Roof Membrane MakeUp

1
(No Transcript)
2
(No Transcript)
3
Roof Membrane Make-Up

• Waterproofing Layer or Layers
• Reinforcement
• Surfacing

4
Membrane Types
5
Mineral Surfaced Built-UpRoofing System
6
Smooth Surfaced Built-Up Roofing System
7
Gravel Surfaced Built-Up Roofing System
8
Advantages of Built-Up Roofing

• Long term History
• Low Cost
• Low Life Cycle Cost
• Easily Repaired
• Multiple Layers
• High Resistance to Punctures and Abuse
• Familiarity for Workers

9
Disadvantages of Built-Up Roofing

• Roof Must be Accessible for Equipment and
  Material Loading
• Asphalt Odor

10
APP Modified - Roof System
11
Advantages of APP Modified Bitumen

• Decades of History
• Easily Repaired
• High Puncture and Abuse Resistance
• Good for Project with Poor Accessibility
• Low Relative cost for Small Projects and Tenant
  Improvements

12
Disadvantages of APP Modified Bitumen

• Applied with Torch Fire Hazard
• Oil and Grease Intolerant
• Moderate Workmanship Concerns
• Snake-Oil Salesman

13
Advantages of Thermoset EPDM

• Decades of History
• Easily Repaired
• Can be Installed Quickly with fewer Workers

14
Disadvantages of Thermoset EPDM

• History of Seam Failure
• Oil and Grease Intolerant
• High Workmanship Concerns
• Less Worker Familiarity
• Less Tenant Familiarity

15
Ballasted Insulation Single PlyRoofing System
16
Mechanically Attached Insulated Single
Ply Roofing System
17
Thermoplastic PVC

• Decades of History
• Heat Welded Seams
• Moderate Puncture Resistance
• Easily Repaired

18
Advantages of Thermoplastic Polyolefins (TPOs)

• Heat Welded Seams
• Moderate Puncture Resistance
• Chemical Resistance
• Can be Installed Quickly

19
Disadvantages of Thermoplastic Polyolefins (TPOs)

• High Workmanship Concerns
• Short History
• Low Worker Familiarity
• Low Tenant Familiarity
