Title: TDSCDMA


1
TD-SCDMA TD-SCDMA Forum
  • 3rd Meeting of the APT IMT-2000 Forum
  • Sept. 2002

Dr. Li WanLin - Vice Chairman of TD-SCDMA Forum
2
Agenda
  • TD-SCDMA Technology
  • TD-SCDMA Achievement
  • TD-SCDMA Forum

3
IMT - 2000 Family Members
TD-SCDMA is a Full Member of the 3G
Mobile Technologies
UMTS
Standard
Freq. Band
IMT-2000
Core network compatibility
Primary stan-dardisation bodies
TDD
4
TD-SCDMA at a Glance
  • TD-SCDMA is the Solution for TDD Unpaired Bands
  • TD-SCDMA has been adopted by ITU and 3GPP
  • TD-SCDMA has a highly efficient air interface
  • TD-SCDMA is a complete 3G solution macro, micro
    and pico coverage, pedestrian and high mobility
  • TD-SCDMA stand-alone or complement to W-CDMA
  • TDD bands already available in Europe and in Asia
    Pacific
  • TD-SCDMA Field Trials have successfully started
    in Beijing
  • TD-SCDMA enjoys a growing Multivendor Support

5
Worldwide Spectrum Allocation -China is well
prepared for Increased Data Traffic with
additional 100 MHz
1850
1900
1950
2000
2050
2100
2150
2200
2250
2300
2350
2400
2010 MHz
ITU allocations
1885 MHz
2025 MHz
2110 MHz
2170 MHz
Europe
TDD
TDD
1880 MHz
1980 MHz
IMT 2000
MSS
GSM 1800
China
TDD
TDD
Reserved (Unpaired)
1885 MHz
1980 MHz
JapanKorea (w/o PHS)
1895 1918 MHz
MSS Mobile Satellite System
Reserved
MSS
North America
MSS
PCS
A
D
B
E
F
C
A
D
B
E
F
C
2160 MHz
2200
2250
2300
2350
2400
1850
1900
1950
2000
2050
2100
2150
6
What is TD-SCDMA?The Solution for TDD Bands
  • A highly efficient air interface ... the newest
    air interface of 3G
  • ... ideal for asymmetrical data

TD-SCDMA Full integration in IMT-2000 and 3GPP
Release 4
A complete 3G solution ideal for large cells
... as well as dense urban
An ideal solution for China ideal for dense
urban capacity ... and data centric applications
An optimal complement to W-CDMA ideal for
capacity bottlenecks ... Ideal for upcoming data
traffic
7
Key Technologies of TD-SCDMA
  • Time Division Duplex
  • ... allows adaptive allocation of radio resources
  • Code Division Multiple Access
  • ... allows simultaneous multiple user access
  • Joint Detection
  • ... minimizes the interference within a cell
  • Dynamic Channel Allocation
  • ... leads to a reduction of interference by other
    cells
  • Smart Antennas
  • ... further minimizes interference

TD-SCDMA Optimizes the Efficient Use of the
Available Spectrum
8
Smart AntennaSmart Antenna brings Energy only
where it is needed
  • With Smart Antennas ...
  • Power is directed to cell areas of mobile
    subscriber activity only no power spread over
    the whole cell!
  • Terminals are tracked throughout the cell
  • Without Smart Antennas ...
  • Power is distributed over the whole cell
  • For areas without mobile activity no
    interference attenuation is foreseen

9
In China everything is bigger. even the hot
spots!
  • Chinas most important provinceshave a
    significant higher population than European
    Countries
  • High population areas are capacity driven and
    require special solutions for capacity
    enhancements
  • There are higher Peak Population Density Areas in
    China than for example in Germany
  • High population areas are capacity-driven and
    require an efficient use of the available, scarce
    spectrum.
  • Therefore mobile technologies with highest
    spectral efficiency are a must
  • TD-SCDMA perfectly fulfills these requirements

10
Agenda
  • TD-SCDMA Technology
  • TD-SCDMA Achievement
  • TD-SCDMA Forum

11
TD-SCDMA Technology ProgressOn the Right Path
for Market Introduction
Releaseby 3GPP
TD-SCDMAFirst Call (voice)
First Call FTMSby CATT
TD-SCDMAForumFounded
Acceptedby ITU
Completion of MTNet Trial Phase 1
4.01
9.00
3.01
5.01
4.02
2002
2001
2000
1999
12.00
10.01
7.01
TD-SCDMApublishedby CWTS
TD-SCDMAtrial startOct. 01(China)
TD-SCDMAnetworkdeployment
TD-SCDMAFirst Call (video)
SIEMENSMoU withCATT
12
Master Trial goals
  • The main objectives of the TD-SCDMA Master Trial
    are
  • Proving voice services, data services as well as
    large cell size and vehicular speed
  • Proving air interface and Interworking
  • Proving network planning tools
  • Demonstrating TD-SCDMA technology
  • Demonstrating smooth introduction/evolution of 3G
    and the reduced investment risk

13
Air Interface Trial
  • Live video transmission with the following
    Reached
  • Speeds up to 160 km/h
  • Cell range up to 21 km
  • Full load per TS 128 kb/s
  • Public demonstrations in a real city environment.
  • video transmission 16 codes, 8 EFR
    channels
  • NodeB air interface 34dBm, 18dBi sector
    antenna
  • TTD air interface 33dBm , 2dBi omni
    antenna
  • application
  • video
  • web browsing

14
Master Trial The Worlds First Live Complete
TD-SCDMA Network
T-RNC
NodeB 2 at Overseas Student House NodeB 2
The first TD-SCDMA field trial istaking place in
downtown Beijingsince October 2001.
NodeB 3White House Hua Yuan Lu Apartment NodeB
3
954 m
910 m
NodeB 1 at the top of CATT building NodeB 1
860 m
15
Customer Trials Standard TD-SCDMA Trial
Configuration
Uu

NodeB
T-RNC
Abis
Asub
GSM Core Network(Siemens)
FTMS
Abis
Uu
NodeB
TRAU
MSC/ HLR
A
TUP/ISUP
TD1.X
FTMS
PLMN/PSTN
Gb
A
Uu
NodeB
SR8.0
Applications
SGSN/GGSN
FTMS
BSC
Gi
Um
BTS
Abis
Asub
Gb
GR1.1
GSM MS
BR5.5
16
Commercial Handset
  • RTXs handset
  • platform
  • Development of a handset platform
  • Activities started in August 2000
  • Based on proven, available concepts
  • Development of a Layer 1

Source RTX
17
RTX Platform AvailabilityMaximise re-use of
GSM/GPRS platforms is key to success in TD-SCDMA
  • Substantial cost and size saving with respect to
    W-CDMA and cdma2000
  • Test Terminal available in 02
  • Commercial Platform available 2H/03

Source RTX , TD-SCDMA Forum
18
Conclusions
  • TD-SCDMA
  • fulfill market requirements of Users, Operators
    and Chinese demographic distribution
  • handle voice and data traffic transport
    efficiently
  • need few base station sites (esp. in dense
    urban areas)
  • minimize operational effort (such as
    installation and maintenance)
  • have proven cell ranges of 21 km with terminal
    speed of 160 km/h
  • is a breakthrough for the Chinese Industry

19
Agenda
  • TD-SCDMA Technology
  • TD-SCDMA Achievement
  • TD-SCDMA Forum

20
Council of TD-SCDMA Forum
21
Senior Member of TD-SCDMA Forum
22
Organization Chart of the Forum
Executive Organization
Presidium
Council
External Contact Team
Secretariat
Industrialization Promotion Group
Working Group N.N
Marketing Promotion Group
Technology Development Group
23
Forum Members Status
Total Forum Members 392 !
Members Category
24
Activities of the Forum ltcont.gt
  • Foundationconference
  • Date Dec, 12th 2000
  • Venue Beijing,peoples hall

25
Other Events / Activities
26
Web-site of the Forum
http//www.tdscdma-forum.org
27
2002 TD-SCDMA Forum Working Focuses
28
Thank You !
