• Multi-Faceted U.S.-Japan Program in Natural
  Hazard Mitigation

2
WIND HAZARD EARTHQUAKE ENGINEERING LAB WHEEL

• Established in 1999 by Dr. Makola Abdullah
• Research interests include
• Passive, semi-active and active structural
  control designs.
• Sensor/actuator placement using evolutionary
  algorithms.
• Damage mitigation assessment after natural
  disasters.
• Computational fluid dynamics for the design and
  analysis of structures exposed to high winds.
• Mitigation of pounding.
• Analysis of earthquakes in the southeastern U.S.
• Computational fluid dynamic applications to
  multi-phase separation.

3
Sensor/Actuators Placement on Civil Structures
Using A Real Coded Genetic Algorithm
By Andy Richardson Makola Abdullah, Ph.D
FAMU-FSU College of Engineering Department of
Civil Engineering
4
RESEARCH OBJECTIVE

• Determine the optimal placement of k feedback
  controllers on an n-story structure.
• Place and design controllers simultaneously using
  a real coded genetic algorithm.
• Compare results to similar work that uses a
  hybrid method.

5
GENETIC ALGORITHM

• What?
• Probabilistic search method based on the
  mechanics of
• Darwins natural selection

• Why?
• Simple yet powerful search method for
  optimization
• problems not readily solved by conventional
  search techniques

• How?
• Replicating evolution by selection and survival
  of the fittest
• using the following steps
• Coding
• Breeding
• Selection

6
REAL CODED GENETIC ALGORITHM

• Discrete Recombination-is the process
  whereby new chromosomes are generated from
  existing individuals

Individual 1 12 25 5 Individual 2
123 4 34 Selected Ind 1 2 2
1 Selected Ind 2 1 2 1 Off
Spring 1 123 4 5 Off Spring 2
12 4 5
7
REAL CODED GENETIC ALGORITHM
Real Valued Mutation- randomly created values are
added to the variables with a low probability.
8
STOCHASTIC SELECTION
Pointer 1
Pointer 2
Pointer 3

1

Individual
2
3
4
5
Fitness
0
0.2
0.5
0.6
0.8
1
Random number
N number of individuals to be selected,
(N3) Pointer 1?0,1/N
Individuals 1,3,5 are selected for future
breeding operations
9
SYSTEM MODEL
Equations of Motion
10
PERFORMANCE FUNCTION
x System states u Control force Q
Weighting matrix with respect to the buildings
response R Weighting matrix with respect to the
controlled input ? Modal stiffness matrix I
Identity
11
PLACEMENT DESIGN METHOD
Start
Evaluate
Generic
Start
Start
Gains
Real Coded Genetic Algorithm
Genetic
Algorithm
End
End
Gradient
Optimization
End
Hybrid Design
Real Coded Design
12
CODING GENETIC STRING

• Place k controllers on an n-story structure
• Example of a genetic string for the structure
• shown below is

HYBRID
REAL CODED GA
13
GENETIC ALGORITHM ITERATIONS
14
SENSOR/ACTUATOR PLACEMENT
15
TOP FLOOR RESPONSE TO EL CENTRO EARTHQUAKE
16
TOP FLOOR RESPONSE TO THE NORTH RIDGE AT SANTA
MONICA EARTHQUAKE
17
SUMMARY OF BUILDING RESPONSE
18
SUMMARY OF CONTROL FORCES
19
CONCLUSION

• Both methods are effective in reducing the
  buildings response.
• Proposed method is more convenient and less
  computationally intensive than the hybrid method.
• Proposed Method has a high convergence rate.
• The convergence rate improves with the number of
  iterations of the algorithm.
• Both methods are subjective to the weighting
  matrices Q and R.

20
FUTURE WORK

• Consider actuator dynamics, controller
  saturation
• Apply concept to a multi-bay frame 2-D building
  model
• Apply concept to a multi-bay frame 3-D building
  model
• Develop a general scheme for determining the
  optimal placement of sensor/actuators

21
STATE SPACE REPRESENTATION
Expressing in terms of closed loop plant
22
PERFORMANCE FUNCTION (Cont.)
Lyapunov equation
Gradient of the gain matrix
Lyapunov equation
23
PERFORMANCE FUNCTION (Cont.)
Expand in terms of fundamental transition matrix
24
BINARY GENETIC ALGORITHM
Coding-representing variable parameter
information in binary Crossover - cutting and
replacing the tail of one string with that of the
other 100011111
100011000
111101000 111101111
Point of Crossover
Mutation - randomly switches 1 to 0 or vice
versa 100011111
101011110
Selection - the process of choosing the fittest
strings from the current population for use in
future reproductive operations
25
DECENTRALIZED COLLOCATED DESIGN
x(t) Building response
w(t) Earthquake
Building Dynamics
y(t) Sensed output
u(t) Control Force
F
