Web Programming Course

1
Web Programming Course

• Lecture 4 Concurrent Programming 1

2
Concurrent Programming

• What is a concurrent program?
• A sequential program has a single flow.
• A concurrent program has multiple flows.
• Allows to perform multiple computations in
  parallel
• Allows to control multiple external activities
  occurring at the same time.
• Programming paradigm expressing the natural
  potential parallelism and solving the resulting
  synchronization and communication problems

3
Main Motivation CPU Utilisation
Response time in seconds
4
Parallelism Between CPU and I/O Devices
5
Sequential Maze Search
6
Concurrent Maze Search
7
Why Concurrent Programming?

• To allow the expression of potential parallelism,
  such that more than one computer can be used to
  solve the problem
• To model the parallelism in the real world
• Many real-life systems are inherently concurrent,
  as devices operate in parallel in the real world
• Performance gain from multiprocessing hardware
• Application throughput and responsiveness
• an I/O call partially blocks functionality
• handling user requests

8
Terminology

• Process is a sequential program, i.e. a sequence
  of statements executed one after another
• Unofficially, instance of program
• Each process has a single thread of control
• A concurrent program is a collection of
  autonomous sequential processes, executed
  (logically) in parallel

9
Terminology

• The actual implementation (i.e. execution) of a
  collection of processes usually takes one of
  three forms
• Multiprogramming processes multiplex their
  executions on a single processor
• Multiprocessing processes multiplex their
  executions on a multiprocessor system where there
  is access to shared memory
• Distributed Processing processes multiplex
  their executions on several processors which do
  not share memory

10
Common Concurrent Applications

• Web Services
• I/O processing
• Simulations
• GUI-based applications
• Real-time systems
• Embedded systems
• Mobile code

11
Process Creation and Termination

• Principal events causing process creation
• Execution of a process creation system call
• System initialization
• User request to create a new process
• Tree-like structure of processes is managed by OS
• Conditions which terminate processes
• Normal exit (voluntary)
• Error exit (voluntary)
• Fatal error (involuntary)
• Killed by another process (involuntary)

12
Scheduling Processes

• Processes are managed by OS process called
  scheduler
• Well-known scheduling policies include
• First Come First Served
• Shortest Job First
• Priorities Scheduling
• Round Robin
• and their combinations

13
Context Switch

• Storing the data of the current process and
  loading the data of the next process

14
Process States
15
Challenges

• Concurrent programs are harder to get right
• Communication send or receive information
• Synchronization wait for another process to act
• Atomicity do not stop in the middle
• Some problems are inherently sequential
• E.g., computations waiting for the output of
  previous computations

16
Why is Concurrent Programming Hard?

• Non-Determinism
• Deterministic two executions on the same input
  it always produce the same output
• Non-deterministic two executions on the same
  input may produce different outputs
• Why does this cause difficulty?
• May be many possible executions of one system
• Hard to think of all the possibilities
• Hard to test since some errors occur infrequently

17
Non-Determinism

• Interleaving execution order
• Consider the following program
• What are the possible interleavings?

p1a p1b p2a p2b p2a p2b p1a p1b p1a p2a
p1b p2b p2a p1a p2b p1b p1a p2a p2b
p1b p2a p1a p1b p2b
18
Non-Determinism

• Consider the following program
• What are the possible values of c1 and c2 after
  execution of the program?

Two possible answers c1 9 c2 3 if p1
executes before p2 c1 15 c2 3 if p2
executes before p1
19
Coordination Between Processes

• Critical section
• Two processes may access shared resource
• Inconsistent behavior if two actions are
  interleaved
• Allow only one process in critical section
• Deadlock
• Process may hold some locks while awaiting others
• Deadlock occurs when no process can proceed

20
Processes in Java

• To create a new process
• Runtime.GetRuntime().exec(String command)
• Platform-dependent functionality
• Returns reference to Process object
• To terminate a process
• System.exit(int status)
• Other process can be killed by destroy()

21
Processes in Java

• The following methods may be used to pass
  information between processes
• OutputStream getOutputStream()
• InputStream getIntputStream()
• InputSteam getErrorStream()
• waitFor() waits for another process to end.
  Returns its exit value (0-success, other-failure)
• exitValue() gets exit value of a process

22
Example

• public class Runner
• final static String JAVA_PATH
  "C\\JBuilderX\\jdk1.4\\bin\\"
• final static String Prog_PATH
  "C\\JBuilderX\\jbprojects\\Tester\\classes\\"
• public static void main(String args)
• try
• Process hello null
• String cmdJAVA_PATH"java -classpath
  "Prog_PATH" HelloWorld"
• System.out.println("CMD"cmd)
• hello Runtime.getRuntime().exec(cmd)
• int exitValue hello.exitValue()
• System.out.println("The exit value is "
  exitValue)
• catch (Exception ex)
• System.out.println (ex)

Try inserting here hello.waitFor()
23
Example

• public class HelloWorld
• public static void main(String args)
• System.out.println("Hello World")
• System.exit(0)
• The output is
• java.lang.IllegalThreadStateException process
  has not exited
• Scheduling is needed!
• After inserting hello.waitFor() the output
  is The exit value is 0

24
Thread Model

• Thread is a set of instructions to be executed
  one at a time, in a specified order
• Often called Light-Weight Process
• Threads of one given process share the same
  address space
• Context-switch is simpler
• Can read and write the same memory

25
Single and Multithreaded Processes
26
Threads vs. Processes

• Creating threads is cheaper than processes
• Context switch is faster
• Inter-thread communication
• In general is easier
• Sometimes, may be very complicated
• Allow independent execution flows
• Simpler blocking handling
• Inherently supported by Java API

27
Example Multi-Threaded Server

• Single-threaded server can not process multiple
  requests
• In multi-threaded server
• Manager thread recognized incoming requests
• The requests are handled by worker threads
• Better availability is achieved

28
Java Thread States
29
Java Thread States

• Java threads are managed by the JVM.
• As a thread is launched, it is registered with
  the JVM thread scheduler.
• Threads are launched using start() method
• Wraps call to run() method
• start() can be called only once
• Also, tree-like structure of threads
• Scheduler determines which thread will run in the
  CPU at any given point of time
• When a thread gets CPU, run() method is executed

30
Java Thread States

• The suspend() method allows a thread to make
  another thread un-runnable.
• The suspended thread becomes runnable when some
  other thread resumes it using the resume()
  method.
• The stop() method allows a thread to kill another
  thread.

31
Java Thread States

• When the run() method ends the execution is
  considered completed and the thread is considered
  dead.
• A dead thread cannot be started again
• But it still exists and like any other object,
  its methods and data can be accessed.

32
Threads Scheduling

• Each thread has a numeric priority
• Between Thread.MIN_PRIORITY and
  Thread.MAX_PRIORITY
• In Java, these are respectively 1 and 10
• The JVM implicitly creates a thread (named main
  thread) when executing program main()method
• Main has default priority Thread.NORM_PRIORITY
  (5)
• New thread has same priority as thread created it

• Accessing priorities via getPriority() and
  setPriority()
• All the ready threads contend for the CPU time
• Scheduler gives preference to higher-priority
  threads

33
Java Threads Implementation

• New threads may be created in Java by
• Extending Thread class
• Implementing Runnable interface
• They are descendants of the main thread

34
Implementing Runnable Interface

• The class implements an interface called Runnable
  interface, which defines a single abstract method
  run().
• package java.lang
• public interface Runnable
• public void run()

35
Implementing Runnable Interface

• When a class implements Runnable interface, it
  provides an implementation of the run() method.
• public class ConcurrentReader implements Runnable

• ...
• public void run()
• / code here executes concurrently with the
  caller /
• ...

36
Implementing Runnable Interface

• To start the thread, you need to create an object
  of type Runnable, bind it to a new Thread object,
  and then start it.
• Calling start()
• Creates the thread data structures
• Invokes the run() method of the Runnable object
  as the first procedure on that new thread.

37
Implementing Runnable Interface

• The java.lang.Thread class has a constructor that
  takes an object of type Runnable
• Thread(Runnable object)
• This constructor must be provided an object that
  implements Runnable interface
• i.e., contains an implementation of run() method

38
Implementing Runnable Interface

• ConcurrentReader readerThread new
  ConcurrentReader()
• Thread t new Thread(readerThread)
• // create thread using a Runnable object
  t.start()
• // automatically calls ConcurrentReader.run()

39
Implementing Runnable Interface
class Interleave public static int c1 2
public static int c2 3 public static void
main (String args) Thread p1 new
Thread(new P1()) Thread p2 new Thread(new
P2()) p1.start () p2.start ()
class P1 implements Runnable public void run
() Interleave.c1 Interleave.c1
Interleave .c2 class P2 implements
Runnable public void run ()
Interleave.c1 Interleave.c1
Interleave.c2
Sometimes it is desirable to implement the run()
method in a class implementing interface Runnable.
40
Extending Thread Class

• Alternatively, we can define a subclass of the
  class Thread directly.
• class ConcurrentWriter extends Thread
• public void run()
• //provide the code to run as a //separate
  thread of control

41
Extending Thread Class

• To start this thread you just need to do the
  following
• ConcurrentWriter writerThread new
  ConcurrentWriter()
• writerThread.start()
• // start calls run() automatically

42
Extending Thread Class
class Interleave public static int c1 2
public static int c2 3 public static void
main (String args) Thread p1 new P1 ()
Thread p2 new P2 () p1.start () p2.start
()
class P1 extends Thread public void run ()
Interleave.c1 Interleave.c1 Interleave
.c2 class P2 extends Thread public void
run () Interleave.c1 Interleave.c1
Interleave.c2
Usually, it is easier to extend the Thread class
and override its run() method.
43
Extending Thread Class Example

• class MyThread extends Thread
• private String message
• public MyThread(String m) messagem
• public void run()
• for(int r0 rlt20 r)
  System.out.println(message running ...)
• public class ThreadRunner
• public static void main(String args)
• MyThread t1,t2
• t1new MyThread(1st thread")
• t2new MyThread(2nd thread")
• t1.start()
• t2.start()

44
Possible Output

• 1st thread running ...
• 1st thread running ...
• 1st thread running ...
• 1st thread running ...
• 1st thread running ...
• 1st thread running ...
• 1st thread running ...
• 1st thread running ...
• 2nd thread running ...
• 2nd thread running ...
• 2nd thread running ...
• 2nd thread running ...
• 2nd thread running ...
• 2nd thread running ...
• 2nd thread running ...
• 2nd thread running ...
• 2nd thread running ...
• 2nd thread running ...
• 2nd thread running ...

• 2nd thread running ...
• 2nd thread running ...
• 2nd thread running ...
• 2nd thread running ...
• 2nd thread running ...
• 2nd thread running ...
• 2nd thread running ...
• 2nd thread running ...
• 1st thread running ...
• 1st thread running ...
• 1st thread running ...
• 1st thread running ...
• 1st thread running ...
• 1st thread running ...
• 1st thread running ...
• 1st thread running ...
• 1st thread running ...
• 1st thread running ...
• 1st thread running ...

There is no guarantee for the order of outputs,
since the threads are concurrent
45
Thread Priority Example

• class A extends Thread
• public void run()
• System.out.println("Thread A
  started")
• for(int i1ilt4i)
• System.out.println("\t From
  ThreadA i "i)
• System.out.println("Exit from
  A")
• class B extends Thread
• public void run()
• System.out.println("Thread B
  started")
• for(int j1jlt4j)
• System.out.println("\t From
  ThreadB j "j)

46
Thread Priority Example

• class C extends Thread
• public void run()
• System.out.println("Thread C
  started")
• for(int k1klt4k)
• System.out.println("\t From
  ThreadC k "k)
• System.out.println("Exit from
  C")
• class ThreadPriority
• public static void main(String args)
• A threadAnew A()
• B threadBnew B()
• C threadCnew C()
• threadC.setPriority(Thread.MAX
  _PRIORITY)
• threadB.setPriority(threadA.ge
  tPriority()1)

47
Thread Priority Example

• Started Thread A
• Started Thread B
• Thread B started
• From ThreadB j 1
• From ThreadB j 2
• From ThreadB j 3
• From ThreadB j 4
• Exit from B
• Started Thread C
• Thread C started
• From ThreadC k 1
• From ThreadC k 2
• From ThreadC k 3
• From ThreadC k 4
• Exit from C
• End of main thread
• Thread A started
• From ThreadA i 1
• From ThreadA i 2

48
Extending vs. Implementing

• Why does Java allow two different ways to provide
  thread objects?
• How do you decide when to extend the Thread class
  versus implementing the Runnable interface?
• Java only allows single class inheritance, so if
  a class inherits from another class, but also
  needs to run as a thread, then it extensd the
  other class and implements the Runnable
  interface.
• So, it is quite common for a class X to extend
  some class Y and implement the Runnable interface

49
Extending vs. Implementing

• class X extends Y implements Runnable
• public void do_it()
• //the code to run as a thread of control
• public void run() do_it() // can be run
  a thread if needed

50
Extending vs. Implementing

• By implementing Runnable interface, rather than
  extending the Thread class, you declare that an
  object of type X will run as a thread
• But not always it has to run as a thread.
• Since all the run() method does, in this case, is
  call another public method that could be called
  without running a thread, it gives the user the
  option of either having an object of type X run
  concurrently, or sequentially.

51
Extending vs. Implementing

• X obj new X()
• obj.do_something() // runs sequentially in the
  current thread
• Thread t new Thread(new X()) // create X and
  run as a separate thread
• t.start() // start() calls run() which calls
  do_it()

52
Thread class

• public static Thread currentThread()
• public static void dumpStack()
• public final void setName( String name )
• public final String getName()
• public final void setPriority( int newPriority )
• public final int getPriority()
• public final native boolean isAlive()
• public void start()
• public final void suspend()
• public final void resume()
• public final void stop()
• public static void sleep(long millis )
• public static void yield()
• public void join()

53
public static Thread currentThread()

• Static methods that returns a reference to the
  currently running thread
• try
• System.out.println( Thread.currentThread().getNam
  e()
• catch(InterruptedException e)e.printStackTrace()


54
public static void sleep(long millis )

• Causes a thread to be blocked for a given time
• Afterwards, it becomes ready
• try
• Thread.sleep(1000)
• catch(InterruptedException e)e.printStackTrace()

• It is unknown whether the thread will get the CPU
  as soon it becomes ready. It just starts
  contending for the CPU time with the other
  threads.

55
sleep() Example

• class MyThread extends Thread
• private String message
• public MyThread(String m) messagem
• public void run()
• for(int r0 rlt20 r)
• try
• System.out.println(message running ...)
• Thread.sleep((long) 100)
• catch (InterruptedException e)
• // end of for
• // end of run
• // end of class

56
Output

• 1st thread running ...
• 2nd thread running ...
• 1st thread running ...
• 2nd thread running ...
• 1st thread running ...
• 2nd thread running ...
• 1st thread running ...
• 2nd thread running ...
• 1st thread running ...
• 2nd thread running ...
• 1st thread running ...
• 2nd thread running ...
• 1st thread running ...
• 2nd thread running ...
• 1st thread running ...
• 2nd thread running ...
• 1st thread running ...
• 2nd thread running ...
• 1st thread running ...

• 1st thread running ...
• 2nd thread running ...
• 1st thread running ...
• 2nd thread running ...
• 1st thread running ...
• 2nd thread running ...
• 1st thread running ...
• 2nd thread running ...
• 1st thread running ...
• 2nd thread running ...
• 1st thread running ...
• 2nd thread running ...
• 1st thread running ...
• 2nd thread running ...
• 1st thread running ...
• 2nd thread running ...
• 1st thread running ...
• 2nd thread running ...
• 1st thread running ...

57
public final boolean isAlive()

• Returns true as long as a thread is not dead
• Blocked thread is not dead!
• MyThread executive new MyThread(thread1")
• executive.start()
• if (executive.isAlive())
• //do something
• else
• //do something else

58
public void join()

• The execution continues only when the thread is
  dead
• MyThread executive new MyThread(thread1")
• executive.start()
• try
• executive.join()
• catch(InterruptedException e)e.printStackTrace()


59
public static void yield()

• Causes the thread to voluntarily release the CPU
  for a thread with the same (or higher) priority
• Only a recommendation for the scheduler
• try
• while(! cobdition)
• Thread.currentThread().yield()
• catch(InterruptedException e)e.printStackTrace()


60
Memory Management

• Shared memory objects are managed in the address
  space of the process.
• Every thread separately manages registers and
  program counter.
• Every thread manages its own memory address space
  on a heap.
• Calling methods within thread uses stack.

61
Memory Management

• class Worker implements Runnable
• Object arg, other
• Worker(Object a)
• arg a
• public void run()
• Object tmp new Object()
• other new Object()
• for(int i 0 i lt 1000 i)
• // do something

62
Memory Management

• class Demo
• static public void main(String args)
• Object shared new Object()
• Runnable worker1new Worker(shared)
• Thread t1 new Thread(worker1)
• Runnable worker2 new Worker(shared)
• Thread t2 new Thread(worker2)
• t1.start()
• t2.start()
• // do something here

63
Memory Management
64
Whats the Problem

• Both threads use shared
• What happens if both of them access it
  concurrently?
• E.g., both of them try to modify it?
• Synchronization is needed!
