Protein Folding Programs

1
Protein Folding Programs

• By
• Asim OKUR
• CSE 549
• November 14, 2002

2
Protein Structure

• DNA Sequence ? Protein Sequence ? Structure ?
  (Mis)function
• It is believed that all the information necessary
  to determine the structure of a protein is
  present in its primary sequence.

3
Protein Folding Programs

• Protein folding is one of the biggest
  computational challenges
• Different types of folding and structure
  predictions programs
• Simulations
• Homology Modeling Approaches

4
Simulations

• Simulate the real behavior of proteins
• High detail, short time scales
• 2 main simulation types
• Molecular Dynamics
• Monte Carlo

5
The Energy Function

• Calculate energies for each particle
• Since long range interactions important for each
  pair of particles the pair-wise interactions
  should be calculated

6
Homology Modeling

• Template Selection and Fold Assignment
• Target Template Alignment
• Model Building
• Loop Modeling
• Sidechain Modeling
• Model Evaluation

7
Fold Assignment and Template Selection

• Identify all protein structures with sequences
  related to the target, then select templates
• 3 main classes of comparison methods
• Compare the target sequence with each database
  sequence independently, pair-wise sequence
  sequence comparison, BLAST and FASTA
• Multiple sequence comparisons to improve
  sensitivity, PSI-BLAST
• Threading or 3-D template matching methods

8
Target Template Alignment

• Most important step in Homology Modeling
• A specialized method should be used for alignment
• Over 40 identity the alignment is likely to be
  correct.
• Regions of low local sequence similarity become
  common when overall sequence identity is under
  40. (Saqi et al., Protein Eng. 1999)
• The alignment becomes difficult below 30
  sequence identity. (Rost, Protein Eng. 1999)

9
Model Building

• Construct a 3-D model of the target sequence
  based on its alignment on template structures
• Three different model building approaches
• Modeling by rigid body assembly
• Modeling by segment matching
• Modeling by satisfaction of spatial restraints
• Accuracies of these models are similar
• Template selection and alignment have larger
  impact on the model

10

• Screenshots from the Homology Modeling Server
  Swiss-Model
• Construct a framework using known protein
  structures
• Generate the location of the target amino acids
  on the framework
• If loop regions not determined, additional
  database search or short simulations

Swiss-MOD Web Server
11

• Procedure of the MODELLER program
• After obtaining restraints run a geometry
  optimization or real-space optimization to
  satisfy them

12
Errors in Homology Models

• Errors in sidechain packing
• Distortions and shifts in correctly aligned
  regions
• Errors in regions without a template

13
d. Errors due to misalignment e. Incorrect
templates
14
Model Building Programs
15
(No Transcript)
16
Applications
17
Critical Assessment of protein Structure
Prediction (CASP)
Venclovas et al. Proteins, 2001
18
Critical Assessment of protein Structure
Prediction (CASP)
Venclovas et al. Proteins, 2001
19
Conclusions

• Computer Simulations are powerful to show
  detailed motions but they cannot cover long
  enough time spans to simulate folding for large
  systems
• Homology Modeling techniques can be successful if
  the target protein has a known fold
• The higher the sequence similarity the more
  likely the model will be successful
• With the implementation of better techniques the
  errors in fold assignment, alignment, and
  sidechain and loop modeling are decreasing
• Theoretically, if at least one member of every
  possible fold is known, it is possible to predict
  the structure of every coding sequence to within
  a certain accuracy
