Transmission Lines

1
Transmission Lines
2
Water Wave Motion
3
Speed of Voltage Wave
4
Speed of Voltage Wave
5
Transmission Line of Infinite Length
Assuming that the wire resistance is zero.
6
Open Transmission Line of Finite Length
Assuming that the wire resistance is zero. 16.292
uS is the time it takes for the wave front to
travel 1 mile and be reflected back..
7
Shorted Transmission Line of Finite Length
Assuming that the wire resistance is zero. 16.292
uS is the time it takes for the wave front to
travel 2 miles.
8
Transmission Line Terminated with Characteristic
Impedance
Assuming that the wire resistance is zero.
9
LC model of transmission line
10
Propagation of voltage wave front

                         Propagate at speed of
light.
11
(No Transcript)
12
Characteristic Impedance
13
Long and Short Transmission Lines

• In a short line, the propagation time is way less
  than ¼ of the period time of the RF on the line.
• In a long line, the propagation time is at least
  ¼ of the period time of the RF on the line.
• Thus long lines are at least ¼ wave length long.
  (775 miles for 60 Hz, 1.62 feet for 100 MHz))

14
Reflected Wave
1
15
Reflected Wave
2
16
Reflected Wave
3
17
Reflected Wave
4
18
Reflected Wave
5
19
Reflected Wave
6
20
Reflected Wave
7
21
Reflected Wave
8
22
Reflected Wave
9
23
Reflected Wave
10
24
Reflected Wave
11
25
Reflected Wave
12
26
Reflection Coefficient

• The amount of reflected voltage

27
The Reflected Voltage
28
Maximum Voltage on the Line
29
SWR
30
Standing Wave
31
Standing Wave Ratio if the Load is a resistor
only.
Whichever is Greater
32
The Standing Wave

• Adding the reflected wave to the incident wave
  produces a standing wave.
• The standing wave is actually the ONLY voltage
  along the line.
• The standing wave oscillates in magnitude

33
SWR

• A perfectly terminated line has SWR 1
• A line with high SWR acts like an antenna.
• High voltage nodes may stress the insulation of a
  transmission line.

34
The Open Transmission Line
DC
RF
¼ l
35
¼ Wave Open Transmission line
36
½ Wave Open Transmission Line
1/2l
37
¼ Wave Shorted Transmission Line
38
Shorted Transmission Line
DC
RF
¼ l
39
½ Wave Shorted Transmission Line
1/2l
40
¼ Wave Transmission Line as an Impedance Matching
Transformer

• Find the necessary ZO
• From the cable specs get the velocity factor
• Calculate the length the wavelength
• Use a ¼ wave transmission line.

41
Constant XL curves
Origin marked 1.0
Distance Scale
Resistive Axis
Constant XC curves
42
Why use a Smith Chart?

• Design antenna matching networks
• Calculate input impedance of transmission lines
• Calculate SWR
• Express frequency-impedance relationships
  graphically
• Characterize the impedance of RF processors

43
Smith Chart fun and games

• The origin represents the characteristic
  impedance of the processor (or transmission line)
• Normalization to the characteristic impedance
  makes the Smith Chart universal.

Do not plot this
Plot this
44
Terminating Impedance
SWR
