Title: BP2110: Whats New in SonicMQ V5.0


1
BP2110Whats New in SonicMQ V5.0
  • Dave Chappell
  • mailtochappell_at_sonicsoftware.com
  • Vice President Chief Technology Evangelist
  • Technology Advancement Group

2
Agenda
  • Messaging Review
  • Clustering in SonicMQ CWADS CWAQS
  • Dynamic Routing Architecture
  • Security
  • Management
  • HTTP Direct
  • Performance
  • Flow Control

3
What is Messaging For?
  • In support of distributed computing
  • Communicating events
  • Making requests
  • Most typically for integration
  • Where a business process is realised by multiple
    applications
  • Creating an application out of components
  • Monitoring equipment on a network
  • Front ending RPC systems

4
RPC-based Solution
Point-to-Point Integration
Data A
Data B
Data C
Data D
Data E
?
Application A
Application B
Application C
Application D
Application E
?
API A
API B
API C
API D
API E
  • Each application must understand all other APIs
    and how to locate/call them across the network
  • n(n-1)/2 up to 10 interfaces!
  • If one application changes or breaks, others will
    be affected

5
Message-Oriented Middleware (MOM)
Robust, Loosely-Coupled
Data A
Data B
Data C
Data D
Data E
Application B
Application A
Application C
Application D
Application E
Message i/f
Message i/f
Message i/f
Message i/f
Message i/f
Messaging Backbone
  • Able to cope with API changes
  • n 5 interfaces
  • Continues to operate if one component dies

6
SonicMQ at Work
Multi-National Bank
Middle Office
Back Office
Internal External Users
Front Office
Web Browser
Derivatives Presentation / Trading
Client Application
Firewall
SonicMQ Messaging Backbone
7
What Makes SonicMQ Different?
  • Manageability
  • Addresses cost of ownership
  • Scalability
  • Single broker
  • Clusters
  • Communities of clusters
  • Performance
  • Security
  • More secure
  • Few CPU cycles
  • Better integration with 3rd party products

8
The Programming Model
  • Picture of JMS objects
  • Followed by code

JMS Client
JMS Client
Connection
Connection
Message Broker
Session
Message
Message
Session
Destination eg Queue1
Consumer
Producer
9
Hello World
  • TopicConnection conn conFactory.createTopicConne
    ction(username,password)
  • TopicSession pubSession conn.createTopicSession(f
    alse, Session.AUTO_ACKNOWLEDGE)
  • TopicSession subSession connection.createTopicSe
    ssion(false,

  • Session.AUTO_ACKNOWLEDGE)
  • TopicPublisher publisher pubSession.createPubli
    sher(chatTopic)
  • TextMessage message pubSession.createTextMessage
    ()
  • message.setText(Hello world)
  • publisher.publish(message)

10
Message Types
11
Queues vs Topics
  • Queues
  • One message goes to one consumer
  • Point to point conversation between 2 parties
  • Or workflow with many parties
  • Topics
  • One messages goes to many subscribers
  • Typically publishers and subscribers are very
    decoupled
  • Fire and forget
  • Or, point to point plus audit

12
Qualities of Service
  • Discardable
  • Non-persistent async
  • Non-persistent
  • Persistent
  • Durable
  • Locally Transacted
  • Distributed Transacted

13
Guaranteed Delivery
Ensures Reliable Messaging
Publisher
Subscriber
SonicMQBroker
Inventory
Retail
2-Disconnect
7-Publish() method returns
RecoveryLog
5-Message retained in persistent store
14
Anatomy of a Broker


SonicMQ Broker

Producer

TCP/IP

As necessary,

Consumer






Check permissions

send()

TCP/IP


Producer




Log

process





Deliver to clients

send()



Buffer for slow clients

process

send()



Buffer for disconnected




Recovery Log
Database
15
Agenda
  • Messaging Review
  • Clustering in SonicMQ CWADS CWAQS
  • Dynamic Routing Architecture
  • Security
  • Management
  • HTTP Direct
  • Performance
  • Flow Control

16
Clusters
  • The challenge
  • When I reach the scalability limits of a single
    broker how do I add in more capacity
  • How do I ensure that each broker is contributing
    equally
  • How do ensure that it is completely transparent
    to clients
  • Destinations, durable subscriptions,
    authorization, authentication
  • Can I add capacity dynamically with no impact to
    cluster or clients

Broker 1
Broker 3
Broker 2
17
Load Balancing and Failover
  • Clusters have recognized entry points
  • Stored in connection factory
  • Multiple entry points for failover purposes
  • The entry points then redirect connections to
    another broker in the cluster
  • Ability to weight brokers so that the algorithm
    is not purely round robin

Broker 1
Broker 2
Broker 3
18
Cluster Wide Queues
Queue Receivers
  • Clustered Queues are defined on the cluster
    rather than a broker
  • Both senders and receivers can be load balanced
    across the cluster
  • If a broker fails the rest of the queues
    contents are available

Broker 1
Broker 3
Broker 2
Queue Senders
19
Cluster Wide Queues
  • New Option when Creating the Queue
  • Management Console
  • Configure Queue on the Cluster (not on the
    Broker)
  • One configuration definition ? applied to each
    broker as it joins cluster
  • same name/size/properties for all instances
  • Fragment of each Clustered Queue is created on
    every broker in the cluster
  • Total state of the queue is federated across the
    fragments
  • Senders and receivers manipulate messages in
    Queue fragment on broker they are connected to
  • Should a receiver empty his local queue fragment
    messages are pulled from other fragments

20
Cluster Wide Durable Subscriptions
Durable Subscribers
  • Adds the ability to subscribe to messages
    regardless of which broker the client is
    connected to
  • Allows use of load balancing when reconnecting to
    the cluster
  • If a broker fails the rest of the subscriptions
    contents are available

Broker 1
Broker 3
Broker 2
Topic Publishers
21
Group Subscriptions
Subscriber Pool A
  • One slow subscriber can slow down the performance
    for all subscribers
  • One solution is to add in more clients to process
    the subscription
  • Allow a single subscription to be shared by a
    group of clients
  • Stream of messages for subscription is divided up
    amongst the clients
  • Used to allow load sharing for a single
    subscription

Subscriber A
Subscriber A
Subscriber A
Publisher
Topic X
Subscriber B
Subscriber C
22
Syntax
  • Create Topic name with Group Prefix
  • group-prefixTopic-name
  • Topic Object
  • Can be stored in JNDI
  • Old Clients can subscribe to this topic
  • No non-JMS API calls
  • Therefore works with App Servers
  • Cannot Publish to this topic
  • ACLs / QoP based only on Topic-name

23
Agenda
  • Messaging Review
  • Clustering in SonicMQ CWADS CWAQS
  • Dynamic Routing Architecture
  • Security
  • Management
  • HTTP Direct
  • Performance
  • Flow Control

24
Dynamic Routing Architecture - DRA
  • The challenge how do I scale beyond a single
    cluster?
  • The cluster is getting too big, or
  • I need to extend outside my organization
  • Departments, sites, subsidiaries, business
    partners
  • Need a loosely coupled solution
  • Connections
  • Security domain
  • Solution is the ability to link clusters together
    into more complex topologies

25
DRA and Connections
Broker 4
Broker 1
Broker63
Broker 5
Broker 3
Broker 2
  • Choice of outgoing broker
  • Choice of load balancing incoming broker
  • Messaging pending transfer in routing queue
  • Connections on demand
  • Disconnected when idle
  • Routing User for incoming connection

26
DRA Flavor 1 Directed Sends
  • Directed sending for Queues and Topics
  • Use NODEDestination syntax
  • Sender directs a send to a different Node
  • DRA Connection acts as a on-demand proxy
    connection
  • Not delivered to clients on sending node
  • Behavior
  • Send / Publish (NodeTopic) puts message in
    Routing Queue
  • Routing Connection triggered by message
  • Delivered broker-to-broker

27
Flavor 2 - Global Subscriptions
  • A very flexible extension to the existing
    clustering of topics
  • Administrators specify how subscriptions are
    propagated
  • Table of topic / node maps
  • Can use wildcards for topic names
  • Publishers are completely unaware of who is
    subscribed
  • Message makes its way across routing connection
    to remote subscriber
  • Multi-hop delivery can be configured

Topic A publisher
Topic A subscriber
Cluster 1
Topic A subscriber
Cluster 2
Topic A subscriber
Cluster 3
28
GSA Multi-node Diagram
29
Agenda
  • Messaging Review
  • Clustering in SonicMQ CWADS CWAQS
  • Dynamic Routing Architecture
  • Security
  • Management
  • HTTP Direct
  • Performance
  • Flow Control

30
Comprehensive Security
Flexible Deployment Options
  • Encryption
  • Built-in payload encryption
  • Secure messaging without performance cost of SSL
  • Channel encryption
  • SSL with up to 256-bit keys
  • Authentication
  • Built-in username/password authentication
  • Supports digital certificates for user
    authentication
  • Authorization
  • Specify rights of authenticated users
  • Exploit destination hierarchies and groups of
    users to simplify administration

31
Pluggable Authentication
  • At the client
  • A plug-in capability to insert whatever
    authentication technology you want
  • User / password, operating system login,
    thumbprint, iris scan,
  • Uses an open standard - JAAS
  • In authentication stacks if appropriate
  • Will allow integration with Single Signon,
    operating system sign on, 3rd party products, etc
  • At the server
  • 5.0 will add integration with external LDAP store
    of principals
  • Will require a small amount of configuration via
    PSO
  • Other stores or schemas through PSO

SonicMQ Client
JAAS Plugin
Credentials
Connect
Broker
SPI
Credentials
Login
LDAP Security Repository
32
Agenda
  • Messaging Review
  • Clustering in SonicMQ CWADS CWAQS
  • Dynamic Routing Architecture
  • Security
  • Management
  • HTTP Direct
  • Performance
  • Flow Control

33
Driving down the TCO
Cluster 1
Cluster 2
100 Clustered Queues 1000 Topics across both
clusters5000 Users in 100 groups Deployed on
single- processor Intel boxes
Broker 1
Broker 2
Broker 3
Broker 4
  • 8 Capacity Units WebSphere MQ _at_ 2,250
  • 4 Capacity Units Event Brokers _at_ 22,500
  • 4 PCs _at_ 2000
  • 0.5 Administrator _at_ 50,000 / year
  • 4 Enterprise Plus _at_ 7,500
  • 4 PCs _at_ 2000
  • No Administrator166,000 vs 38,000

34
How Do We Achieve This?
  • Tools
  • Boost productivity with new management tools
  • 1st rate infrastructure
  • Underpin new tools with a robust infrastructure
  • Dynamic discovery vs static configuration
  • Automate much of the configuration work
  • Use of Open Standards
  • JMX for management
  • Underpinned by SonicMQ for transport

35
Managing Clusters
Broker 1
Directory Storage
JMS Agent
Directory Service
Mgmt Broker
Cluster
Domain Manager
36
Management Console - Configure
  • Create / edit configuration of brokers
  • No more broker.ini
  • Create configuration templates which are reused
    many times
  • All configuration data written to the Directory
    Service
  • Also pushed out to broker and cached locally

37
Management Console - Manage
  • Perform lifecycle operations
  • Start / Stop
  • Reload
  • Schedule start / stop
  • View Metrics / Notifications
  • The health of brokers can be monitored remotely
  • What are they?
  • Component specific operations
  • Clear messages on a queue
  • Drop connections
  • Browse Durable Subscriptions

38
Agenda
  • Messaging Review
  • Clustering in SonicMQ CWADS CWAQS
  • Dynamic Routing Architecture
  • Security
  • Management
  • HTTP Direct
  • Performance
  • Flow Control

39
HTTP Direct Features
  • New in 5.0
  • Web Services handlers
  • Inbound SOAP
  • Outbound SOAP
  • HTTP Direct
  • Polling receive
  • Allows light-weight devices to receive messages
  • HTTP Direct for JMS

Web Service
SonicMQ
JMS Client
40
HTTP-Direct Features
- New to MQ 5.0
41
Agenda
  • Messaging Review
  • Clustering in SonicMQ CWADS CWAQS
  • Dynamic Routing Architecture
  • Security
  • Management
  • HTTP Direct
  • Performance
  • Flow Control

42
Where have we improved?
  • Durable Subscriptions
  • Reconnected durables are 2.5 times faster
  • Transactions
  • Have re-architected the transaction sub-system
  • Now 5 times faster than before
  • Secure Messaging
  • Strong QoP approximately 100 faster than SSL

43
Agenda
  • Messaging Review
  • Clustering in SonicMQ CWADS CWAQS
  • Dynamic Routing Architecture
  • Security
  • Management
  • HTTP Direct
  • Performance
  • Flow Control

44
Flow Control
  • The challenge for all messaging providers
  • What do I do when production rate exceeds
    consumption rate
  • The options
  • Buffer in memory
  • Buffer on disk but not in memory
  • Throw an exception on the producer
  • Block the offending producer
  • Our approach
  • 1 (3 4)

45
Questions
Write a Comment
User Comments (0)
About PowerShow.com
