Water in the Environment

1
(No Transcript)
2
Atlas 2m thermal infrared image, Atlanta, GA
3
Units kW/m2/day Source R. L. Sass, Rice Univ.
, Houston, TX http//www.ruf.rice.edu/sass/UHI.h
tml
4
Atmospheric Moisture
5
Environmental Significance of Water

• Important component of global energy fluxes
• (latent heat)
• Powerful agent of erosion
• Universal solvent transports nutrients and
  contaminants

• Required for biological processes availability
  determines species distributions


6
Outline

• Hydrologic cycle (water balance)
• Atmospheric moisture (precipitation)
• Clouds and implications for climate change

7
1. Hydrologic Cycle
8
Hydrologic Cycle
9
Water Balance

• Describes the relationship among fluxes of water

Land surface
Oceans
Precipitation
Input
Input
Evaporation Transpiration
Output --
Output
Runoff
Output
Input
Land Precipitation Runoff
Evapotranspiration Oceans Precipitation Run
off Evaporation
10
Water Balance

• Describes the relationship among fluxes of water

Land surface
Precipitation
Input
Evaporation Transpiration
Output
Runoff
Output
Land Precipitation - Evapotranspiration Runoff
11
2. Atmospheric Moisture
12
Atmospheric Moisture

• Amount of moisture held in air depends upon air
  temperature

26 g/kg
15 g/kg
2 g/kg
13
Atmospheric Moisture
http//www.weather.com
Dew point temperature Temperature of an air ma
ss at which it is saturated with moisture
14
Atmospheric Moisture
http//www.weather.com
Relative humidity Amount of water vapor curren
tly in air relative to what air could hold at
that temperature if saturated
If air on 70o F day held 5 g/kg water,
RH 5/15 33
15
Atmospheric Moisture
Who cares?
16
Atmospheric Moisture
As air rises, it cools. Cooler air holds less m
ositure
Adiabatic Cooling
17
Atmospheric Lifting Mechanisms
Convection local heating
18
Atmospheric Lifting Mechanisms
Orographic Lifting topographic barriers
19
Atmospheric Lifting Mechanisms
Frontal Lifting cold / warm air masses
20
Atmospheric Lifting Mechanisms
Convergence high / low pressure gradients
21
(No Transcript)
22
(No Transcript)
23
Monga Bay, Peru
24
Worldwide annual precipitation
25
(No Transcript)
26
3. Clouds
27
Clouds
28
Clouds
29
Clouds
Cloud form

• Stratiform - horizontal
• Cumuliform - vertical
• Cirroform wispy, ice crystals

30
Role of Clouds in Global Climate System
http//www.giss.nasa.gov/research/briefs/delgenio_
03/

31
Role of Clouds in Global Climate System
32
Role of Clouds in Global Climate System
33
Role of Clouds in Global Climate System
Low clouds reflect shortwave radiation
34
Role of Clouds in Global Climate System
Global albedo without clouds
Source E. F. Harrisson et al.,
http//eumetcal.meteo.fr/euromet/english/satmet/s8
220/s8220210.htm
35
Role of Clouds in Global Climate System
36
Role of Clouds in Global Climate System
Global longwave radiation
Source Eugene S. Takle, 2006
http//www.meteor.iastate.edu/gccourse/influ/influ
_lecture_new.html
37
Implications of clouds for climate change

• Surface warming may induce more cloud formation
• Clouds reduce incoming shortwave (albedo)
• Clouds increase counterradiated longwave
  (greenhouse gas)

• Clouds introduce considerable uncertainty to
  climate change scenarios

38
Summary

• Hydrologic cycle describes processes controlling
  fluxes of water

• Water balance used to describe relationship
  between precipitation, runoff and
  evaporation/transpiration

• Moisture content of air is temperature dependent
  (warmer air holds more moisture)

• Air must be cooled for precipitation to occur
  (atmospheric lifting mechanisms)

39
Summary (cont.)

• Atmospheric lifting creates clouds.
• Clouds have varying effects on net radiation
• Effects of climate change on cloud formation
  introduces considerable uncertainty into
  predictions
