Bacteria and Archaea: The Prokaryotic Domains

1
Bacteria and ArchaeaThe Prokaryotic Domains
2
Bacteria and Archaea The Prokaryotic Domains

• Why Three Domains?
• General Biology of the Prokaryotes
• Prokaryotes in Their Environments
• Prokaryote Phylogeny and Diversity
• The Bacteria
• The Archaea

3
Why Three Domains?

• Biologists now categorize all life into three
  domains Bacteria, Archaea, and Eukarya.
• Members of all three domains have certain
  characteristics in common
• They conduct glycolysis.
• They replicate their DNA semiconservatively.
• They have DNA that encodes polypeptides.
• They produce polypeptides by transcription and
  translation and use the same genetic code.
• They have plasma membranes and ribosomes.

4
Why Three Domains?

• All three domains had a single common ancestor.
• Present-day Archaea share a more recent common
  ancestor with eukaryotes than they do with
  bacteria.
• The common ancestor of all three domains was
  prokaryotic.
• It likely had a circular chromosome and
  structural genes organized into operons.
• The three domains are products of billions of
  years of natural selection. Prokaryotes were the
  only life-forms for billions of years.

5
Figure 27.2 The Three Domains of the Living World
6
General Biology of the Prokaryotes

• Prokaryotes live all around and even within us.
• Prokaryotes are important to the biosphere
• Some perform key steps in the cycling of
  nitrogen, sulfur, and carbon.
• Some trap energy from the sun and from inorganic
  chemical sources.
• Some help animals digest their food.

7
General Biology of the Prokaryotes

• Prokaryotes are found in every conceivable
  habitat on the planet.
• They live at extremely hot temperatures.
• They can survive extreme alkalinity and
  saltiness.
• Some survive in the presence of oxygen, while
  others survive without it.
• Some live at the bottom of the sea.
• Some live in rocks more than 2 km into Earths
  solid crust.

8
General Biology of the Prokaryotes

• Three shapes are common to prokaryotes spheres,
  rods, and curved or spiral forms.
• Spherical prokaryotes are called cocci (singular
  coccus). Cocci live singly or in two- or
  three-dimensional arrays of chains, plates, or
  blocks.
• Rod-shaped prokaryotes are called bacilli. These
  live in chains or singularly.
• Chains (filaments) and other associations do not
  signify multicellularity because each cell is
  viable independently.

9
Figure 27.3 Shapes of Prokaryotic Cells
10
General Biology of the Prokaryotes

• The prokaryotic cell differs from the eukaryotic
  cell in three important ways
• The DNA of the prokaryotic cell is not organized
  within a membrane-enclosed nucleus.
• Prokaryotes have no membrane-enclosed cytoplasmic
  organelles. Some do have plasma membrane
  infoldings.
• Prokaryotes lack a cytoskeleton and thus do not
  divide by mitosis. Instead, they divide by
  fission after replicating their DNA.

11
General Biology of the Prokaryotes

• Some prokaryotes are motile.
• Some spiral bacteria called spirochetes use a
  rolling motion made possible by modified flagella
  called axial filaments.
• Many cyanobacteria and some other bacteria use a
  gliding mechanism.
• Some aquatic prokaryotes move slowly up and down
  in the water by adjusting the amount of gas in
  gas vesicles.
• The most common type of locomotion is driven by
  flagella.

12
Figure 27.4 Structures Associated with
Prokaryote Motility (Part 1)
13
Figure 27.4 Structures Associated with
Prokaryote Motility (Part 2)
14
General Biology of the Prokaryotes

• Bacterial flagella consist of a single fibril
  made of the protein flagellin projecting from the
  surface, plus a hook and basal body.
• The structure of the bacterial flagellum is
  entirely different from the eukaryotic flagellum.
• In addition, the prokaryotic flagellum rotates
  about its base, rather than beating, as a
  eukaryotic flagellum does.

15
Figure 27.5 Some Bacteria Use Flagella for
Locomotion
16
General Biology of the Prokaryotes

• Most prokaryotes have a thick and stiff cell wall
  containing peptidoglycan.
• Peptidoglycan is unique to bacteria.
• The Gram stain, developed by Hans Christian Gram
  in 1884, separates bacteria into two distinct
  groups based on the nature of their cell walls.

17
General Biology of the Prokaryotes

• In a Gram stain, cells are soaked in violet dye
  and treated with iodine, then washed with alcohol
  and counterstained with safranine.
• Gram-positive bacteria stain violet.
  Gram-negative bacteria stain pink to red.
• Gram-positive cell walls have a thick layer of
  peptidoglycan.
• Gram-negative cell walls have a second membrane
  outside the cell wall, and the cell wall has less
  peptidoglycan.
• The space between the outer membrane and the cell
  wall is called the periplasmic space.

18
Figure 27.6 The Gram Stain and the Bacterial
Cell Wall (Part 1)
19
Figure 27.6 The Gram Stain and the Bacterial
Cell Wall (Part 2)
20
General Biology of the Prokaryotes

• Different features of the cell wall contribute to
  disease-causing characteristics of some
  prokaryotes.
• Many antibiotics act by disrupting cell-wall
  synthesis and tend to have little or no effect on
  eukaryotic cells.

21
General Biology of the Prokaryotes

• Prokaryotes reproduce asexually by fission.
• However, prokaryotes can exchange genetic
  material through transformation, conjugation, and
  transduction.
• Rates of division vary with species
• E. coli divides about once every 20 minutes.
• The shortest known generation time for
  prokaryotes is about 10 minutes.
• Bacteria living deep in Earths crust might not
  divide for as long as 100 years.

22
General Biology of the Prokaryotes

• The long evolutionary history of bacteria and
  archaea has led to a diversity of metabolic
  pathways.
• Obligate anaerobes live only in the absence of
  oxygen. Oxygen is toxic to them.
• Facultative anaerobes can shift between anaerobic
  metabolism (such as fermentation) and the aerobic
  mode (cellular respiration).
• Aerotolerant anaerobes cannot conduct cellular
  respiration, but are not damaged by oxygen when
  it is present.
• Obligate aerobes are unable to survive for
  extended periods in the absence of oxygen.

23
General Biology of the Prokaryotes

• There are four nutritional categories among
  prokaryotes
• Photoautotrophs
• Photoheterotrophs
• Chemoautotrophs
• Chemoheterotrophs

24
General Biology of the Prokaryotes

• Photoautotrophs are photosynthesizers, using
  light for energy and CO2 as a carbon source
• Cyanobacteria use chlorophyll a and produce
  oxygen as a byproduct.
• Other photosynthetic bacteria use
  bacteriochlorophyll and do not produce O2. Some
  use H2S instead of H2O as an electron donor and
  produce particles of pure sulfur.
• Bacteriochlorophyll absorbs longer wavelengths
  than other chlorophylls do. This longer
  wavelength of light penetrates farther into water
  and is not absorbed by plants.

25
Figure 27.7 Bacteriochlorophyll Absorbs
Long-Wavelength Light
26
General Biology of the Prokaryotes

• Photoheterotrophs use light as a source of energy
  but must get carbon from other organisms.
• They use carbohydrates, fatty acids, and alcohols
  for carbon.
• Purple nonsulfur bacteria are photoheterotrophs.

27
General Biology of the Prokaryotes

• Chemolithotrophs obtain energy from oxidizing
  inorganic substances and use some of the energy
  to fix CO2.
• Some use pathways to fix CO2 identical to those
  of the Calvin cycle.
• Others oxidize ammonia, hydrogen gas, hydrogen
  sulfide, sulfur, or methane.
• Some deep-sea ecosystems around thermal vents are
  based on chemolithotrophs, which form the basis
  for a food chain that includes giant worms,
  crabs, and mollusks.

28
General Biology of the Prokaryotes

• Chemoheterotrophs typically obtain energy and
  carbon atoms from one or more organic compounds.
• Most known bacteria and archaea are
  chemoheterotrophs, as are all animals, fungi, and
  many protists.

29
General Biology of the Prokaryotes

• Some bacteria use oxidized inorganic ions, such
  as nitrate, nitrite, or sulfate, as electron
  acceptors.
• Denitrifiers are normally aerobic bacteria,
  mostly Bacillus and Pseudomonas.
• Under anaerobic conditions they use NO3- in place
  of oxygen as an electron acceptor.
• They release nitrogen to the atmosphere as N2 gas.

30
General Biology of the Prokaryotes

• Nitrogen fixers convert atmospheric N2 gas into
  ammonia by means of the following reaction
• N2 6 H 2 NH3
• All organisms require fixed nitrogen for their
  proteins, nucleic acids, and other
  nitrogen-containing compounds.
• Only archaea and bacteria, including some
  cyanobacteria, can fix nitrogen.

31
General Biology of the Prokaryotes

• Bacteria of two genera, Nitrosomonas and
  Nitrosococcus, are nitrifiers, meaning that they
  convert ammonia to nitrite.
• Nitrobacter is a nitrifier that oxidizes nitrite
  to nitrate.
• Chemosynthesis in these bacteria is powered by
  the energy released by the oxidation process.

32
Prokaryotes in Their Environments

• Prokaryotes are important in element cycling.
• Plants depend on prokaryotic nitrogen-fixers for
  their nutrition.
• Denitrifiers prevent accumulation of toxic levels
  of nitrogen in lakes and oceans.
• Cyanobacteria have had a powerful effect on
  changing Earth by generating atmospheric O2.
• The accumulation of O2 in the atmosphere made the
  evolution of more efficient glucose metabolism
  possible and caused the extinction of many
  species that couldnt tolerate oxygen.

33
Prokaryotes in Their Environments

• Archaea help stave off global warming.
• There are ten trillion tons of methane lying deep
  under the ocean floor.
• Archaea present at the bottom of the seas
  metabolize this methane as it rises from its
  deposits, preventing it from hastening global
  warming.

34
Prokaryotes in Their Environments

• Prokaryotes live on and in other organisms
• Mitochondria and chloroplasts are assumed to be
  descendants of free-living bacteria.
• Plants and bacteria form cooperative
  nitrogen-fixing nodules on the plant roots.
• The tsetse fly obtains the vitamins needed for
  reproduction from a bacterium living inside its
  cells.
• Cows depend on prokaryotes in their digestive
  tract to digest cellulose.
• Humans use vitamins B12 and K produced by our
  intestinal bacteria.

35
Prokaryotes in Their Environments

• Kochs postulates, or rules, for determining that
  a particular microorganism causes a particular
  disease
• The microorganism must always be found in
  individuals with the disease.
• The microorganism can be taken from the host and
  grown in pure culture.
• A sample of the culture produces the disease when
  injected into a new, healthy host.
• The newly infected host yields a new, pure
  culture of microorganisms.

36
Prokaryotes in Their Environments

• Only a tiny proportion of prokaryotic species are
  pathogens. All known prokaryotic pathogens are
  Bacteria (not Archaea).
• For an organism to be a pathogen, it must
• Arrive at the body surface.
• Enter the body.
• Evade detection and defenses.
• Multiply inside the host.
• Infect new hosts.

37
Prokaryotes in Their Environments

• For the host, the seriousness of the infection
  depends on the invasiveness and the toxigenicity
  of the pathogen.
• Corynebacterium diphtheriae, the agent that
  causes diphtheria, has low invasiveness but
  produces powerful toxins.
• Bacillus anthracis, which causes anthrax, has low
  toxigenicity, but is so invasive that the
  bloodstream of infected animals teems with
  organisms.

38
Prokaryotes in Their Environments

• There are two major types of toxins
• Endotoxins, such those produced by Salmonella and
  Escherichia are lipopolysaccharides from the
  outer membrane of Gram-negative bacteria. They
  are released when the bacteria grow or lyse.
• Exotoxins, which are produced and released by
  living, multiplying bacteria, can be highly
  toxic, even fatal.
• Tetanus, botulism, cholera, and plague are all
  examples of exotoxins.

39
Prokaryotes in Their Environments

• Many unicellular microorganisms, prokaryotes in
  particular, form dense films called biofilms.
• The cells lay down a gel-like polysaccharide
  matrix when they contact a solid surface.This
  matrix traps other bacteria, forming a biofilm.
• Biofilms can make bacteria difficult to kill.
  Pathogenic bacteria may form a film that is
  impermeable to antibiotics, for example.
• Biofilms can form on just about any available
  surface and are the object of much current
  research.

40
Prokaryote Phylogeny and Diversity

• Classification schemes are used to help identify
  unknown organisms, reveal evolutionary
  relationships, and provide names for organisms.
• In the past, phenotypic characters such as color,
  shape, antibiotic resistance, and staining were
  used to classify prokaryotes.
• Now, nucleic acid sequencing is providing clues
  to evolutionary relationships.

41
Prokaryote Phylogeny and Diversity

• Ribosomal RNA (rRNA) is particularly useful for
  evolutionary studies for several reasons
• rRNA is evolutionarily ancient.
• All organisms have rRNA.
• rRNA functions the same way in all organisms.
• rRNA changes slowly enough that sequence
  similarities between groups of organisms are
  easily found.

42
Prokaryote Phylogeny and Diversity

• Lateral gene transfer among bacteria of different
  species has complicated the use of sequencing
  information for determining the evolutionary
  relationships of bacteria.
• There is currently great controversy over
  prokaryotic phylogeny.

43
Figure 27.8 Two Domains A Brief Overview
44
Prokaryote Phylogeny and Diversity

• Mutations are a major source of prokaryotic
  variation.
• The rapid multiplication of many
  prokaryotesalong with mutation, selection, and
  genetic driftcauses rapid changes.
• Important changes, such as acquired resistance to
  antibiotics, can occur broadly in just a few
  years.

45
The Bacteria

• The most well-studied prokaryotes are the
  bacteria.
• Focus will be on five groups the proteobacteria,
  cyanobacteria, spirochetes, chlamydias, and
  firmicutes.
• Three of the bacterial groups that may have
  branched out earliest are thermophiles.

46
The Bacteria

• The proteobacteria, or purple bacteria, make up
  the largest group in terms of the number of
  species.
• Some are Gram-negative, bacteriochlorophyll-contai
  ning, and sulfur-using photoautotrophs. However,
  others have dramatically different phenotypes.
• The mitochondria of eukaryotes were derived from
  proteobacteria by endosymbiosis.

47
The Bacteria

• The common ancestor to all proteobacteria was
  probably a photoautotroph.
• Early in evolutionary history, two of the five
  proteobacteria groups lost the ability to
  photosynthesize and became chemoheterotrophs.
• There also are some chemolithotrophs and
  chemoheterotrophs in all three of the other
  groups.
• Some fix nitrogen (Rhizobium) and some help cycle
  nitrogen and sulfur.

48
Figure 27.9 The Evolution of Metabolism in the
Proteobacteria
49
The Bacteria

• Cyanobacteria (blue-green bacteria) are
  photoautotrophs.
• They use chlorophyll a for photosynthesis and
  release O2. Their photosynthesis was the basis of
  the transformation of Earths atmosphere.
• Cyanobacteria have highly organized internal
  membranes called photosynthetic lamellae or
  thylakoids.
• Chloroplasts are derived from an endosymbiotic
  cyanobacterium.
• Some filamentous colonies differentiate into
  three cell types vegetative cells, spores, and
  heterocysts (specialized for nitrogen fixation).

50
Figure 27.11 Cyanobacteria (Part 1)
51
Figure 27.11 Cyanobacteria (Part 2)
52
The Bacteria

• Spirochetes are Gram-negative bacteria with axial
  filaments, which are fibrils running through the
  periplasmic space.
• The cell body is a long cylinder coiled into a
  spiral.
• Many spirochetes live in humans as parasites. A
  few are pathogens (e.g., those that cause
  syphilis and Lyme disease). Others live free in
  mud or water.

53
Figure 27.12 A Spirochete
54
The Bacteria

• Chlamydias are Gram-negative intracellular
  parasites that are among the smallest bacteria.
• Their life cycle involves two different forms of
  cells elementary bodies and reticulate bodies.
• In humans, they cause eye infections, sexually
  transmitted disease, and some forms of pneumonia.

55
Figure 27.13 Chlamydias Change Form during Their
Life Cycle
56
The Bacteria

• Most firmicutes are Gram-positive, but some are
  Gram-negative, and some have no cell wall at all.

• When a key nutrient becomes scarce, some produce
  endospores, which are heat-resistant resting
  structures.
• The bacterium replicates its DNA and encapsulates
  one copy in a tough cell wall, thickened with
  peptidoglycan and covered with a spore coat.
• The parent cell then breaks down, releasing the
  endospore.
• Some endospores can be reactivated after more
  than a thousand years of dormancy.

57
Figure 27.14 The Endospore A Structure for
Waiting Out Bad Times
58
Figure 27.15 Gram-Positive Firmicutes
59
The Bacteria

• Actinomycetes are firmicutes that develop an
  elaborately branched system of filaments.
• Some reproduce by forming chains of spores at the
  tips of filaments.
• In others, the filamentous growth ceases and the
  structure breaks up into typical cocci or
  bacilli, which then reproduce by fission.
• Mycobacterium tuberculosis is an actinomycete.
• Most of our antibiotics are derived from
  actinomycetes. Streptomyces produces the
  antibiotic streptomycin, as well as hundreds of
  other antibiotics.

60
Figure 27.16 Filaments of an Actinomycetes
61
The Bacteria

• Mycoplasmas lack cell walls, are the smallest
  bacteria (some have a diameter of 0.2 µm), and
  have the least amount of DNA.
• They may have the minimum amount of DNA necessary
  to code for the essential properties of a living
  cell.

62
Figure 27.17 The Tiniest Living Cells
63
The Archaea

• The study of Archaea is still in its very early
  stages.
• It is possible that the domain Archaea is
  paraphyletic.
• Most archaea live in environments that are
  extreme in one way or another temperature,
  salinity, oxygen concentration, or pH.
• There are two groups of Archaea Euryarchaeota
  and Crenarchaeota.

64
The Archaea

• The Archaea lack peptidoglycan in their cell
  walls and have distinctive lipids in their cell
  membranes.
• When biologists sequenced the first archaean
  genome, more than half of its 1,738 genes were
  unlike any found in the other two domains.
• The unusual lipids in the membranes of archaea
  are long fatty acids bonded to glycerol via an
  ether linkage, as opposed to the ester linkage
  found in other organisms.

65
Figure 27.18 Membrane Architecture in Archaea
66
The Archaea

• Most Crenarchaeota are both thermophilic and
  acidophilic.
• Members of the genus Sulfolobus live in hot
  sulfur springs at temperatures of 7075ºC and die
  at 55º C (131ºF).
• They grow best at pH 2pH 3 but can survive pH
  0.9.

67
Figure 27.19 Some Would Call It Hell Archaea
Call It Home
68
The Archaea

• Some species of Euryarchaeota are methanogens,
  producing methane (CH4) from CO2.
• All methanogens are obligate anaerobes.
• Methanogens release approximately 2 billion tons
  of methane gas into Earths atmosphere. About
  one-third of this comes from methanogens in the
  guts of grazing herbivores.
• Methanopyrus lives on the ocean bottom near
  volcanic vents and can live at 110ºC.

69
The Archaea

• Some Euryarchaeota, called extreme halophiles,
  live exclusively in very salty environments such
  as the Dead Sea or in pickle brine.
• Some of these organisms survive a pH of 11.5.
• Some of the extreme halophiles use the pigment
  retinol combined with a protein to form the
  light-absorbing molecule bacteriorhodopsin, and
  make ATP using a chemiosmotic mechanism.

70
Figure 27.20 Extreme Halophiles
71
The Archaea

• Thermoplasma is thermophilic and acidophilic it
  has no cell wall, an aerobic metabolism, and
  lives in coal deposits.
• It has the smallest genome (1,100,000 base pairs)
  of the archaea.
