Parsing

1
Parsing
2
Parsing

• Calculate grammatical structure of program, like
  diagramming sentences, where
• Tokens words
• Programs sentences

For further information, read Aho, Sethi,
Ullman, Compilers Principles, Techniques, and
Tools (a.k.a, the Dragon Book)
3
Outline of coverage

• Context-free grammars
• Parsing
• Tabular Parsing Methods
• One pass
• Top-down
• Bottom-up
• Yacc

4
Parser extracts grammatical structure of program
function-def
name
arguments
stmt-list
stmt
main
expression
operator
expression
expression
variable
string
ltlt
cout
hello, world\n
5
Context-free languages

• Grammatical structure defined by context-free
  grammar
• statement ? labeled-statement
  expression-statement
  compound-statementlabeled-statement ? ident
  statement case
  constant-expression statementcompound-statement
  ? declaration-list
  statement-list

Context-free only one non-terminal in
left-part
terminal
non-terminal
6
Parse trees

• Parse tree tree labeled with grammar symbols,
  such that
• If node is labeled A, and its children are
  labeled x1...xn, then there is a productionA
  ??x1...xn
• Parse tree from A root labeled with A
• Complete parse tree all leaves labeled with
  tokens

7
Parse trees and sentences

• Frontier of tree labels on leaves (in
  left-to-right order)
• Frontier of tree from S is a sentential form
• Frontier of a complete tree from S is a sentence

8
Example

• G L ??L E E E ??a b
• Syntax trees from start symbol (L)

Sentential forms
9
Derivations

• Alternate definition of sentence
• Given ?, ? in V, say ??? is a derivation step if
  ??????? and ? ??? , where A ? ??is a
  production
• ? is a sentential form iff there exists a
  derivation (sequence of derivation steps)
  S??????? ( alternatively, we say that S?? )

Two definitions are equivalent, but note that
there are many derivations corresponding to each
parse tree
10
Another example

• H L ??E L E E ??a b

L
L
L
L
E

E

L

E
E
b
E
b
a
a
11
Ambiguity

• For some purposes, it is important to know
  whether a sentence can have more than one parse
  tree
• A grammar is ambiguous if there is a sentence
  with more than one parse tree
• Example E ? EE EE id

12

• If e then if b then d else f
• int x y 0
• A.b.c d
• Id -gt s s.id
• E -gt E T -gt E T T -gt T T T -gt id T
  T -gt id T id T -gt id id id T -gt
• id id id id

13
Ambiguity

• Ambiguity is a function of the grammar rather
  than the language
• Certain ambiguous grammars may have equivalent
  unambiguous ones

14
Grammar Transformations

• Grammars can be transformed without affecting the
  language generated
• Three transformations are discussed next
• Eliminating Ambiguity
• Eliminating Left Recursion (i.e.productions of
  the form A?A ? )
• Left Factoring

15
Eliminating Ambiguity

• Sometimes an ambiguous grammar can be rewritten
  to eliminate ambiguity
• For example, expressions involving additions and
  products can be written as follows
• E ? ET T
• T ? Tid id
• The language generated by this grammar is the
  same as that generated by the grammar on
  tranparency 11. Both generate id(idid)
• However, this grammar is not ambiguous

16
Eliminating Ambiguity (Cont.)

• One advantage of this grammar is that it
  represents the precedence between operators. In
  the parsing tree, products appear nested within
  additions

17
Eliminating Ambiguity (Cont.)

• An example of ambiguity in a programming language
  is the dangling else
• Consider
• S ? if b then S else S if b then S a

18
Eliminating Ambiguity (Cont.)

• When there are two nested ifs and only one else..

19
Eliminating Ambiguity (Cont.)

• In most languages (including C and Java), each
  else is assumed to belong to the nearest if that
  is not already matched by an else. This
  association is expressed in the following
  (unambiguous) grammar
• S ? Matched
• Unmatched
• Matched ? if b then Matched else
  Matched
• a
• Unmatched ? if b then S
• if b then
  Matched else Unmatched

20
Eliminating Ambiguity (Cont.)

• Ambiguity is a property of the grammar
• It is undecidable whether a context free grammar
  is ambiguous
• The proof is done by reduction to Posts
  correspondence problem
• Although there is no general algorithm, it is
  possible to isolate certain constructs in
  productions which lead to ambiguous grammars

21
Eliminating Ambiguity (Cont.)

• For example, a grammar containing the production
  A?AA ? would be ambiguous, because the
  substring aaa has two parses

A
A
A
A
A
A
A
A
a
A
A
a
a
a
a
a

• This ambiguity disappears if we use the
  productions
• A?AB B and B? ?
• or the productions
• A?BA B and B? ?.

22
Eliminating Ambiguity (Cont.)

• Examples of ambiguous productions
• A?AaA
• A?aA Ab and
• A?aA aAbA
• A language generated by an ambiguous CFG is
  inherently ambiguous if it has no unambiguous CFG
• An example of such a language is
• Laibjcm ij or jm which can be generated
  by the grammar
• S?AB DC
• A?aA e C?cC e
• B?bBc e D?aDb e

23
Elimination of Left Recursion

• A grammar is left recursive if it has a
  nonterminal A and a derivation A?Aa for some
  string a. Top-down parsing methods (to be
  discussed shortly) cannot handle left-recursive
  grammars, so a transformation to eliminate left
  recursion is needed.
• Immediate left recursion (productions of the form
  A?A ? ) can be easily eliminated.
• We group the A-productions as
• A?A ?1 A ?2 A ?m b1 b2 bn
• where no bi begins with A. Then we replace the
  A-productions by
• A? b1 A b2 A bn A
• A? ?1 A ?2 A ?m A e

24
Elimination of Left Recursion (Cont.)

• The previous transformation, however, does not
  eliminate left recursion involving two or more
  steps. For example, consider the grammar
• S?Aa b
• A?Ac Sd e
• S is left-recursive because S?Aa??Sda, but it is
  not immediately left recursive

25
Elimination of Left Recursion (Cont.)

• Algorithm. Eliminate left recursion
• Arrange nonterminals in some order A1, A2 ,,, An
• for i 1 to n
• for j 1 to i -1
• replace each production of the form Ai?Aj g
• by the production Ai? d1 g d2 g dn g
• where Aj? d1 d2 dn are all the current
  Aj-productions
• eliminate the immediate left recursion among the
  Ai-productions

26
Elimination of Left Recursion (Cont.)

• To show that the previous algorithm actually
  works all we need notice is that iteration i only
  changes productions with Ai on the left-hand
  side. And m gt i in all productions of the form
  Ai?Am ?
• Induction proof
• Clearly true for i1
• If it is true for all iltk, then when the outer
  loop is executed for ik, the inner loop will
  remove all productions Ai?Am ? with m lt i
• Finally, with the elimination of self recursion,
  m in the Ai?Am ? productions is forced to be gt i
• So, at the end of the algorithm, all derivations
  of the form Ai?Ama will have m gt i and therefore
  left recursion would not be possible

27
Left Factoring

• Left factoring helps transform a grammar for
  predictive parsing
• For example, if we have the two productions
• S ? if b then S else S
• if b then S
• on seeing the input token if, we cannot
  immediately tell which production to choose to
  expand S
• In general, if we have A? ? b1 ? b2 and the
  input begins with a, we do not know (without
  looking further) which production to use to
  expand A

28
Left Factoring (Cont.)

• However, we may defer the decision by expanding A
  to ?A
• Then after seeing the input derived from ?, we
  may expand A to ?1 or to ?2
• Left-factored, the original productions become
• A? ? A
• A? b1 b2

29
Non-Context-Free Language Constructs

• Examples of non-context-free languages are
• L1 wcw w is of the form (ab)
• L2 anbmcndm n ? 1 and m? 1
• L3 anbncn n ? 0
• Languages similar to these that are context free
• L1 wcwR w is of the form (ab) (wR stands
  for w reversed)
• This language is generated by the grammar
• S? aSa bSb c
• L2 anbmcmdn n ? 1 and m? 1
• This language is generated by the grammar
• S? aSd aAd
• A? bAc bc

30
Non-Context-Free Language Constructs (Cont.)

• L2anbncmdm n ? 1 and m? 1
• is generated by the grammar
• S? AB
• A? aAb ab
• B? cBd cd
• L3anbn n ? 1
• is generated by the grammar
• S? aSb ab
• This language is not definable by any regular
  expression

31
Non-Context-Free Language Constructs (Cont.)

• Suppose we could construct a DFSM D accepting
  L3.
• D must have a finite number of states, say k.
• Consider the sequence of states s0, s1, s2, , sk
  entered by D having read ?, a, aa, , ak.
• Since D only has k states, two of the states in
  the sequence have to be equal. Say, si ? sj
  (i?j).
• From si, a sequence of i bs leads to an accepting
  (final) state. Therefore, the same sequence of i
  bs will also lead to an accepting state from sj.
  Therefore D would accept ajbi which means that
  the language accepted by D is not identical to
  L3. A contradiction.

32
Parsing

• The parsing problem is Given string of tokens
  w, find a parse tree whose frontier is w.
  (Equivalently, find a derivation from w.)
• A parser for a grammar G reads a list of tokens
  and finds a parse tree if they form a sentence
  (or reports an error otherwise)
• Two classes of algorithms for parsing
• Top-down
• Bottom-up

33
Parser generators

• A parser generator is a program that reads a
  grammar and produces a parser
• The best known parser generator is yacc It
  produces bottom-up parsers
• Most parser generators - including yacc - do not
  work for every CFG they accept a restricted
  class of CFGs that can be parsed efficiently
  using the method employed by that parser generator

34
Top-down parsing

• Starting from parse tree containing just S, build
  tree down toward input. Expand left-most
  non-terminal.
• Algorithm (next slide)

35
Top-down parsing (cont.)

• Let input a1a2...an
• current sentential form (csf) S
• loop
• suppose csf t1...tkA?
• if t1...tk ??a1...ak , its an error
• based on ak1..., choose production A ??
• csf becomes t1...tk??

36
Top-down parsing example

• Grammar H L ??E L E
  E ??a b
• Input ab
• Parse tree Sentential form Input

L
ab
EL
ab
aL
ab
37
Top-down parsing example (cont.)

• Parse tree Sentential form Input

aE
ab
ab
ab
38
LL(1) parsing

• Efficient form of top-down parsing
• Use only first symbol of remaining input (ak1)
  to choose next production. That is, employ a
  function M? ? N? P in choose production step
  of algorithm.
• When this works, grammar is called LL(1)

39
LL(1) examples

• Example 1
• H L ??E L E E ??a b
• Given input ab, so next symbol is a.
• Which production to use? Cant tell.
• ? H not LL(1)

40
LL(1) examples

• Example 2
• Exp ?? Term Exp
• Exp ? Exp
• Term ??id
• (Use for end-of-input symbol.)

Grammar is LL(1) Exp and Term have only one
production Exp has two productions but only
one is applicable at any time.
41
Nonrecursive predictive parsing

• It is possible to build a nonrecursive predictive
  parser by maintaining a stack explicitly, rather
  than implicitly via recursive calls
• The key problem during predictive parsing is that
  of determining the production to be applied for a
  non-terminal

42
Nonrecursive predictive parsing

• Algorithm. Nonrecursive predictive parsing
• Set ip to point to the first symbol of w.
• repeat
• Let X be the top of the stack symbol and a the
  symbol pointed to by ip
• if X is a terminal or then
• if X a then
• pop X from the stack and advance ip
• else error()
• else // X is a nonterminal
• if MX,a X?Y1 Y2 Y k then
• pop X from the stack
• push YkY k-1, , Y1 onto the stack with Y1 on
  top
• (push nothing if Y1 Y2 Y k is ? )
• output the production X?Y1 Y2 Y k
• else error()
• until X

43
LL(1) grammars

• No left recursion
• A ?? Aa If this production is chosen, parse
  makes no progress.
• No common prefixes
• A ?? ab ag
• Can fix by left factoring
• A ?? aA
• A ? b g

44
LL(1) grammars (cont.)

• No ambiguity
• Precise definition requires that production to
  choose be unique (choose function M very hard
  to calculate otherwise)

45
Top-down Parsing
L
Start symbol and root of parse tree
Input tokens ltt0,t1,,t-i,...gt
E0 E-n
L
Input tokens ltt-i,...gt
E0 E-n
From left to right, grow the parse tree
downwards
...
46
Checking LL(1)-ness

• For any sequence of grammar symbols ?, define set
  FIRST(a) ? S to be
• FIRST(a) a a ? ab for some b

47
Checking LL(1)-ness

• Define Grammar G (N, ?, P, S) is LL(1) iff
  whenever there are two left-most derivations (in
  which the leftmost non-terminal is always
  expanded first)
• S gt wA? gt w?? gt wx
• S gt wA? gt w?? gt wy
• such that FIRST(x) FIRST(y), it follows that ?
  ?
• In other words, given
• 1. A string wA? in V and
• 2. The first terminal symbol to be derived from
  A?, say t
• there is at most one production that can be
  applied to A to
• yield a derivation of any terminal string
  beginning with wt
• FIRST sets can often be calculated by inspection

48
FIRST Sets
Exp ?? Term Exp Exp ? Exp Term
??id (Use for end-of-input symbol)
FIRST() FIRST( Exp) FIRST() ?
FIRST( Exp) ? grammar is LL(1)
49
FIRST Sets
L ??E L EE ??a b

FIRST(E L) a, b FIRST(E) FIRST(E L) ?
FIRST(E) ? ? grammar not LL(1).
50
Computing FIRST Sets

• Algorithm. Compute FIRST(X) for all grammar
  symbols X
• forall X ? V do FIRST(X)
• forall X ? ? (X is a terminal) do FIRST(X)X
• forall productions X ? ? do FIRST(X) FIRST(X)
  U ?
• repeat
• c forall productions X?Y1 Y2 Y k do
• forall i ? 1,k do
• FIRST(X) FIRST(X) U (FIRST(Yi) - ?) if
  ? ? FIRST(Yi) then continue c
• FIRST(X) FIRST(X) U ?
• until no more terminals or ? are added to any
  FIRST set

51
FIRST Sets of Strings of Symbols

• FIRST(X1X2Xn) is the union of FIRST(X1) and all
  FIRST(Xi) such that ? ? FIRST(Xk) for k1, 2, ,
  i-1
• FIRST(X1X2Xn) contains ? iff ? ? FIRST(Xk) for
  k1, 2, , n

52
FIRST Sets do not Suffice

• Given the productions
• A? T x
• A? T y T? w T? e
• T? w should be applied when the next input token
  is w.
• T? e should be applied whenever the next terminal
  (the one pointed to by ip) is either x or y

53
FOLLOW Sets

• For any nonterminal X, define set FOLLOW(X) ? S
  as
• FOLLOW(X) a S ?aXab

54
Computing the FOLLOW Set

• Algorithm. Compute FOLLOW(X) for all nonterminals
  X
• FOLLOW(S)
• forall productions A ? ?B? do FOLLOW(B)Follow(B)
  U (FIRST(?) - ?)
• repeat
• forall productions A ? ?B or A ? ?B? with ? ?
  FIRST(?) do
• FOLLOW(B) FOLLOW(B) U FOLLOW(A)
• until all FOLLOW sets remain the same

55
Construction of a predictive parsing table

• Algorithm. Construction of a predictive parsing
  table
• M,
• forall productions A ? ? do
• forall a ? FIRST(?) do
• MA,a MA,a U A ? ?
• if ? ? FIRST(?) then
• forall b ? FOLLOW(A) do
• MA,b MA,b U A ? ?
• Make all empty entries of M be error

56
Another Definition of LL(1)

• Define Grammar G is LL(1) if for every A? N
  with productions A ? a1 . . . an
• FIRST(ai FOLLOW(A)) ? FIRST(aj FOLLOW(A) ) ?
  for all i, j

57
Regular Languages

• Definition. A regular grammar is one whose
  productions are all of the type
• A ? aB
• A ? a
• A Regular Expression is either
• a
• R1 R2
• R1 R2
• R

58
Nondeterministic Finite State Automaton
a
b
b
start
a
0
1
2
3
b
59
Regular Languages

• Theorem. The classes of languages
• Generated by a regular grammar
• Expressed by a regular expression
• Recognized by a NDFS automaton
• Recognized by a DFS automaton
• coincide.

60
Deterministic Finite Automaton
space, tab, new line
START
digit
digit
NUM



KEYWORD
letter
, , -, /, (, )
OPERATOR
61
Scanner code

• state start
• loop
• if no input character buffered then read
  one, and add it to the accumulated token
• case state of
• start
• case input_char of
• A..Z, a..z state id
• 0..9 state num
• else ...
• end
• id
• case input_char of
• A..Z, a..z state id
• 0..9 state id
• else ...
• end
• num
• case input_char of
• 0..9 ...

62
Table-driven DFA
63
Language Classes
L0
L0
CSL
CFL NPA
LR(1)
LL(1)
RL DFANFA
64
Question

• Are regular expressions, as provided by Perl or
  other languages, sufficient for parsing nested
  structures, e.g. XML files?
