BHEL / Ranipet
Innovator Identification Camp 2006 Chennai 26th
September
Areas For Development
and
Commercialization
2
Potential For Wind Electric Generator Components

• Wind Power
• Annual Capacity Addition (India) 1500 MW
• Annual Capacity Addition (Global) 11000 MW
• Each WEG should have all the parts discussed in
  this presentation

3
Potential For Wind Electric Generator Components
Liquid Level sensors Accurate liquid level
sensors which can be integrated to control
panels for logical decision making. The sensors
should work on non contact principle, accurate,
reliable, weather proof and shock
proof. Minimum Requirement 3000 Nos. (OEM
Spares )
4
Potential For Wind Electric Generator Components
Anemometers Wind speed measurement device for
wind electric generator application. Anemometer
should be compact, reliable and should have very
good accuracy of better than ? 2 Minimum
Requirement 3000 Nos. (OEM Spares )
5
Potential For Wind Electric Generator Components
Wind vanes Wind direction indicators for wind
electric generator application. Wind vane
should be compact, reliable and should have very
good accuracy of better than ? 2 deg. Minimum
Requirement 3000 Nos. (OEM Spares )
6
Potential For Wind Electric Generator Components
Wire less data transmitters Wire less data
transmitters for wind farm applications using
standard RS 232 ports covering minimum distance
of 1 km for Monitoring wind farms. Potential
Infinite potential. All wind farm owners once
informed on the financial benefits will go for
this. This technology can be extended to all
other areas for remote monitoring in factories
etc. Highly profitable area.
7
Potential For Wind Electric Generator Components
Constant velocity couplings Constant velocity
couplings for small to large power transmissions.
This is a very simple but precisely
manufactured component. Potential Huge
potential. Wind turbines have CV couplings.
However in automotive industries CV couplings are
widely used. Highly profitable area.
8
Potential For General Engineering Components
9
Potential For General Engineering
Components
Huck Type Bolts High quality Huck Type bolts of
various sizes for industrial applications to make
permanent joints. The design should be unique and
innovative delivering similar functions as Huck
bolts. A Huck bolt is essentially a rivet that is
installed with a hydraulic tool Potential Huge
potential. In BHEL alone very large quantity is
required per annum.
10
Potential For General Engineering
Components Contd
Electronic Manometers for various ranges 0.1 to
5 bar 5 to 25 bar handheld type Non contact
type temperature indicators, Torque transducers (
flange mounted), proximity speed
sensors Potential BHEL uses these measuring
instruments and Indian market can absorb these
products easily.
11
Potential For General Engineering
Components Contd
Flow control Valves, digital anemometers, limit
switches, level switches, lube oil regulators,
oil filters, Ash level indicators, hand held
vibration measuring meters etc., ---
specifications can be given Potential BHEL
uses these measuring instruments and Indian
market can absorb these products easily.
