Loop Transformations

1
Loop Transformations

• Vectorization
• Statement Reordering
• Loop distribution

2
Strategies for Optimization

• Loop transformations can be used systematically
  in a variety of different ways to achieve a
  desired program form.
• This particular strategy was developed to
  generate code for vector supercomputers
• It can be used for vector co-processors and with
  few modifications for SIMD co-processors

3
The xvector option

• Transforms loops using an intrinsic function to a
  single call to a faster vectorized equivalent
• for ( I0 IltN I)
• xI exp(yI)
• Syntax -xvectoryes no
• These vector functions are a part of the libmvec
• (man libmvec)
• It has to be added on the link line also

4
Vectorization
Vector supercomputers, vector co-processors and
with few modifications for SIMD co-processors

• Goals
• generate array syntax
• convert Fortran 77 to Fortran 90
• create vector code for vector supercomputers or
  vector co-processors
• Approach
• convert as many statements in program loops as
  possible into vector form

5
Vector Code

• A(2 101) B(1100) A(1100)
• right hand side is evaluated, then left hand side
• Above is not the same as
• DO I 2, 101
• A(I) B(I-1) A(I -1)
• END DO

True dependence!
6
Vector Code
A(2 101) B(1100) A(1100)

• is the same as
• DO I 2, 101
• TEMP(I) B(I-1) A(I-1)
• END DO
• DO I 2, 101
• A(I) TEMP(I)
• END DO

No dependences!
Finish this loop before we start next one!
No dependences!
7
Vectorization

• Transformation generates a vector statement to
  replace a statement within a loop nest.
• It is applied to individual statements.
• But we must first generate series of loop nests
  where the loop body consists of a single
  statement.
• Vectorization is legal if it preserves all
  dependences of the original code.

8
Example
DO I 1, N A(I) B(I) C(I) D(I)
A(I-1) D(I) END DO
this becomes A(1N) B(1N) C(1N)

• is equivalent to-

DO I 1, N A(I) B(I) C(I) END DO DO I
1, N D(I) A(I-1) D(I) END DO
this becomes D(1N) A(0N-1) D(1N)
9
Strategy

• First, loop distribution is used to replace a
  loop nest by multiple loops with a single
  statement each
• and then vector code generation is used to
  vectorize each statement in both loops.
• Works so long as there is no dependence cycle
  involving these statements.

10
In General

• If there is a dependence with source in a
  statement that comes textually after the sink
  statement, we re-order the statements in the loop
  first.
• The vector statement defining new values must be
  executed before the vector statement using them.

11
Statement Reordering Example
antidep
DO I 1, N A(I) B(I) C(I) D(I)
A(I1) D(I) END DO
this becomes D(1N) A(0N-1) D(1N)
DO I 1, N D(I) A(I-1) D(I) END DO DO I
1, N A(I) B(I) C(I) END DO

• is equivalent to-

DO I 1, N D(I) A(I1) D(I) A(I) B(I)
C(I) END DO
this becomes A(1N) B(1N) C(1N)
12
Statement Reordering

• The statement reordering transformation has many
  uses
• Synopsis Exchange the position of two adjacent
  statements in the body of a loop.
• Legality test Valid iff there is no
  loop-independent dependence between the pair of
  statements.

13
Statement Reordering
bef appears in source text before

• Exchanges text position of two adjacent
  statements in a loop.
• Given loop L containing adjacent statements S,
  S, with S bef S and S S does not hold.
  Creates loop L with S and S swapped.
• Suppose S1 S2 for statements S1 and S2. Then
  there are iteration vectors i1 and i2 such that
  S1(i1) k S2(i2), and the former defines a
  value used by the latter.
• If k , this would change the meaning of the
  loop. So this is what we must test for.

14
Loop Distribution

• Used to isolate some statements in a loop nest
  from other statements.
• Simple form of loop distribution attempts to
  transform a loop nest with multiple assignment
  statements in loop body to a series of loop
  nests, each containing a single assignment
  statement.
• It is not necessary that the statements are all
  enclosed in exactly the same loop nest.

15
Loop Distribution Example
DO K 1, M A(K) 0. DO J 1, N
A(K) A(K) B(J,K) END DO END DO
DO K 1, M A(K) 0. END DO DO K 1, M
DO J 1, N A(K) A(K) B(J,K) END
DO END DO
becomes
16
Validity of Loop Distribution

• Let S, S be statements in a loop L.
• A dependence S S is backward iff S bef S.
• We call all other dependences forward.
• A backward dependence is loop-carried.
  Distribution of L would destroy it.
• Therefore loop distribution may be applied to a
  loop L iff all of its dependences are forward.

17
Illegal Loop Distribution Example
S2 S1
DO I 1, N S1 A(I) B(I) C(I-1) S2 C(I)
B(I) END DO
DO I 1, N S1 A(I) B(I) C(I-1) END DO
DO I 1, N S2 C(I) B(I) END DO
is not equivalent to
Of course, if we had applied statement reordering
first.
18
Loop Distribution

• Let L be a loop and L be the code obtained by a
  legal distribution of loop L.
• Then L preserves the type of all dependences in
  L. But it does not preserve the level.
• If S S in L, then S S in L.
• If S c S in L. then S c S in L.
• If S c S in L, where S ! S, then S S
  in L.

19
Loop Distribution

• A loop L can be transformed into an equivalent
  loop L with no backward dependences
• by a sequence of valid statement reordering
  transformations
• iff its dependence graph is
• either acyclic or
• contains only single-statement cycles.
• If vectorization is the objective, it can
  immediately follow

20
Limits of Loop Distribution

• If there is a non-trivial cycle in the dependence
  graph,
• e.g. S S and S S
• then any legal statement reordering will exchange
  the dependences.
• But this does not eliminate backward edges, so
  loop distribution cannot be applied to the
  resulting loop.

21
Loop Distribution

• Assume loop L has an acyclic dependence graph.
• 1. Number nodes of graph S1, .., Sn such that if
  Sj Sk, then j lt k.
• Then if S bef S1, S S1 does not hold.
• 2. So S1 can be moved to the first position in
  the loop by legal statement reorderings, etc.
• 3. Now assume the first k statements in loop are
  S1,..,Sk. Let S be statement immediately before
  Sk1.
• Since S Sk1 cannot hold, Sk1 can be reordered
  to follow Sk.
• This has only forward edges.

22
Loop Fission

• Name sometimes given to more general form of loop
  distribution
• Some loops are only partially distributive.
• The general transformation separates distributive
  statements from non-distributive code.
• The former can then be vectorized.

23
Loop Fission Example

• DO I 1, N
• DO J 1, M
• S1 A(I,J) ..
• S2 A(I,J1) A(I,J)
• END DO
• S3 B(I) X Y(I)
• S4 D(I) B(I) 1
• END DO

dt
do
S3
dt
S4
24
Loop Fission Example

• DO I 1, N
• DO J 1, M
• S1 A(I,J) ..
• S2 A(I,J1) A(I,J)
• END DO
• END DO

vectorizable
DO I 1, N S3 B(I) X Y(I) END DO DO I
1, N S4 D(I) B(I) 1 END DO
Not vectorizable
25
Loop Fission Example

• DO I 1, N
• DO J 1, M
• S1 A(I,J) ..
• S2 A(I,J1) A(I,J)
• END DO
• END DO
• S3 B(1N) X Y(1N)
• S4 D(1N) B(1N) 1

dt
do
26
Vector Code Generation

• Replaces single-statement loop that is not
  recurrence by vector (array) form
• DO I L, U
• A(I) B(I) C(I1)
• END DO
• becomes
• A(LU) B(LU) C(L1U1)

27
General Vector Code Generation

• Find cycles in dependence graph D.
• 2. Create the acyclic condensation (this is new
  graph where each cycle is represented by a node)
  AC(D). Order its nodes.
• 3. Perform sequence of statement reordering
  transformations so that all statements in a cycle
  are adjacent, and the order of statements in
  different cycles corresponds to their order in
  AC(D).
• 4. Apply loop distribution to this loop.

28
Example
S1

• DO I L, U
• S1 A(I) B(I) C(I1)
• S2 B(I1) A(I-1) D(I)
• S3 E(I) E(I-1) 1
• S4 C(I2) E(I) F(I)
• END DO
• S1 and S2 are in a dependence cycle
• S3 has a single statement cycle
• S3 d S4 and S4 d S1

dt
dt
S2
dt
dt
S3
dt
S4
29
Example

• The acyclic condensation is
• DO I L, U
• S3 E(I) E(I-1) 1
• END DO
• DO I L, U
• S4 C(I2) E(I) F(I)
• END DO
• DO I L, U
• S1 A(I) B(I) C(I1)
• S2 B(I1) A(I-1) D(I)
• END DO

S3
S4
S1,S2
30
Example

• Only the second loop is vectorizable
• DO I L, U
• S3 E(I) E(I-1) 1
• END DO
• S4 C(L2U2) E(LU) F(LU)
• DO I L, U
• S1 A(I) B(I) C(I1)
• S2 B(I1) A(I-1) D(I)
• END DO

recurrence
Dependence cycle
31
Vector Code Algorithm

• This does not suffice to deal well with many loop
  nests encountered in practice.
• Fortunately, we can still improve upon this
  result in general.

• We
• can sometimes further transform a loop nest so
  that the vector code transformation is applicable
• can exploit opportunities for vectorization of
  some levels of a loop nest.
• may also apply additional dependence-breaking
  transformations.

32
Scalar Expansion
DO K 1,N DO I 1, N T(I)
T(I) A(K)
DO K 1,N DO I 1, N T T
A(K)

• This transformation creates a copy of a scalar
  variable for each iteration of the loop nest in
  which it occurs by replacing the variable with an
  appropriately dimensioned array.
• This transformation may eliminate dependences
  while preserving the semantics of the code.
• It is particularly useful in vectorizing and
  shared memory parallelization.

33
Scalar Expansion

• Replaces a scalar variable by an array of the
  same size as a loops iteration space.
• Input perfect nest L of n loops with scalar A on
  left hand side of assignment in L.
• A is not a formal parameter, induction variable,
  single- statement reduction or element in common
  block.
• The kth loop in L has lower bound Lk and upper
  bound Uk.
• Output modified loop where all references to A
  are replaced by a reference to an n-dimensional
  array A(L1U1,,LnUn), followed by assignment
  to A immediately after loop nest
• A A( U1, U2, , Un)

34
Scalar Expansion

• If the first occurrence of A in L is a use, we
  modify the above as follows
• the lower bound in the last dimension is (Ln-1)
  instead.
• An assignment to A is inserted immediately
  before the loop A(L1,..,Ln-1) A.
• All uses of A before the first definition in L
  are replaced by A(I1,I2,..,In-1). All other
  occurrences are replaced as previously.

35
Idiom Recognition
Maybe we can handle this after all
DO I L, U E(I) E(I-1) 1 END DO

• Recognize frequent (small) computations that can
  be tuned to target architecture, and perform
  specific optimizations.
• Examples
• dot product,
• max and min values of array
• maxloc and minloc of array
• scalar product
• matrix multiplication

36
Loop Interchange

• Powerful transformation to exchange order of two
  loops
• Reorders execution of statement instances, so
  only legal if this does not change semantics of
  program
• Has many uses, e.g.
• Move vectorizable loops to innermost position of
  loop
• Move parallelizable loops to outermost position
  to increase granularity and decrease
  synchronization

37
Loop Interchange

• Rearrange execution order of statement instances
  in loop
• Goals increase use of cache, move dependence
  cycles
• Legality valid if data dependences are preserved
• Input a (perfectly) nested loop L of depth n gt
  1, interchange level c lt n
• Output loop nest L that is obtained from L by
  exchanging the order of the DO loop headers for
  Lc and Lc1
• Generalizations to imperfectly nested loops, and
  to pairs of non-adjacent loops

38
Loop Interchange Example

• DO J 1, M
• DO I 1, N
• A(I,J1) A( I1, J) B
• END DO
• END DO

DO I 1, N ? DO J 1, M
A(2,2) is defined in iteration (1,2) and used in
(2,1)
39
Loop Interchange Example
dir(gt,lt)
da

• Loop interchange is not legal for this loop
• DO J 1, M
• DO I 1, N
• A(I,J1) A( I1, J) B
• END DO
• END DO
• A(2,2) will get the wrong value

DO I 1, N DO J 1, M
A(2,2) is defined in iteration (2,1) and used in
(1,2)
40
Loop Interchange

• The direction vector records the loop levels
  associated with each dependence.
• After interchanging a pair of adjacent loops, the
  new direction vector is formed by exchanging the
  corresponding entries in the direction vector.
• If loop interchanges swaps the references
  involved in a dependence, then it will change the
  semantics of the program.
• A dependence with direction vector (lt,gt) would
  become (gt,lt) if the loops are swapped. But this
  does reverse the access pattern!

41
Loop Interchange

• So we must test whether there are direction
  vectors of the form (lt,gt) involving the loop
  levels that we want to exchange.
• If not we can apply the transformation.
• If there are such direction vectors, the
  transformation is illegal and cannot be applied.

42
Legal Loop Interchange

• The transformation exchanging loops c, c1 does
  not modify any loop dependences at levels other
  than c, c1.
• If dir(i,i) is (c-1,lt,,,..,) then in the
  modified loop this will become (c,lt,,..,). If
  dir(i,i) is ( c-1, lt, lt,,,) it remains
  unchanged.
• Thus if S(i) d k S(i) for any 1 k lt c or
  c1 lt k n, or if k then S(i) d k
  S(i) in the modified loop.
• If S(i) d c1 S(i), then in the new loop S(j)
  d c S(j)

If a loop at some level p is not involved in any
loop-carried dependences, then it may be moved
inward to any other level.
43
Example

• DO J 1, 100
  DO K 1, 100
• DO I 1, 100
  DO I 1, 100
• DO K 1, 100
  DO J 1, 100
• C(I,J) C(I,J) A(I,K) B(K,J)
  C(I,J) C(I,J) A(I,K) B(K,J)
• END DO
  END DO
• END DO
  END DO
• END DO
  END DO
• Version on left has true dependence in innermost
  loop.
• In version on right, loop level 1 has been
  interchanged with loop level 3. This is legal
  because the level 1 loop has no dependences.

44
Example
Here, there is a dependence at the innermost level

• DO I 1, L
• DO J 1, M
• C(I,J) 0.0
• DO K 1, N
• C(I,J) C(I,J) A(I,K) B(K,J)
• END DO
• END DO

dt
dt
There are many ways to vectorize matrix
multiplication
45
Example

• DO I 1, L
• DO J 1, M
• C(I,J) 0.0
• ENDDO
• ENDDO
• DO K 1, N
• DO I 1, L
• DO J 1, M
• C(I,J) C(I,J) A(I,K) B(K,J)
• END DO END DO
• END DO

Apply loop distribution and then loop interchange
to move dependence to outermost level
46
Example

• C(1L,1M) 0.0
• DO K 1, N
• C(1L, 1M) C(1L, 1M) A(1L,K)
  B(K,1M)
• END DO
• We now have vector code, although this may not be
  the most suitable form for many machines
• It may be more appropriate to vectorize in one
  dimension only and to apply strip mining to it

47
Example

• DO J 1, M
• C(1L, J ) 0.0
• DO K 1, N
• C(1L, J) C(1L, J) A(1L,K)
  B(K,J)
• END DO
• END DO
• is vectorized in a single dimension

48
Example

• DO J 1, M, 32
• DO J J, J31
• C(1L, J ) 0.0
• DO K 1, N
• C(1L, J) C(1L, J) A(1L,K)
  B(K,J)
• END DO
• END DO
• breaks up work into vectors of length 32

49
Example
Here, the problem is that the updates use a
temporary scalar, T. We cannot apply scalar
forward substitution.

• DO I 1, L
• DO J 1, M
• T 0.0
• DO K 1, N
• T T A(I,K) B(K,J)
• END DO
• C(I,J) T
• END DO

50
Scalar Expansion
Scalar expansion generates an array that replaces
the scalar T

• DO I 1, L
• DO J 1, M
• T ( I, J) 0.0
• DO K 1, N
• T(I,J) T(I,J) A(I,K)
  B(K,J)
• END DO
• C(I,J) T (I,J)
• END DOs

Unfortunately, this is very wasteful of memory!
51
Strip Mining

• DO I 1, L
• DO J 1, M, 32
• DO J J, J 31
• T ( I, J ) 0.0
• DO K 1, N
• T(I, J ) T(I, J )
  A(I,K) B(K,J)
• END DO
• C( I,J) T ( I, J )
• END DO
• END DO
• END DO

Strip mining creates vectors with length equal to
that of the vector registers (here, we use 32)
52
Software Pipelining

• Recall this overlaps execution of multiple
  iterations of a loop nest
• To exploit multiple hardware resources
  concurrently
• Requires data dependence testing to determine
  legality
• Some transformations may improve results
• Loop unrolling may increase workload in an
  iteration to enable more efficient schedule
• For large loops, loop distribution may reduce the
  amount of data used in an iteration to avoid
  register spills
