Biological Membranes and Transport

1
Biological Membranes and Transport

• Brooker Chapter 5

2
Membranes of the Cell

• Plasma membrane (Cell membrane)
• Membranes that make-up organelles

3
All cell membranes are made of phospholipids and
proteins

• Phospholipids have hydrophilic heads and
  hydrophobic carbon chain tails
• Phospholipids form a bilayer membrane

4
The Phospholipid Bilayer

• Hydrophilic heads
• phosphate
• other charged groups

• Hydrophobic tails
• fatty acid side chains
• saturated
• unsaturated

5
Sandwich and Fluid Mosaic Models
How are proteins and lipids arranged in cell
membranes?
6
Proteins and lipids can move within the membrane

• Lateral movement of lipids/proteins is quick
• Lipids and proteins rarely flip across the lipid
  bilayer

Fluid Mosaic Model
7
The Fluid Mosaic Model Today

• There are three types of membrane proteins
• Integral membrane proteins
• Transmembrane proteins
• Lipid anchored proteins
• Peripheral proteins
• Are attached to other proteins or lipids on the
  surface of the membrane

8
ABO Blood Groups in Humans
FYI

• Cells that have A B blood types have slightly
  different versions of the enzyme galactosyl
  transferase. This enzyme adds a sugar chain to
  a membrane protein.
• Type O blood has a protein that is unable to add
  this sugar

9
Did you know?
FYI

• Approximately 25 of all cellular proteins are
  membrane proteins
• Approximately 70 of all medications exert their
  effects by binding to membrane proteins
• Aspirin, ibuprofen, acetaminophen bind to an ER
  membrane protein that is necessary for the
  synthesis of chemicals that play a role in pain
  sensation and inflammation

10
Membrane Permeability Getting things in and out
of the cell

• Biological membranes are selectively permeable
• Small molecules and lipids pass through the
  membrane
• Larger and charged/polar molecules cannot
• Proteins allow movement of charged/polar
  molecules

11
Transport Across Membranes

• Diffusion and Osmosis
• Channel proteins
• Transport Proteins
• ATPase Pumps
• Bulk Transport
• Endocytosis and Exocytosis

12
Diffusion

• Molecules in solution tend to slowly spread apart
  over time. This is diffusion.

13
Diffusion is Concentration Dependant

• Concentration gradient a difference in
  concentration of a substance
• Diffusion is the net movement of particles from a
  region of higher to lower concentration down a
  concentration gradient.
• At equilibrium particles are uniformly distributed

14
Concentration gradient
15
Passive Diffusion
Movement of gases and small hydrophobic molecules

• Unaided by proteins
• No energy required
• Move across a concentration gradient (high-gt
  low)
• Dependant upon hydrophobicity of the molecule

16
Osmosis

• ALL compounds undergo diffusion.
• Osmosis is the diffusion of water across a
  membrane.
• Since cells have membranes, osmosis is important
  to cells
• Water can pass directly through the membrane OR
• In special cells, it crosses the plasma membrane
  through proteins called aquaporins

17
Osmotic Terminology
Solution Solute Solvent

• Hypertonic more concentrated
• Hypotonic less concentrated
• Isotonic equally concentrated

Refers to the solute concentration

• Hyper, hypo, and iso are used to compare two
  solutions to each other.

18
Membranes and Osmosis

• Tank w/ semi-permeable membrane water may pass,
  solute (particles)cant
• At first the concentration of solute is very high
  on the left.

19

• But over time, the water moves across the
  semi-permeable membrane, and dilutes the
  particles.

A
B
20
Animal Cells and Osmotic Pressure
21
Cells and Osmotic Pressure

• All cells have thin delicate membranes
• They respond to differences in external solute
  concentration and osmotic pressure
• If placed in an isotonic environment (usually
  0.9 w/vol NaCl), no change in shape
• If placed in an hypertonic environment (high
  salt) then the cell shrinks
• If placed in an hypotonic environment (low salt),
  then the cell expands and can lyse (burst)

22
(No Transcript)
23
Plant Cells and Osmosis
24
Plant Cells and Osmosis

• In plants, hypotonic solutions produce osmotic
  pressure also called turgor pressure
• Turgor means tight or stiff owing to being very
  full
• Keeps plant upright in hypertonic conditions
  plants wilt

25
The exchange of CO2 between body cells and RBCs
FYI
26
Movement of Molecules across a membrane

• Passive Diffusion
• Protein independent movement of molecules
• Simple diffusion of small molecules across the
  bilayers
• Protein dependant movement
• Facilitated diffusion
• Active transport
• Bulk Transport Endocytosis and Exocytosis

27
Transport Across Membranes

• Facilitated Diffusion
• Channel Proteins
• Ion Channels
• membrane potential
• CFTR
• Transporters
• Uniporters
• Symporters
• Antiporters

• Active transport
• ATP Pumps
• Na/K Pump

28
Facilitated diffusion

• Channel Proteins
• Protein channels in the plasma membrane
• Transport ions with the concentration gradient

29
Facilitated diffusion

• Channel proteins
• A transport protein aids the movement of solutes
  down a concentration gradient.
• Movement is powered by a concentration gradient.

30
Cystic Fibrosis

• Most common lethal autosomal recessive genetic
  disease of Caucasian population
• CFTR is the gene for a Cl- ion channel protein
• Channels are located in the epithelia of the
  lungs, pancreas, sweat glands, kidneys
• Chloride channels defective or absent
• Sodium channels effected too

31
2. Transporters

• Uniporter
• one molecule/time down a concentration gradient
• Symporter/ Antiporter
• Simultaneous mvmt of two different molecules

32

• Uniporters move a single solute in one direction.
• Uniporters are different from channels because
  they dont move just ions.

33

• Symports move 2 solutes in same direction

34

• Antiports move 2 solutes in opposite direction
• One must bind, then the other, to the same
  transmembrane protein, then both move

35
Active Transport

• ATP-Pumps
• transport against concentration gradients
• depends upon ATP hydrolysis
• Organelles/Organs that use pumps to maintain
  acidic pH lysosomes, vacuoles, and the stomach

36
Active Transport

• ATP-derived energy is used to move solutes across
  the membrane, against a gradient.
• Shown the Na/K pump
• Here, two gradients are formed, one for each ion.
• Gradients have opposite orientation
• Sodium is high outside, low inside
• Potassium is high inside and low outside

37
The Na/K ATPase (Pump) in Action
38
Other Pumps FYI
39
Pumps, Channels, and Transporters work together
to maintain levels of ions and other molecules in
the cell
40
Summary of Transport, Diffusion, and Osmosis
41
Bulk Transport

• Exocytosis out of the cell
• Endocytosis into the cell
• Phagocytosis
• Receptor mediated endocytosis
• Pinocytosis intake of fluids

42
Transport by Vesicles Exocytosis

• Very energy-expensive !!
• How are the vesicles getting from the Golgi to
  the Plasma membrane?

43
Endocytosis
44
Endocytosis Phagocytosis

• Uptake of particles
• Phagocytosis Cell eating (bacteria, viruses,
  etc)
• Food particles are digested by fusion of the
  uptake vesicle with lysosomes

45
Receptor-Mediated Endocytosis

• Receptors on the surface of cell binds specific
  ligand
• Transport by clathrin coated vesicles
• Here, cholesterol uptake by the LDL receptor

46
0.25µm
(b)
