Independent Motion Estimation

1
Independent Motion Estimation

• Luv Kohli
• COMP290-089
• Multiple View Geometry
• May 7, 2003

2
Outline

• The motion segmentation problem
• Motivation
• Background
• Recursive RANSAC
• More sophisticated algorithms
• Results

3
Motion segmentation

• The problem according to Phil Torr how to detect
  a set of independently moving objects in the 2D
  projection of an otherwise rigid scene, given
  that the camera is moving in an arbitrary and
  unpredetermined manner

4
Motivation

• Many practical applications for motion
  segmentation
• Navigation
• Image compression and representation
• Video indexing
• Recovery of 3D structure
• Difficult to generalize for all types of scenes

5
Background

• The methods thus far proposed for motion
  segmentation can be split into several categories
• Methods for a stationary camera do not
  distinguish several independently moving objects
  in the scene can determine that there is motion
  but now how many objects

6
Background (2)

• Methods based on image motion constraints
• For example, compute velocities in the image
  using a local correspondence scheme and group
  similar velocities

7
Background (3)

• Methods that require knowledge of the camera
  motion
• Methods based on world constraints and epipolar
  geometry
• An object undergoing a rigid transformation is
  equivalent to a camera moving in the opposite
  direction effective motion can be described by
  epipolar geometry

8
Recursive RANSAC

• RANSAC can be used to robustly estimate the
  fundamental matrix
• Determines a highly probable solution to the
  problem and separates matches into a set of
  inliers and a set of outliers
• Outliers may correspond to a second rigid motion
  in the scene

9
Recursive RANSAC (2)

• Run RANSAC on set of putative matches to get
  inliers and outliers
• Remove inliers from putative match set, and run
  RANSAC on outliers
• This can be repeated multiple times, but
  generally it is difficult to fit data for more
  than 2 or 3 objects
• Each matrix can then be improved through
  nonlinear minimization

10
Degeneracy

• Data is degenerate if insufficient to determine a
  unique solution
• This can cause many problems especially when
  there is a significant level of noise in the data
• Phil Torr created the PLUNDER (Pick Least
  UNDEgenerate Randomly) algorithm for detecting
  degeneracy

11
Degeneracy (2)

• The PLUNDER algorithm essentially determines
  which model (affinity, projectivity, etc.) a data
  set is consistent with
• Fundamental matrices for different subsets of
  data can be estimated using different models
• Phil Torrs thesis goes into much more detail

12
Results (Rec. RANSAC)
13
Results (putative)
14
Results (segmentation)
15
Results (segmentation)
16
Results (outliers)
17
Results (epipolar)
18
Results (epipolar)
19
Results
20
Results (putative)
21
Results (segmentation)
22
Results (segmentation)
23
Results (outliers)
24
Results (epipolar)
25
Results (epipolar)
26
Results
27
Results (putative)
28
Results (segmentation)
29
Results (segmentation)
30
Results (outliers)
31
Results (epipolar)
32
Results (epipolar)
33
Results
34
Results (putative)
35
Results (segmentation)
36
Results (segmentation)
37
Results (outliers)
38
Results (epipolar)
39
Results (epipolar)
40
References

• P.H.S. Torr and D.W. Murray. Outlier detection
  and motion segmentation. In P.S. Schenker,
  editor, Sensor Fusion VI, pages 432-443. SPIE
  volume 2059, 1993. Boston.
• P.H.S. Torr. Motion Segmentation and Outlier
  Detection. Ph.D Thesis, Department of Engineering
  Science, University of Oxford, 1995.
