify tasks
• Create circuit for each task
• Communication between tasks with buffers
• How to create circuit for each task?
• Want to exploit bit-level, arithmetic-level, and
  pipeline-level parallelism
• Solution Systolic architectures
  (arrays/computing)

12
Systolic Architectures

• Systolic definition
• The rhythmic contraction of the heart, especially
  of the ventricles, by which blood is driven
  through the aorta and pulmonary artery after each
  dilation or diastole.
• Analogy with heart pumping blood
• We want architecture that pumps data through
  efficiently.
• Data flows from memory in a rhythmic fashion,
  passing through many processing elements before
  it returns to memory. Hung

13
Systolic Architecture

• General Idea Fully pipelined circuit, with I/O
  at top and bottom level
• Local connections - each element communicates
  with elements at same level or level below

Inputs arrive each cycle
Outputs depart each cycle, after
pipeline is full
14
Systolic Architecture

• Simple Example
• Create DFG (data flow graph) for body of loop
• Represent data dependencies of code

for (i0 i lt 100 I) ai bi bi1
bi2
bi
bi1
bi2


ai
15
Simple Example

• Add pipeline stages to each level of DFG

bi
bi1
bi2


ai
16
Simple Example

• Allocate one resource (adder, ALU, etc) for each
  operation in DFG
• Resulting systolic architecture

b0
b1
b2
Cycle 1

for (i0 i lt 100 I) ai bi bi1
bi2

17
Simple Example

• Allocate one resource for each operation in DFG
• Resulting systolic architecture

b1
b2
b3
Cycle 2

for (i0 i lt 100 I) ai bi bi1
bi2
b0b1
b2

18
Simple Example

• Allocate one resource for each operation in DFG
• Resulting systolic architecture

b2
b3
b4
Cycle 3

for (i0 i lt 100 I) ai bi bi1
bi2
b1b2
b3

b0b1b2
19
Simple Example

• Allocate one resource for each operation in DFG
• Resulting systolic architecture

b3
b4
b5
Cycle 4

for (i0 i lt 100 I) ai bi bi1
bi2
b2b3
b4

b1b2b3
First output appears, takes 4 cycles to fill
pipeline
a0
20
Simple Example

• Allocate one resource for each operation in DFG
• Resulting systolic architecture

b4
b5
b6
Cycle 5

for (i0 i lt 100 I) ai bi bi1
bi2
b3b4
b5

b2b3b4
Total Cycles gt 4 init 99 103
One output per cycle at this point, 99 more until
completion
a1
21
uP Performance Comparison

• Assumptions
• 10 instructions for loop body
• CPI 1.5
• Clk 10x faster than FPGA
• Total SW cycles
• 100101.5 1,500 cycles
• RC Speedup
• (1500/103)(1/10) 1.46x

for (i0 i lt 100 I) ai bi bi1
bi2
22
uP Performance Comparison

• What if uP clock is 15x faster?
• e.g. 3 GHz vs. 200 MHz
• RC Speedup
• (1500/103)(1/15) .97x
• RC is slightly slower
• But!
• RC requires much less power
• Several Watts vs 100 Watts
• SW may be practical for embedded uPs gt low power
• Clock may be just 2x faster
• (1500/103)(1/2) 7.3x faster
• RC may be cheaper
• Depends on area needed
• This example would certainly be cheaper

for (i0 i lt 100 I) ai bi bi1
bi2
23
Simple Example, Cont.

• Improvement to systolic array
• Why not execute multiple iterations at same time?
• No data dependencies
• Loop unrolling

for (i0 i lt 100 I) ai bi bi1
bi2
Unrolled DFG
bi
bi1
bi2
bi1
bi2
bi3


. . . . .


ai
ai1
24
Simple Example, Cont.

• How much to unroll?
• Limited by memory bandwidth and area

Must get all inputs once per cycle
bi
bi1
bi2
bi1
bi2
bi3


. . . . .


ai
ai1
Must write all outputs once per cycle
Must be sufficient area for all ops in DFG
25
Unrolling Example

• Original circuit

for (i0 i lt 100 I) ai bi bi1
bi2
1st iteration requires 3 inputs
b0
b1
b2


a0
26
Unrolling Example

• Original circuit

Each unrolled iteration requires one additional
input
for (i0 i lt 100 I) ai bi bi1
bi2
b0
b1
b2
b3




a0
a1
27
Unrolling Example

• Original circuit

Each cycle brings in 4 inputs (instead of 6)
for (i0 i lt 100 I) ai bi bi1
bi2
b1
b2
b3
b4


b3
b2
b0b1
b1b2


28
Performance after unrolling
for (i0 i lt 100 I) ai bi bi1
bi2

• How much unrolling?
• Assume b elements are 8 bits
• First iteration requires 3 elements 24 bits
• Each unrolled iteration requires 1 element 8
  bit
• Due to overlapping inputs
• Assume memory bandwidth 64 bits/cycle
• Can perform 6 iterations in parallel
• (24 8 8 8 8 8) 64 bits
• New performance
• Unrolled systolic architecture requires
• 4 cycles to fill pipeline, 100/6 iterations
• 21 cycles
• With unrolling, RC is (1500/21)(1/15) 4.8x
  faster than 3 GHz microprocessor!!!

29
Importance of Memory Bandwidth

• Performance with wider memories
• 128-bit bus
• 14 iterations in parallel
• 64 extra bits/8 bits per iteration 8 parallel
  iterations
• 6 original unrolled iterations 14 total
  parallel iterations
• Total cycles 4 to fill pipeline 100/14 11
• Speedup (1500/11)(1/15) 9.1x
• Doubling memory width increased speedup from 4.8x
  to 9.1x!!!
• Important Point
• Performance of hardware often limited by memory
  bandwidth
• More bandwidth gt more unrolling gt more
  parallelism gt BIG SPEEDUP

30
Delay Registers

• Common mistake
• Forgetting to add registers for values not used
  during a cycle
• Values delayed or passed on until needed

Instead of


Correct
Incorrect
31
Delay Registers

• Illustration of incorrect delays

for (i0 i lt 100 I) ai bi bi1
bi2
b0
b1
b2
Cycle 1


32
Delay Registers

• Illustration of incorrect delays

for (i0 i lt 100 I) ai bi bi1
bi2
b1
b2
b3
Cycle 2

b0b1

b2 ?????
33
Delay Registers

• Illustration of incorrect delays

for (i0 i lt 100 I) ai bi bi1
bi2
b2
b3
b4
Cycle 3

b1b2

b0 b1 b3
b2 ?????
34
Another Example

• Your turn
• Steps
• Build DFG for body of loop
• Add pipeline stages
• Map operations to hardware resources
• Assume divide takes one cycle
• Determine maximum amount of unrolling
• Memory bandwidth 128 bits/cycle
• Determine performance compared to uP
• Assume 15 instructions per iteration, CPI 1.5,
  CLK 15x faster than RC

short b1004, a1000 for (i0 i lt 1000 i)
ai avg( bi, bi1, bi2, bi3,
bi4 )
35
Another Example, Cont.

• What if divider takes 20 cycles?
• But, fully pipelined
• Calculate the effect on performance

In systolic architectures, performance usually
dominated by throughput of pipeline, not latency
36
Dealing with Dependencies

• op2 is dependent on op1 when the input to op2 is
  an output from op1
• Problem limits arithmetic parallelism, increases
  latency
• i.e. Cant execute op2 before op1
• Serious Problem FPGAs rely on parallelism for
  performance
• Little parallelism Bad performance

op1
op2
37
Dealing with Dependencies

• Partial solution
• Parallelizing transformations
• e.g. tree height reduction

a
b
c
d
c
d
a
b






Depth of adders
Depth log2( of adders )
38
Dealing with Dependencies

• Simple example w/ inter-iteration dependency -
  potential problem for systolic arrays
• Cant keep pipeline full

a0 0 for (i1 i lt 8 I) ai bi
bi1 ai-1
Cant execute until 1st iteration completes -
limited arithmetic parallelism, increases latency
b1
b2
a0
b2
b3
a1




39
Dealing with Dependencies

• But, systolic arrays also have pipeline-level
  parallelism - latency less of an issue

a0 0 for (i1 i lt 8 I) ai bi
bi1 ai-1
b1
b2
a0
b2
b3
a1




40
Dealing with Dependencies

• But, systolic arrays also have pipeline-level
  parallelism - latency less of an issue

a0 0 for (i1 i lt 8 I) ai bi
bi1 ai-1
b1
b2
a0
b2
b3



a1

41
Dealing with Dependencies

• But, systolic arrays also have pipeline-level
  parallelism - latency less of an issue

a0 0 for (i1 i lt 8 I) ai bi
bi1 ai-1
b1
b2
a0
b2
b3
b4
b3




a1
. . . .

a2

42
Dealing with Dependencies

• But, systolic arrays also have pipeline-level
  parallelism - latency less of an issue

a0 0 for (i1 i lt 8 I) ai bi
bi1 ai-1
b1
b2
a0
b2
b3
b4
b3



Add pipeline stages gt systolic array

a1
. . . .

a2

Only works if loop is fully unrolled! Requires
sufficient memory bandwidth
Outputs not shown
43
Dealing with Dependencies

• Your turn

char b1006 for (i0 i lt 1000 i)
acc0 for (j0 j lt 6 j) acc
bij

• Steps
• Build DFG for inner loop (note dependencies)
• Fully unroll inner loop (check to see if memory
  bandwidth allows)
• Assume bandwidth 64 bits/cycle
• Add pipeline stages
• Map operations to hardware resources
• Determine performance compared to uP
• Assume 15 cycles per iteration, CPI 1.5, CLK
  15x faster than RC

44
Dealing with Control

• If statements

Cant wait for result of condition - stalls
pipeline
char b1006, a1000 for (i0 i lt 1000 i)
if (I 2 0) aI bI bI1
else aI bI2 bI3
Convert control into computation - if conversion
bI2
bi
bI1
bI3
i
2



MUX
ai
45
Dealing with Control

• If conversion, not always so easy

char b1006, a1000, a21000 for (i0 i lt
1000 i) if (I 2 0) aI bI
bI1 else a2I bI2 bI3
bI2
ai
bi
bI1
bI3
i
2
a2i



MUX
MUX
ai
a2i
46
Other Challenges

• Outputs can also limit unrolling
• Example
• 4 outputs, 1 input
• Each output 32 bits
• Total output bandwidth for 1 iteration 128 bits
• Memory bus 128 bits
• Cant unroll, even though inputs only use 32 bits

long b1004, a1000 for (i0, j0 i lt 1000
i4, j) ai bj 10 ai1
bj 23 ai2 bj - 12 ai3
bj bj
47
Other Challenges

• Requires streaming data to work well
• Systolic array
• But, pipelining is wasted because small data
  stream
• Point - systolic arrays work best with repeated
  computation

for (i0 i lt 4 i) ai bi bi1
b3
b4
b0
b1
b2
b2
b3
b1




a3
a0
a2
a1
48
Other Challenges

• Memory bandwidth
• Values so far are peak values
• Can only be achieved if all input data stored
  sequentially in memory
• Often not the case
• Example
• Two-dimensional arrays

long a100100, b100100 for (i1 i lt 100
i) for (j1 j lt 100 j) aij
avg( bi-1j, bIj-1, bI1j,
bIj1)
49
Other Challenges

• Memory bandwidth, cont.
• Example 2
• Multiple array inputs
• b and c stored in different locations
• Memory accesses may jump back and forth
• Possible solutions
• Use multiple memories, or multiported memory
  (high cost)
• Interleave data from b and c in memory
  (programming effort)
• If no compiler support, requires manual rewite

long a100, b100, c100 for (i0 i lt 100
i) ai bi ci
50
Other Challenges

• Dynamic memory access patterns
• Sequence of addresses not known until run time
• Clearly, not sequential
• Possible solution
• Something creative enough for a Ph.D thesis

int f( int val ) long a100, b100,
c100 for (i0 i lt 100 i) ai
brand()100 ci val
51
Other Challenges

• Pointer-based data structures
• Even if scanning through list, data could be all
  over memory
• Very unlikely to be sequential
• Can cause aliasing problems
• Greatly limits optimization potential
• Solutions are another Ph. D.
• Pointers ok if used as array

int f( int val ) long a100, b100 for
(i0 i lt 100 i) ai bi 1

int f( int val ) long a100, b100
long p b for (i0 i lt 100 i, p)
ai p 1
equivalent to
52
Other Challenges

• Not all code is just one loop
• Yet another Ph.D.
• Main point to remember
• Systolic arrays are extremely fast, but only
  certain types of code work
• What can we do instead of systolic arrays?

53
Other Options

• Try something completely different
• Try slight variation
• Example - 3 inputs, but can only read 2 per cycle

Not possible - can only read two inputs per cycle
for (i0 i lt 100 I) ai bi bi1
bi2


54
Variations

• Example, cont.
• Break previous rules - use extra delay registers

for (i0 i lt 100 I) ai bi bi1
bi2
bi2
bi
bi1


55
Variations

• Example, cont.
• Break previous rules - use extra delay registers

for (i0 i lt 100 I) ai bi bi1
bi2
Junk
b0
b1
Cycle 1


56
Variations

• Example, cont.
• Break previous rules - use extra delay registers

for (i0 i lt 100 I) ai bi bi1
bi2
b2
Junk
Junk
b2
b0
b1
Cycle 2

Junk

57
Variations

• Example, cont.
• Break previous rules - use extra delay registers

for (i0 i lt 100 I) ai bi bi1
bi2
Junk
b1
b2
Junk
Junk
Cycle 3

b2
b0b1

Junk
58
Variations

• Example, cont.
• Break previous rules - use extra delay registers

for (i0 i lt 100 I) ai bi bi1
bi2
b3
Junk
Junk
b1
b3
b2
Cycle 4

Junk
Junk

b0b1b2
Junk
59
Variations

• Example, cont.
• Break previous rules - use extra delay registers

for (i0 i lt 100 I) ai bi bi1
bi2
Junk
b2
b3
Junk
Junk
Junk
Cycle 5

b3
b1 b2

First output after 5 cycles
Junk
a0
60
Variations

• Example, cont.
• Break previous rules - use extra delay registers

for (i0 i lt 100 I) ai bi bi1
bi2
b4
Junk
Junk
b2
b4
b3
Cycle 6

Junk
Junk

Junk on next cycle
b1b2b3
Junk
61
Variations

• Example, cont.
• Break previous rules - use extra delay registers

for (i0 i lt 100 I) ai bi bi1
bi2
Junk
b3
b4
Junk
Junk
Junk
Cycle 7

b4
b2b3
Valid output every 2 cycles - approximately 1/2
the performance

Second output 2 cycles later
Junk
a1
62
Entire Circuit
RAM
Input Address Generator
Buffers handle differences in speed between RAM
and datapath
Buffer
Controller
Datapath
Buffer
Output Address Generator
RAM
