Well completion

1
Well completion

• The value of smart well technology

Hans Ivar Berge 30 Oct. 2007
2
Well completion reservoir management

• Important elements in well completion
  assessments
• Field production strategy (gas / water
  injection)
• Commingled production (multiple zone completion)
• Formation properties and expected well
  productivity will help to decide
• Number of wells, single zone / multi zone
  completions...?
• The need for multi lateral technology?
• Multi lateral technology including branch
  control?
• Across field communication and the effect of
  injection scheme?
• What do we need?A flexible downhole completion
  solution to be able to handle unexpected
  production results as water gas breakthrough,
  loss of productivity etc

3
Smart well concept
4
Schlumberger On/Off valve
TRFC-H
TLFC-H
Path of fluid flow
Annulus to Tubing
In Line
Path of fluid flow
5
Norne, Smart well tech., Welldynamics
- Upper, Middle and Lower Assembly -
Infinitely Variable Choke
6
WellDynamics Low cost valve (MC)

• On/off
• Two control lines to operate
• Short (1 m)

7
Smart well completions, some key pro- elements.

• Remotely controlled inflow systems, ref. the
  trade mark s-c-r-a-m-s
• Production inflow control for the individual
  production interval.
• Pressure monitoring for each of the zones without
  intervention..
• Allows for individual zonal cleanup in reservoirs
  with contrasts in res. pressure.
• Represents a major improvement of injection
  control incommingled water injectors, ref.
  thermal fracturing and change in inflow profile
• Provides critical data for well planning,
  placement of future wells..!
• Will allow for reduced frequency of well
  interventions
• Plug and perf. operations..
• Running of straddle sleeves for isolation of gas
  and water breakthrough
• Reduced need for PLTs etc...

8
Smart well completions, some cons- key elements.

• Production inflow control for the individual
  production interval.
• To allow for production inflow control for the
  individual production interval external zonal
  isolation is critical..
• Smart well equipment could have the potential to
  choke back and
• Often reduce the maximum flow capacity of the
  well.
• Can smear out the potential production profile,
  impacting net present value
• Segmentation in well design has to match the
  segmentation in the reservoir
• Equipment reliability is important
• Increased upfront investments, 1,5 3 mil UDS
  time for installation.
• Compatibility with other completion equipment /
  interfacing particular in subsea developments..

9
The Tampen Area
10
Tampen and the Snorre installations
Snorre B. Reservoirs Lunde 2 STOIIP138.2
MSm3 Reserves 58.1 MSm3
Snorre A. Reservoirs Statfjord, Lunde 2 STOIIP
399.2 MSm3 Reserves 174 MSm3
11
Snorre A B
Challenge big contrasts in kH-product and
uncertain injection pressure support
12
Snorre production experience

• Production and completion challenges
• Heavily faulted and stacked multiple reservoirs.
  Gross thickness gt 1000 m TVD
• Multiple zone injection of gas and water..
• Big contrasts in productivity and connectivity.
• Multiple zone production
• Snorre A, experience
• Experienced early breakthrough of gas and water
  in high perm. thief zones
• Well intervention with PLT for reservoir
  diagnostics complicated, x-flow!
• Positive experience with smart well equipment..

13
Experiences from Snorre A P-14B

• Background
• Snorre A producer
• 4 sleeves 1 mechanical
• Gas breakthrough expected after6 months in the
  Lunde fm.
• Experience
• Gas breakthrough 3 months after startup
• Remotely controlled smart well equipment
  identified zone of breakthrough.
• Result 1815 Sm3/d increase in oil rate

14
Experiences from Snorre B C-5H PLT/WSO

• One of three predrilled wells with no smart well
  technology installed.
• Water breakthrough after 2 weeks of production.
• PLT run in April 2003 Inconclusive due to
  X-flow masking flow information.
• Set plug based on reservoir understanding,
  reservoir simulation and separator testing.
• Straddle set over anticipated water producing
  interval. Oil production came back as water was
  produced out of x-flowed interval after 5 days of
  production.

• Swapped production lines. Increase in oil
  production of app 2450 Sm3/d for C-5H.
• In the event of smart well technology potential
  increased value app. 590 MNOK!

15
Risk analysis of installation of smart well
technology
16
(No Transcript)
17
Smart well completions, service companies...

• All the big service providers are involved
• Schlumberger, Weatherford, Baker Inteq,
  Halliburtion (Welldynamics)
• Technology
• Direct hydraulic
• Electric and hydraulic
• Electric, hydraulic and chemical downhole
  injection.
• Fiber optics for distributed temperature and
  pressure sensing in the production interval.
  Veslefrikk downhole mono-phase flowmetering.
• Future wireless communication. Saudi Aramco
  Welldynamics....

18
Smart well completions and subsea

• Challenges
• Many subsea providers and hydraulic and electric
  communication systems not standarized.
• Through 2002 2006 the industry has agreed to
  adapt to Intelligent well interface
  standarization.
• As a result all completion providers can
  interface hydraulic and electic signals through
  the subsea control systems.

19
Smart well and subsea interfacing.
Surface
Subsea control module
5 suppliers
Subsea control system
Power Communication
Downhole sensor control
10 suppliers
Well
20
IWIS (Intelligent Well Interface Standard)
Surface
Subsea control module
5 suppliers
Subsea control system
Standard
Power Communication
Downhole sensor control
10 suppliers
Well
21
IWIS update

• JIP completed (ex. Qantex) beginning of April
  2006 - Successfully

FMC
Vetco
Kværner
Cameron
DrillQuip
Schlumberger
Weatherford
Roxar
Wood Group
WellDynamics
Promore
22
IWIS testing
FMC
Vetco
Kværner
Cameron
DrillQuip
Schlumberger
WellDynamics
Promore
Roxar
Wood Group
Weatherford
23
Implementing IWIS
Downhole application
Surface Control
Surface Control
Subsea Electronic Module
Subsea Electronic Module
Interface Card
Interface Card
Well equipment
Well equipment
24
Full flexibility
25
The value of smart well completions

• Close linked to a multi disciplinary
  understanding of the challenge
• Understanding the reservoir production strategy
  and production profile.
• Completion strategy and effect of same on
  production profile
• Acceleration / possible negative effect on
  production profile.
• Economics and net present value.!
• The value of production flexibility and
  production monitoring (future wells, bypassed
  reserves..)
• Understanding the risk and interfaces in the
  installation phase.
• Every case is unique and requires good multi
  engineering input from the subsurface teams as
  well as from the production facilities group..

26
Back-up
27
Light Well Intervention due to lack of smart well
technology
28
Tyrihans, an example of a multi lateral oil
producer

• Multi laterals with individual flow control.
• Increased reservoir contact to minimize gas and
  water coning.
• Installation of gas lift to aid production at
  start up and to increase oil production at high
  water cuts.
