Web Ranking

1
Web Ranking
2
Information Retrieval

• Input Document collection
• Goal Retrieve documents or text with information
  content that is relevant to users information
  need

3
Classic information retrieval

• Ranking is a function of query term frequency
  within the document (tf) and across all documents
  (idf)
• This works because of the following assumptions
  in classical IR
• Queries are long and well specified
• What is the impact of the Falklands war on
  Anglo-Argentinean relations
• Documents (e.g., newspaper articles) are
  coherent, well authored, and are usually about
  one topic
• The vocabulary is small and relatively well
  understood

4
Web information retrieval

• None of these assumptions hold
• Queries are short 2.35 terms in avg
• Huge variety in documents language, quality,
  duplication
• Huge vocabulary 100s million of terms
• Deliberate misinformation
• Ranking is a function of the query terms and of
  the hyperlink structure

SPAM
5
Hyperlink analysis

• Idea Mine structure of the web graph
• Each web page is a node
• Each hyperlink is a directed edge
• Related work
• Classic IR work (citations links) a.k.a.
  Bibliometrics K63, G72, S73,
• Socio-metrics K53, MMSM86,
• Many Web related papers use this approach
  PPR96, AMM97, S97, CK97, K98, BP98,

6
So...

• Our basic problem
• Given a DiGraph G, of web documents, rank all
  documents relevant to query q

1
2
7
Topics

• Eigenvectors review
• HITS, variants
• Pagerank, variants
• Rank aggregation
• Page Reputations

8
Eigenvectors review

• Lets say we have a matrix M
• Now consider V1 , V2 , V3
• We have MV1 , MV2 , MV3
• In other words, MV1 0V1 , MV2 -4V2, MV33V3

9
Eigenvectors review

• MV? ? V?
• a matrix can have many of these.

Eigenvector
Eigenvalue
10
Eigenvectors review

• Combine Vx to form P
• Now P-1.M.P
• Or M P P-1

Diagonal Matrix
11
Eigenvectors review

• This implies
• Mn P P-1
• Or Mn P P

(Well need this)
12
Some definitions

• Non-negative matrix Mij 0 gt (M 0)
• Irreducible matrix square, nonnegative, and
  there exists t s.t. (Mt)ij gt 0
• For adjacency matrix Strongly connected digraph
• Period of i gcd(t (Mt)ii gt 0)
• For irreducible period same for all i.
• For adjacency matrix period gcd of length of
  cycle
• Primitive matrix There exists t s.t. Mt gt 0
• Diff. from irreducible all gt 0
• Adjacency matrix gcd of cycle lengths 1

13
Perron-Frobenius Theorem

• For a nonnegative, irreducible, primitive matrix
  M, there exists an eigenvalue ? s.t.
• ? is real and positive and that ? gt ? for
  every other ? ? a
• ? corresponds to a strictly positive eigenvector
• ? is a simple root of the char. eq.(M a In) 0
• This property allows us to compute dominant
  eigenvalue / eigenvector easily.

14
Dominant Eigenvector

• Since MV? ? V?, and (a1, , an) coordinates
  of vector x in basis formed by eigenvectors.
• Mtx Sai?ti Vi
• Now since ?1 gt ?i, igt1,
• Mt a1 ?t1 V1 for large t
• Since V1 is strictly positive, any random
  positive vector will work

i
Dominant Eigenvector!
15
(Contd)

• Special case Stochastic matrix, ?11, and Mt
  converges exponentially
• lim Mt 1Tr
• where r stationary distribution of Markov chain

t ? 8
Random surfer model
16
HITS

• Introduced by Jon M. Kleinberg (1998).
• Hypertext Induced Topic Selection
• Find a set of interesting pages
• Find a base subgraph (of Web) using this set
• Use hubness and authoritativeness to rank
• Recursive Concept
• Good hubs point to good authorities
• Good authorities are pointed by good hubs

17
HITS Authority and Hubness
5
2
3
1
1
6
4
7
h(1) a(5) a(6) a(7)
a(1) h(2) h(3) h(4)
18
HITS Base Subgraph

• BaseSubgraph( R, d)
• S ? r
• for each v in R
• do S ? S U chv
• P ? pav
• if P gt d
• then P ? arbitrary subset of P having size d
• S ? S U P
• return S

S
R
19
HITS Algorithm

• HubsAuthorities(G)
• 1 ? 1,,1 ? R
• a ? h ? 1
• t ? 1
• repeat
• for each v in V
• do a (v) ? S h (w)
• h (v) ? S a (w)
• a ? a / a
• h ? h / h
• t ? t 1
• until a a h h lt
  e
• return (a , h )

V
0
0
t
w ? pav
t -1
w ? pav
t
t -1
t
t
t
t
t
t
t
t
t -1
t -1
t
t
20
HITS Ensuring Convergence

• Recursive dependency
• a(v) ? S h(w)
• h(v) ? S a(w)

w ? pav
w ? chv

• we can prove

a(v) and h(v) converge
21
HITS Ensuring Convergence

• at MTht-1 and ht Mat-1
• Thus, after t iterations
• at at(MTM)t-1MT1
• ht ßt(MMT)t1
• It can be shown that these converge, e.g. for
  nonnegative symmetric matrix M, to
• a ?1(MTM) and h ?1(MMT)

22
HITS (contd)

• Spamming
• Identical links
• distribute scores by normalizing effects from
  same host. (e.g. 1/n)
• topic drift many unrelated pages
• weight the edges of the graph according the
  relevance of the source and destination (e.g.
  link text nbd.)
• Hub replication, clique attacks, link farms?
• Solution ?

23
demo!

• Intuition of Hubness / Authness
• Teoma.com
• foosball
• mountain dew

24
SALSA

• SALSA (Lempel, Moran 2001)
• Probabilistic extension of the HITS algorithm
• Random walk is carried out by following
  hyperlinks both in the forward and in the
  backward direction
• Two separate random walks
• Hub walk
• Authority walk

25
SALSA (contd)

• Hub walk
• Follow a Web link from a page uh to a page wa (a
  forward link) and then
• Immediately traverse a backlink going from wa to
  vh, where (u,w) ? E and (v,w) ? E
• Authority Walk
• Follow a Web link from a page w(a) to a page u(h)
  (a backward link) and then
• Immediately traverse a forward link going back
  from vh to wa where (u,w) ? E and (v,w) ? E

26
SALSA (contd)

• Hub weight computed from the sum of the product
  of the inverse degree of the in-links and the
  out-links
• This solves the clique attack / link farm problems

27
PHITS

• Co-citation matrix community
• Effect on eigenvector authority of document in
  community
• HITS uses only dominant eigenvector principal
  community.
• What about smaller communities? (smaller
  eigenvectors)

28
PHITS Model

• P(d) P(zd)
  P(cz)
• Add communities between documents and citations
• Describe citation likelihood as
• P(d,c) P(d)P(cd), where
• P(cd) S P(cz)P(zd)
• Total likelihood of citations matrix M
• L(M) ? P(d,c)
• this becomes a max. likelihood problem

d
z
c
Note this is factored. (Different for mixture
model)
z
(d,c) ? M
29
PHITS (contd)

• Open up the eqn
• P(d,c) S P(z)P(cz)P(dz)
• Alternate between
• Computing P(zd,c)
• Re-estimating P(z), P(cz) and P(dz)
• Issues not globally optimal, cannot guarantee
  fits (soln restarts start with HITS / PCA
  model)
• How to decide of factors? (Topic hierarchy)

30
PageRank

• Page, et. al.1998
• Different from HITS
• HITS takes Hubness Authority weights
• The page rank is proportional to its parents
  rank, but inversely proportional to its parents
  outdegree

31
PageRank Model

• Just measuring in-degree (citation count) doesnt
  account for the authority of the source of a
  link.
• Initial page rank equation for page p
• Nq is the total number of out-links from page q.
• A page, q, gives an equal fraction of its
  authority to all the pages it points to (e.g. p).
• c is a normalizing constant set so that the rank
  of all pages always sums to 1.

32
Algorithm

• Iterate rank-flowing process until convergence
• Let S be the total set of pages.
• Initialize ?p?S R(p) 1/S
• Until ranks do not change (much)
  (convergence)
• For each p?S
• For each p?S R(p) cR(p)
  (normalize)

33
Linear Algebra Version

• Treat R as a vector over web pages.
• Let M be a 2-d matrix over pages where
• Mvu 1/Nu if u ?v else Mvu 0
• Then RcMR
• R converges to the principal eigenvector of M.

34
Problems

• Dangling page Problem
• Many Web pages have no inlinks/outlinks
• Results in dangling edges in the graph
• E.g.
• no parent ? rank 0
• MT converges to a matrix
• whose last column is all zero
• no children ? no solution
• MT converges to zero matrix

35
Modifications

• Surfer will restart browsing by picking a new Web
  page at random
• M ( B E )
• E escape matrix
• M stochastic matrix
• Still
• It is not guaranteed that M is primitive
• If M is stochastic and primitive, PageRank
  converges to corresponding stationary
  distribution of M

36
New Formula

• Hence we get

Escape / Damping Vector. Can also be overloaded
as personalization vector
37
PageRank Algorithm
Let S be the total set of pages. Let ?p?S E(p)
?/S (for some 0lt?lt1, e.g. 0.15) Initialize
?p?S R(p) 1/S Until ranks do not change
(much) (convergence) For each
p?S For each p?S R(p)
cR(p) (normalize)
38
Stochastic interpretation

• PageRank can be seen as modeling a random
  surfer that starts on a random page and then at
  each point
• With probability E(p) randomly jumps to page p.
• Otherwise, randomly follows a link on the
  current page.
• R(p) models the probability that this random
  surfer will be on page p at any given time.
• E jumps are needed to prevent the random surfer
  from getting trapped in web sinks with no
  outgoing links.

39
PageRank (cont.)

• Simplifying and adding a damping factor d
• PageRank stationary probability for this Markov
  chain, i.e.
• where n is the total number of nodes in the
  graph

40
demo!

• JUNG demo
• General intuition
• Pagerank.xls
• Changes in initial values
• dangling pages zero PR
• Changes in damping factors
• Number of iterations

41
Damping factor

• P (1-d)P d/n
• A low damping factor ( much damping) will make
  calculations easier. Since the flow of PageRank
  is dampened the iterations will quickly converge.

• A high damping factor ( little damping) will
  result in the average pages PageRank growing
  higher. Since there is little damping, PageRank
  received from external pages will be passed
  around in the system. It will not grow forever
  though - the maximum limit is Inbound PageRank
  d/(1-d).

42
PageRank Communities

• Bianchini et al.
• Community level interpretation
• E(community energy) of subgraph GI
• EI I EIin - EIout - EIdp
• where EI Spxi , xi stable PR, dpdangling
  pages
• Implications
• Same content divided into small pages good
  (I)
• Dangling pages loss in energy

43
Stability

• Whether the link analysis algorithms based on
  eigenvectors are stable in the sense that results
  dont change significantly?
• The connectivity of a portion of the graph is
  changed arbitrary
• How will it affect the results of algorithms?

44
Stability of HITS

• Ng et al (2001)
• A bound on the number of hyperlinks k that can
  added or deleted from one page without affecting
  the authority or hubness weights
• It is possible to perturb a symmetric matrix by
  a quantity that grows as d that produces a
  constant perturbation of the dominant eigenvector

d eigengap ?1 ?2d maximum outdegree of G
45
Stability of PageRank
Ng et al (2001)
V the set of vertices touched by the perturbation

• The parameter e of the mixture model has a
  stabilization role
• If the set of pages affected by the perturbation
  have a small rank, the overall change will also
  be small

tighter bound byBianchini et al (2001)
d(j) gt 2 depends on the edges incident on j
46
PageRank vs. HITS

• Computation
• Once for all documents and queries (offline)
• Query-independent requires combination with
  query-dependent criteria
• Hard to spam

• Computation
• Requires computation for each query
• Query-dependent
• Relatively easy to spam
• Quality depends on quality of start set
• Gives hubs as well as authorities

47
PageRank vs. HITS

• Lempel Not rank-stable O(1) changes in graph
  can change O(N2) order-relations
• Ng,Zheng, Jordan01 Value-Stable change in k
  nodes (with PR values p1,pk) results in p s.t.

• Not rank-stable
• value-stablility depends on gap g between
  largest and second largest eigenvector change of
  O(g) nodes results in p s.t.

48
PageRank variants

• ObjectRank
• Hristidis, et al.
• Create network of objects in databases
• Additional processing step (thanks to size)
• Create a PR vector for each word
• Merge word lists at query time
• Is this web-scalable?
• Not all words are distinct (synonyms)
• Popular queries 100,000 (4B pages 4 1014
  ints)

49
PageRank variants

• Topic Sensitive Pagerank
• Havelivala, 2002
• Pre-compute PPV(ri) for a topical basis r1,,rk,
  k20
• Query user submits a topic by
• Query engine combines PPV(ri) vectors using
  personalization weights

50
Rank Aggregation

• Why?
• Metasearch (Dogpile Y! G Ask)
• Rank Aggregation (PageRank TF/IDF)
• HowGiven lists A and B, A(i) rank of element
  i in A.
• Minimize Distance measures
• Spearman footrule distance sum of rank distance
  S A(i) B(i) (linear)
• Kendall Tau distance pairwise disagreements
  (i, j) i lt j, A(i) lt A(j), but B(i) gt B(j)
  (nlogn)
• What about top-k lists? Take union, and project.

S i1
51
Rank Aggregation

• Strategy Make global list, minimize distance
• Kemeny aggregation (minimize kendall) NP-hard,
  even with 4 lists.
• This has a max. likelihood interpretation
• Consider each candidate list as noisy version of
  the global list.
• Find list max. likely to produce candidate
  lists.
• Kemeny satisfies ext.Condorcet criterionpartition
  global list, part A beats part B by majority.
• Good for spam hard to spam a majority of search
  engines.

52
Page Reputations

• Penetration Pp(t) I(p, t) / N(t)Focus
  Ft(p) I(p, t) / In(p)
• I(p, t) pages on t, pointing to p
• In(p) pages pointing to p
• N(t) pages on t
• RM(p,t) (Pp(t) L(p))/L(p) (NwI(p,
  t)/N(t)In(p)) - 1
• L(p) In(p) / Nw
• t derived from snippets, pre-decided.

53
fin.
54
bibliography

• J. Kleinberg, et. al. HITS Inferring Web
  communities from link topology (link)
• R. Lempel, S. Moran. SALSA the stochastic
  approach for link-structure analysis. ACM
  Transactions on Information Systems (TOIS), 2001.
  (link)
• Sergey Brin and Lawrence Page. The anatomy of a
  large-scale hypertextual Web search engine. In
  Proceedings of the 7th International Conference
  on the World Wide Web, pages 107-117, 1998.
  Elsevier Science B. V. 12
• Arvind Arasu, Jasmine Novak, Andrew Tomkins, and
  John Tomlin. PageRank computation and the
  structure of the web Experiments and algorithms.
  In Proceedings of the 11th International
  Conference on the World Wide Web, 2002. ACM
  Press. 2
• Monica Bianchini, Marco Gori, and Franco
  Scarselli. Inside PageRank. ACM Transactions on
  Internet Technology, 5(1)92-128, 2002. ACM
  Press. 6
• David Cohn and Huan Chang. Learning to
  probabilistically identify authoritative
  documents. In Pat Langley, editor, Proceedings of
  the 17th International Conference on Machine
  Learning, pages 167-174, 2000. Morgan Kaufmann.
  19
• Andrey Balmin, Vagelis Hristidis, and Yannis
  Papakonstantinou. Authority-Based Keyword Queries
  in Databases using ObjectRank. (link)
• Taher Haveliwala. Topic Sensitive PageRank in WWW
  2002. (link)
• Cynthia Dwork, Ravi Kumar, Moni Naor, and D.
  Sivakumar. Rank aggregation methods for the Web.
  In Proceedings of the 10th International
  Conference on the World Wide Web, pages 613-622,
  2001. ACM Press. 23
• Alberto O. Mendelzon and Davood Rafiei. What do
  the neighbours think? Computing web page
  reputations. IEEE Data Engineering Bulletin,
  23(3)9-16, 2000. 417 PageRank explained with
  bright colors (link)
• Hyperlink Analysis of the Web Monika
  Henzinger,Google Inc. presentation. (link)
• Modeling the Internet and the Web - Pierre
  Baldi, Paolo Frasconi, Padhraic Smyth (link)
• Mining the Web Soumen Chakrabarti (link)
