A CMOS SoC for 56/18/16 CD/DVD-dual/RAM
Applications (ISSCC2006 paper 14.8)

• Speaker Bing-Yu Hsieh
• MediaTek Inc.,
• Hsin-Chu, Taiwan
• Authors
• Jyh-Shin Pan, Hao-Cheng Chen, Bing-Yu Hsieh,
  Hong-Ching Chen, Roger Lee, Ching-Ho Chu,
  Yuan-Chin Liu, Chuan Liu, Lily Huang, Chang-Long
  Wu, Meng-Hsueh Lin, Chun-Yiu Lin, Shang-Nien
  Tsai, Jenn-Ning Yang, Chang-Po Ma, Yung Cheng,
  Shu-Hung Chou, Hsiu-Chen Peng, Peng-Chuan Huang,
  Benjamin Chiu, Alex Ho

3
Outline

• Overview
• System Architecture
• Solutions for Low Power Issue
• Performance Comparison
• Summary

4
Overview

• Highly Integrated Commercial Application
• Integrated Analog Front-End
• Built-in 1.5Gb/s SATA PHY
• On-Chip Write Strategy Generator
• PRML Read Channel
• Low Power Control
• Supports Multiple Format of Discs
• CD/DVD-dual/DVD-RAM Record/Playback Operation
  Speed up to 56xS/18xS/16xS

5
System Architecture of FMSOC
Spindle
Pick-up
6
Solutions for Low Power Issue
Optimization Efficiency
ARCHITECTURE

• Efficient DRAM Access
• Adaptive Clock Control
• Multiple Clock Design
• Clock Suppression and Gating
• Voltage Partition
• Reduce Clock Buffer

RTL
BACK-END
7
Efficient DRAM Access - Bandwidth

• Large DRAM B.W. Requirement
• DRAM is shared to multiple functions
• DRAM Access Efficiency
• Performance Index Ave. cycle to access each
  word
• Dominated by the times of DRAM Row Addr. Change

8
Efficient DRAM Access - Recursive Encode
9
Adaptive Clock Control - Background

• Data Rate of Optical Storage Varies with
• Rotation Speed
• Radius of the Access Point
• Numerical Controlled Oscillator
• Adaptive Control with Linear Steps

10
Adaptive Clock Control - Architecture
Automatically adjust system clock with linear
increments according to a throughput rate
indicator
11
Adaptive Clock Control - Performance
.
q
Fixed Freq.
73MHz
e
r
67MHz
70
(94.4mA)
F
)

z
k
(90.1mA)
H
60
56MHz
c
o
M
l
Adaptive

50
(81.5mA)
C

(Digital Core Current)
t
42MHz

i
Freq.
n
m
40
u
e
(70.4mA)
(
t
s
30
y
S
9.2
12.5
16
15.3
DVD Read Speed (unit xS)
12
Chip Micrograph
13
Chip Specification
14
Comparisons of the Chip Performance
15
Summary

• Performance
• Single Chip SoC with CD/DVD-dual/RAM Operation
  Speed up to 56xS/18xS/16xS
• Integration
• SATA, WSG, PRML, Analog Front-End Integration
• 0.18 ?m CMOS with 27.5 mm2 die size
• 772mW _at_ 16xS DVD playback
• Architectural Optimization for Low Power
• Recursive Parity Encode
• Adaptive Clock Control
