Title: Chapter 30 Sources of Magnetic Fields


1
Chapter 30 Sources of Magnetic Fields
  • PHYS 2326-18

2
Concepts to Know
  • Earths Field
  • Magnetic Declination / Inclination
  • 10 deg E of N declination here, inclination is
    up / down from horizontal
  • Magnetic flux
  • Gausss law for magnetism

3
Concepts to Know
  • Magnetic Field Of Moving Charge
  • Permeability Constant
  • Biot Savart Law
  • Magnetic Field of a long straight wire
  • Right Hand Rule

4
Biot-Savart Law
  • dB perpendicular to ds and to r where ds points
    in the direction of current I and r is the vector
    from the current element to P
  • dB magnitude inversely proportional to r2 and
    proportional to current and magnitude ds and to
    the sine of ?, the angle between ds and r

5
Permeability of Free Space
  • The constant µo in Biot-Savart is called the
    permeability of free space.
  • µo 4p 1.0E-7 T m /A Tesla meters /amp.
  • µo 1.2566 E-6 Wb/A m where Wb is a weber or
    Tesla meter2 (magnetic flux)
  • Note too that the speed of light c is related
  • c2 1/(µo eo ) the permeability and
    permitivity of free space

6
Finding B
  • Note that Biot-Savart shows a differential dB
    rather than the total B at a point P
  • To find B one must integrate over the current
    distribution
  • Note that the integrand is a vector

7
Magnetic field of Long Straight Wire
  • See and go through Example 30.1
  • Include eqn 30.5 on your next note card

P
?2
?1
a
I
O
x
8
Current Right Hand Rule
  • Grasp wire with thumb pointed in current flow
    direction.
  • Fingers are wrapped around in direction of B
    which tends to be circular and with a magnitude
    at radius a from the wire given by eqn 30.5

9
Field of Circular Coil
  • Given a current loop of radius a at a distance x
    from the loop on the center axis find the B field
  • by symmetry B will along the x axis

dB-
dB
ds
I
r
a
x
x
P
dBx
10
Circular Coil
  • See Example 30.3
  • Also note for a solenoid of multiple turns N that
    these multiply by N since that multiples I

11
Magnetic FluxGausss Law in Magnetism
  • Electric flux is similar definition to magnetic
    field flux
  • There is no magnetic monopole so no enclosed
    magnetic charge can be inside

12
Magnetic Field of a Moving Charge
  • A moving charge creates a magnetic field in the
    same fashion a current element creates a charge
    except that differential current element is part
    of a whole while a moving charge is the whole
    contribution

13
Biot Savart Compared to Moving Particle
  • Note the similarity between Biot Savarts current
    law and this moving particle
  • I is charge per time moving past a point,
    velocity is distance per time
  • For a point charge, dB becomes the whole field B

14
Example 1
  • Two protons moving together along the x-axis
    separated by 1mm in the y axis with a velocity
    v1.00 E7 m/s
  • a) find the electric force between them
  • b) find the magnetic force between them
  • c) find the total force
  • d) what happens if v 100 m/s

15
Example 1
  • Electric field Fe qE
  • E k q/r2 1.439 E-3 N/C (a)
  • Fe 2.3E-22 N repulsive
  • B µo /4p q v/r2 1.6E-13
  • Fb qvB 1.6 E-13 N/Am attractive (b)
  • F Fe Fb 2.3E-22 N repulsive (c)
  • Ratio Fe/Fb 899

16
Example 1
  • If velocity reduces, E field unchanged, B field
    changes, Fb changes
  • B 1.6E-18 N/Am
  • Fb 2.56E-34 N attractive
  • F 2.3E-22N repulsive
  • R Fe/Fb 8.99 E11

17
Example 2
  • Given a rectangular loop of 10cm x 20cm (a by b)
    with counter clockwise current I2A what is the
    magnitude and direction of magnetic field at the
    center point P
  • B direction right hand rule out of page
  • B BabBbcBcdBda 2Bab 2Bbc

a
d
I
P
b
c
18
Example 2
  • B 1.79E-5 T
