Advanced Technical Writing 2006

1
Advanced Technical Writing2006
Session 3
2
Today in Class

• Show-n-tell your CSS Objects from exercise 1
• Meet with your editorial team, refine/post
  deliverables
• Send URL for deliverables to Bill to post on
  class page
• Brief intro to XML

3
A brief introduction to XML
As customized as necessary As generalized as
possible
4
What is XML

• eXtensible Markup Language (much cooler than eML,
  eh?)
• Think of it as a generic way to describe markup
  languagesallowing users to create their own tags
  which describe what is sometimes called the
  semantic structure of a document

5
What is XML

• Still confused? XML is a subset of SGML, the
  publishing industry standard for describing
  content so that it can be stored, referenced,
  distributed, and presented consistently across
  diverse systems

6
This is XML
This could be finer grained..

• lt?xml version"1.0"?gt
• ltcitationgt
• ltauthorgtHart-Davidson, Williamlt/authorgt
• ltdategt2000lt/dategt
• ltpublishergt
• ltpnamegtDrybooks Inc.lt/pnamegt
• ltpcitygtAntwerplt/pcitygt
• lt/publishergt
• lt/citationgt

Well formed, but not valid XML
7
What does XML do? 1

• XML allows you to define the pieces of
  information (or objects, as we came to know them
  last week) that make up a document in such a way
  as to allow both humans and machines to recognize
  them and act upon them

8
What does XML do? 2

• For machines, XML defines the logical structure
  of the document, giving names to things so they
  can be recognized (parsed) or referenced in
  conditional statements, etc
• for people, it provides a way to describe what
  Id rather call the rhetorical structure of the
  document

9
How does XML work?
xml
style rules
Dtd
An xml document is made valid when a Document
Type Definition (or Schema) is present that
describes types of elements and the relationships
among elements for the document
10
An XML scenario, 1
Chicago dtd
Using a program that exports citation listings in
XML, he enters info for lots of books..each is
stored as an XML file
Bill downloads a DTD that describes citation
lists according to the Chicago Manual of Style
11
An XML scenario, 1
Bill watches as the browser builds his reference
list
Bill creates a CSS document that describes how
Chicago Style references lists look
Chicago css
He could have also used XSLT
12
An XML scenario, day 2
Bill downloads a new DTD, this one for MLA style
citations, and a new style sheet too!
Bills editor wants the same list in MLA format!
13
A bit more about DTDs

• DTDs are the place where XML tag sets are
  defined. They are pretty powerful meta-documents
  that determine what the folks reading and writing
  XML documents of a particular type can and cannot
  include, search for, etc.

14
A bit more about DTDs

• We can consider DTDs, or their newer and more
  flexible counterparts called XML Schema, as
  workspaces. They define conceptual and physical
  boundaries for content developers
• Their design is a critical task for the content
  specialist. Well wrought DTDs Schema can
  greatly impact the both user experience, the
  development cycle, and, hence, the
  business/mission.

15
Lets Do a Little XML exercise

• Think of a document type that has sufficiently
  granular content as to make it pretty simple to
  come up with some XML tags to describe it.
• Hint if you must, use a recipebut try to be
  more creative
• Draft an xml document and make up the tags that
  you think you would need.
• Name your tags with semantic labelsthat is,
  identify functional objects within the document
  that we would want to keep separate from the
  structure

16
Inside the DTD

• A DTD is just a list of declarations. Lets
  consider three common types
• The first declaration names the DOCTYPE.

lt!DOCTYPE document_name the rest of the dtd
heregt
17
Inside the DTD, 2

• 2. Then come declarations of document ELEMENTs.

lt!ELEMENT element_name (data_type)gt
18
Inside the DTD, 3

• 3. Finally, there may be declarations for
  ATTRIBUTES of an ELEMENT.

lt!ATTLIST parent_element attribute_name data_type
default_valuegt
19
This is a DTD

• lt!DOCTYPE citation
• lt!ELEMENT book (author, date, publisher)gt
• lt!ELEMENT author (PCDATA)gt
• lt!ELEMENT date (PCDATA)gt
• lt!ELEMENT publisher (PCDATA)gt
• lt!ATTLIST publisher pname CDATA REQUIREDgt
• lt!ATTLIST publisher pcity CDATA REQUIREDgt
• gt

20
Another X-ercisewell review these next time!

• Find an article in the online version of your
  local newspaper.
• 2. Go to http//www.xmlnews.org/docs/story-tutoria
  l.html
• And follow along with the tutorial, using your
  story as an example.
• 3. Pick out several objects and create markup
  by using CSS to color code your news story each
  color should correspond to an item on the DTD

21
A Few More Xs

• What is XHTML?
• Quite simply, it is html redescribed as an XML
  DTD. Or another way to say it is that XHTML is
  the current default web DTD. The W3C may stop
  issuing HTML spec. in the future and just
  describe a baseline web DTD or Schema.

22
A Few More Xs

• What is XSL? XSL-T?
• The xml stylesheet specification. XSLT is a very
  robust spec for transforming an XML document of
  one type into one of another typemeaning you can
  do more than just style information for
  display, you can also change it into other forms.

23
Good references for CSS XML

• www.webmonkey.com
• www.xml.com
• www.w3c.org

24
Readings.

• http//12.108.175.91/ebookweb/stories/storyReader
  380
• An article on eBookWeb about XML, structure, and
  content.
• If you have it handy, you can read Rockley Ch. 14
  and Ch. 20.

25
Next Time

• Semantic Markup 1 - CSS, XML, More
• Read Rockley, Ch. 1 and Ch. 14 Clark (pdf)
• Send e-mail to Bill H-D w/ URL for editorial team
  deliverables
