A Multiband Imager for Magellan

1
A Multiband Imager for Magellan

• Christopher Stubbs
• Department of Physics Department of Astronomy
• Harvard University
• cstubbs_at_fas.harvard.edu

2
Conceptual Design
r
g
Pass l gt 5500 A
Pass l gt 8500 A
z
Pass l gt 7000 A
Common shutter
i
3
Existing standard passbands
U B V R I
4
Pan-Starrs bands
4000 A break at z of 0.2 0.5
0.8 1.0 1.25 1.5
g r i z
y
5
Collaborators

• Christopher Stubbs, CfA Harvard Physics
• Melissa Franklin, Harvard Physics Dept
• Tony Stark, CfA
• John Geary, CfA
• South Pole Telescope/Dark Energy Survey
  collaboration J. Carlstrom, J. Mohr...
• Alan Uomoto, OCIW, has been very supportive

6
Science Opportunities

• Supernova followup observations
• Type Ia and type II Sne as cosmological probes
• Requires multiband images, multiple epochs
• Photometric redshifts of clusters
• 4 band imaging over modest field
• Transient followup
• Evolution of SED for GRBs
• Microlensing light curves
• Planetary occultations
• Multiband data useful for discrimination

7
Cosmology from SZ Clusters

• Multiple projects now funded and under way to use
  SZ effect to detect galaxy clusters, down to 2 x
  1014 Msolar
• Expectation is 7 clusters per sq degree
• South Pole Telescope will map 4000 sq deg 29,000
  clusters
• SZ signal strength z-independent
• Optical observations needed for z
• Spectroscopy SALT
• Wide field multiband survey DEC 2009
• Targeted moderate field multiband observations

8
South Pole Telescope (SPT) Survey

• Bolometric focal plane, 1000 elements, and 10m
  aperture telescope.
• Will map Southern extragalactic sky
• RA from 20 hrs to 7 hrs
• DEC from 30 to 75 degrees
• Currently funded by NSF polar programs, under
  construction
• Early 2007 first light.

9
Anticipated Cluster z-distribution
90 within zlt1.2 50 within zlt0.5
Carlstrom, Holder and Reese Ann Rev Astron
Astrophys, 2002
10
Photometric Redshift for Clusters

• Photo-zs for individual galaxies tend to have
  scatter of sz/(1z)0.03, but with a few
  catastrophic outliers.
• Combination of morphology, magnitude, color and
  location can be used to establish clusters
  redshift.
• Robust statistics can be used to eliminate
  outliers.

11
Photometric Redshifts in SDSS bands
Blanton et al, astro-ph/0205243
12
Early-type galaxies in SDSS bands
Bernardi et al, astro-ph/031629

• g-r 0.7
• r-i 0.3
• r-z 0.8

g 20.7 r 20.0 i 19.7 z
19.2
13
Relevant Magnitudes are 18ltrlt24
Brodwin et al, astro-ph/0310038
14
Time (sec) to reach SNR10 Extended source,
ABmag in 2.2 arcsec aperture Dark time, 0.8
arcsec, airmass1.2, scaled to Magellan and
high-r http//rpm.cfht.hawaii.edu/megacam/diet/DI
ET.rpm
Galaxy colors roughly follow contours of constant
integration Shaded boxes are DEC target 10s
magnitudes. We should get ½ the clusters (those
with zlt0.5) in 60 sec
15
Clusters per unit telescope time
16
Return on Magellan Time Investment

• Could get 200 clusters out to z1, or 100
  clusters out to z of 1.5, in 1 night.
• Fifteen dark nights on Magellan could produce
  photo-zs for 3000 clusters out to z1, about 10
  of the total expected from SPT.

17
Conceptual Optical Design Exists
Identical triplets (all spherical)
Doublet field flattener (2 aspheric surfaces)
Field stop
T. Stark, CfA
18
Optical Performance

• Plate scale is 0.062 arcsec per 15 mm pixel
• FOV is 4.1 x 4.1 arcminutes ( 700 kpc at z0.3)
• 80 encircled energy in 0.15 arcsec

19
Tightly coupled software/observing
Take Image 1 30 sec
Analyze Image flatten, WCS, sextractor
Galactic reddening corr. Produce z, sz OK?
Offset Take Image 2 30 sec
Offset if appropriate More images
Slew to next target
20
Rapid Readout and High Efficiency

• Integrated SW reduces wasted time
• Binning 2x2 gives
• 0.124 arcsec/pix,
• Single amplifier output per 2K x 4K chip
• 8 sec readout _at_ 250Kpix/sec
• Effective telescope time multiplier
• For balanced exposures, sequential images take
• Tseries 4(texptreadout)x Nframes
• Parallel imager takes (with 0.8 throughput
  degradation)
• Tparallel (texp/0.8 treadout) x
  Nframes
• For texpgtgttreadout total time is reduced by a
  factor of 3

21
Controlling Systematics

• Our design is readily baffled
• Can use both field stop and pupil stop
• Suppresses stray and scattered light
• Better flatfielding
• Single common shutter near pupil
• Reduced shutter artifacts
• Flux ratios with a single pointing and 2-3
  exposures, under all conditions!
• Even with patchy cloud cover, get Poisson-limited
  colors.

22
Complementarity with Dark Energy Camera

• Multiband Camera 16 arcmin2, 6.5m aperture
• - Get 100 clusters to z1 in 4 hours.
• - Can be on the sky at start of SPT survey
• Dark Energy Camera 3 sq deg, single band, 4m
  aperture
• - Survey approach on CTIO 4m gets 3 sq deg
  x 7 clusters/sq deg 21 clusters per hour, or 84
  clusters in 4 hours.
• - Delivers other science as well weak
  lensing, SN detection...
• Multiband imagers cluster hunting advantage is
  100/84 1.2
• Does not take into account seeing advantage on
  Magellan
• Does not take into account cloud-immunity of
  multiband imager
• If SPT survey falls short of flux goals,
  multiband advantage increases
• Multiband camera better suited to chasing zgt1
  clusters.

23
Two-stage plan

• 2007 2009
• SPT in operation
• Use multiband camera to image 2000 clusters
• Initial cluster count vs. z results
• Use camera for SN followup as well...
• Post-2009
• Dark Energy Camera on Blanco 4m (if )
• Deep wide DEC survey will find SNe
• Follow SN light curves with multiband camera
• Chase higher-z clusters with multiband camera

24
Status

• Rough conceptual design done
• Proof-of-concept optical design done
• Detectors are in hand
• Lincoln labs 2K x 4K, 15 mm pixels
• Some epitaxial, some high-resistivity
• Readout electronics require replication
• MegaCam architecture and board set
• Machine shop capacity available

25
Task list

• Modeling
• Slew vs. expose tradeoffs vs. redshift and
  richness
• Photo-z determination
• Hardware
• Finish design work, order optics
• Mechanical design, fabrication
• Electronics and detector optimization
• System integration, testing...
• Software
• Scripts that connect Sextractor to photoz codes
• Test with SDSS and IMACS data
• Integrate with instrument
• Proposals
• Plan is to submit NSF ATI proposal Nov 1.

26
Summary

• A multiband imager for Magellan makes sense
• Multiple science drivers
• Unique capability
• Quality photometry
• Conceptual design completed
• Detectors on hand, optics straightforward
• Design needs to be refined, and optimal observing
  strategy devised
• Software is a key aspect.
• Your comments participation welcome!

27
Backup Slides and residual clutter
28
Cluster luminosity function

• DM 38.2 implies L 17.1 AB r mag at z 0.1

F(M)
Christlein and Zabludoff, astro-ph/0304031
29
Solid w - 1 Dotted w -
0.6 Shortdash w - 0.2 Longdash open CDM
30
Limiting Magnitude

• ½ L cluster galaxies at redshift 4000A break
  leaving blue filter
• g,r,i,z 22.8,23.4,24.0,23.3
• Complete cluster catalog
• Galaxy catalog completeness
• g,r,i,z 22.8,23.4,24.0,23.6
• Simple selection function
• Blue galaxy photo-z at faint mags
• g,r,i,z 24.0,24.0,24.0,23.6
• Photo-z for angular power spectra and weak
  lensing

AB Mag of ½ L
