How to use Digital Technology

1
How to use Digital Technology

• Digital Camera Demonstration
• By
• Instructional Technology Services, SAISD

2
Topics Covered

• What is a digital technology
• History of Digital Cameras
• Parts of a Digital Camera
• The hardware needed to create your own digital
  studio
• What type of memory card should you purchase

Continued
3
Topics Covered

• Transferring your images from your camera to your
  PC
• What is the right format for your digital
  projects
• How to create photo-quality prints suitable for
  framing

Continued
4
Image Software Demo

• Using Macromedia Fireworks
• How to correct minor imperfections in your images
• Changing the appearance of your images using
  special effects
• Combining text and other images with your photos

5
What is a Digital Technology?
6
Digital Technology

• Technology that uses a binary representations to
  store information.
• Binary a number of base two, which uses only
  the digits 0 and 1.
• Computers operate by using binary (presence and
  absence of electricity) to perform computations
  and make logical decisions
• Memory is store using a digital format (CD-ROMS,
  CD-Rs, CD-RW, DVD, Memory Cards, )

7
Why go Digital?

• Freedom and Flexibility
• No longer tied to purchasing film and its
  expiration date
• Instant preview of images
• Choice in downloading only the images you want to
  keep
• Power to change your images using a secondary
  software program (Adobe Photoshop, Macromedia
  Freehand 10 and Fireworks, Jasc Paint Shop Pro )

8
Why go Digital?

• Personalization of projects by importing your
  images (greeting cards, web pages, presentations,
  )
• The ability to print your images in any size or
  format of your choosing
• Lower end models are still functional and
  cheaper. They make great gifts for beginner
  photographers and younger consumers

9
History of Digital Cameras
10
History of Digital Cameras

• First digital cameras appeared in the 1990s
• Captured low resolution, fuzzy images of poor
  quality
• Relied on a light sensor to capture the image or
  CMOS chip.
• VGA resolution (640x480 pixels) was the standard
  size of a digital image.
• Because of the low resolution the image printed
  fuzzy and unclear.

11
First digital cameras were very expensive
Data taken from How to do Everything with Your
Digital Camera, 3rd Ed. By Dave Johnson,
McGraw-Hill/Osborne, 2003
12
Stop
What is a high resolution, 3-2 mega pixel digital
still camera?
13
But what does it mean?

• Digital Composed of, or employing a binary
  representation of information
• Mega Million
• Pixel Short for Picture Element, a small,
  discrete unit of visual information on a video
  screen.
• Low Resolution Images that do not appear sharp
  and detailed because they are made up of a small
  number of dots per inch.

14
But what does it mean?

• High resolution Refers to images that appear
  sharp and detailed because they are made up of a
  large number of dots per inch.
• Dots per inch (DPI) The measurement of how
  sharp your print will be. The more dots, the
  better the resolution or appearance of the
  picture.
• MB Mega Bytes
• Mb Mega Bit

15

• A mega pixel camera can create a image with
  millions of pixels or millions of dots of
  information.

Data taken from How to do Everything with Your
Digital Camera, 3rd Ed. By Dave Johnson,
McGraw-Hill/Osborne, 2003
16
Follow this rule of thumb

• The more pixels you have,
• the sharper the image,
• the larger it can be printed

And the more expensive the camera
17
Difference in Resolution
18
Difference in Resolution
19
Parts of a Digital Camera
20
Parts of a Digital Camera

• Lens
• Flash

21
Parts of a Digital Camera

• Digital Viewfinder
• Optical Viewfinder
• Menu buttons
• Zoom

22
Parts of a Digital Camera

• Ports
• AC
• USB
• Video

23
Parts of a Digital Camera

• Power Button
• Mode Selector

24
Parts of a Digital Camera

• Media and Battery area

25
The hardware needed to create your own digital
studio
26
Your own Digital Studio

• A Camera
• A Personal Computer (plenty of RAM and a fast
  processor)
• Batteries (rechargeable are recommended)
• Memory Card for the Camera (128MB, 256MB, or
  higher)
• Image editing software (Adobe Photoshop,
  Macromedia Freehand 10 and Fireworks, Jasc Paint
  Shop Pro )
• Color Inkjet Printer and premium photo paper

27
What type of memory cardshould you purchase
28
Memory cards

• The cameras removable memory
• There are several different types SD, SmartMedia,
  CompactFlash, Memory Stick
• Several different sizes 16MB, 32MB, 64MB, 128MB,
  256MB, 512MB, and are even available in gigs
• But, may only work in certain brands of cameras.

• Some cameras may also use Floppy Disk
• and CD-Rs as storage devices

29
Secure Digital (SD)

• The newest kind of removable memory
• About the size of your thumbnail
• Used as extended memory in PDAs
• Can hold large amounts of memory currently
  256MB or more

30
SmartMedia

• The oldest of all memory formats
• About the size of your thumbnail
• Are wafer thin and somewhat flexible
• Can only hold up to 128MB of memory

31
CompactFlash

• Same age as SmartMedia
• Reasonably small (about an 1/8th of an inch
  thick)
• Ideal for high-Mega Pixel cameras
• Comes in capacities up to 4GB

32
Memory Stick

• Originally made only for Sony and Sony products
• Resembles a stick of gum
• Two different formats
• Memory Stick (only up to 128MB)
• Memory Stick Pro (from 256MB to 1GB)

33
Floppy Disk and CD-Rs

• Floppies hold only 1.44MB (a tiny amount)
• CD-Rs hold up to 700MB
• Image transfer is easy
• Floppies go strait from the camera into the
  floppy drive of the PCs
• CD-Rs may require finalization first prior to
  image transfer

34
How many images can fit
Assuming youre capturing JPG images in
high-quality compression
Data taken from How to do Everything with Your
Digital Camera, 3rd Ed. By Dave Johnson,
McGraw-Hill/Osborne, 2003
35
Transferring your images from your camera to your
PC
36
Transferring Images

• The camera should come with the software and a
  cable to connect it to the PC
• Todays cameras use the USB connection, though
  older ones may still need a serial cable instead.
• Some high-end models may also use a FireWire

37
Things to Know

• USB comes in two formats USB 1.1 and USB 2.0
• USB 1.1 used to the standard and transfers data
  at 12 Mbps (mega bits per second)
• USB 2.0 runs as 450 Mbps
• In order to use USB 2.0, both your computer and
  camera must be USB 2.0 compliant

38
Things to Know

• If connect a new USB Camera to your computer
• Start by installing the software first
• NEVER plug in a USB cable connected to the
  hardware prior to install the software (unless
  directed)

39
Things to Know

• Memory Card readers or adapters
• Lets you insert a memory card and read images
  from it like a floppy disk
• Will be recognized by your PC as several
  removable disk drives (found in the My Computer
  window)
• Transfers my be faster with the adapter
• Most adapters have slots for several different
  types of memory cards

40
What is the right formatfor your digital projects
41
Problem Limited Space

• Certain file formats take up more space (MB) than
  others when saved to your PC
• Other file formats may not be recognized by
  certain programs and will need to be converted to
  another type by the user
• And still others may compress well to take up
  less space and still maintain their picture
  quality

42
Most Common File Formats

• JPG Joint Photographic Experts Group
• Will compress to save storage space
• May sacrifice image quality in order to save on
  space
• Does an outstanding job on preserving all visual
  information that can be seen by the human eye

43
Most Common File Formats

• TIF Tagged Image File
• Can be save with or without compression
• Will preserve 100 of the information for about
  every pixel in the original image
• Can be used in both the Windows and the Macintosh
  platforms

44
Most Common File Formats

• BMP Bitmapped file format
• Used for general-purpose storage and as wallpaper
  on your Windows desktop
• Not used on the Internet
• Tend to be quite large because no file
  compression will be used to save the image

45
Most Common File Formats

• GIF Graphics Interchange Format
• Has a few advantages over the JPG format on the
  Web
• Can make the background of GIF images transparent
• Images can also be displayed in interlace mode,
  which means you can get an overall impression of
  the picture even before it has fully downloaded.

46
How to create photo-quality prints suitable for
framing
47
A Must A Great Printer

• A digital camera isnt very useful unless you can
  make great prints.
• Invest in a color inkjet printer, which is
  measured in dots per inch (dpi). Look for
• High resolution 200 to 300 dpi
• Number of color a tri-color cartridge with a
  separate black
• Speed Inkjets print more slowly (color should
  be their selling point not speed)

48
A Must A Great Printer

• Eyeball the prints try out the printer in the
  store before purchasing (demo button)
• Ease of installation USB versus an older
  parallel port connector
• Direct printing Some printers let you connect
  your digital camera directly to the printer or
  insert the cameras memory card into the printer
  for quick and painless printing.

49
A Must A Great Printer

• Size and capacity of the paper tray some
  printers differ dramatically in terms of what
  kind of paper you can print on. You may have to
  purchase a wide-format printer if you want to
  create posters or large size prints
• Expense of printer cartridges depending on the
  type of printer and the type of cartridge,
  tri-color and black cartridge may run from 23 to
  57 each

50
Which paper is best?

• Stock and use paper according to you needs.
• For daily use that doesnt involve printing
  photos, use plain copy paper or inkjet paper
• For high quality printing, you have a number of
  choices depending on weight, grade, and glossy
  application

51
Types of paper

• Plain paper inexpensive and the ink tends to
  absorb quickly and blur the image
• Inkjet paper Makes a better draft-quality
  photographic prints. Has embed clay or some
  other ink fixture to stop the inks from spreading
  before they dry

52
Types of paper

• Photo paper bright-white coated paper thats
  designed explicitly for photographs
• Glossy photo paper Expensive (generally a
  dollar a sheet). You can only print on one side
  of the photo paper

53
Image Software Demonstration
54

• Using Macromedia Fireworks
• How to correct minor imperfections in your images
• Changing the appearance of your images using
  special effects
• Combining text and other images with your photos
