ECS150 Discussion

1
ECS150 Discussion

• 10/28/2004
• Lynn Nguyen

2
TA Website

• http//wwwcsif.cs.ucdavis.edu/nguyenly/

3
Announcement

• Extra OH
• T 100 430pm (Midterm question)
• Th 100-400pm (Homework1 question)

4
Homework1 Help

• System call setProcessPriority() must access the
  process table
• Process table is located inside the kernel
• Must go between user-space to server-space(MM),
  and then server-space(MM) to kernel-space to
  access the process table

5
System Call Control Flow

• /usr/include/prioirity.h

setProcessPriority() library function Call
accessible from user space. Calls _syscall(MM,
SETPRIORITY, m) Function trapping to kernel.
User Process
MM
1. setProcessPrioirity (2, 100)
System
Kernel
6

• priority.h setProcessPriority()
• traps to kernel
• /usr/src/lib/other/syscall.c _syscall()
• - the syscall function determins the
• message is for the MM and pass control to the
  MM

User Process
MM
1
2. _sendrec(MM, msg)
System
Kernel
7

• priority.h setProcessPriority() traps
• to kernel
• /usr/src/lib/other/syscall.c sendrec()
• directs message to MM
• /usr/src/mm/table.c call_vec()
• function receives message and dete-
• mines which function to execute
• /usr/src/mm/misc.c implements
• function, e.g. do_setpriority, which
• includes a call to systask defined
• in /usr/src/kernel/system.c

User Process
MM
1
2
3. _taskcall(SYSTASK, SYS_SETPRIORITY, m)
System
Kernel
8
1. priority.h setProcessPriority() traps
to kernel 2 /usr/src/lib/other/syscall.c
sendrec() directs message to MM 3.
/usr/src/mm/misc.c invokes _taskcall
include ltminix/com.hgt here 4. sys_task()
receives message, dete- mines which function
to perform within kernel code, as defined in
/usr/include/minix/com.h this function has
access to the kernel globals and can update
values in proc table
User Process
MM
1
2
3
System
Kernel
4. do_syspriority(m)
9
1. priority.h setProcessPriority() traps
to kernel 2 /usr/src/lib/other/syscall.c
sendrec() directs message to MM 3.
/usr/src/kernel/misc.c invokes _taskcall 4.
/usr/src/kernel/system.c do_setpriority()
modifies kernel structures. 5. Returns value from
do_syspriority() function

User Process
MM
1
2
5. Return value
3
System
Kernel
4
10
1. priority.h setProcessPriority() traps
to kernel 2 /usr/src/lib/other/syscall.c
sendrec() directs message to MM 3.
/usr/src/kernel/misc.c invokes _taskcall 4.
/usr/src/kernel/system.c do_setpriority()
modifies kernel structures. 5. Returns value from
do_syspriority() function 6. Propagates return
value from do_setpriority() function

User Process
MM
1
2
5.
3
6. Return value
System
Kernel
4
11
1. priority.h setProcessPriority() traps
to kernel 2 /usr/src/lib/other/syscall.c
sendrec() directs message to MM 3.
/usr/src/kernel/misc.c invokes _taskcall 4.
/usr/src/kernel/system.c do_setpriority()
modifies kernel structures. 5. Returns value from
do_setpriority() function 6. Propagates return
value from do_setpriority() function 7.
Returns from syscall with the propagated
return value
User Process
MM
7. Return value
1
2
5.
3
6
System
Kernel
4
12
Adding MINIX System Call
13
Homework1 help

• setProcessPriority( pid, priority)
• sets the priority for the process to priority
• setProcessPriority( pid, priority)
• Should return the priority actually assigned
  to process pid

14
Proc Table
proc0
TASK_ADDR
procNR_TASKS
SERVER_ADDR
procNR_TASKS LOW_USER
USER_ADDR
USER_ADDR
Where we are interested in
procNR_TASKSNR_PROCS
15
Loop Through the Proc Table

• define BEG_PROC_ADDR (proc0)
• define END_PROC_ADDR (procNR_TASKS
  NR_PROCS)
• define END_TASK_ADDR (procNR_TASKS)
• define BEG_SERV_ADDR (procNR_TASKS)
• define BEG_USER_ADDR (procNR_TASKS
  LOW_USER)
• All defined in /usr/src/kernel/proc.c

16
List of files to modify

• User space
• /usr/include/unistd.h
• Add prototype for system call
• /usr/include/priority.h
• Invoke _syscacll through message passing
• /usr/include/minix/callnr.h
• Set system call number
• /usr/include/minix/com.h
• add systask for SYSPRIORITY
• /usr/include/minix/config.h
• Turn on/off the debugger

17
List of files to modify

• MM
• /usr/src/fs/table.c
• Put entry in call_vec
• /usr/src/mm/table.c
• Add entry to call_vec on mm side
• /usr/src/mm/proto.h
• Add prototype for do_setpriority
• /usr/src/mm/misc.c
• Implement MM side do_setpriority
• Invoke _taskcall

18
List of files to modify

• Kernel
• /usr/src/kernel/main.c
• ?? (for you)
• /usr/src/kernel/proc.h
• Add a field to proc table
• /usr/src/kernel/proc.c
• Implement the actual priority scheduling
• Use LinkedList implementation by using
  rdy_headUSER_Q
• rdy_tailUSER_Q, and p_nextready
• /usr/src/kernel/system.c
• Add kernel side do_syspriority
• What else?

19
Midterm review
20
Chapter1 Chapter 3

• System calls interface b/w process and OS
• see page 66 for categories of system calls

21
Context Switching
22
Context Switch

• Important
• Context Switch time is pure over-head. The
  system does no useful work while switching.
• One reason that we prefer threads over processes

23
User Threads vs. Kernel Threads

• User Threads
• Thread management done by user-level
• No support/intervention from kernel
• Kernel is unaware of user-level threads
• Problem if the kernel is single-threaded, then
  any user-level thread performing a blocking
  system call will cause the entire process to
  block, even if other threads are available to run
  within the application

24
User Threads vs. Kernel Threads

• Kernel Threads
• Supported directly by the kernel
• Thread management done in kernel-space
• Kernel threads are slower to create manage
• If a thread performs a blocking system call, the
  kernel can schedule another thread in the
  application for execution
• Kernel can schedule threads on different
  processors in multiprocessor environment

25
Multithreading model

• Many-to-one
• pros efficient since thread management is done
  in user space
• Cons
• Entire process blocks if a thread makes a
  blocking system call
• Multiple threads are unable to run in parallel on
  multiprocessors

26
Multithreading model

• One-to-one model
• Pros
• More concurrency allowing another thread to run
  when a thread makes a blocking system call
• Allow multiple threads to run in parallel on
  multiprocessors
• Cons
• Creating a user thread requires creating the
  corresponding kernel thread
• Overhead restrict the number of threads supported
  by the system

27
Multithreading model

• Many-to-many model
• Pros
• Can create as many as user threads as wishes
• The corresponding kernel threads can run in
  parallel on a multiprocessor
• When a thread performs a blocking system call,
  the kernel can schedule another thread for
  execution
• Cons
• True concurrency is not gained since the kernel
  can schedule only one thread at a time

28
CPU Scheduling

• FCFS (nonpreemptive)
• Pros
• Easy to implement
• Efficient-minimize context switching
• Cons
• Penalty ratio for short jobs much greater than
  for long jobs
• Convoy effect all processes wait for the one
  big process to get off the CPU. Results in lower
  CPU and device utilization
• Shortest Job first (nonpreemptive or preemptive)
• Problem difficulty of knowing the length of the
  next CPU request

29
CPU scheduling

• Priority (nonpreemptive or preemptive)
• Major problem starvation
• Solution aging. Gradually increase the
  priority of waiting process
• Round Robin (preemptive)
• Quantum to be large with respect to context
  switch time
• If quantum is too large, RR becomes FCFS
• Rule 80 of the CPU bursts should be shorter
  than the time quantum

30
CPU scheduling

• Multilevel queue
• Partition the ready queue into several separate
  queues
• Multilevel feedback queue scheduling
• Let a process move between queues.
• Same as aging process waits too long in the low
  priority queue moves to higher.

31
CPU scheduling

• Lottery Scheduling

2
34
50
10
23
1
6
15
3
1
24..26
38
11
2..2
9.23
If a random number 10 is generated, who will win
the lottery?
32
CPU scheduling

• Lottery Scheduling

2
34
50
10
23
1
6
15
3
1
24..26
38
11
2..2
9.23
If a random number 10 is generated, who will win
the lottery?
PID 34
33
Semaphore

• Wait(S)
• S.Value --
• If (S.value lt 0)
• Add this process to the queue
• block //suspend the process
• Signal(S)
• S.Value
• If (S.value lt 0)
• remove a process P from the queue
• wakeup(P) //resume execution of Ps

34
Deadlock

• P0 P1
• wait(S) S-- wait(Q) Q--
• wait(Q) wait(S)
• Signal(S) Signal(Q)
• Signal(Q) Signal(S)

S and Q are two semaphores initialize to 1
35
Is it safe?

• Process 1
• while(check1 TRUE)
• check0 FALSE while(check1 TRUE)
• check0 TRUE ltcritical sectiongt
  check0 FALSE ....

• Process 2 .... while(check0 TRUE)
• check1 FALSE while(check0 TRUE)
• check1 TRUE ltcritical sectiongt check1
  FALSE ....

L1
L2
L3
L4
L5
L6
Check0
FALSE
UNSAFE
FALSE
Check1
36
Is it Deadlock free?

• Process 1
• while(check1 TRUE)
• check0 FALSE while(check1 TRUE)
• check0 TRUE ltcritical sectiongt
  check0 FALSE ....

• Process 1 .... while(check0 TRUE)
• check1 FALSE while(check0 TRUE)
• check1 TRUE ltcritical sectiongt check1
  FALSE ....

L1
L2
L3
L4
L5
L6
Start Value
L4
L2
TRUE
FALSE
Check0
TRUE
DEADLOCK
Check1
TRUE
FALSE
TRUE
