What is VHDL?

• VHDL
• VHSIC Hardware Description Language
• where VHSIC
• Very High Speed Integrated Circuit
• A technology independent, standard language for
• hardware description
• simulation
• synthesis

3
What is VHDL?

• VHDL is a programming language that has been
  designed and optimized for describing the
  behavior of digital systems.
• Syntax is similar to C (actually, more like Ada)
• It is highly typed
• includes a rich set of data types
• Allows concurrent processing
• Not a general purpose programming language

4
History of VHDL Development

• Outgrowth of the DARPA VHSIC Program
• Vendors designing large chips needed to exchange
  data describing their designs
• IBM, Texas Instruments, and Intermetrics got the
  contract in 1983 and released VHDL 7.2 in 1985
• Released to the IEEE for standardization in 1986
• Became IEEE Std 1076-1987
• Reballoted/upgraded to IEEE Std 1076-1993
• Released IEEE Std 1164-1993, STD_LOGIC_1164
• 9-valued logic definition, math functions for
  std_logic

5
Why VHDL?

• It is a Standard
• Data Exchange medium between Vendors
• Communications medium between CAD Tools
• Not Proprietary
• Promotes interoperability and design re-use
• Not technology-specific
• Human-Readable
• Can be used to describe the behavior of a design,
  or to synthesize the design itself
• Supports a wide range of abstraction levels
• Can model a system, board, chip,
  register-transfer-level (RTL), or gate level
  designs

6
VHDL Features

• Supports Hierarchy
• Flexible design methodology Top-down, bottom-up,
  or both
• Has elements to make large-scale design easier
• e.g., components, functions, procedures,
  packages, configuration
• Supports three types of modeling styles
• Behavioral (sequential statement model like a
  program)
• Dataflow (concurrent statement modeling)
• Structural (for connecting components)
• Test Benches can be written in the same language
• circuits can be verified by simulation before
  synthesis
• Propagation delays, min-max delays, setup and
  hold timing, timing constraints, etc. can all be
  described naturally

7
Basic Hardware Design Flow
8
VHDL Design Flow

• 1. Hierarchical / block diagram
• Figuring out the basic approach and building
  blocks at the block-diagram level.
• Large logic designs are usually hierarchical, and
  VHDL gives you a good framework for defining
  modules and their interfaces and filling in the
  details later.
• 2. Coding
• Actual writing of VHDL code for modules, their
  interfaces, and their internal details.

9
Design Flow

• 3. Compilation
• Analyses your code for syntax errors and checks
  it for compatibility with other modules on which
  it relies.
• Compilation also creates the internal information
  that is needed for simulation.
• 4. Simulation
• A VHDL simulator allows you to define and apply
  inputs to your design, and to observe its
  outputs.
• Simulation is part of a larger step called
  verification. A functional verification is
  performed to verify that the circuits logical
  operation works as desired independent of timing
  considerations and gate delays.

10
Design Flow

• 5. Synthesis
• Converting the VHDL description into a set of
  primitives or components that can be assembled in
  the target technology.
• For example, with PLDs or CPLDs, the synthesis
  tool may generate two-level sum-of products
  equations. With ASICs, it may generate a netlist
  that specifies how the gates should be
  interconnected.
• 6. Fitting / Placement Routing
• Maps the synthesized components onto physical
  devices.

11
Design Flow

• 7. Timing verification
• At this stage, the actual circuit delays due to
  wire lengths, electrical loading, and other
  factors are known, so precise timing simulation
  can be performed.
• Study the circuits operation including
  estimated delays, and verify that the setup,
  hold, and other timing requirements for
  sequential devices (like flip-flops) are met.

12
Elements of VHDL

• Syntax (the rules)
• Five design units (or elements)
• Identifiers (naming constraints)
• Data objects (what you name)
• Data types (enumerated, integer, arrays, etc.)
• Examples

13
VHDL Provides Five Design Units

• Entity Declaration
• Specifies the NAME and lists the interface PORTS
• Architecture Body
• Models the actual circuit guts within an entity
• Configuration Declaration
• Identifies which arch. should be used with an
  entity
• Specifies location of components used within
  arch.
• Package Declaration like a header file in C
• Package Body like an implementation file in C
• Packages are libraries containing type
  definitions, overloaded operators, components,
  functions, and procedures. They have a
  declarative section and a BODY section.
  Elements of a Package can be used by many
  entities in a design, or many designs.

14
VHDL Identifiers (Names)

• Basic identifier
• starts with a letter
• made up of letters, numbers, and underscore _
  character
• cannot end with an underscore
• case-insensitive MY_Signal_Name
  my_signal_name
• Extended Identifier
• any text within 2 backslashes
• e.g., \2FOR\ \-23signal\ etc.
• case is significant \COUNT\ not equal to
  \count\, and\FRAMUS\ not equal to basic
  identifier FRAMUS
• Not often used not necessarily supported in
  synthesis !!

15
Four Classes of Data Objects

• Constant
• Holds a single value of a given type cannot
  change.
• Variable
• Holds a single value of a given type.
• New value of same type can be assigned
  (instantly)
• Signal
• Holds a LIST of values of a given type.
• Present value a set of possible future values
• New values can be assigned at some future time
  not now!
• Signals have ATTRIBUTES signalattribute
• File
• Contains a sequence of values of one or more
  types.
• Usually read or written to using procedures
• For simulation not synthesis

16
Data Types

• Scalar Types
• Enumerated a list of values
• Integer
• Floating Point
• Physical with units, for physical quantities
• Composite Types
• Array (all of same type)
• Record (can be different types)
• Access Type
• File Type

17
Enumerated Types

• CHARACTER one of the ASCII set
• BOOLEAN can be FALSE or TRUE
• BIT can be 0 or 1 (note single quotes)
• STD_LOGIC
• Has NINE legal values
• U, X, 0, 1, Z, W, L, H, -
• Example Declarations
• Type CAR_STATE is (back, stop, slow, medium,
  fast)
• Subtype GO_KART is CAR_STATE range stop to
  medium
• Type DIGIT is (0, 1, 2, 3, 4, 5, 6,
  7, 8, 9 )

18
Integers

• All implementations support 32-bit integers, with
  a range of values from (231 1) to (231
  1)
• Integer data types with a smaller rage can be
  defined to save hardware (no sense forcing a
  32-bit counter when you need a 4-bit counter)
• Examples of legal integers
• 56349 6E2 0 98_71_28
• (Underscores can be thrown in anywhere, and dont
  change the value of the number.)

19
Integers

• Type Declarations
• Type INDEX is range 0 to 15
• Type WORD_LENGTH is range 31 downto 0
• Subtype DATA_WORD is WORD_LENTH range 15 downto
  0
• Object Declarations
• Constant MUX_ADDRESS INDEX 5
• Signal DATA_BUS DATA_WORD

20
Arrays

• An Array of type BIT is called a BIT_VECTOR
• signal MYSIG IN BIT_VECTOR( 0 to 3)
• An Array of type STD_LOGIC is called a
  STD_LOGIC_VECTOR
• signal yourSIG OUT BIT_VECTOR( 31 downto 0)
• A STRING is a character array
• csonstant GREETING STRING Hello!

21
VHDL Key Idea

• A key idea in VHDL is to define the interface of
  a hardware module while hiding its internal
  details.
• A VHDL entity is simply a declaration of a
  modules inputs and outputs, i.e., its external
  interface signals or ports.
• A VHDL architecture is a detailed description of
  the modules internal structure or behavior.

22
VHDL Interface - Ports

• You can think of the entity as a wrapper for
  the architecture
• hiding the details of whats inside
• providing ports to other modules

input port
23
VHDL Conceptual Model

• VHDL actually allows you to define multiple
  architectures for a single entity
• it also provides a configuration management
  facility that allows you to specify which
  architecture to use during a particular
  synthesis run

24
VHDL Program File

• In the text file of a VHDL program
• the entity, architecture, and configuration
  declarations are all separated
• not nested as the previous diagram may have
  implied
• We will use white space to set them apart

mydesign.vhd
entity
architecture
configuration
25
Entity Declaration

• Specifies the name of the entity
• Lists the set of interface PORTS
• PORTS are SIGNALS that enter or leave the entity
• This is the black box, or block diagram view

26
Entity Declaration
entity half_adder is port( A, B in BIT SUM,
CARRY out BIT) end half_adder entity
half_adder is port( A, B in BIT SUM
out BIT CARRY out BIT ) end entity
half_adder
White space is ignored
27
Entity Declaration
entity half_adder is port( A, B in BIT SUM,
CARRY out std_logic) end half_adder entity
half_adder is port( A, B in std_logic
SUM out std_logic CARRY out std_logic
) end entity half_adder
Using IEEE 1164 standard signals and data types
28
VHDL Signal Modes

• in means input-ONLY, you cannot use a mode in
  signal on the LEFT side of an equation (that is,
  you cant assign a new value to inputs)
• out means output-ONLY, you cannot use a mode
  out signal on the RIGHT side of an equation (that
  is, you cant use the outputs)
• inout means bi-directional, like a three-state
  bus, for example. This mode is typically used for
  three-state input/output pins on PLDs
• buffer means the signal is an output of the
  entity, and its value can also be read inside the
  entitys architecture

29
Example LogicFcn
30
Entity Declaration for LogicFcn
library IEEE use IEEE.std_logic_1164.all   entit
y LogicFcn is port ( A in std_logic B
in std_logic C in std_logic Y out
std_logic ) end entity LogicFcn
A
B
Y
C
31
Architecture Body

• Specifies the internal circuitry of an entity,
  using any one of the following modeling styles
• As a set of interconnected components, as wired
  (called structural modeling)
• As a set of concurrent signal assignment
  statements (called dataflow modeling)
• As a set of sequential assignment statements,
  i.e., a process (called behavioral modeling)
• As any combination of the above (called mixed
  modeling)

32
Parts of Architecture Body
architecture ARCH_NAME of ENTITY_NAME is
ltdeclarative section list internal signals,
variables, and components here. For each
component used show the port map, (unless
port map defined is in a package)
gt begin ltstatement section all concurrent
statements and components and processes in
this section execute at the same time, NOT
sequentiallygt end ARCH_NAME
33
Architecture Body (Dataflow)
With a signal assignment statement
  architecture dataflow of LogicFcn is begin Y
lt (not A and not B) or C end dataflow
34
Architecture Body (Dataflow)
With a conditional signal assignment statement
  architecture dataflow of LogicFcn is begin Y
lt '1' when (A '0' AND B '0') OR
(C '1') else '0' end dataflow
35
Architecture Body (Behavioral)
architecture behavioral of LogicFcn is begin
fcn process (A,B,C) begin wait on A,B,C
if (A '0' and B '0') then Y lt '1'
elsif C '1' then Y lt '1' else
Y lt '0' end if end process end
behavioral
36
Architecture Body (Structural)
Internal signals are LOCAL to the Architecture,
and cannot be seen outside it !
A
B
Y
C
architecture
entity
37
Architecture Body (Structural)
architecture structural of LogicFcn is signal
notA, notB, andSignal std_logic begin i1
inverter port map (i gt A,
o gt notA) i2 inverter port map (i gt B,
o gt notB) a1 and2 port
map (i1 gt notA, i2 gt
notB, y gt andSignal) o1
or2 port map (i1 gt andSignal,
i2 gt C, y gt Y) end
structural
38
Components for Structural Model
component OR2 port ( i1 in std_logic
i2 in std_logic y out std_logic ) end
component component INVERTER port ( i in
std_logic o out std_logic ) end
component end primitive
library IEEE use IEEE.std_logic_1164.all package
primitive is component AND2 port ( i1 in
std_logic i2 in std_logic y out
std_logic ) end component
these are component declarations
