Design and Application Spaces for 6LoWPAN

• (draft-ekim-6lowpan-scenarios-01)
• IETF-70 Vancouver
• Wednesday, December 5th 2007
• 1300 1500 Afternoon Session I
• Eunsook Kim, Nicolas Chevrollier, Dominik Kaspar,
  JP Vasseur

2
Goal of design and application spaces draft

• Goal
• This is an Recommendation for 6LoWPAN
  applications
• Documents how 6LoWPAN networks deploy and list
  main characteristics (e.g. topology, security,
  traffic pattern, )
• Non Goal
• We are not trying to provide an EXHAUSTIVE
  description of the all possible deployments

3
In the last meeting

• Major parameters
• Deployment (Manual vs. Automatic, Addressing
  Mechanism dynamic configuration, battery/mains
  power)
• Network Size (10, 100, 1000, )
• Routing (Topology, Single-hop, Multi-hop, data
  centric, event driven, address centric,
  localization based)
• Mobility (fixed vs. moving)
• Connectivity (always connected, intermittent,
  sporadic)
• Security/ Threat model
• Scenarios
• Structure Monitoring
• Healthcare
• Vehicular Networks
• Agricultural Monitoring

4
Update (-01)

• Four Parameters are added
• Security Level
• Power Source
• QoS
• Traffic Pattern

5
Update (-01)

• Four Scenarios are updated based on the added
  parameters
• Two scenarios are added
• Industrial Monitoring
• Connected Home

6
Industrial Monitoring (1/2)

• Application fields
• Process Monitoring and Control
• Machine Surveillance
• Supply Chain Management and Asset Tracking
• Storage Monitoring
• Ex
• Various sensor measurements together with
  controllers and actuators
• gas pressure
• the flow of liquids and gases
• room temperature and humidity
• tank charging levels
• to improve a plant's productivity in a continuous
  self-controlling loop

7
Industrial Monitoring (2/2)

• Dominant Parameters
• Deployment pre-planned, manually attached
• Mobility no (except Asset Tracking)
• Network size medium to large
• Power source battery-operated
• Security level high
• Routing multi-hop, highly event-driven
• Connectivity always on for crucial case,
  otherwise intermitted
• QoS important
• Traffic pattern P2P (actuator control), MP2P
  (data collection)

8
Connected Home

• Application fields
• Home safety/security
• Home automation and control
• Healthcare
• Smart appliances
• Dominant Parameters
• Deployment multi-hop topologies
• Mobility small degree of mobility
• Network size medium number of nodes, potentially
  high density
• Power Source mix of battery and AC powered
• Security level authentication and encryption
  required
• Routing no requirement for multi-topology or QoS
  routing
• Connectivity intermittent (usage-dependent sleep
  modes)
• QoS support of limited QoS (small number of
  Class of Service)
• Traffic Pattern P2P (inter-device), P2MP and
  MP2P (polling)

9
Questions and Future work

• WG feed-back on the document very much welcome
• Does the WG agree that such a document is useful?
• If so, what can be the next step for the ID?
• (more scenarios? More detail description?
  etc.)
