Software Quality

1
Software Quality

• CIS 375
• Bruce R. Maxim
• UM-Dearborn

2
Software Quality Principles

• Conformance to software requirements is the
  foundation from which quality is measured.
• Specified standards define a set of development
  criteria that guide the manner in which software
  is engineered.
• Software quality is suspect when a software
  product conforms to its explicitly stated
  requirements and fails to conform to the
  customer's implicit requirements (e.g. ease of
  use).

3
McCalls Quality Factors

• Product Operation
• Correctness
• Efficiency
• Integrity
• Reliability
• Usability

• Product Revision
• Flexibility
• Maintainability
• Testability
• Product Transition
• Interoperability
• Portability
• Reusability

4
McCalls Quality Factors
5
McCalls Software Metrics

• Auditability
• Accuracy
• Communication commonality
• Completeness
• Consistency
• Data commonality
• Error tolerance
• Execution efficiency
• Expandability
• Generality

• Hardware independence
• Instrumentation
• Modularity
• Operability
• Security
• Self-documentation
• Simplicity
• Software system independence
• Traceability
• Training

6
FURPS Quality Factors

• Functionality
• Usability
• Reliability
• Performance
• Supportability

7
ISO 9126 Quality Factors

• Functionality
• Reliability
• Usability
• Efficiency
• Maintainability
• Portability

8
Measurement Process - 1

• Formulation
• derivation of software measures and metrics
  appropriate for software representation being
  considered
• Collection
• mechanism used to accumulate the date used to
  derive the software metrics
• Analysis
• computation of metrics

9
Measurement Process - 2

• Interpretation
• evaluation of metrics that results in gaining
  insight into quality of the work product
• Feedback
• recommendations derived from interpretation of
  the metrics is transmitted to the software
  development team

10
Technical Metric Formulation

• The objectives of measurement should be
  established before collecting any data.
• Each metric is defined in an unambiguous manner.
• Metrics should be based on a theory that is valid
  for the application domain.
• Metrics should be tailored to accommodate
  specific products and processes

11
Software Metric Attributes

• Simple and computable
• Empirically and intuitively persuasive
• Consistent and objective
• Consistent in use of units and measures
• Programming language independent
• Provides an effective mechanism for quality
  feedback

12
Representative Analysis Metrics

• Function-based metrics
• Bang metric
• function strong or data strong
• Davis specification quality metrics

13
Specification Quality Metrics - 1

• nn nf nnf
• nn requirements specification .
• nf functional .
• nnf non-functional .
• Specificity, Q1 nai/qr
• nai of requirements with reviewer agreement.

14
Specification Quality Metrics - 2

• Completeness, Q2 nu / (ni ns)
• nu unique functions.
• ni of inputs.
• ns of states.
• Overall completeness, Q3 nc / (nc nnv)
• nc validated correct.
• nnv not validated.

15
Representative Design Metrics - 1

• Architectural design metrics
• Structural complexity (based on module fanout)
• Data complexity (based on module interface inputs
  and outputs)
• System complexity (sum of structural and data
  complexity)
• Morphology (number of nodes and arcs in program
  graph)
• Design structure quality index (DSQI)

16
Representative Design Metrics - 2

• Component-level design metrics
• Cohesion metrics (data slice, data tokens, glue
  tokens, superglue tokens, stickiness)
• Coupling metrics (data and control flow, global,
  environmental)
• Complexity metrics (e.g. cyclomatic complexity)
• Interface design metrics (e.g. layout
  appropriateness)

17
Halsteads Software ScienceSource Code Metrics

• Overall program length
• Potential minimum algorithm volume
• Actual algorithm volume
• number of bits used to specify program
• Program level
• software complexity
• Language level
• constant for given language

18
Testing Metrics

• Metrics that predict the likely number of tests
  required during various testing phases
• Metrics that focus on test coverage for a given
  component

19
Estimating Number of ErrorsError Seeding - 1

• (s / S) (n / N)
• S of seeded errors
• s seeded errors found
• N of actual errors
• n of actual errors found so far

20
Estimating Number of ErrorsError Seeding 2

• E(1) (x / n)
• ( of real errors found by 1/ total of real
  errors)
• q / y
• ( errors found by both / real errors found by
  2)
• E(2) (y / n) q / x
• ( real errors found by both / found by 1)
• n q/(E(1) E(2))

21
Estimating Number of ErrorsError Seeding 3

• Assume
• x 25
• y 30
• q 15
• E(1) (15 / 30) .5
• E(2) (15 / 25) .6
• n 15 / (.5)(.6) 50 errors

22
Software Confidence

• S of seeded errors.
• N of actual errors.
• C (confidence level) 1 if n gt N
• C (confidence level)
• S / (S N 1) if n lt N
• Example N 0 and S 10
• C 10/(10 0 1) 10/11 ? 91

23
Confidence Example

• How many seeded errors need to be used and found
  to have a 90 confidence a program is bug free?
• N 0
• C S/(S 0 1) 98/100
• Solving for S
• S 49

24
Failure Intensity

• Suppose that intensity is proportional to of
  faults or errors present at the start of testing.
• function A has 90 of duty time
• function B has 10 of duty time
• Suppose there are 100 total errors
• 50 in A, 50 in B
• (.9)50K (.1)50K 50K
• (.1)50K 5K
• or
• (.9)50k 45K

25
Maintenance MetricsSoftware Maturity Index

• SMI Mt (Fa Fc Fd)/Mt
• Mt number of modules in current release.
• Fa modules added.
• Fc modules changed.
• Fd modules deleted.
• SMI approaches 1.0 as product begins to stabilize
