Dynamic networks

1
Dynamic networks clathrin-mediated
endocytosis
Eva Schmid (LMB Cambridge)
Gerrit Praefcke (now at Cologne)
Marijn Ford (now at UC Davis)
2
What is a Hub? Are they static? Why have them?
3
At the synapse speed and fidelity are important
to ensure the quantal nature and reliability of
synaptic vesicle exocytosis
speed
fidelity

4
Fidelity?
What is
Exo
Endo
5
Clathrin-mediated endocytosis
The overall process is a series of linear steps
but at the same time it is a series of
simultaneous micro-reactions (e.g. cargo
recruitment, membrane invagination and coat
assembly occurring in parallel)
6
Clathrin-mediated endocytosis
The overall process is a series of linear steps
but at the same time it is a series of
simultaneous micro-reactions (e.g. cargo
recruitment, membrane invagination and coat
assembly occurring in parallel)
7
Clathrin-mediated endocytosis
The overall process is a series of linear steps
but at the same time it is a series of
simultaneous micro-reactions (e.g. cargo
recruitment, membrane invagination and coat
assembly occurring in parallel) Involving
clathrin, adaptors (AP2) and at least 20
different accessory proteins
8
The endocytic interactome
Accessory Proteins
(over 20 different proteins bind to the AP2
a-appendage)
Hubs
9
The AP2 hub binds to accessory proteins via it
appendage domains
10
The a-appendage two independent binding sites
W840
Top Site
Peptide containing an FxDxF motif Binds with an
affinity of 4.6mM
F740
Side Site
Peptide containing a WVxF motif Binds with an
affinity of 0.7mM
11
Endocytic accessory proteins have a similar
overall structure
Structured domains

• Proteinprotein interaction domains
• with no obvious tertiary structure
• Contain multiple motifs, short amino acid
  sequences,
• Please dont call them unstructured domains as
  they may have some secondary structure!!

Motif domains
Epsin
12
Motif domains
Structured domains
AP2 a-motifs
13
Eps15 affinity for the a-appendage
Eps15 Motif Domain
14
Eps15 affinity for the a-appendage
contains 15 repeats of the sequence DPF
15
Eps15 affinity for the a-appendage

2-3 sites of 16mM
1 site of 20nM
So not all 15 motifs are available for
simultaneous interactions
16
Eps15 affinity for the a-appendage
2-3 sites of 16mM
1 site of 20nM
16mM
16mM
16mM
20nM

• From mutagenesis we know that the 20nM affinity
  is due to occupation of both top and side sites
  of one appendage
• Thus this is a novel way to gain high affinity
  yet a readily reversible interaction ie. 2
  linear peptides linked by a flexible linker

17
Eps15 affinity for the a-appendage
2-3 sites of 16mM
1 site of 20nM

• Eps15 with its simultaneous interactions with 4
  appendage domains could help to cluster AP2s at
  sites of endocytosis

18
Motif domains are not unstructured and linear
But neither are they stable globular
domains. They are designed to package motifs in
an efficient manner, such that when one motif is
occupied then further motifs are exposed
Motif
Motif domain
a-appen- dage
structural cooperativity in motif binding
19
This low structural stability means that these
motif domains can search a wide range of space
for potential ligands
20
This low structural stability means that these
motif domains can search a wide range of space
for potential ligands
Like a fishing line with lots of hooks
But for entropic and statistical reasons the
domain will prefer a more compact fold And thus
the hooks will gather ligands back to the core
folded domains
21
Motifdomain interactions

• A novel way to gain relatively high affinity and
  yet reversibility
• Give rise to dynamic instability (a necessary
  characteristic of many cellular processes)
• Allow cross-linking/multimerisation of binding
  targets
• Efficient packaging of many different
  interactions surfaces
• Multiple interactions that filter noise
• A way to search space and draw ligands to a point

22
The network behaviour makes sense..

• Clathrin is an organising hub, not a protein
  recruitment hub. This ensures that empty clathrin
  cages do not form in the absence of membranes and
  cargo
• AP2 does not self assemble, and only weakly binds
  to cargo. This ensures that cargo recruitment,
  membrane bending and polymerisation are tightly
  coupled.

23
Properties of endocytic and other biological
networks
(feed forward and competitive loops)
Noise reduction Low affinity interactions ensure
that processes are only activated on coincidence
of several signals Information processing The
multimeric state of the AP2 hub allows it to bind
multiple ligands according to their relative
affinities and concentrations. Thus the hub
integrates information. The competition between
AP2 and clathrin also means that there is a
sensing of the commitment along the endocytic
pathway (the process gestalts).
24
Building the network around AP2.
25
There are 4 potential ligand interaction sites on
each AP2 complex
26
Thus 4 potential ligand interaction sites on each
AP2 complex. Does this make it a HUB?
27
Thus 4 potential ligand interaction sites on each
AP2 complex. Does this make it a HUB? No
28
It is the concentration of AP2s on the membrane
that gives it the ability to bind multiple
partners according to affinities and
concentrations
AP2 hub zone
29
Changing hubs gives directionality
Recruitment of AP2 to membrane and concentration
Clathrin polymerisation
30
The clathrin hub
Miele et al 2004 Ter Haar et al 2002
b3 adaptor hinge LLDLD
Amph WxxW
31
Changing hubs gives directionality
Recruitment of AP2 to membrane and concentration
Clathrin polymerisation

• Only on self-polymerisation does clathrin become
  a hub

32
Clathrin binding to the b -appendage displaces
ligands, pushing accessory proteins to the edge
of a clathrin-coated pit (appendage assembly
zones)
Clathrin
b -appendage
33
Clathrin binding to the b -appendage displaces
ligands, pushing accessory proteins to the edge
of a clathrin-coated pit (appendage assembly
zones)
Clathrin terminal domain
34
Clathrin binding to the b -appendage displaces
ligands, pushing accessory proteins to the edge
of a clathrin-coated pit (appendage assembly
zones)
35
Clathrin binding to the b -appendage displaces
ligands, pushing accessory proteins to the edge
of a clathrin-coated pit (appendage assembly
zones)
36
How clathrin-coated pits mature
affinity
avidity
matricity

• Sequential displacement of core and accessory
  proteins (affinity matures to avidity matures to
  matricity)
• The process is pulled forward from the end

37
How clathrin-coated pits mature
affinity
avidity
matricity
38
How clathrin-coated pits mature
ATP GTP

• Sequential displacement of core and accessory
  proteins (affinity matures to avidity matures to
  matricity)
• The process is pulled forward from the end

39
A Network view of clathrin-coated vesicle
formation
A AP2 adaptors sense lipids, cargo, accessory
proteins and other cargo adaptors
AP2
40
B Building the cage AP2 network hub is
stabilized through crosslinking by accessory
proteins
AP2
41
C Clathrin is recruited and polymerisation
stabilises the forming vesicle. AP2 loses its
position as a hub. Clathrin is the
new organising hub
AP2
42
D Dynamin and other late interacting partners
(like uncoating factors) start to function The
point of no return.
AP2
43
E Energy is used to re-prime the system for a new
start.
AP2
44
Changing hubs gives directionality
Recruitment of AP2 to membrane and concentration
Clathrin polymerisation

• Only on self-polymerisation does clathrin become
  a hub
• Note in a clathrin-coated pit one has a
  snap-shot of the network at several different
  stages

45
AP2 hubs and clathrin hubs co-exist at the same
time, but spatially separated
46
In a coated-pit there may even be the beginning
stages of uncoating, as the lipid phosphatase
begins to work under the clathrin lattice
47
This means that fluorescent imaging will
frequently not have the resolution to deduce the
time dependence of recruitment
48
But we can deduce this information from the
path-length in the network
49
Early and late events can be predicted
Time
1
2
Cage formation
3
Vesicle scission
3
Uncoating and repriming of molecules

• A short path-length gives an immediate response
• To put a time delay in the response an additional
  interaction step is added

50
This view maintains that Overexpression of a
pathway hub will have little phenotype Underexpre
ssion of a pathway hub will have a major
phenotype Overexpression of an accessory node
will have a major phenotype Underexpression of
an accessory node will have little phenotype
Hubs
