Thread in Java

1
Thread in Java

• Lang Zhao
• COP5614
• 4/14/2008

2
Outline

• What is Thread?
• Introduction (life circle, Method)
• Thread priority (with example)
• Thread creation (with example)
• Scheduler (with example)
• Synchronization (with example)
• Monitor (with example)
• Daemon (with example)

3
What is a thread?

• A thread is a lightweight process
• which exist within a program and
• executed to perform a special task.
• Several threads of execution may be
• associated with a single process.

4
Introduction

• In Java programming language
• thread is a sequential path of code execution
  within a program.
• the thread class is defined in the package
  java.lang, which needs to be imported

5
Life circle of one thread

• New state the thread is considered
• not alive.
• Runnable (Ready-to-run) state
• A thread start its life. On this state a
  thread is waiting for a turn on the processor.
• 3. Running state the thread is
• currently executing
• 4. Dead state its run() method completes.
• 5. Blocked is waiting the resources that are
  hold by another thread.

6
Life circle of multiple-threads
7
Life circle of multiple-threads

• non-runnable states
• Sleeping the thread is still alive but it is not
  runnable. On this state a thread sleeps for a
  specified amount of time. You can use the method
  sleep( ) to stop the running state of a thread.
• Waiting for Notification A thread waits for
  notification from another thread. The thread
  sends back to runnable state after sending
  notification from another thread.
• Blocked on I/O waiting I/O resource, the thread
  sends back to runnable state after availability
  of resources.
• Blocked for joint completion waiting the
  completion of another thread.
• Blocked for lock acquisition waiting to acquire
  the lock of an object.

8
Some Important Methods defined in java.lang.Thread
9
Some Important Methods defined in java.lang.Thread
10
Thread Creation

• Two ways
• Extending the java.lang.Thread Class
• Implementing the java.lang.Runnable Interface

11
Prefer for Implementing a Runnable Interface

• Two reasons
• If you extend the Thread Class, that means that
  subclass cannot extend any other Class, but if
  you implement Runnable interface then you can do
  this.
• The class implementing the Runnable interface can
  avoid the full overhead of Thread class which can
  be excessive.
• Example
• class MyThread10 implements Runnable
   Thread t  String snull
• MyThread10(String s1)
  ss1    tnew Thread(this)    t.start()
   public void run()      System.out.println(s)
      public class RunableThread  public stati
  c void main(String args)    MyThread10 m1new
  MyThread10("Thread started....")

12
Multiple-threads

• Advantages
• Reduces the computation time.
• Improves performance of an application.
• Threads share the same address space so it saves
  the memory.
• Context switching between threads is usually less
  expensive than between processes.
• Cost of communication between threads is
  relatively low.

13
Multiple-threads Creation

• Implementing a Runnable interface
• class MyThread11 implements Runnable  Threa
  d t  MyThread11(String s)      tnew Thread(th
  is,s)    t.start()     public void run()
      for(int i0ilt5i)       System.out.printl
  n("Thread Name  "Thread.currentThread().getName(
  ))      try       Thread.sleep(1000)      c
  atch(Exception e)      public class Runna
  bleThread1
•  public static void main(String args)
    System.out.println("Thread Name "Thread.curren
  tThread().getName())       MyThread11 m1new MyT
  hread11("My Thread 1")    MyThread11 m2new MyTh
  read11("My Thread 2")
• both threads are registered with the thread
  scheduler and the CPU
• scheduler executes them one by one.

14
Thread Priorities

• In Java
• The thread scheduler can use the thread
  priorities to determine the execution schedule of
  threads .
• 2. The thread scheduler provides the CPU time to
  thread of highest
• priority during ready-to-run state.
• 3. Priorities are integer values
• Thread.MIN_PRIORITY 1
• Thread.MAX_PRIORITY 10
• Thread.NORM_PRIORITY 5

15
Example of set priority

• class MyThread12 extends Thread  MyThrea
  d12(String s)    super(s)    start()    pu
  blic void run()    for(int i0ilt3i)      T
  hread curThread.currentThread()      cur.setPri
  ority(Thread.MIN_PRIORITY)      int pcur.getPri
  ority()      System.out.println("Thread Name  "
  Thread.currentThread().getName())      System.o
  ut.println("Thread Priority  "cur)
    class MyThread22 extends Thread  MyThread22(
  String s)    super(s)    start()  public
  void run()    for(int i0ilt3i)      Thread
   curThread.currentThread()      cur.setPriority
  (Thread.MAX_PRIORITY)      int pcur.getPriority
  ()      System.out.println("Thread Name  "Thre
  ad.currentThread().getName())      System.out.pr
  intln("Thread Priority  "cur)        pub
  lic class ThreadPriority  public static void mai
  n(String args)      MyThread12 m1new MyThread
  12("My Thread 1")    MyThread22 m2new MyThread2
  2("My Thread 2")

16
Thread Scheduler

• Preemptive scheduling In Java runtime system, if
  the new thread has a higher priority, the current
  running thread leaves the runnable state and
  higher priority thread enter to the runnable
  state.
• Time-Sliced (Round-Robin) Scheduling if two
  threads of the same priority are waiting  to be
  executed by the cpu. A running thread is allowed
  to be execute for the fixed time, after
  completion the time, current thread indicates to
  the another thread to enter it in the runnable
  state.

17
Synchronization

• Only methods (or blocks) can be synchronized,
  Classes and variable cannot be synchronized.

• All methods in a class need not to be
  synchronized. A class can have both synchronized
  and non-synchronized methods.
• If two threads wants to execute a synchronized
  method in a class, and both threads are using the
  same instance of the class to invoke the method
  then only one thread can execute the method at a
  time.
• If a class has both synchronized and
  non-synchronized methods, multiple threads can
  still access the class's non-synchronized
  methods. If you have methods that don't access
  the data you're trying to protect, then you don't
  need to synchronize them. Synchronization can
  cause a hit in some cases (or even deadlock if
  used incorrectly), so you should be careful not
  to overuse it.
• You can synchronize a block of code rather than a
  method.
• Constructors cannot be synchronized

18
Synchronized Method of Threads

• class Share extends Thread  static String msg
  "This", "is", "a", "synchronized", "variable"
   Share(String threadname)    super(threadname)
      public void run()    display(getName())
     public synchronized void display(String threa
  dN)    for(int i0ilt4i)      System.out.pr
  intln(threadNmsgi)      try      this.sleep
  (1000)  catch(Exception e)    public cla
  ss SynThread1   public static void main(String
   args)       Share t1new Share("Thread One ")
      t1.start()    Share t2new Share("Thread Tw
  o ")    t2.start()

19
Monitor

• Monitor is any class with synchronized code in
  it.
• Monitor controls its client threads using wait()
  and notify() ( or notifyAll() ) methods.
• wait() and notify() methods must be called in
  synchronized code.
• Monitor asks client threads to wait if it is
  unavailable.
• Normally a call to wait() is placed in while
  loop. The condition of while loop generally tests
  the availability of monitor. After waiting,
  thread resumes execution from the point it left.

20
Example of Monitor

• public class DemoWait extends Thread  i
  nt val20  public static void main(String args
  )      DemoWait dnew DemoWait()    d.start()
      new Demo1(d)    public void run()    tr
  y        synchronized(this)    wait()    Sys
  tem.out.println("value is  "val)
  catch(Exception e)   public void valchange(
  int val)        this.valval        try
     synchronized(this)        notifyAll()
       catch(Exception e)  class Demo1 ex
  tends Thread  DemoWait d  Demo1(DemoWait d)
    this.dd  start()    public void run()
    try    System.out.println("Demo1 value is
  "d.val)    d.valchange(40)  catch(Exception
  e)

21
Daemon

• In Java,
• any thread can be a Daemon thread.
• Daemon threads are like a service providers for
  other threads or objects running in the same
  process as the daemon thread.
• Daemon threads are used for background supporting
  tasks and are only needed while normal threads
  are executing.
• If normal threads are not running and remaining
  threads are daemon threads then the interpreter
  exits.

22
Example of Daemon

• public class DaemonThread extends Thread   publi
  c void run()     System.out.println("Entering ru
  n method")    try       System.out.println("I
  n run Method currentThread() is"           Thre
  ad.currentThread())      while (true)
   try           Thread.sleep(500)         catc
  h (InterruptedException x)                 Sy
  stem.out.println("In run method woke up again")
             finally       System.out.println("
  Leaving run Method")        public static vo
  id main(String args)     System.out.println("E
  ntering main Method")    DaemonThread t  new D
  aemonThread()    t.setDaemon(true)    t.start(
  )    try       Thread.sleep(3000)     catc
  h (InterruptedException x)         System.out
  .println("Leaving main method")

23
Questions

• ?

24
Reference

• http//www.bpurcell.org/blog/index.cfm?modeentry
  ENTRY934
• http//www.javaprepare.com/notes/threads.html
• http//www.roseindia.net/java/thread/index.shtml
