Enter the Physicists

1
Enter the Physicists

• Reading Ch 3-3..3-5

2
Galileo The Physicist
3
Falling Objects
4
Describing Motion

• Speed distance over time (miles per hour)
• Speed is a scalar, i.e. just a number (60 mph)
• Velocity speed AND direction
• Drive at 60 mph due East
• Velocity is a vector (magnitude and direction)
• Acceleration change in velocity over time
• Speed can increase or decrease
• Acceleration is also a vector

5
Galileos Results

• A falling object feels a constant acceleration of
  gravity he called g (direction down)
• No matter what the composition or shape of the
  object, it fell with the same acceleration g
• For Earth g 9.8 m/s2

6
(No Transcript)
7
How Galileo really did it
a g sin(q)
Needed to slow down acceleration
Best Timer Sand Clock
8
Apollo 15 Galileo Demo

• http//www.youtube.com/watch?v4mTsrRZEMwANR1

9
If there was no air
10
Weight and Mass

• The mass of object, m, is determined by the
  number of molecules of what type make it up. So
  the mass of a book is constant no matter where it
  is in the SS
• Scientific units of mass are kilograms (kg)
• The weight, W, of an object is its mass times
  the acceleration of gravity
• W mg
• In scientific units weights are measure in
  Newtons (N). In common units weights are measured
  in pounds (lb)

11
On the Moon or Elsewhere

• BUT, g will change from planet to planet and moon
  to moon. For example, on our moon g? (1/6) g?
• So the weight of an object will change as go to
  different bodies in the SS.

12
Sir Issac NewtonThe Genius
13
Newtons Leap of Intuition

• The same natural laws that work on the Earth,
  also work throughout the universe.
• By now, has been proved a countless number of
  times

14
Describing Motion

• Speed distance over time (miles per hour)
• Speed is a scalar, i.e. just a number (60 mph)
• Velocity speed AND direction
• Drive at 60 mph due East
• Velocity is a vector (magnitude and direction)
• Acceleration change in velocity over time
• Speed can increase or decrease
• Speed can remain the same but direction change
• Acceleration is also a vector

15
Centripetal Acceleration
16
First Law of Motion

• Every body will stay in a state of rest or
  uniform motion in a straight line unless that
  state is changed by forces impressed upon it.
• Often called the Law of Inertia
• Property of matter that it resists having its
  state of motion changed.

17
Second Law of Motion

• The size of an acceleration is directly
  proportional to the force applied, and inversely
  proportional to the mass of the body.
• The resulting acceleration is in the same
  direction as the applied force.

18
The Second Law of Motion

• Expressed Mathematically
• a F / m
• Acceleration is proportional to force, and
  inversely proportional to mass.
• F m a
• Force is mass times acceleration.

19
Force, Mass, Acceleration

• Second law has two parts
• 1) Quantifies "force" in terms of its effects on
  a massive body.
• Forces produce accelerations.
• The more mass a body has, the less it can be
  accelerated by a given force.
• 2) Forces and accelerations have directions
• Acceleration is in the same direction as the
  applied force.

20
(No Transcript)
21
Newtons Third Law

• For every action there is a reaction
• If one object exerts a force on another object,
  it feels an equal and opposite force on itself
• Forces always come in pairs

22
(No Transcript)
23
RocketPropulsion

• Spacecraft Dawn Ion Engine
• An electrical Force pushes Xenon ions out of the
  spacecraft
• Therefore, spacecraft feels an equal force from
  the ions. Dawn is constantly being accelerated

24
Isaac Newton
Edmund Halley
25
Gravitational Force

• The Force of Gravity between any two objects
  depends only upon
• The masses of the two objects
• More massive objects exert a stronger force.
• The distance between them
• The force gets stronger as they move closer.
• The force gets weaker as they move apart.
• It is an attractive force pulls to objects
  toward each other

26
Newtons Gravitational Force Law

• F Force of Gravity
• M1 Mass of the first object
• M2 Mass of the second object
• d Distance between their centers
• G Gravitational Force Constant
• Example of an inverse square law.

27
What if the distance changes?
28
What if the masses change?
29
Gravity extending to the Orb of the Moon
30
(No Transcript)
31
Predictive Power of Gravity

• Halleys Comet
• Using Newtonian Gravity, Edmond Halley found that
  the orbit of the Great Comet of 1682 was similar
  to comets seen in 1607 and 1537.
• Predicted it would return in 1758.
• Seen again Christmas night 1758.
• Dramatically confirmed Newtons Laws of Motion
  and Gravitation.

32
Universal Gravitation

• The Law of Gravity is truly Universal
• Governs the fall of apples on the Earth
• Governs the fall of the Moon around the Earth
• Governs the fall of the Earth/Moon system around
  the Sun
• Governs the fall of the Sun around the center of
  the Milky Way Galaxy.
• Governs the fall of the Milky Way and Andromeda
  Galaxies in their mutual orbit...

33
Orbital Mechanics
34
Newtons Generalization

• Newton showed that Keplers Laws can be derived
  from first principles
• Three Laws of Motion
• Law of Universal Gravitation
• Newton generalized the laws to apply to any two
  bodies moving under the influence of their mutual
  gravitation.
• Moon orbiting the Earth
• Two stars orbiting each other
• And beyond...

35
First Law of Orbital Motion

• The shape of a gravitational orbit is a conic
  section
• Conic Sections
• Curves found by cutting a cone with a plane.
• Circles, Ellipses, Parabolas, and Hyperbolas

36
Conic Sections
37
Keplers First Law Expanded
v
38
Closed and Open Orbits

• Closed (bound) Orbits
• Ellipses
• Circles special case of an ellipse with zero
  eccentricity
• Orbits are bound and objects orbit perpetually.
• Open (unbound) Orbits
• Hyperbolas
• Parabolas special case of a hyperbola
• Orbits are unbound and objects escape.

39
(No Transcript)
40
Getting into orbit

• Shoot cannonball with high enough speed it will
  constantly be falling around the curvature of
  the Earth
• Experience Weightlessness
• Low-earth orbit, high-earth orbits
• Telescopes in Space
• Geosynchronous orbits

41
Getting out of orbit
42
Escape Velocity

• Escape Velocity is the minimum velocity needed to
  enter an unbound orbit
• Unbound Parabola Hyperbola
• NEVER escape gravity
• For Earth 25,000 mph
• If below Escape Velocity, will enter closed or
  bounded orbit Ellipse Circle

43
Escape Velocity

• More massive a planet or moon higher the escape
  velocity
• Smaller a planet or moon higher the escape
  velocity

44
Mars Sojourner
45
Perfect Interplanetary Trajectory
