Data Base Concepts

1
Data Base Concepts
2
Origin of DB Concept

• Data base concept of military system origin
• Probable source is SDC circa 1960 a RAND
  corporation spin-off doing USAF systems
• SDC made deliberate attempts to promote systems
  approach for corporate management
• Crucial Characteristics
• Constantly updated
• Accessed interactively (real-time)
• Shared between users/systems, gives different
  views to each

3
DB in Corporate World

• Data base concept crosses over to corporate use
  in early 1960s
• Total Systems Concept
• (aka Management Information System)
• Integrated command system for management real
  time, on-line
• Data base gains scattered usage as crucial,
  shared bucket of facts for this system
• Discussion of DB predates discussion of DBMS by
  about seven years.

4
File Management Software

• As old as corporate computing
• First documented in GE, mid-1950s
• Generalized set of subroutines to update, query,
  maintain sequential files
• Applications keep separate files
• But coding, altering, sharing become easier
• By mid-1960s, becoming more sophisticated
• Offered as commercial products
• Working with new random-access devices
• Often called Information Management software
  (GIS, IMS etc)

5
A File Based System, 1962
6
State of Play circa 1967

• Data base concept is
• Fashionable
• Widely promoted as key to MIS
• Vaporware, revolutionary
• Real-time, on-line, total system
• Closely tied to information retrieval
• File management software is
• Growth area
• Slowly evolving
• Practical, batch-oriented, evolutionary

7
The Information Pyramid

• Information turns control of low-level
  administration into a claim to strategic
  centrality in a new vision of management
• Bottom level of the pyramid is the data base

8
Data Base Management System

• New concept Data Base Management System
• At last! File Management System meets Data Base.
• Appears circa 1968
• CODASYL Data Base Task Group
• Originally in context of extensions to COBOL
• Based on consideration of current file management
  products, directions for future.

9
ANSI-SPARC Three-level Architecture
10
DBMS Foundational Concept

• DBMS as software layer between data, users
• Different interfaces, languages for
• Programs programmers
• Ad-hoc managerial reporting
• Data definition
• maintenance and administration
• Sets up links between files
• BUT rigid, standardized format remain

11
Components of a DBMS
12
Implications

• DBMS concept
• Shapes evolution of modern computing
• Underlies interest in information/data as
  strategic resource from mid-70s onward
• Aids in corporate information system development,
  maintenance
• But at a price
• New concept of database is narrower
• More general information retrieval problems are
  excluded

13
DBMS For Corporate Applications

• Advantages
• easier reporting,program independence from
  details of data,
• faster application development,
• easier maintenance
• Aids integration of different applications
• Disjoint with organizational hopes for data base
  as savior of MIS concept!
• Still unable to deliver on initial dream
• More for programmers than managers

14
Not One Big Database

• Big central database doesnt work
• Finish up with dozens/hundreds of little data
  bases
• Physically separate
• All incomplete
• Different data formats
• Different concepts of data
• Dominant model is relational (eg Oracle)
• Good for updating
• Flexible
• Can be slow complex to extract data for reports

15
From Recent DB Textbook
Management Hierarchy
External data sources and
Top
summarized, tactical databases
(strategic)
Summarized, integrated
Middle
operational databases
(tactical)
Lower
Individual operational
(operational)
databases
Operational databases
16
Data Warehouse Concept

• Emerges early 1990s
• One big DB for everything has failed, so
• Leave transactional systems spread out
  (physically, organizationally), BUT
• Make a second, read-only copy of everything in a
  centralized data warehouse. Update regularly.
• Lots of work for consultants
• Copying, cleaning, reformatting data
• Restructuring data around business areas and for
  easy querying
• Providing query tools for managerial users

17
Data Warehouse Information Flows
