UAS Regional Optical Network

1
UAS Regional Optical Network

• June 15, 2006

2
Opportunities for Collaboration
Ultrahigh-speed Networks

• 100s Gigabytes/second
• End-to-end performance guarantees
• Quality-of-service
• Advanced network monitoring and reporting

3
Internet Member Universities September 1997
4
(No Transcript)
5
Why RON When We Have I2?

• Greater bandwidth
• Dedicated bandwidth
• Collaboration competitive edge
• Freedom from acceptable use policies
• Catalyst for economic development
• Need both a production experimental network
• Achieve Cost Savings with multiple networks using
  same infrastructure

6
National LambdaRail Infrastructure
7
National LambdaRail (NLR)

• Consortium of research universities and leading
  edge technology companies
• Deploying national infrastructure for
• advanced network research
• next-generation, computationally intensive
  network-based applications
• Supporting multiple, independent high speed links
  to research universities and centers

8
NLR Members

• CENIC Stanford, UC, CSU, CIT, USC
• PNWGP Pacific Rim, Alaska, Idaho, Montana,
  Oregon, Washington, British Columbia
• Duke University NC universities
• MATP Virginia Tech, UVA, Old Dominion, VCU,
  George Mason, William Mary
• Cornell University

9
NLR Members

• FLR Florida Atlantic, Florida International,
  Florida Institute Technology, FSU, University of
  Florida, University of Miami, etc.
• Georgia Tech SLR GT, GSU, UGA, Medical
  College of Georgia
• Louisiana Board of Regents
• Oklahoma State Board of Regents

10
NLR Members

• Lonestar Education and Research Network UT
  system, Texas AM system, Texas Tech system,
  Baylor
• University of New Mexico
• UCAR Colorado, Wyoming, Utah
• Oak Ridge National Laboratory

11
NLR/RON Network Model

• Supports multiple, distinct experimental and
  production networks
• Supports Point-to-point switched Ethernet as well
  as routed IP networks
• We purchase long term leases of dark fiber
• We light the dark fiber
• We own and manage the infrastructure
• RONs connect to NLR backbone
• RONs connect to Internet - commodity I2

12
NLR and the RONs
13
UAS Motivation

• Attract and retain the best and brightest
• Leverage our individual strengths to reach out to
  collaborate
• Provide infrastructure to widen research
  opportunities
• Control our wide area networking destiny
• Take advantage of current market opportunities
• Solve real world problems

14
Progress to Date

• Feb 2005 campus Presidents approve pursuing
  dark fiber acquisitions
• Mar 2005 IT committee briefed
• Summer 2005 bids for dark fiber routes
• Awarded Nashville to Atlanta (Level3)
  Tuscaloosa to Birmingham (Deltacom)
• Negotiate with NASA/NLR/SLR to connect MSFC in
  Huntsville

15
SLR Agreement

• SLR uses UAS fiber in exchange for optronics to
  light the fiber to connect MSFC to NLR
• UAS campuses would only have to pay incremental
  costs to connect each campus

16
Next Steps

• Establish local fiber loops in Huntsville
  Birmingham
• Finalize SLR agreement
• Purchase optronics
• Negotiate partnerships with AREN and Tennessee
  for additional services

17
Estimated Costs for UAS RON
18
Costs Funding by University
19
UA Timeline
20
UAB Timeline
21
UAH Timeline
22
Collaboration Success Story

• 2004 Estimated cost was 15M
• 2006 Estimated cost is 1.5M

23
Questions?
24
Request Approval

• Resolution approving establishment of a Regional
  Optical Network for the Three Campuses of The
  University of Alabama System found on page 2 in
  your committee packet.
