Optimizing Bandwidth Limited Problems Using OneSided Communication and Overlap

1
Optimizing Bandwidth Limited Problems Using
One-Sided Communication and Overlap

• Christian Bell1,2, Dan Bonachea1,
• Rajesh Nishtala1, and Katherine Yelick1,2
• 1UC Berkeley, Computer Science Division
• 2Lawrence Berkeley National Laboratory

2
Conventional Wisdom

• Send few, large messages
• Allows the network to deliver the most effective
  bandwidth
• Isolate computation and communication phases
• Uses bulk-synchronous programming
• Allows for packing to maximize message size
• Message passing is preferred paradigm for
  clusters
• Global Address Space (GAS) Languages are
  primarily useful for latency sensitive
  applications
• GAS Languages mainly help productivity
• However, not well known for their performance
  advantages

3
Our Contributions

• Increasingly, cost of HPC machines is in the
  network
• One-sided communication model is a better match
  to modern networks
• GAS Languages simplify programming for this model
• How to use these communication advantages
• Case study with NAS Fourier Transform (FT)
• Algorithms designed to relieve communication
  bottlenecks
• Overlap communication and computation
• Send messages early and often to maximize overlap

4
UPC Programming Model

• Global address space any thread/process may
  directly read/write data allocated by another
• Partitioned data is designated as local (near)
  or global (possibly far) programmer controls
  layout

Global arrays Allows any processor to directly
access data on any other processor
shared
g
g
g
private
l
l
l
Proc 0
Proc 1
Proc n-1

• 3 of the current languages UPC, CAF, and
  Titanium
• Emphasis in this talk on UPC (based on C)
• However programming paradigms presented in this
  work are not limited to UPC

5
Advantages of GAS Languages

• Productivity
• GAS supports construction of complex shared data
  structures
• High level constructs simplify parallel
  programming
• Related work has already focused on these
  advantages
• Performance (the main focus of this talk)
• GAS Languages can be faster than two-sided MPI
• One-sided communication paradigm for GAS
  languages more natural fit to modern cluster
  networks
• Enables novel algorithms to leverage the power of
  these networks
• GASNet, the communication system in the Berkeley
  UPC Project, is designed to take advantage of
  this communication paradigm

6
One-Sided vs Two-Sided
host CPU
one-sided put (e.g., GASNet)
network interface
dest. addr.
data payload
memory
two-sided message (e.g., MPI)
message id
data payload

• A one-sided put/get can be entirely handled by
  network interface with RDMA support
• CPU can dedicate more time to computation rather
  than handling communication
• A two-sided message can employ RDMA for only part
  of the communication
• Each message requires the target to provide the
  destination address
• Offloaded to network interface in networks like
  Quadrics
• RDMA makes it apparent that MPI has added costs
  associated with ordering to make it usable as a
  end-user programming model

7
Latency Advantages

• Comparison
• One-sided
• Initiator can always transmit remote address
• Close semantic match to high bandwidth, zero-copy
  RDMA
• Two-sided
• Receiver must provide destination address
• Latency measurement correlates to software
  overhead
• Much of the small-message latency is due to time
  spent in software/firmware processing

down is good
8
Bandwidth Advantages

• One-sided semantics better match to RDMA
  supported networks
• Relaxing point-to-point ordering constraint can
  allow for higher performance on some networks
• GASNet saturates to hardware peak at lower
  message sizes
• Synchronization decoupled from data transfer
• MPI semantics designed for end user
• Comparison against good MPI implementation
• Semantic requirements hinder MPI performance
• Synchronization and data transferred coupled
  together in message passing

up is good
Over a factor of 2 improvement for 1kB messages
9
Bandwidth Advantages (cont)

• GASNet and MPI saturate to roughly the same
  bandwidth for large messages
• GASNet consistently outperforms MPI for
  mid-range message sizes

up is good
10
A Case Study NAS FT

• How to use the potential that the microbenchmarks
  reveal?
• Perform a large 3 dimensional Fourier Transform
• Used in many areas of computational sciences
• Molecular dynamics, computational fluid dynamics,
  image processing, signal processing, nanoscience,
  astrophysics, etc.
• Representative of a class of communication
  intensive algorithms
• Sorting algorithms rely on a similar intensive
  communication pattern
• Requires every processor to communicate with
  every other processor
• Limited by bandwidth

11
Performing a 3D FFT

• NX x NY x NZ elements spread across P processors
• Will Use 1-Dimensional Layout in Z dimension
• Each processor gets NZ / P planes of NX x NY
  elements per plane

Example P 4
NZ
NZ/P
1D Partition
NX
p3
p2
p1
NY
p0
12
Performing a 3D FFT (part 2)

• Perform an FFT in all three dimensions
• With 1D layout, 2 out of the 3 dimensions are
  local while the last Z dimension is distributed

Step 1 FFTs on the columns (all elements local)
Step 2 FFTs on the rows (all elements local)
Step 3 FFTs in the Z-dimension (requires
communication)
13
Performing the 3D FFT (part 3)

• Can perform Steps 1 and 2 since all the data is
  available without communication
• Perform a Global Transpose of the cube
• Allows step 3 to continue

Transpose
14
The Transpose

• Each processor has to scatter input domain to
  other processors
• Every processor divides its portion of the domain
  into P pieces
• Send each of the P pieces to a different
  processor
• Three different ways to break it up the messages
• Packed Slabs (i.e. single packed Alltoall in
  MPI parlance)
• Slabs
• Pencils
• An order of magnitude increase in the number of
  messages
• An order of magnitude decrease in the size of
  each message
• Slabs and Pencils allow overlapping
  communication and computation and leverage RDMA
  support in modern networks

15
Algorithm 1 Packed Slabs

• Example with P4, NXNYNZ16
• Perform all row and column FFTs
• Perform local transpose
• data destined to a remote processor are grouped
  together
• Perform P puts of the data

put to proc 0
put to proc 1
put to proc 2
put to proc 3
Local transpose

• For 5123 grid across 64 processors
• Send 64 messages of 512kB each

16
Bandwidth Utilization

• NAS FT (Class D) with 256 processors on
  Opteron/InfiniBand
• Each processor sends 256 messages of 512kBytes
• Global Transpose (i.e. all to all exchange) only
  achieves 67 of peak point-to-point bidirectional
  bandwidth
• Many factors could cause this slowdown
• Network contention
• Number of processors that each processor
  communicates with
• Can we do better?

17
Algorithm 2 Slabs

• Waiting to send all data in one phase bunches up
  communication events
• Algorithm Sketch
• for each of the NZ/P planes
• Perform all column FFTs
• for each of the P slabs
• (a slab is NX/P rows)
• Perform FFTs on the rows in the slab
• Initiate 1-sided put of the slab
• Wait for all puts to finish
• Barrier
• Non-blocking RDMA puts allow data movement to be
  overlapped with computation.
• Puts are spaced apart by the amount of time to
  perform FFTs on NX/P rows

plane 0
Start computation for next plane

• For 5123 grid across 64 processors
• Send 512 messages of 64kB each

18
Algorithm 3 Pencils

• Further reduce the granularity of communication
• Send a row (pencil) as soon as it is ready
• Algorithm Sketch
• For each of the NZ/P planes
• Perform all 16 column FFTs
• For r0 rltNX/P r
• For each slab s in the plane
• Perform FFT on row r of slab s
• Initiate 1-sided put of row r
• Wait for all puts to finish
• Barrier
• Large increase in message count
• Communication events finely diffused through
  computation
• Maximum amount of overlap
• Communication starts early

plane 0
Start computation for next plane

• For 5123 grid across 64 processors
• Send 4096 messages of 8kB each

19
Communication Requirements
With Slabs GASNet is slightly faster than MPI

• 5123 across 64 processors
• Alg 1 Packed Slabs
• Send 64 messages of 512kB
• Alg 2 Slabs
• Send 512 messages of 64kB
• Alg 3 Pencils
• Send 4096 messages of 8kB

20
Platforms
21
Comparison of Algorithms

• Compare 3 algorithms against original NAS FT
• All versions including Fortran use FFTW for local
  1D FFTs
• Largest class that fit in the memory (usually
  class D)
• All UPC flavors outperform original Fortran/MPI
  implantation by at least 20
• One-sided semantics allow even exchange based
  implementations to improve over MPI
  implementations
• Overlap algorithms spread the messages out,
  easing the bottlenecks
• 1.9x speedup in the best case

up is good
22
Time Spent in Communication

• Implemented the 3 algorithms in MPI using Irecvs
  and Isends
• Compare time spent initiating or waiting for
  communication to finish
• UPC consistently spends less time in
  communication than its MPI counterpart
• MPI unable to handle pencils algorithm in some
  cases

28.6
312.8
34.1
MPI Crash (Pencils)
down is good
23
Performance Summary
MFLOPS / Proc
up is good
24
Conclusions

• One-sided semantics used in GAS languages, such
  as UPC, provide a more natural fit to modern
  networks
• Benchmarks demonstrate these advantages
• Use these advantages to alleviate communication
  bottlenecks in bandwidth limited applications
• Paradoxically it helps to send more, smaller
  messages
• Both two-sided and one-sided implementations can
  see advantages of overlap
• One-sided implementations consistently outperform
  two-sided counterparts because comm model more
  natural fit
• Send early and often to avoid communication
  bottlenecks

25
Try It!

• Berkeley UPC is open source
• Download it from http//upc.lbl.gov
• Install it with CDs that we have here

26
Contact Us

• Associated Paper IPDPS 06 Proceedings
• Berkeley UPC Website http//upc.lbl.gov
• GASNet Website http//gasnet.cs.berkeley.edu

• Authors
• Christian Bell
• Dan Bonachea
• Rajesh Nishtala
• Katherine A. Yelick
• Email us
• upc_at_lbl.gov

• Special thanks to the fellow members of the
  Berkeley UPC Group
• Wei Chen
• Jason Duell
• Paul Hargrove
• Parry Husbands
• Costin Iancu
• Mike Welcome
