High Performance Parallel Programming

• Dirk van der Knijff
• Advanced Research Computing
• Information Division

2
High Performance Parallel Programming

• Lecture 1 Introduction to Parallel Programming

3
Introduction

• Parallel programming covers all occasions where
  more than 1 functional element is involved.
• Most simple hardware parallelism is already
  exploited
• Bit-parallel adders and multipliers
• Multiple arithmetic units
• Overlapped compute and I/O
• Pipelined instruction execution
• We are concerned with higher levels.

4
Why parallel?

• Because its faster!!!
• Even without good scalability -
• but not always
• Because its cheaper!
• Leverages commodity components
• Allows arbitrary size computers
• Because its natural!
• The real world is parallel
• Computer languages usually force a serial view

5
Taxonomy

• Flynns taxonomy
• based on hardware but can be applied to software
  also.

Today all hardware is MIMD Most programs are SPMD
(based on SIMD)
6
Parallel Architectures
SIMD - Single Instruction Multiple Data Data
Parallel Machines MIMD - Multiple Instruction
Multiple Data SMP - Shared Memory
Processing ccNUMA - cache coherent Non-Uniform
Memory Access DM - Distrubuted Memory MPP -
Massively Parallel Processors NOWS - Network Of
Work-Stations
7
Programming Models

• Machine architectures and Programming models
  have a natural affinity, both in their
  descriptions and in there effects on each other.
  Algorithms have been developed to fit machines
  and machines have been built to fit algorithms.
• Purpose built Supercomputers - ASCI
• FPGAs - QCDmachines

8
Parallel Programming Models

• Control
• How is parallelism created?
• What orderings exist between operations?
• How do different threads of control synchronize?
• Data
• What data is private vs. shared?
• How is logically shared data accessed or
  communicated?
• Operations
• What are the atomic operations?
• Cost
• How do we account for the cost of each of the
  above?

9
Trivial Example

• Parallel Decomposition
• Each evaluation and each partial sum is a task.
• Assign n/p numbers to each of p procs
• Each computes independent private results and
  partial sum.
• One (or all) collects the p partial sums and
  computes the global sum.
• Two Classes of Data
• Logically Shared
• The original n numbers, the global sum.
• Logically Private
• The individual function evaluations.
• What about the individual partial sums?

10
Model 1 Shared Address Space

• Program consists of a collection of threads of
  control.
• Each has a set of private variables, e.g. local
  variables on the stack.
• Collectively with a set of shared variables,
  e.g., static variables, shared common blocks,
  global heap.
• Threads communicate implicitly by writing and
  reading shared variables.
• Threads coordinate explicitly by synchronization
  operations on shared variables -- writing and
  reading flags, locks or semaphores.
• Like concurrent programming on a uniprocessor.

11
Shared Address Space
Machine model - Shared memory
12
Shared Memory Code for Computing a Sum
Thread 1 s 0 initially local_s1 0 for i
0, n/2-1 local_s1 local_s1 f(Ai) s s
local_s1
Thread 2 s 0 initially local_s2 0 for i
n/2, n-1 local_s2 local_s2 f(Ai) s s
local_s2
What could go wrong?
13
Solution via Synchronization

• Pitfall in computing a global sum s local_s1
  local_s2

Thread 1 (initially s0) load s from mem to
reg s slocal_s1 local_s1, in reg
store s from reg to mem
Thread 2 (initially s0) load s from
mem to reg initially 0 s slocal_s2
local_s2, in reg store s from reg to mem
Time

• Instructions from different threads can be
  interleaved arbitrarily.
• What can final result s stored in memory be?
• Problem race condition.
• Possible solution mutual exclusion with locks

Thread 1 lock load s s slocal_s1
store s unlock
Thread 2 lock load s s slocal_s2
store s unlock

• Locks must be atomic (execute completely without
  interruption).

14
Model 2 Message Passing

• Program consists of a collection of named
  processes.
• Thread of control plus local address space -- NO
  shared data.
• Local variables, static variables, common blocks,
  heap.
• Processes communicate by explicit data transfers
  -- matching send and receive pair by source and
  destination processors(these may be broadcast).
• Coordination is implicit in every communication
  event.
• Logically shared data is partitioned over local
  processes.
• Like distributed programming -- program with MPI,
  PVM.

15
Message Passing
send P0,X
recv Pn,Y
X
Y
. . .
P
P
n
0
Machine model - Distributed Memory
16
Computing s x(1)x(2) on each processor

• First possible solution

Processor 1 send xlocal, proc2 xlocal
x(1) receive xremote, proc2 s xlocal xremote
Processor 2 receive xremote, proc1 send xlocal,
proc1 xlocal x(2) s xlocal xremote

• Second possible solution -- what could go wrong?

Processor 1 send xlocal, proc2 xlocal
x(1) receive xremote, proc2 s xlocal xremote
Processor 2 send xlocal, proc1 xlocal
x(2) receive xremote, proc1 s xlocal xremote

• What if send/receive acts like the telephone
  system? The post office?

17
Model 3 Data Parallel

• Single sequential thread of control consisting of
  parallel operations.
• Parallel operations applied to all (or a defined
  subset) of a data structure.
• Communication is implicit in parallel operators
  and shifted data structures.
• Elegant and easy to understand and reason about.
• Like marching in a regiment.
• Used by Matlab.
• Drawback not all problems fit this model.

18
Data Parallel
Machine model - SIMD
19
SIMD Architecture

• A large number of (usually) small processors.
• A single control processor issues each
  instruction.
• Each processor executes the same instruction.
• Some processors may be turned off on some
  instructions.
• Machines are not popular (CM2), but programming
  model is.
• Implemented by mapping n-fold parallelism to p
  processors.
• Programming
• Mostly done in the compilers (HPF High
  Performance Fortran).
• Usually modified to Single Program Multiple Data
  or SPMD

20
Data Parallel Programming

• Data Parallel programming involves the processing
  and manipulation of large arrays
• Processors should (simultaneously) perform
  similar operations on different array elements
• Each processor has a local memory gt large arrays
  must be distributed across many different
  processors
• Arrays can be distributed in different ways
  depending on how they are used
• We want to choose a distribution which maximises
  the ratio of local work to communication

21
Data Parallel Programming (HPF)

• Most successful Data-parallel language
• Extension to Fortran90/95
• Fastest language
• Has powerful array constructs
• Has suitable data structures implementation
• HPF is based on compiler directives
• Easiest way to write parallel programs
• Compiler does most of the work

22
OpenMP - Shared Memory Systems

• Key feature is a single address space across the
  whole memory system.
• every processor can read and write all memory
  locations
• Caches are kept coherent
• all processors have same view of memory.
• Two main types
• true shared memory
• distributed shared memory

23
Threads and thread teams

• A thread is a (lightweight) process - an instance
  of a program and its data.
• Each thread can follow its own flow of control
  through a program.
• Threads can share data with other threads, but
  also have private data.
• Threads communicate with each other via the
  shared data.
• A thread team is a set of threads which
  co-operate on a task.
• The master thread is responsible for
  co-ordinating the team.

thread 1
thread 2
thread 3
PC
PC
PC
Private data
Private data
Private data
shared data
24
Directives and sentinels

• A directive is a special line of source code with
  meaning only to a compiler that understands it.
• Note the difference between directives (must be
  obeyed) and hints (may be obeyed).
• A directive is distinguished by a sentinel at the
  start of the line.
• OpenMP sentinels are
• Fortran !OMP (or COMP or OMP)
• C/C pragma omp

25
Parallel region

• The parallel region is the basic parallel
  construct in OpenMP.
• A parallel region defines a section of a program.
• Program begins execution on a single thread (the
  master thread).
• When the first parallel region is encountered,
  the master thread creates a team of threads.
  (Fork/join model)
• Every thread executes the statements which are
  inside the parallel region
• At the end of the parallel region, the master
  thread waits for the other threads to finish, and
  continues executing the next statements

26
Parallel region
program fred . . !omp
parallel . . . .
. !omp end parallel . .
. !omp parallel . .
. !omp end parallel . .
27
Shared and private data

• Inside a parallel region, variables can either be
  shared or private.
• All threads see the same copy of shared
  variables.
• All threads can read or write shared variables.
• Each thread has its own copy of private
  variables these are invisible to other threads.

• A private variable can only be read or written by
  its own thread.

28
Parallel loops

• Loops are the main source of parallelism in many
  applications.
• If the iterations of a loop are independent (can
  be done in any order) then we can share out the
  iterations between different threads.
• e.g. if we have two threads and the loop

• do i 1, 100
• a(i) a(i) b(i)
• end do
• we could do iteration 1-50 on one thread and
  iterations 51-100 on the other.

29
Synchronisation

• Need to ensure that actions on shared variables
  occur in the correct order e.g.
• thread 1 must write variable A before thread 2
  reads it,
• or
• thread 1 must read variable A before thread 2
  writes it.
• Note that updates to shared variables (e.g. a
  a 1)are not atomic!
• If two threads try to do this at the same time,
  one of the updates may get overwritten.

30
Reductions

• A reduction produces a single value from
  associative operations such as addition,
  multiplication, max, min, and, or.
• For example
• b 0
• for (i0 iltn i)
• b b a(i)
• Allowing only one thread at a time to update b
  would remove all parallelism.
• Instead, each thread can accumulate its own
  private copy, then these copies are reduced to
  give final result.

31
Parallel region directive

• Code within a parallel region is executed by all
  threads.
• Syntax
• Fortran C/C
• !omp parallel pragma omp parallel
• block
• !omp end parallel block
• e.g.
• call fred
• !omp parallel
• call billy
• !omp end parallel
• call daisy

fred
billy
billy
billy
billy
daisy
32
Useful functions

• Often useful to find out number of threads being
  used.
• Fortran integer function omp_get_num_threads()
• C/C include ltomp.hgt
• int omp_get_num_threads(void)
• Also useful to find out number of the executing
  thread.
• Fortran integer function omp_get_thread_num()
• C/C include ltomp.hgt
• int omp_get_thread_num(void)
• Takes values between 0 and omp_get_num_threads()-
  1

33
Clauses

• Specify additional information in the parallel
  region directive through clauses
• Fortran !omp parallel clauses
• C/C pragma omp parallel clauses
• Clauses are comma or space separated in Fortran,
  space separated in C/C.

34
Shared and private variables

• Inside a parallel region, variables can be either
  shared (all threads see same copy) or private
  (each thread has private copy).
• Defined using shared, private and default clauses
• Fortran shared(list)
• private(list)
• default(sharedprivatenone)
• C/C shared(list)
• private(list)
• default(sharednone)

35
Shared and private (cont)

• Example each thread initialises its own column
  of a shared array
• !OMP PARALLEL DEFAULT(NONE),PRIVATE(I,MYID),
• !OMP SHARED(A,N)
• myid omp_get_thread_num() 1
• do i 1,n
• a(i,myid) 1.0
• end do
• !OMP END PARALLEL

36
Shared and private (cont)

• How do we decide which variables should be shared
  and which private?
• Most variables are shared
• Loop indices are private
• Loop temporaries are private
• Read-only variables - shared
• Main arrays - shared
• Write-before-read scalars - usually private
• Sometimes either is semantically OK, but there
  may be performance implications in making the
  choice.
• N.B. can have private arrays as well as scalars

37
Initialising private variables

• Private variables are uninitialised at the start
  of the parallel region.
• If we wish to initialise them, we use the
  FIRSTPRIVATE clause
• Fortran firstprivate(list) C/C firstprivate(li
  st)
• e.g. b 23.0
• . . . . .
• !OMP PARALLEL FIRSTPRIVATE(B),
• !OMP PRIVATE(I,MYID)
• myid omp_get_thread_num() 1
• do i 1,n
• b b c(i,myid)
• end do
• c(n1,myid) b
• !OMP END PARALLEL

38
Reductions

• A reduction produces a single value from
  associative operations such as addition,
  multiplication,max, min, and, or.
• Would like each thread to reduce into a private
  copy, then reduce all these to give final result.
• Use REDUCTION clause
• Fortran reduction(oplist) C/C
  reduction(oplist)
• N.B. Cannot have reduction arrays, only scalars
  or array elements!

39
Reduction example

• !OMP PARALLEL REDUCTION(B),
• !OMP PRIVATE(I,MYID)
• myid omp_get_thread_num() 1
• do i 1,n
• b b c(i,myid)
• end do
• !OMP END PARALLEL

40
Parallel do loops

• Loops are the most common source of parallelism
  in most codes. Parallel loop directives are
  therefore very important!
• A parallel do loop divides up the iterations of
  the loop between threads.
• Fortran !OMP DO clauses C/C pragma omp
  for clauses
• do loop for loop
• !OMP END DO
• Restrictions in C/C. It has to look like a DO
  loop - it must be of the
• form for (var a var logical-op b incr-exp)
• where logical-op is one of lt, lt, gt, gt
• and incr-exp is var var /- incr or var.

41
Parallel do loops (cont)

• With no additional clauses, the DO/FOR directive
  will usually partition the iterations as equally
  as possible between the threads.
• However, this is implementation dependent, and
  there is still some ambiguity
• e.g. 7 iterations, 3 threads. Could partition as
  331 or 322
• How can you tell if a loop is parallel or not?
• Useful test if the loop gives the same answers
  if it is run in reverse order, then it is almost
  certainly parallel
• e.g. do i2,n
• a(i)2a(i-1)
• end do

42
Parallel do loops (cont)

• ix base
• do i1,n
• a(ix) a(ix)b(i)
• ix ix stride
• end do
• do i1,n
• b(i) (a(i)-a(i-1))0.5
• end do

43
Parallel do loops (example)

• Example
• !OMP PARALLEL
• !OMP DO
• do i1,n
• b(i) (a(i)-a(i-1))0.5
• end do
• !OMP END DO
• !OMP END PARALLEL

44
SCHEDULE clause

• The SCHEDULE clause gives a variety of options
  for specifying which loops iterations are
  executed by which thread.
• Syntax schedule (kind, chunksize)
• where kind is one of
• STATIC, DYNAMIC, GUIDED or RUNTIME
• and chunksize is an integer expression with
  positive value.

45
STATIC schedule

• With no chunksize specified, the iteration space
  is divided into (approximately) equal chunks, and
  one chunk is assigned to each thread (block
  schedule).
• If chunksize is specified, the iteration space is
  divided into chunks, each of chunksize
  iterations, and the chunks are assigned
  cyclically to each thread (block cyclic schedule)

T0
T1
T2
T3
schedule(static)
T0
T1
T2
T3
T0
T1
T2
T3
T0
T1
T2
T3
T0
schedule(static,4)
46
DYNAMIC schedule

• DYNAMIC schedule divides the iteration space up
  into chunks of size chunksize, and assigns them
  to threads on a first-come-first-served basis.
• i.e. as a thread finishes a chunk, it is assigned
  the next chunk in the list.
• When no chunksize is specified, it defaults to 1.

• Note - this may be inefficient - you should
  specify a chunksize that matches the cache-line
  length to avoid false sharing

schedule(dynamic,4)
47
GUIDED schedule

• GUIDED schedule is similar to DYNAMIC, but the
  chunks start off large and get smaller
  exponentially.
• The size of the next chunk is (roughly) the
  number of remaining iterations divided by the
  number of threads.
• The chunksize specifies the minimum size of the
  chunks.
• When no chunksize is specified it defaults to 1.

schedule(guided,3)
48
RUNTIME schedule

• The RUNTIME schedule defers the choice of
  schedule to run time, when it is determined by
  the value of the environment variable
  OMP_SCHEDULE.
• e.g. export OMP_SCHEDULEguided,4
• It is illegal to specify a chunksize with the
  RUNTIME schedule.

49
Synchronization

• Recall
• Need to synchronise actions on shared variables.
• Need to respect dependencies (true and anti)
• Need to protect updates to shared variables (not
  atomic by default)

50
Critical sections

• A critical section is a block of code which can
  be executed by only one thread at a time.
• Can be used to protect updates to shared
  variables.
• The CRITICAL directive allows critical sections
  to be named.
• If one thread is in a critical section with a
  given name, no other thread may be in a critical
  section with the same name, though they can be in
  critical sections with other names.
• Fortran !OMP CRITICAL ( name )
• block
• !OMP END CRITICAL ( name )
• C/C pragma omp critical ( name )
• structured block

51
BARRIER directive

• No thread can proceed past a barrier until all
  the other threads have arrived.
• Note that there is an implicit barrier at the end
  of DO/FOR, SECTIONS and SINGLE directives.
• Fortran !omp barrier
• C/C pragma omp barrier
• Either all threads or none must encounter the
  barrier (DEADLOCK!!)
• e.g. !OMP PARALLEL PRIVATE(I,MYID)
• myid omp_get_thread_num()
• a(myid) a(myid)3.5
• !OMP BARRIER
• b(myid) a(neighb(myid)) c
• !OMP END PARALLEL

52
ATOMIC directive

• C/C pragma omp atomic
• statement
• where statement must have one of the forms
• x binop expr, x, x, x--, or --x
• and binop is one of , , -, /, , , ltlt, or gtgt
• Note that the evaluation of expr is not atomic.
• May be more efficient that using CRITICAL
  directives,e.g. if different array elements can
  be protected separately.

53
ATOMIC directive

• Used to protect a single update to a shared
  variable.
• Applies only to a single statement.
• Syntax
• Fortran !OMP ATOMIC
• statement
• where statement must have one of these forms
• x x op expr, x expr op x, x intr (x,
  expr) or
• x intr(expr, x)
• op is one of , , -, /, .and. , .or. , .eqv., or
  .neqv.
• intr is one of MAX, MIN, IAND, IOR or IEOR

54
Lock routines

• Occasionally we may require more flexibility than
  is provided by CRITICAL and ATOMIC directions.
• A lock is a special variable that may be set by a
  thread. No other thread may set the lock until
  the thread which set the lock has unset it.
• Setting a lock can either be blocking or
  non-blocking.
• A lock must be initialised before it is used, and
  may be destroyed when it is not longer required.
• Lock variables should not be used for any other
  purpose.

55
Choosing synchronisation

• As a rough guide, use ATOMIC directives if
  possible, as these allow most optimisation.
• If this is not possible, use CRITICAL directives.
  Make sure you use different names wherever
  possible.
• As a last resort you may need to use the lock
  routines, but this should be quite a rare
  occurrence.

56
Further reading

• OpenMP Specification
• http//www.openmp.org/
• My self-paced course (under development)
• http//www.hpc.unimelb.edu.au/vpic/omp/contents.h
  tml

57
High Performance Parallel Programming

• Tomorrow - MPI programming.
