1Physics 1251The Science and Technology of
Musical Sound
- Unit 2
- Session 16 MWF
- The Wave Properties Propagation
2Physics 1251 Unit 2 Session 16 Wave
Properties Propagation
- Foolscap Quiz
- What is frequency of the pitch that a person
will perceive, if he hears the harmonics in the
vibration recipe 350 Hz, 525 Hz, 700 Hz and 875
Hz?
Answer 175 Hz (F3), fundamental of series 350
Hz (F4), 525 Hz (C5), 700 Hz (F5) and 875 Hz
(A5). We hear the difference frequencies
(525-350) (700-525) (875-350) 175 Hz!
3Physics 1251 Unit 2 Session 16 Wave
Properties Propagation
- Georg Phillip Telemann
- Sonata IV in E minor
- Recorded by Ron DiIulio (UNT September 2001)
4Physics 1251 Unit 2 Session 16 Wave
Properties Propagation
- Georg Phillip Telemann
- Sonata IV in E minor
- Notice the difference tones
5Physics 1251 Unit 2 Session 16 Wave
Properties Propagation
- 1' Lecture
- The intensity of sound decreases with the square
of the inverse of the distance from the source in
an open area. - I / I0 (r0 /r) 2
6Physics 1251 Unit 2 Session 16 Wave
Properties Propagation
- 1' Lecture
- The Sound Intensity Level (SIL) diminishes with
distance thus - SIL SIL0 20 Log (r / r0 )
7Physics 1251 Unit 2 Session 16 Wave
Properties Propagation
- Thought question
- What happens to a sound wave as it propagates or
travels?
8Physics 1251 Unit 2 Session 16 Wave
Properties Propagation
- The intensity of a spherical sound wave decreases
as the distance from the source increases.
Inverse
d m I W/m2
1.0 1.0
12 /12 12/2 2 12 /3 2 12 /4 2 12 /5 2 As
1/r 2
2.0 0.25
3.0 0.11
4.0 0.068
5.0 0.040
9Physics 1251 Unit 2 Session 16 Wave
Properties Propagation
- Intensity is Power per Unit Area
- Why does intensity
- diminish as 1/r 2?Area 2/3p ? r 2
- I Power/Area
- I I0 (A0 /A)
- I I0 (r0 / r ) 2
A ?p r 2
r
10Physics 1251 Unit 2 Session 16 Wave
Properties Propagation
- Demonstration of Inverse Square Law
I1 I1 ? (r1 /r2) 2 I1 ? (r1
/r3)2
Source
r1
r2
r3
The fraction of the sound energy that enters the
ear decreases as the ratio of the inverse of the
square of the distance because the fractional
area decreases as 1/r 2.
11Physics 1251 Unit 2 Session 16 Wave
Properties Propagation
- 80/20Inverse Square Law
- The intensity of sound (originating from a point
source in an open environment) diminishes as the
square of the inverse ratio of the distances from
a source. - I / I0 (r0 /r) 2
12Physics 1251 Unit 2 Session 16 Wave
Properties Propagation
- Practice
- The sound intensity is 1.0 x10 -9 W/m2 at a
distance of 3.0 m from a speaker. What is the
intensity 20 m away?
I2 / I1 ( r1 /r2 ) 2 I2 / (1 .0 x10-9
W/m2) ( 3.0 m / 20 m ) 2 I2 (1 .0 x10-9
W/m2) (.0225) 2.25 x10 -11 W/m2
13Physics 1251 Unit 2 Session 16 Wave
Properties Propagation
- 80/20Inverse Square Law
- The Sound Intensity Level (SIL) decreases by 20
dB for every 10x increase in distance.
SIL SIL0 20 Log (r / r0)
14Physics 1251 Unit 2 Session 16 Wave
Properties Propagation
- 80/20Inverse Square Law
- If I / I0 (r0 /r) 2
Then 10 Log (I / I0 ) 10 Log((r0 /r) 2)
10 Log(I/Ithreshold) 10 Log(I0 /Ithreshold)
20 Log((r0 /r))
SIL SIL0 -20 Log(r/r0 )
SIL SIL0 20 Log (r / r0)
15Physics 1251 Unit 2 Session 16 Wave
Properties Propagation
- Practice
- The sound intensity level of the professors
lecture is 80 dB on the front row of the
classroom, 3 m from the his mouth. What is the
SIL at the back row if it is 6 m away and there
are no reflections?
SIL SIL0 20 dB Log ( r /r0 ) SIL 80 dB
20 dB Log ( 6 m/3 m) 74 dB
16Physics 1251 Unit 2 Session 16 Wave
Properties Propagation
- Summary
- The intensity of sound decreases with the square
of the inverse of the distance from the source in
an open area. - I / I0 ( r /r0 ) 2
- The Sound Intensity Level diminishes with
distance thus - SIL SIL0 20 Log (r / r0)
