Title: Introduction: What is Chemical Biology


1
IntroductionWhat is Chemical Biology?
English presentation skills seminars in chemical
biology
2
Chemical Biology is
  • Chemical Biology seeks to develop new tools based
    on small molecules that allow minimal
    perturbation of biological systems while
    providing detailed information about their
    function.

3
Why small moleculesif you can make knock-out
mice?
  • Perturb protein function at given timepoint
  • Temporal control
  • No compensation effects
  • Allows study of lethal knock-outs
  • Lead compound for drug development

4
Overview
  • Small molecule screens looking for targets
  • Proteomics identifying targets
  • Probe design for enzymes smart targeting
  • Imaging techniques visualizing targets

5
Forward chemical genetics
  • Libraries collection of small molecules
  • Chemicals as mutagens
  • Looking for phenotypes
  • Easy readout
  • High throughput (96-well, 384-well)

6
Screening sifting
  • Be aware of
  • False positives
  • False negatives
  • Often several selectivity-filters
  • 2nd or 3rd screen lower throughput

7
Example
8
Goal
  • Get to know more about mitosis
  • Only known small molecule inhibitors
  • target tubulin

Taxol
Vinblastine
Green tubulin Blue chromatin
9
Screening
  • 1st screen cytoblot assay
  • Detects post-translational modification
  • in whole cells
  • Low volumes (µl-nl)

10
Cytoblot
  • Culture cells in 384, 1536- or 6144-well plates
  • Incubate with library compounds/controls
  • Fix detect by antibody-HRP conjugate

Stockwell, Schreiber, Chem. Biol. 1999
11
Screening for mitotic arrest
  • Use antibody against Phospho-Nucleolin
  • 139 of 16320 compounds show increase

12
Second screen in vitro tubulin polymerization
  • Why? We dont want tubulin-targeting molecules
  • 86 show no effect

13
Third screen fluorescent microscopy
  • 86 compounds
  • 27 no effect -gt false positives
  • 42 effects in interphase mitosis
  • 5 only affect mitosis

14
One interesting compound Monastrol
  • Result no spindle bipolarity
  • Eg5 (a kinesin motor protein)
  • involved in separation of
  • centrosomes
  • Not a general kinesin inhibitor
  • organel localization normal

15
Overview
  • Small molecule screens looking for targets
  • Proteomics identifying targets
  • Probe design for enzymes smart targeting
  • Imaging techniques visualizing targets

16
Use small molecule as fishing hook
  • Non-covalent binding to protein
  • Make affinity-resin

Leslie, Hergenrother, Chem. Soc. Rev. 2008,
1347-60
17
Enriching for your target
  • Incubate with cell lysate/tissue homogenate
  • Wash to eliminate non-binding proteins
  • Elute
  • Denature
  • Add free ligand

18
Use small molecule as fishing hook
  • Covalent binding to protein

Affinity Matrix
Biotinylated molecule
19
Streptavidin-mediated enrichment
  • Streptavidin-Biotin
  • KD 10-15 mol/L
  • ? Efficient enrichment of
  • diluted proteins

20
Identify targets by Mass Spectrometry
21
Tandem Mass Spectrometry
  • Ionize fragment tryptic peptides
  • Algorithm can assign
  • peptide sequence search
  • database

22
Overview
  • Small molecule screens looking for targets
  • Proteomics identifying targets
  • Probe design for enzymes smart targeting
  • Imaging techniques visualizing targets

23
Activity-based Proteomics
  • Use enzyme mechanism gt covalent tagging
  • Proteases nucleophile in active site

24
Activity-based probes
  • Covalent inhibitors with a tag

Cravatt et al., PNAS 1999, Bogyo et al., Chem
Biol. 2000
25
Covalent modification of active site
  • Only with active enzyme

26
Profiling of protease activity
  • Profiling of Protease Activity

Mouse Pancreatic Cancer Model Cathepsin
activities upregulated
Joyce et al., Cancer Cell 2004
27
When its hard to get selectivity
  • Kinases 491 kinase domains in human genome
  • most drugs target ATP binding site
  • 20 of kinases have small Thr- gatekeeper

Cohen, M. S, Taunton, J et al., Science 2005,
308, 1318
28
Look for a second selectivity filter
  • Cysteine in flexible loop in 11 kinases

29
Inhibit specific kinases
  • RSK2 has both Thr and Cys

Detection autophosphorylation of RSK2
  • Mutating MSK1 gatekeeper sensitization

30
Overview
  • Small molecule screens looking for targets
  • Proteomics identifying targets
  • Probe design for enzymes smart targeting
  • Imaging techniques visualizing targets

31
Why imaging?
  • Protein localization
  • Detection of pathologies in vivo
  • Most common GFP and derivatives
  • Different colors available
  • Large protein
  • Alternatives
  • Target small peptide sequences (modified protein)
  • Target certain activity

32
Targeting modified proteins
Protein Tag
Peptide Tag
Enzyme mediated Tag
Unnatural amino acid
Chen et al. 2005 Curr. Opin. Biotech. 16, 35-40
33
Peptide tags
  • Chemical fluorophores
  • FlAsH
  • (a ton more)
  • FlAsH
  • Tight binding
  • Multiple colors

Tsien et al. 2000 Methods Enzymol.
34
FlAsH application
  • Study dynamic structures
  • Gap junction plaques
  • Small molecule signaling between cells
  • Half life lt5 hours
  • Tetracysteine tag on Connexin43

Tsien, Ellisman et al., Science 2002
35
Enzyme mediated tags
  • Enzymatically linking a fluorophore
  • Trans-glutaminase
  • Biotin ligase

Lin et al. 2006 JACS 128, 4542-4543
36
Target certain activity
  • Activity-based probe mediated imaging
  • Clan CA proteases in Pancreatic cancer

Normal islets
Angiogenic islets
Tumors
37
Is this all?
  • Carbohydrate detection
  • Detection of other post-translational
    modifications
  • Probes to monitor Ca2 or other metals
