Evolutionary Computation I

1
Evolutionary Computation I

• COMP4001/7001
• 5 September 2005

2
Learning ObjectivesAt the end of this lecture
students will understand

• What is an evolutionary algorithm?
• Effects of evolutionary operators
• The course of computational evolution
• Interactions between evolution and

3
Learning ObjectivesAt the end of this lecture
students will understand

• What is an evolutionary algorithm?
• Effects of evolutionary operators
• The course of computational evolution
• Interactions between evolution and

4
Why look to evolution?

• Evolution is inherently interesting
• Evolutionary theories are easy to generate,
  almost impossible to test
• EC modelling can be used as a proof of principle,
  but never existence proof
• Evolution is an optimization technique
• Biological evolution optimizes organisms to their
  environments
• EC can be used to optimize programs / processes
• Evolution is the only process to date which has
  produced intelligence
• EC can be used in an attempt to understand how
  human intelligence works
• May be the best hope for AI

5
History of EC

• 1957 Fraser (Australian geneticist)
• bitstring representation of a chromosome and a
  stochastic Monte Carlo approach
• investigating questions such as the effects of
  linkage on the efficiency of selection, the
  relationship between the fitnesses of alleles and
  factors such as population size and intensity of
  selection, and the comparison of the efficiencies
  of different breeding plans for varying degrees
  of inter-locus interactions
• The algorithm was run on SILLIAC, the parallel
  computer at the University of Sydney. SILLIAC
  (Sydney ILLIAC) was a slightly modified version
  of the ILLIAC developed by the University of
  Illinois, Urbana, United States. It cost 50,000
  to construct, had a store of 1024 40-bit words,
  could perform 13,333 additions/subtractions per
  second, and read its input off punched paper tape

6
More history

• 1957 Box
• evolutionary optimisation process for the
  improvement of processes in a chemical plant,
  involving carefully planned variations to the
  procedures used in the operation of the plant
  itself
• 1966 Fogel, Owens and Walsh
• groundbreaking analysis of the possibilities of
  simulated evolution for the development of
  artificial intelligence
• 1975 John Holland
• Adaptation in Natural and Artificial Systems an
  Introductory Analysis with Applications to
  Biology, Control and Artificial Intelligence
• Classic GA

7
Evolutionary algorithms

• All EC algorithms involve
• a population of individuals
• which undergo repeated generations of genetic
  modification, fitness evaluation and
  fitness-proportionate selection.
• The genetic operators used to perform the
  genetic modifications are simplified versions of
  those found in biological systems.
• Many operators have been described in the
  literature
• Lots of different flavours of EA
• Each makes different decisions about
  implementation

8
Learning ObjectivesAt the end of this lecture
students will understand

• What is an evolutionary algorithm?
• Effects of evolutionary operators
• The course of computational evolution
• Interactions between evolution and

9
Operators

• Representation
• Hollands GA used binary chromosomes
  (bitstrings)
• representations ranging from strings of floating
  point numbers to entire Lisp programs are used
  for different problems by various practitioners
• Mutation
• acts to introduce variability into the population
  by altering the chromosome
• most usual mutation operator for a bitstring
  chromosome consists of flipping a bit from 0 to 1
  or vice versa, with a given probability, the
  mutation rate.

10
More operators

• Crossover
• recombines parts of two (or more) chromosomes to
  form new individuals
• Single point crossover

11
Selection

• Selection should be fitness proportionate
• fitter individuals should contribute more to the
  next generation, on average, than less fit
  individuals
• selection method should have an element of
  stochasticity so that every individual, no matter
  how unfit, has a chance of becoming a parent
• If only the fittest individuals in each
  generation are allowed to breed the population
  rapidly converges to the best solution found
  early, which is very unlikely to be the global
  best solution
• Lots of different selections algorithms, produce
  different types of selection pressure

12
The Simple Genetic Algorithm
13
Other Approaches

• Evolutionary Programming (EP)
• Fogel in the early 1960s, it has no genomic
  representation. Each individual in the population
  is an algorithm chosen at random over an
  appropriate sample space. Mutation is the only
  genetic operator used EP does not use crossover
• Evolution Strategies (ES)
• Schwefel, also in the 1960s, as an optimisation
  tool. ES uses a real-valued chromosome with a
  population size of one and mutation as the only
  genetic operator. In each generation the parent
  is mutated to produce a descendant if the
  descendant it fitter it becomes the parent for
  the next generation, otherwise the original
  parent is retained.

14
And more

• Classifier Systems
• Holland (1975). A classifier takes inputs from
  the environment and produces outputs indicating a
  classification of the input events. A classifier
  system produces new classifiers through the
  action of a genetic algorithm on the systems
  population of classifiers
• Genetic Programming (GP)
• Koza in the late 1980s, the aim of GP is the
  automatic programming of computers allowing
  programs to evolve to solve a given problem. The
  population consists of programs expressed as
  parse trees operators used include crossover,
  mutation and architecture-altering operations
  patterned after gene duplication and gene
  deletion in nature
• Many others, often tailored to problem at hand

15
Learning ObjectivesAt the end of this lecture
students will understand

• What is an evolutionary algorithm?
• Effects of evolutionary operators
• The course of computational evolution
• Interactions between evolution and

16
Fitness landscapes

• Wright (1932) for a given set of genes each
  possible combination of gene values (alleles)
  could be assigned a fitness value for a
  particular set of conditions
• Entire genotype space can then be visualized as a
  landscape, with genotypes of high fitness
  occupying peaks and those of low fitness forming
  troughs
• Generally very high-dimensional

17
The course of evolution in silico
This EA has a chromosome length of 10 bits and a
population of 10 individuals. The fitness
function is simply a count of the number of 1s in
the chromosome maximum fitness is therefore 10.
The EA uses elitism, where the fittest individual
in each generation is retained. Elitism ensures
that a good solution, once found, is never lost,
and means that the maximum fitness in the
population always increases
18
Computational evolution

• Fitness originally random
• Increases over time
• Faster at first
• Eventually converges to a local optimum
• Not necessarily the global optimum
• Stochastic, so usually must be repeated
• Can be time consuming
• Can produce good solutions that work unexpectedly

19
Schema Theorem

• Holland, 1975
• short, low-order, above-average schemata receive
  exponentially increasing trials in subsequent
  generations
• If the chromosome is a bit string, a schema is a
  set of building blocks described by a template
  consisting of ones, zeros and asterisks
• Template 100011 can be
• 10100111
• 10100101
• 10000101
• 10000111

20
Schema theorem

• an evolutionary algorithm proceeds by identifying
  short schemas of high fitness in different
  individuals, and recombining them using crossover
  in order to produce longer schemas of higher
  fitness, and eventually entire individuals having
  high fitness
• attractive because it suggests that schemas can
  be identified and the effects of mutation and
  crossover upon schemas in a population of a given
  size can be calculated exactly
• mathematical tractability would potentially
  provide useful insights into the way in which an
  EA functions

21
Testing schema theory

• Royal road functions - Mitchell, Forrest and
  Holland (1991)
• structured to provide a smooth, easy path to
  maximum fitness under the assumptions of schema
  theory
• hierarchical fitness landscape, in which
  crossover between instances of fit lower-order
  schemas tends to produce ever fitter higher-order
  schemas
• relatively highly fit intermediate stages could
  in fact interfere with the finding of fit
  higher-order solutions, since once an instance of
  a fit intermediate schema is discovered its
  relatively high fitness allows it to spread
  quickly throughout the population, carrying with
  it hitchhiking genes in positions not included
  in the schema. Low-order schemas tend to be
  discovered more-or-less sequentially, rather than
  in parallel

22
Variability

• Basis of evolution
• Mostly mutation
• In Eas, mostly point mutations

23
Mutation
24
Mutation rate

• Mutational meltdown a mutation rate so high
  that the species cannot survive in the face of
  the number of errors generated
• about 1 mutation per genome per generation given
  that mutations occur at random
• maximum rate at which an organism can expect to
  produce at least one error-free offspring in its
  lifetime
• Many EC implementations use a mutation rate of
  1/genome
• In RNA viruses, about one nucleotide per genome
  is incorrectly reproduced per replication for
  retroviruses the rate is one nucleotide per ten
  genomic replications and for DNA-based microbes
  it is about one per 300 replications
• Longer genomes do not have higher mutation rates
  error-correcting machinery

25
Error correction (Ridley, 2000)

• Autocopying the first reproducers were probably
  molecules of RNA or something similar, that could
  copy themselves using bases from their
  environment
• Copying enzymes the evolution of enzymes which
  catalysed the copying process would also have
  made the process more reliable
• Double stranded genetic material organisms which
  used DNA rather then RNA have the advantage of
  having a more stable information carrying
  molecule, plus the advantage of having a two
  complementary copies of the sequence, to
  facilitate error checking
• Suite of proofreading and repair enzymes
• Development a developmental process translating
  a genotype into a phenotype allows for the
  correction of errors on the fly in the course of
  development all errors do not have to be
  corrected in the genome
• Ploidy using two or more copies of each
  chromosome provides redundancy of the genetic
  information, permitting the identification and
  correction of errors
• Sex recombination of genetic material from more
  than one individual introduces the possibility of
  concentrating genetic errors in a small
  proportion of scapegoat offspring, allowing the
  other offspring to be error-free

26
Neutrality

• Before the details of the molecular basis of
  genetics were worked out in the late 1950s, it
  was generally assumed that most mutations cause
  phenotypic alterations that are immediately
  subject to selection. Under these circumstances
  all the variation in a population is adaptive
• Electrophoresis huge amount of variability at
  the protein level
• Motoo Kimura (1968) evolution is driven
  primarily by random drift among equally
  well-adapted sequence variants
• Ohta (1973) Nearly neutral variants which do,
  in fact, have a small selective difference can
  become effectively neutral in small populations,
  where random events become more important
• Neutral networks in EC have been demonstrated
  to affect the course of evolution by facilitating
  random drift to more useful areas of the search
  space

27
Managing variability

• Variability is systematically eroded by
  selection, while at the same time being
  replenished via mutation and recombination
• Different flavours of EA emphasise the importance
  of mutation (e.g. evolutionary programming)
  versus recombination (e.g. genetic algorithms) in
  generating novelty
• Effects of selection tend to outweigh those of
  mutation and recombination, and the population
  converges towards a peak in fitness space
• Neutral mutations rarely occur, unless
  deliberately designed into the algorithm

28
Premature convergence

• In most EAs the entire population eventually
  reaches a single peak and tends to stay there
• If this peak is not the global maximum, the EA is
  considered to have converged prematurely
• Premature convergence occurs when the population
  loses the genetic variability which is essential
  to continued evolution
• This almost complete loss of genetic diversity is
  never observed in biological populations

29
Causes of premature convergence

• Haploid genotype exposes every mutation to
  selection
• Diploid genotype have been used require a
  dominance map or equivalent
• EAs using diploid chromosomes do
• tend to maintain more genetic variability
• than haploid EAs, but they rarely find
• better solutions
• benefit of recessively masked variability
• will only be realised if the environment
• in which the population is evolving changes

30
Psuedo Founder Effects

• The Founder Effect occurs when a population
  passes through a population size bottleneck, from
  which only a few individuals emerge to establish
  a new population, for example when a small number
  of individuals colonize a new island
• In EAs a related phenomenon frequently occurs
  when a very fit individual arises in the
  population it tends to dominate future
  generations
• since most individuals are descended from a
  single individual they tend to be very similar in
  sequence, and so the crossover operator will have
  little effect
• any genes which happen to be on the
  pseudo-founders chromosome will also spread
  throughout the population, whether or not they
  are valuable, a phenomenon know as hitchhiking

31
Other factors

• Intense, unidirectional selection pressure
• Development
• Troubleshooting mechanisms
• Added source of noise
• Environmental interactions

32
Speciation

• Preselection two individuals are mated to
  produce an offspring, which is compared with both
  the parents. If the fitness of the child is
  greater than that of the worst parent, it
  replaces that parent in the population. The idea
  is that individuals are replaced by others which
  are fitter than they are, but similar in
  sequence, so that a number of different solutions
  can be maintained in the population, improving
  gradually over time
• Crowding the crowding of solutions in search
  space is discouraged, for example by comparing a
  new individual with a subset of the existing
  population, and replacing the most similar of
  that subset with the new individual.
• Fitness Sharing when there are a number of
  individuals with very similar sequences, the
  fitness of that genotype is shared amongst them
  all. This is a very popular diversity maintenance
  operator, and there are a large number of
  variants on the scheme.

33
More speciation

• Niching encouraging the development of different
  ecological niches in the population, using an
  approach such as the spatially restrained
  grid-based algorithm
• Coevolution evolving more than one type of
  individual at once, with different species
  attempting as part of their fitness function to
  maintain as much genetic distance from other
  species as possible.
• Restricted Mating individuals are only allowed
  to mate if they are in the basin of attraction of
  the same optimum. Once again, this scheme
  attempts to replace like with like in the
  population. There are a number of variants on the
  restricted mating approach

34
Hill Climbing

• implicit parallelization by maintaining a
  population of candidate solutions which are
  modified by mutation and/or crossover, the
  algorithm is, in effect, exploring different
  regions of its search space in parallel
• simplest alternative to a population based EA is
  a hill climber, an algorithm which has a
  population of one individual, and performs a
  strictly local search using mutation
• The parallel nature of an EA provides no
  advantages over multiple random restarts of a
  hill climber in terms of the number of solution
  evaluations performed

35
When is an EA better?

• the action of the genetic operators used in the
  EA provided advantages over local search, which
  would, indeed, be the case if the schema theorem
  was acting as described, with useful partial
  solutions discovered by different individuals
  being recombined to produce fitter individuals
  more rapidly than could be done by mutation
  alone or
• the structure of the fitness landscape was such
  that the implicit memory of a population-based
  algorithm (i.e. the memory encoded into the
  structure of the population itself as a result of
  evolution) allowed it to concentrate its search
  in areas of high fitness in a manner that would
  not be possible for a hill climber
• In practice, hill climbers with multiple restarts
  often perform as efficiently as or better than
  population-based algorithms

36
Learning ObjectivesAt the end of this lecture
students will understand

• What is an evolutionary algorithm?
• Effects of evolutionary operators
• The course of computational evolution
• Interactions between evolution and

37
Coevolution

• The interactions between two or more species as
  they evolve
• Kauffmans rubber sheet evolution by one species
  modifies the fitness landscape for both species
  the coevolving species is thus given a spur to
  further evolution, as its environment changes
• Fitness landscape is constantly changing
• powerful strategy for avoiding premature
  convergence in evolutionary algorithms is less
  chance of the population converging to a local
  minimum, since local (and global) minima are
  constantly forming and dissolving as the fitness
  landscape changes

38
Using coevolution

• Samuels checker players (1963)
• hill climber, in which two programs played
  against each other
• In the course of the game one program modified
  its parameter settings, while the other remained
  static
• If the modified copy won the game, it was
  accepted, otherwise the original was retained
• eventually played checkers at the level of a
  human champion
• Fogel (2001) still using evolution to develop
  checkers players (Blondie21)

39
Learning and evolution

• Neural networks may be evolved architecture,
  connection weights, or both
• Baldwin Effect (Baldwin, 1896) learning on the
  part of individuals could guide the course of
  evolution in the population as a whole
• A particular trait may be learned, or it may be
  innate
• A learned trait has the advantage of providing
  flexibility, but the disadvantage of being slow
  to acquire an innate trait is present from
  birth, but inflexible
• Traits which are initially learned may become,
  over time, encoded into the genotype of the
  population

40
The Baldwin effect

• Two preconditions must be met
• The trait in question (which may be a behaviour
  or a physical trait) must be influenced by
  several interacting genes, so that a mutation in
  one of these genes will make the phenotypic
  expression of the trait more likely and
• an individual bearing such a mutation can learn
  to express the trait
• learning acts to provide partial credit for a
  mutation
• An individual carrying a mutation that
  predisposes it towards an advantageous phenotype
  will learn the trait more easily than its less
  fortunately genetically endowed conspecifics, and
  thus will survive and pass on more copies of that
  allele to the next generation. Over time,
  multiple mutations will accumulate in the genes
  for the desirable trait, which will thus become
  innate in the population

41
Baldwin landscapes
42
Conclusions

• Evolutionary computation can be used to
• Model biological evolution
• Optimize arbitrary functions
• Evolve artificial intelligence?
• EC is a very simplified version of real evolution
• It is important to understand what these
  simplifications involve
• Can be combined with many of the other approaches
  discussed to date
• EC can be used to solve problems which are
  otherwise intractable

43
Learning ObjectivesAt the end of this lecture
students will understand

• What is an evolutionary algorithm?
• Population-based, adaptive, optimization, not
  necessarily global optimum
• Effects of evolutionary operators
• Mutation, crossover, selection, others
• The course of computational evolution
• Fitness increase, variability, premature
  convergence, etc
• Interactions between evolution and
• Coevolution, evolution and learning
