Processing Text Files with Arrays and Lists

1
Chapter 7

• Processing Text Files with Arrays and Lists

2
Objectives

• Learn about processing textual data
• Open, read, and close a sequential file
• Use arrays to manage lists of data
• Parse input lines
• Sort arrays
• Write to a sequential file
• Group items using structures
• Create instances of the ComboBox and ListBox
  controls

3
Processing Textual Data

• Many applications work with text files
• Word, Excel, and others
• Text files are read and written from beginning to
  end
• This strategy is called sequential access
• Sequential files are also called ASCII-delimited
  files

4
Characteristics of Sequential Files

• Contents are separated into lines
• Each line ends with a carriage return
• Also known as a hard carriage return
• Pressing the Enter key generates a carriage
  return in most applications
• A line is called a record
• A record contains a logical group of items
• A record contains one or more fields
• Each field contains a unique piece of information
  from a record
• Each field is separated by a delimiter
• A comma is the most common delimiter character

5
Caveats of Sequential Files

• Make sure that each record contains the correct
  number of fields
• If a field contains no information, place two
  delimiters next to one another
• Make sure that each line ends with a carriage
  return
• Last line must end with a carriage return
• Make sure that no extra carriage returns exist at
  the end of the file
• Formatting errors will likely cause VB .NET to
  raise an exception
• Note that sequential file processing has changed
  considerably in VB .NET

6
Sequential File (Example)
Beets Joe,131.216.39.3,Truman Bill,182.219.42.4,44
8
Deems Mary,131.216.39.3,Truman Bill,181.219.42.4,2
88
Five fields separated by commas (delimiter)
7
Working with Sequential Files

• The System.IO namespace supplies two classes to
  read and write sequential files
• The StreamReader class reads sequential files
• The StreamWriter class writes sequential files

8
Opening a Sequential File

• To read a sequential file you must first open it
• Open a file by creating an instance of the
  StreamReader class
• Standard prefix for the StreamReader class is
  "srd"
• Syntax
• Overloads Public Sub New (path As String )
• path argument contains the path and file name of
  the file to open

9
Opening a Sequential File (Example)

• Open the file name stored in the instance of the
  OpenFileDialog control named ofdCommon
• Dim psrdCurrent As System.IO.StreamReader
• psrdCurrent New _ System.IO.StreamReader(ofdComm
  on.FileName)

10
Reading a Sequential File

• After opening a sequential file, you read it
• You typically use a loop to read a sequential
  file
• Use the methods of the StreamReader class to read
  the file
• Read method reads a single character or multiple
  characters
• ReadLine method reads a line into a string
• Line is terminated by a carriage return
• ReadToEnd method reads from its current position
  to the end of the file
• The Read method returns Nothing when the file has
  been read

11
Reading a Sequential File (Example)

• Assuming that psrdCurrent is an instance of the
  StreamReader class, the following loop reads the
  sequential file. The contents are stored in the
  string pstrFile
• Dim pstrLine, pstrFile As String
• pstrLine psrdCurrent.ReadLine()
• Do Until pstrLine Nothing
• pstrFile pstrLine CrLf
• pstrLine psrdCurrent.ReadLine()
• Loop

12
Logic to Read a Sequential File
Read first line
pstrLine psrdCurrent.Readline()
Does input line contain data?
Do Until pstrLine Nothing
no
yes
pstrFile pstrLine CrLf
Process current line
pstrLine psrdCurrent.Readline()
Read next input line
Loop
Exit loop
13
Closing a File

• After reading a file, you must explicitly close
  it
• Failure to explicitly close a file may cause file
  corruption or loss of data (especially when
  writing a file
• Call the Close method of the StreamReader class
• Example (Assume psrdCurrent is an instance of the
  StreamReader class)
• psrdCurrent.Close()

14
Passing Arguments to a Constructor

• Remember that a constructor is a procedure named
  New that executes when VB .NET creates a form or
  other class instance
• Any constructor can accept arguments
• Argument list works the same as the argument list
  for any function or sub procedure
• Public Sub New(ByVal pstrInput As String)
• MyBase.New()
• InitializeComponent()
• txtInputFile.Text pstrInput
• End Sub

15
Introduction to Arrays

• Variables storing a single item of information
  are called scalar variables
• Integer, Double, and so on
• Arrays on the other hand store lists of data
• Lists of Integers, Doubles, and so on

16
General Information about Arrays

• An array stores a list of several items each
  having the same data type
• An array has one or more dimensions
• The number of dimensions in an array is called
  the rank
• An array with one dimension has a rank of 1
• Each data item in an array is called an element
• Each individual element is referenced by a unique
  index number known as a subscript
• In VB .NET, arrays are classes (reference types)
  supporting properties and methods

17
Comparing Scalar Variables with an Array
twelve variables for months of the year
mintJanuary
mintFebruary
mintMarch

mintDecember
18
A Note About VB 6 Arrays

• In VB 6, arrays were not classes. Thus they did
  not support properties or methods
• VB 6 arrays could have a lower bound other than 0
• All VB .NET arrays have a lower bound of 0

19
The Array Class

• Properties
• Length Gets the total number of elements in the
  array
• Rank Gets the number of dimensions in the array
• Methods
• GetLowerBound Gets the smallest subscript for
  an array dimension
• Value is always 0
• GetUpperBound Gets the largest subscript for an
  array dimension
• Reverse Reverses the elements in a
  one-dimensional array
• Sort Sorts an array in ascending order

20
Common Array Operations

• You declare an array the same way as you declare
  a scalar variable
• You store and retrieve individual elements from
  an array
• Arrays can grow and shrink at run time
• You can change the number of array dimensions or
  the number of elements in an array dimension
• You must often search for a particular element in
  an array
• The elements of an array often need to be sorted

21
Declaring Arrays

• When you declare an array, you are allocating
  memory (RAM) to store the array
• Remember that arrays are reference types so an
  array variable stores a memory address
• To declare an array, you use the Dim, Private or,
  Public statements just as you would use to
  declare any variable

22
Declaring Arrays (Syntax)

• Dim Private Public array-name
• ( size ) As datatype initexpr
• The Dim, Private, and Public keywords define the
  scope of the array
• Same meaning as a scalar variable
• Array-name can be any valid variable name
• Optional size argument defines the initial number
  of array elements
• If omitted, the array has no initial size
• As datatype clause defines the data type of each
  element
• Required when strict type checking is enabled
• Initexpr allows you to assign values to each
  element when the array is declared

23
Declaring Arrays (Example)

• Declare an empty array having a data type of
  Integer
• Private mintEmpty() As Integer
• Declare an array with 4 elements having a data
  type of Integer, subscripted from 0 to 3
• Private mintValues(3) As Integer
• Declare an array with 5 elements having a data
  type of Single, subscripted from 0 to 4
• Private msngValues(4) As Single
• (see testArray.sln)

24
Declaring and Initializing Arrays (1)

• Syntax differs because you are not initializing a
  scalar variable but rather elements in a list
• You initialize an array by entering values in a
  comma separated list. The list is enclosed in
  braces
• Declare a dynamic Integer array named pintList
  and initialize the array elements
• Dim pintList() As Integer 24, 12, 34, 42

25
Declaring and Initializing Arrays (2)

• String arrays can also be declared and
  initialized
• As with all strings, literal values are enclosed
  in double quotation marks

Private mstrMonthNames() As String _
"January", "February", "March", "April", _
"May", "June", "July", "August", _
"September", "October", "November", _
"December"
26
Redimensioning Arrays

• The process of changing an array's size is known
  as redimensioning an array
• All VB .NET arrays are dynamic so any array can
  be redimensioned
• Arrays are redimensioned with the ReDim statement
• As an executable statement, ReDim must appear
  inside of a procedure
• You can change the size of an array but you
  cannot change an array's data type

27
The ReDim Statement (Syntax)

• ReDim Preserve varname( size )
• The ReDim statement resizes an array
• The optional Preserve keyword preserves the
  existing contents
• When using the Preserve keyword, you can only
  change the size of the last dimension
• When reducing the size, elements will be deleted
• varname contains the array to resize
• size argument contains the new size (dimension)

28
The ReDim Statement (Example)

• Resize an array and destroy its contents
• ReDim mintMonths(11)
• Resize an array and preserve its contents
• ReDim Preserve mintMonths(11)

29
Performing Assignment Statements with Arrays (1)

• Assignment process is the same as with ordinary
  variables
• However you assign individual elements rather
  than the entire array
• Store the value 84616 in the first array element
• Remember that all arrays in VB .NET are 0-based
• mintMailMessages(0) 84616

30
Performing Assignment Statements with Arrays (2)

• Arrays and scalar variables can be declared as
  the following statements illustrate
• Private mintMailMessages(11) As Integer
• Private mintMailMessageItem As Integer
• Store the first array element in the scalar
  variable named mintMailMessageItem
• mintMailMessageItem mintMailMessage(0)

31
Type Conversion with Arrays

• You can use type conversion methods with arrays
  just as you use them with scalar variables
• Convert an Integer array element to a string
• Private mintMailMessages(11) As Integer
• txtMailMessageMonth.Text _
  mintMailMessage(0).ToString

32
Common Array Errors (1)

• The size and shape of an array defines the array
  bounds
• Subscript values cannot exceed the array bounds
• The following statement will cause an error
  because the array has 12 elements but the second
  statement tries to reference element number 500
• Private mintMailMessage(11) As Integer
• mintMailMessage(500) 100

33
Common Array Errors (2)

• To store data in an array element, you must use a
  subscript
• The following assignment statement will cause an
  error because it does not specify an array
  element
• Private mintMailMessages(11) As Integer
• mintMailMessages 100

34
Working with Subscripts

• Both variables and literal values can be used as
  subscripts
• When using variables, the variable should be
  declared as Short, Integer, or Long
• Example
• Dim pintValue As Integer 3
• txtCount.Text mintMailMessages(pintValue).ToStr
  ing

35
Arrays and Loops

• Loops are commonly used to examine all of the
  elements in an array or to store a value in all
  of the array elements
• Example to calculate a total
• Note that pintTotal is an accumulator
• Dim pintCount, pintTotal As Integer
• For pintCount 0 to 11
• pintTotal mintMailMessages(pintCount)
• Next

36
The Split Method (1)

• When you read a record from a sequential file you
  must often split the line into its component
  fields
• This process is called parsing
• The Split method divides a string into an array
  of strings based on a delimiter character or
  characters
• Most files use the comma (,) as the delimiter
  character but other characters can be used

37
The Split Method (2)

• The Split method requires that you declare an
  array having a data type of Char having one
  element
• The following statement declares and initializes
  an array of type Char
• Dim pchrDelimiter() As Char ToChar.(",")

38
The Split Method (Syntax)

• Overloads Public Function Split( ByVal separator(
  ) As Char ) As String( )
• The Split method parses a string into fields
• The separator argument contains an array of
  characters
• Usually just a single character though
• The Split method returns an array of strings

39
The Split Method (Example)

• Assume that pstrLine contains the string to be
  parsed
• Dim pstrLine As String
• Dim pstrFields() As String
• Dim pchrDelimiter As Char() ToChar(",")
• pstrFields pstrLine.Split(pchrDelimiter)

40
Splitting a Text Line
pstrFields pstrLine.Split(pchrDelimiter)
Comma (,)
Deems Mary,131.216.39.3,Truman Bill,181.219.42.4,2
88
41
Sorting Arrays (1)

• You sort an array by calling the Sort method of
  the Array class
• The overloaded Sort method has multiple syntax
  variations
• Overloads Public Shared Sub Sort( array As Array
  )
• Overloads Public Shared Sub Sort( keys As Array,
  items As Array )

42
Sorting Arrays (2)

• The first overloaded method sorts a
  one-dimensional array in ascending order
• The second overloaded method sorts two arrays
• First array contains the keys
• Second array contains the values
• Exchanges to the keys array are made to the
  values array

43
Sorting Arrays (Example)

• Sort the array named mintMailMessages
• System.Array.Sort(mintMailMessages)
• Sort the arrays named mintMailMessages and
  mstrMonthNames
• mintMailMessages contains the keys and
  mstrMonthNames contains the values
• System.Array.Sort(mintMailMessages,
  mstrMonthNames)

44
Writing to a File

• Just as the StreamReader class reads a file, the
  StreamWriter class writes a file
• Properties
• The NewLine property contains the character(s)
  that mark the end of a line.
• When calling WriteLine, this character is
  appended to the line
• Methods
• Close method closes a file
• Write method write a character, character array,
  or string to a file
• WriteLine method writes a line terminated with a
  NewLine character

45
Writing to a File (Example)

• Write two arrays to a file
• Assume pswriCurrent is an instance of the
  StreamWriter class
• For pintCount 0 to 11
• pswriCurrent.Write(mstrMonthNames(pintCount))
• pswriCurrent.Write(",")
• pswriCurrent.Write(mintMailMessages(pintCount))
• pswriCurrent.WriteLine()
• Next
• pswriCurrent.Close()

46
Structures

• Structures group related data times together
  logically
• For example, a customer has a name, address,
  city, state, and zip code
• A structure allows you to create your own data
  type containing elements made up of other data
  items

47
Structures (Syntax)

• Public Private Structure varname
• NonMethod Declarations
• Method Declarations
• End Structure
• Public and Private keywords define the scope of
  the structure
• varname contains the name of the structure
• Standard variable naming rules apply
• NonMethod declarations contain the structure
  members

48
Structures (Example)

• Declare a structure named sLogRecord
• Public Structure sLogRecord
• Public SourceName As String
• Public SourceIP As String
• Public DestName As String
• Public DestIP As String
• Public Bytes As Integer
• End Structure

49
Declaring a Structure Variable

• Once you have declared a type with the Structure
  statement, you can declare variables of that type
• Use the same syntax to declare a Structure
  variable as an ordinary variable
• Declare a structure named LogRecord
• Private LogRecord As sLogRecord
• Declare an array of structures named LogRecords
• Private LogRecords() As sLogRecord

50
Referencing Structures (1)

• To reference an individual structure member use
  the same dot (.) notation that you use to
  reference the properties of an object
• Note that Intellisense technology works on
  structures too
• Dim LogRecord As sLogRecord
• LogRecord.SourceName "Mary"

51
Referencing Structures (2)

• You can work with arrays of structures too
• The key is that both sides of an assignment
  statement must have the same data type
• Private LogRecords(99) As sLogRecord
• Private LogRecord As sLogRecord
• LogRecord LogRecords(0)
• LogRecord.SourceName LogRecords(0).SourceName

52
The ComboBox and ListBox Controls

• Both controls display lists of data, such as a
  list of names
• Both controls allow you to sort data and
  determine which item the user has selected from a
  list of items
• The primary difference is that a ComboBox control
  will drop-down but a list box will not
• Both controls share almost the same set of
  properties

53
ComboBox Styles

• DropDownStyle property controls how the ComboBox
  appears to the user
• DropDown Allows user to select an item from a
  drop-down list of items
• The user can also add a new item
• Simple Control instance appears like a list box
• List does not drop-down
• DropDownList Same as DropDown but user cannot
  add new items

54
ComboBox and ListBox Properties

• Items property defines the items stored in the
  ComboBox or ListBox
• MaxDropDownItems controls maximum number of items
  that will appear in the drop-down list
• The 0-based SelectedIndex property defines which
  item the user has selected
• The value is -1 if no item is selected
• Sorted property if True causes the items to be
  sorted alphabetically
• Text property contains the text of the currently
  selected item

55
ComboBox and ListBox Events

• SelectedIndexChanged event fires when the user
  selects a different item in the ComboBox or
  ListBox
• TextChanged event fires when the user changes the
  text of the current item

56
The Items Collection (General)

• Applies to both the ComboBox and ListBox controls
• Contains the items that appear in the control
  instance
• Similar to an array but contains additional
  methods to locate an item, add new items, and
  remove existing ones
• Items collection is but one collection among many
  supported by VB .NET

57
The Items Collection

• Properties
• Count property returns the number of items in a
  collection
• Item property retrieves a specific element from
  the collection
• Collection is 0-based
• Methods
• Add method adds a new item to the collection
• Clear method removes all items from the
  collection
• RemoveAt method removes a single item

58
Adding Items to a Collection

• The following For loops add items to the Items
  collection using the array of LogRecord
  structures named LogRecords
• For pintCount 0 To LogRecords.GetUpperBound(0)
• cboSourceIP.Items.Add(LogRecords(pintCount).So
  urceName
• Nexts

59
The End!
