CS60002 Distributed Systems

1
CS60002 Distributed Systems
2

• Text Book
• Advanced Concepts in Operating Systems by
  Mukesh Singhal and Niranjan G. Shivaratri
• will cover about half the course, supplemented by
  copies of papers
• Xerox, notes, copies of papers etc. will cover
  the rest.

3
What is a distributed system?

• A very broad definition
• A set of autonomous processes communicating among
  themselves to perform a task
• Autonomous able to act independently
• Communication shared memory or message passing
• Concurrent system a better term probably

4

• A more restricted definition
• A network of autonomous computers that
  communicate by message passing to perform some
  task
• A practical distributed system will probably
  have both
• Computers that communicate by messages
• Processes/threads on a computer that communicate
  by messages or shared memory

5
Advantages

• Resource Sharing
• Higher Performance
• Fault Tolerance
• Scalability

6
Why is it hard to design them?

• The usual problem of concurrent systems
• Arbitrary interleaving of actions makes the
  system hard to verify
• Plus
• No globally shared memory (therefore hard to
  collect global state)
• No global clock
• Unpredictable communication delays

7
Models for Distributed Algorithms

• Topology completely connected, ring, tree etc.
• Communication shared memory/message passing
  (reliable? Delay? FIFO/Causal? Broadcast/multicast
  ?)
• Synchronous/asynchronous
• Failure models (fail stop, crash, omission,
  Byzantine)
• An algorithm need to specify the model on which
  it is supposed to work

8
Complexity Measures

• Message complexity no. of messages
• Communication complexity/Bit Complexity no. of
  bits
• Time complexity For synchronous systems, no. of
  rounds. For asynchronous systems, different
  definitions are there.

9
Some Fundamental Problems

• Ordering events in the absence of a global clock
• Capturing the global state
• Mutual exclusion
• Leader election
• Clock synchronization
• Termination detection
• Constructing spanning trees
• Agreement protocols

10

• Ordering of Events and
• Logical Clocks

11
Ordering of Events

• Lamports Happened Before relationship
• For two events a and b, a ? b if
• a and b are events in the same process and a
  occurred before b
• a is a send event of a message m and b is the
  corresponding receive event at the destination
  process
• a ? c and c ? b for some event c

12

• a ? b implies a is a potential cause of b
• Causal ordering potential dependencies
• Happened Before relationship causally orders
  events
• If a ? b, then a causally affects b
• If a ? b and b ? a, then a and b are concurrent (
  a b)

13
Logical Clock

• Each process i keeps a clock Ci.
• Each event a in i is timestamped C(a), the value
  of Ci when a occured
• Ci is incremented by 1 for each event in i
• In addition, if a is a send of message m from
  process i to j, then on receive of m,
• Cj max(Cj, C(a)1)

14

• Points to note
• if a ? b, then C(a) lt C(b)
• ? is an irreflexive partial order
• Total ordering possible by arbitrarily ordering
  concurrent events by process numbers

15
Limitation of Lamports Clock

• a ? b implies C(a) lt C(b)
• BUT
• C(a) lt C(b) doesnt imply a ? b !!
• So not a true clock !!

16
Solution Vector Clocks

• Ci is a vector of size n (no. of processes)
• C(a) is similarly a vector of size n
• Update rules
• Cii for every event at process i
• if a is send of message m from i to j with vector
  timestamp tm, on receive of m
• Cjk max(Cjk, tmk) for all k

17

• For events a and b with vector timestamps ta and
  tb,
• ta tb iff for all i, tai tbi
• ta ? tb iff for some i, tai ? tbi
• ta tb iff for all i, tai tbi
• ta lt tb iff (ta tb and ta ? tb)
• ta tb iff (ta lt tb and tb lt ta)

18

• a ? b iff ta lt tb
• Events a and b are causally related iff ta lt tb
  or tb lt ta, else they are concurrent
• Note that this is still not a total order

19
Causal ordering of messages application of
vector clocks

• If send(m1)? send(m2), then every recipient of
  both message m1 and m2 must deliver m1 before
  m2.
• deliver when the message is actually given to
  the application for processing

20
Birman-Schiper-Stephenson Protocol

• To broadcast m from process i, increment Ci(i),
  and timestamp m with VTm Cii
• When j ? i receives m, j delays delivery of m
  until
• Cji VTmi 1 and
• Cjk VTmk for all k ? i
• Delayed messaged are queued in j sorted by vector
  time. Concurrent messages are sorted by receive
  time.
• When m is delivered at j, Cj is updated according
  to vector clock rule.

21
Problem of Vector Clock

• message size increases since each message needs
  to be tagged with the vector
• size can be reduced in some cases by only sending
  values that have changed

22

• Capturing Global State

23
Global State Collection

• Applications
• Checking stable properties, checkpoint
  recovery
• Issues
• Need to capture both node and channel states
• system cannot be stopped
• no global clock

24

• Some notations
• LSi local state of process i
• send(mij) send event of message mij from
  process i to process j
• rec(mij) similar, receive instead of send
• time(x) time at which state x was recorded
• time (send(m)) time at which send(m) occured

25

• send(mij) ? LSi iff
• time(send(mij)) lt time(LSi)
• rec(mij) ? LSj iff
• time(rec(mij)) lt time(LSj)
• transit(LSi,LSj) mij send(mij) ? LSi and
  rec(mij) ? LSj
• inconsistent(LSi, LSj) mij send(mij) ? LSi
  and rec(mij) ? LSj

26

• Global state collection of local states
• GS LS1, LS2,, LSn
• GS is consistent iff
• for all i, j, 1 i, j n,
• inconsistent(LSi, LSj) ?
• GS is transitless iff
• for all i, j, 1 i, j n,
• transit(LSi, LSj) ?
• GS is strongly consistent if it is consistent and
  transitless.

27
Chandy-Lamports Algorithm

• Uses special marker messages.
• One process acts as initiator, starts the state
  collection by following the marker sending rule
  below.
• Marker sending rule for process P
• P records its state then for each outgoing
  channel C from P on which a marker has not been
  sent already, P sends a marker along C before any
  further message is sent on C

28

• When Q receives a marker along a channel C
• If Q has not recorded its state then Q records
  the state of C as empty Q then follows the
  marker sending rule
• If Q has already recorded its state, it records
  the state of C as the sequence of messages
  received along C after Qs state was recorded and
  before Q received the marker along C

29

• Points to Note
• Markers sent on a channel distinguish messages
  sent on the channel before the sender recorded
  its states and the messages sent after the sender
  recorded its state
• The state collected may not be any state that
  actually happened in reality, rather a state that
  could have happened
• Requires FIFO channels
• Network should be strongly connected (works
  obviously for connected, undirected also)
• Message complexity O(E), where E no. of links

30
Lai and Youngs Algorithm

• Similar to Chandy-Lamports, but does not require
  FIFO
• Boolean value X at each node, False indicates
  state is not recorded yet, True indicates
  recorded
• Value of X piggybacked with every application
  message
• Value of X distinguishes pre-snapshot and
  post-snapshot messages, similar to the Marker

31

• Mutual Exclusion

32
Mutual Exclusion

• very well-understood in shared memory systems
• Requirements
• at most one process in critical section (safety)
• if more than one requesting process, someone
  enters (liveness)
• a requesting process enters within a finite time
  (no starvation)
• requests are granted in order (fairness)

33
Classification of Distributed Mutual Exclusion
Algorithms

• Non-token based/Permission based
• Permission from all processes e.g. Lamport,
  Ricart-Agarwala, Raicourol-Carvalho etc.
• Permission from a subset ex. Maekawa
• Token based
• ex. Suzuki-Kasami

34
Some Complexity Measures

• No. of messages/critical section entry
• Synchronization delay
• Response time
• Throughput

35
Lamports Algorithm

• Every node i has a request queue qi, keeps
  requests sorted by logical timestamps (total
  ordering enforced by including process id in the
  timestamps)
• To request critical section
• send timestamped REQUEST (tsi, i) to all other
  nodes
• put (tsi, i) in its own queue
• On receiving a request (tsi, i)
• send timestamped REPLY to the requesting node i
• put request (tsi, i) in the queue

36

• To enter critical section
• i enters critical section if (tsi, i) is at the
  top if its own queue, and i has received a
  message (any message) with timestamp larger than
  (tsi, i) from ALL other nodes.
• To release critical section
• i removes it request from its own queue and sends
  a timestamped RELEASE message to all other nodes
• On receiving a RELEASE message from i, is
  request is removed from the local request queue

37

• Some points to note
• Purpose of REPLY messages from node i to j is to
  ensure that j knows of all requests of i prior to
  sending the REPLY (and therefore, possibly any
  request of i with timestamp lower than js
  request)
• Requires FIFO channels.
• 3(n 1 ) messages per critical section
  invocation
• Synchronization delay max. message transmission
  time
• requests are granted in order of increasing
  timestamps

38
Ricart-Agarwala Algorithm

• Improvement over Lamports
• Main Idea
• node j need not send a REPLY to node i if j has a
  request with timestamp lower than the request of
  i (since i cannot enter before j anyway in this
  case)
• Does not require FIFO
• 2(n 1) messages per critical section invocation
• Synchronization delay max. message transmission
  time
• requests granted in order of increasing
  timestamps

39

• To request critical section
• send timestamped REQUEST message (tsi, i)
• On receiving request (tsi, i) at j
• send REPLY to i if j is neither requesting nor
  executing critical section or if j is requesting
  and is request timestamp is smaller than js
  request timestamp. Otherwise, defer the request.
• To enter critical section
• i enters critical section on receiving REPLY from
  all nodes
• To release critical section
• send REPLY to all deferred requests

40
Roucairol-Carvalho Algorithm

• Improvement over Ricart-Agarwala
• Main idea
• once i has received a REPLY from j, it does not
  need to send a REQUEST to j again unless it sends
  a REPLY to j (in response to a REQUEST from j)
• no. of messages required varies between 0 and 2(n
  1) depending on request pattern
• worst case message complexity still the same

41
Maekawas Algorithm

• Permission obtained from only a subset of other
  processes, called the Request Set (or Quorum)
• Separate Request Set Ri for each process i
• Requirements
• for all i, j Ri n Rj ? F
• for all i i ? Ri
• for all i Ri K, for some K
• any node i is contained in exactly D Request
  Sets, for some D
• K D sqrt(N) for Maekawas

42

• A simple version
• To request critical section
• i sends REQUEST message to all process in Ri
• On receiving a REQUEST message
• send a REPLY message if no REPLY message has been
  sent since the last RELEASE message is received.
  Update status to indicate that a REPLY has been
  sent. Otherwise, queue up the REQUEST
• To enter critical section
• i enters critical section after receiving REPLY
  from all nodes in Ri

43

• To release critical section
• send RELEASE message to all nodes in Ri
• On receiving a RELEASE message, send REPLY to
  next node in queue and delete the node from the
  queue. If queue is empty, update status to
  indicate no REPLY message has been sent.

44

• Message Complexity 3sqrt(N)
• Synchronization delay
• 2 (max message transmission time)
• Major problem DEADLOCK possible
• Need three more types of messages (FAILED,
  INQUIRE, YIELD) to handle deadlock. Message
  complexity can be 5sqrt(N)
• Building the request sets?

45
Token based Algorithms

• Single token circulates, enter CS when token is
  present
• No FIFO required
• Mutual exclusion obvious
• Algorithms differ in how to find and get the
  token
• Uses sequence numbers rather than timestamps to
  differentiate between old and current requests

46
Suzuki Kasami Algorithm

• Broadcast a request for the token
• Process with the token sends it to the requestor
  if it does not need it
• Issues
• Current vs. outdated requests
• determining sites with pending requests
• deciding which site to give the token to

47

• The token
• Queue (FIFO) Q of requesting processes
• LN1..n sequence number of request that j
  executed most recently
• The request message
• REQUEST(i, k) request message from node i for
  its kth critical section execution
• Other data structures
• RNi1..n for each node i, where RNij is the
  largest sequence number received so far by i in a
  REQUEST message from j.

48

• To request critical section
• If i does not have token, increment RNii and
  send REQUEST(i, RNii) to all nodes
• if i has token already, enter critical section if
  the token is idle (no pending requests), else
  follow rule to release critical section
• On receiving REQUEST(i, sn) fat j
• set RNji max(RNji, sn)
• if j has the token and the token is idle, send it
  to i if RNji LNi 1. If token is not idle,
  follow rule to release critical section

49

• To enter critical section
• enter CS if token is present
• To release critical section
• set LNi RNii
• For every node j which is not in Q (in token),
  add node j to Q if RNi j LN j 1
• If Q is non empty after the above, delete first
  node from Q and send the token to that node

50

• Points to note
• No. of messages 0 if node holds the token
  already, n otherwise
• Synchronization delay 0 (node has the token) or
  max. message delay (token is elsewhere)
• No starvation

51
Raymonds Algorithm

• Forms a directed tree (logical) with the
  token-holder as root
• Each node has variable Holder that points to
  its parent on the path to the root. Roots Holder
  variable points to itself
• Each node i has a FIFO request queue Qi

52

• To request critical section
• Send REQUEST to parent on the tree, provided i
  does not hold the token currently and Qi is
  empty. Then place request in Qi
• When a non-root node j receives a request from i
• place request in Qj
• send REQUEST to parent if no previous REQUEST
  sent

53

• When the root receives a REQUEST
• send the token to the requesting node
• set Holder variable to point to that node
• When a node receives the token
• delete first entry from the queue
• send token to that node
• set Holder variable to point to that node
• if queue is non-empty, send a REQUEST message to
  the parent (node pointed at by Holder variable)

54

• To execute critical section
• enter if token is received and own entry is at
  the top of the queue delete the entry from the
  queue
• To release critical section
• if queue is non-empty, delete first entry from
  the queue, send token to that node and make
  Holder variable point to that node
• If queue is still non-empty, send a REQUEST
  message to the parent (node pointed at by Holder
  variable)

55

• Points to note
• Avg. message complexity O(log n)
• Sync. delay (T log n)/2, where T max. message
  delay

56
Leader Election
57
Leader Election in Rings

• Models
• Synchronous or Asynchronous
• Anonymous (no unique id) or Non-anonymous (unique
  ids)
• Uniform (no knowledge of n, the number of
  processes) or non-uniform (knows n)
• Known Impossibility Result
• There is no Synchronous, non-uniform leader
  election protocol for anonymous rings
• Implications ??

58
Election in Asynchronous Rings

• Lelann-Chang-Roberts Algorithm
• send own id to node on left
• if an id received from right, forward id to left
  node only if received id greater than own id,
  else ignore
• if own id received, declares itself leader
• works on unidirectional rings
• message complexity ?(n2)

59

• Hirschberg-Sinclair Algorithm
• operates in phases, requires bidirectional ring
• In kth phase, send own id to 2k processes on
  both sides of yourself (directly send only to
  next processes with id and k in it)
• if id received, forward if received id greater
  than own id, else ignore
• last process in the chain sends a reply to
  originator if its id less than received id
• replies are always forwarded
• A process goes to (k1)th phase only if it
  receives a reply from both sides in kth phase
• process receiving its own id declare itself
  leader

60

• Message Complexity O(nlgn)
• Lots of other algorithms exist for rings
• Lower Bound Result
• Any comparison-based leader election algorithm in
  a ring requires ?(nlgn) messages
• What if not comparison-based?

61
Leader Election in Arbitrary Networks

• FloodMax
• synchronous, round-based
• at each round, each process sends the max. id
  seen so far (not necessarily its own) to all its
  neighbors
• after diameter no. of rounds, if max. id seen
  own id, declares itself leader
• Complexity O(d.m), where d diameter of the
  network, m no. of edges
• does not extend to asynchronous model trivially
• Variations of building different types of
  spanning trees with no pre-specified roots.
  Chosen root at the end is the leader (Ex., the
  DFS spanning tree algorithm we covered earlier)

62

• Clock Synchronization

63
Clock Synchronization

• Multiple machines with physical clocks. How can
  we keep them more or less synchronized?
• Internal vs. External synchronization
• Perfect synchronization not possible because of
  communication delays
• Even synchronization within a bound can not be
  guaranteed with certainty because of
  unpredictability of communication delays.
• But still useful !! Ex. Kerberos, GPS

64
How clocks work

• Computer clocks are crystals that oscillate at a
  certain frequency
• Every H oscillations, the timer chip interrupts
  once (clock tick). No. of interrupts per second
  is typically 18.2, 50, 60, 100 can be higher,
  settable in some cases
• The interrupt handler increments a counter that
  keeps track of no. of ticks from a reference in
  the past (epoch)
• Knowing no. of ticks per second, we can calculate
  year, month, day, time of day etc.

65
Clock Drift

• Unfortunately, period of crystal oscillation
  varies slightly
• If it oscillates faster, more ticks per real
  second, so clock runs faster similar for slower
  clocks
• For machine p, when correct reference time is t,
  let machine clock show time as C Cp(t)
• Ideally, Cp(t) t for all p, t
• In practice,
• 1 ? dC/dt 1 ?
• ? max. clock drift rate, usually around 10-5
  for cheap oscillators
• Drift gt Skew between clocks (difference in clock
  values of two machines)

66
Resynchronization

• Periodic resynchronization needed to offset skew
• If two clocks are drifting in opposite
  directions, max. skew after time t is 2 ? t
• If application requires that clock skew lt d, then
  resynchronization period
• r lt d /(2 ?)
• Usually ? and d are known

67
Cristians Algorithm

• One m/c acts as the time server
• Each m/c sends a message periodically (within
  resync. period r) asking for current time
• Time server replies with its time
• Sender sets its clock to the reply
• Problems
• message delay
• time server time is less than senders current
  time

68

• Handling message delay try to estimate the time
  the message with the timer servers time took to
  each the sender
• measure round trip time and halve it
• make multiple measurements of round trip time,
  discard too high values, take average of rest
• make multiple measurements and take minimum
• use knowledge of processing time at server if
  known
• Handling fast clocks
• do not set clock backwards slow it down over a
  period of time to bring in tune with servers
  clock

69
Berkeley Algorithm

• Centralized as in Cristians, but the time server
  is active
• time server asks for time of other m/cs at
  periodic intervals
• time server averages the times and sends the new
  time to m/cs
• M/cs sets their time (advances immediately or
  slows down slowly) to the new time
• Estimation of transmission delay as before

70
External Synchronization

• Clocks must be synchronized with real time
• Cristians algorithm can be used if the time
  server is synchronized with real time somehow
• Berkeley algorithm cannot be used
• But what is real time anyway?

71
Measurement of time

• Astronomical
• traditionally used
• based on earths rotation around its axis and
  around the sun
• solar day interval between two consecutive
  transits of the sun
• solar second 1/86,400 of a solar day
• period of earths rotation varies, so solar
  second is not stable
• mean solar second average length of large no of
  solar days, then divide by 86,400

72

• Atomic
• based on the transitions of Cesium 133 atom
• 1 sec. time for 9,192,631,770 transitions
• about 50 labs maintain Cesium clock
• International Atomic Time (TAI) mean no. of
  ticks of the clocks since Jan 1, 1958
• highly stable
• But slightly off-sync with mean solar day (since
  solar day is getting longer)
• A leap second inserted approx. occasionally to
  bring it in sync. (so far 32, all positive)
• Resulting clock is called UTC Universal
  Coordinated Time

73

• UTC time is broadcast from different sources
  around the world, ex.
• National Institute of Standards Technology
  (NIST) runs radio stations, most famous being
  WWV, anyone with a proper receiver can tune in
• United States Naval Observatory (USNO) supplies
  time to all defense sources, among others
• National Physical Laboratory in UK
• GPS satellites
• Many others

74
NTP Network Time Protocol

• Protocol for time sync. in the internet
• Hierarchical architecture
• primary time servers (stratum 1) synchronize to
  national time standards via radio, satelite etc.
• secondary servers and clients (stratum 2, 3,)
  synchronize to primary servers in a hierrachical
  manner (stratum 2 servers sync. with stratum 1,
  startum 3 with stratum 2 etc.).

75

• Reliability ensured by redundant servers
• Communication by multicast (usually within LAN
  servers), symmetric (usually within multiple
  geographically close servers), or client server
  (to higher stratum servers)
• Complex algorithms to combine and filter times
• Sync. possible to within tens of milliseconds for
  most machines
• But, just a best-effort service, no guarantees
• RFC 1305 and www.eecis.udel.edu/ntp/ for more
  details

76

• Termination Detection

77
Termination Detection

• Model
• processes can be active or idle
• only active processes send messages
• idle process can become active on receiving an
  computation message
• active process can become idle at any time
• termination all processes are idle and no
  computation message are in transit
• Can use global snapshot to detect termination
  also

78
Huangs Algorithm

• One controlling agent, has weight 1 initially
• All other processes are idle initially and has
  weight 0
• Computation starts when controlling agent sends a
  computation message to a process
• An idle process becomes active on receiving a
  computation message
• B(DW) computation message with weight DW. Can
  be sent only by the controlling agent or an
  active process
• C(DW) control message with weight DW, sent by
  active processes to controlling agent when they
  are about to become idle

79

• Let current weight at process W
• Send of B(DW)
• Find W1, W2 such that W1 gt 0, W2 gt 0, W1 W2 W
• Set W W1 and send B(W2)
• Receive of B(DW)
• W DW
• if idle, become active
• Send of C(DW)
• send C(W) to controlling agent
• Become idle
• Receive of C(DW)
• W DW
• if W 1, declare termination

80

• Building Spanning Trees

81
Building Spanning Trees

• Applications
• Broadcast
• Convergecast
• Leader election
• Two variations
• from a given root r
• root is not given a-priori

82

• Flooding Algorithm
• starts from a given root r
• r initiates by sending message M to all
  neighbours, sets its own parent to nil
• For all other nodes, on receiving M from i for
  the first time, set parent to i and send M to all
  neighbors except i. Ignore any M received after
  that
• Tree built is an arbitrary spanning tree
• Message complexity
• 2m (n -1) where m no of edges
• Time complexity ??

83
Constructing a DFS tree with given root

• plain parallelization of the sequential algorithm
  by introducing synchronization
• each node i has a set unexplored, initially
  contains all neighbors of i
• A node i (initiated by the root) considers nodes
  in unexplored one by one, sending a neighbor j a
  message M and then waiting for a response (parent
  or reject) before considering the next node in
  unexplored
• if j has already received M from some other node,
  j sends a reject to i

84

• else, j sets i as its parent, and considers nodes
  in its unexplored set one by one
• j will send a parent message to i only when it
  has considered all nodes in its unexplored set
• i then considers the next node in its unexplored
  set
• Algorithm terminates when root has received
  parent or reject message from all its neighbours
• Worst case no. of messages 4m
• Time complexity O(m)

85
What if no root given?

• Main idea
• Nodes have unique ids
• A node starts building the DFS tree with itself
  as root (a single node fragment) spontaneously as
  in the previous case
• Fragments of the spanning tree gets built in
  parallel, all nodes in each fragment is
  identified by the id of its root
• M carries the fragment id of the sender

86

• when M sent from node in lower id fragment to
  node in higher id fragment, lower id fragment is
  stalled by higher id fragment by not giving a
  response
• When M sent from higher to lower id fragment,
  node in lower id fragment switches parent to node
  in higher id tree, resets unexplored, and starts
  DFS again
• Eventually, the highest id node becomes the root
  (leader election!!)
• Message complexity O(mn) !!
• Time complexity O(m)

87
What about MSTs??

• Gallager-Humblet-Spira Algorithm
• much more complex! but similar to Kruskals
• no root given, edge weights assumed to be
  distinct
• MST built up in fragments (subtree of MST)
• initially each node in its own fragment
• fragments merge, finally just one fragment
• outgoing edge edge that goes between two
  fragments
• known result min. wt. outgoing edge of a
  fragment always in MST

88

• Issues
• How does a node find its min. wt. outgoing edge?
• How does a fragment finds its min. wt. outgoing
  edge?
• When does two fragments merge?
• How does two fragments merge?

89
Some definitions

• Each node has three states
• Sleeping initial state
• Find currently finding the fragments min. wt.
  outgoing edge
• Found found the min. wt. outgoing edge
• Each fragment has a level
• initially, each node is in a fragment of level 0

90
Merging rule for fragments

• Suppose F is a fragment with id X, level L, and
  min. wt. outgoing edge e. Let fragment at other
  end of e be F1, with id X1 and level L1. Then
• if L lt L1, F merges into F1, new fragment has id
  X1, level L1
• if LL1, and e is also the min. wt. outgoing edge
  for F1, then F and F1 merges new fragment has id
  X2 weight of e, and level L 1 e is called
  the core edge
• otherwise, F waits until one of the above becomes
  true

91
How to find min. wt. outgoing edge of a fragment

• nodes on core edge broadcasts initiate message to
  all fragment nodes along fragment edges contains
  level and id
• on receiving initiate, a node find its min. wt.
  outgoing edge (in Find state) how?
• nodes send Report message with min. wt. edge up
  towards the core edge along fragment edges (and
  enters Found state)
• leafs send their min. wt. outgoing edge,
  intermediate nodes send the min. of their min.
  wt. outgoing edge and min. edge sent by children
  in fragment path info to best edge kept
• when Report reaches the nodes on the core edge,
  min. wt. outgoing edge of the fragment is known.

92
What then???

• nodes on core edges send Change_core message to
  node i with min. wt. outgoing edge
• node i then sends a Connect message to node j at
  other end with its level
• If js fragment level is greater than is,
  initiate message sent from j to i. This updates
  level and id of all nodes in js old fragment if
  j has not sent a Report message yet, nodes in is
  old fragment starts finding its min. wt. outgoing
  edge, else not.
• if js fragment level is less, no response sent
  and i just waits till js fragment id becomes
  higher
• if fragment ids match and j sends Connect to i
  also, merge into a level L1 fragment with new
  core edge and id, and send initiate message

93

• some more details skipped, read paper
• Algo. terminates when no outgoing edge found for
  a fragment
• Worst case message complexity O(n log n m)

94

• Fault Tolerance
• and
• Recovery

95
Fault Tolerance Recovery

• Classification of faults
• based on component that failed
• program/process
• processor/machine
• link
• storage
• clock
• based on behavior of faulty component
• Crash just halts
• Failstop crash with additional conditions
• Omission fails to perform some steps
• Byzantine behaves arbitrarily
• Timing violates timing constraints

96

• Types of tolerance
• Masking system always behaves as per
  specifications even in presence of faults
• Non-masking system may violate specifications
  in presence of faults. Should at least behave in
  a well-defined manner
• Fault tolerant system should specify
• Class of faults tolerated
• what tolerance is given from each class

97

• Some building blocks (assumptions/primitives that
  help in designing fault tolerant systems)
• Agreement (multiple processes agree on some
  value)
• Clock synchronization
• Stable storage (data accessible after crash)
• Reliable communication (point-to-point,
  broadcast, multicast)
• Atomic actions

98
Agreement Problems

• Model
• total n processes, at most m of which can be
  faulty
• reliable communication medium
• fully connected
• receiver always knows the identity of the sender
  of a message
• byzantine faults
• synchronous system. In each round, a process
  receives messages, performs computation, and
  sends messages.

99
Different problem variations

• Byzantine agreement (or Byzantine Generals
  problem)
• one process x broadcasts a value v
• all nonfaulty processes must agree on a common
  value (Agreement condition).
• The agreed upon value must be v if x is nonfaulty
  (Validity condition)
• Consensus
• Each process broadcasts its initial value
• satisfy agreement condition
• If initial value of all nonfaulty processes is v,
  then the agreed upon value must be v

100

• Interactive Consistency
• Each process i broadcasts its own value vi
• all nonfaulty processes agree on a common vector
  (v1, v2,,vn)
• If the ith process is nonfaulty, then the ith
  value in the vector agreed upon by nonfaulty
  processes must be vi
• Solution to Byzantine agreement problem implies
  solution to other two

101
Byzantine Agreement Problem

• no solution possible if
• asynchronous system, or
• n lt (3m 1)
• needs at least (m1) rounds of message exchange
  (lower bound result)
• Oral messages messages can be forged/changed
  in any manner, but the receiver always knows the
  sender

102
Lamport-Shostak-Pease Algorithm

• Recursively defined
• OM(m), m gt 0
• Source x broadcasts value to all processes
• Let vi value received by process i from source
  (0 if no value received). Process i acts as a new
  source and initiates OM(m -1), sending vi to
  remaining (n - 2) processes
• For each i, j, i ? j, let vj value received by
  process i from process j in step 2 using O(m-1).
  Process i uses the value majority(v1, v2, , vn
  -1)

103

• OM(0)
• Source x broadcasts value to all processes
• Each process uses the value if no value
  received, 0 is used
• Time complexity m1 rounds
• Message Complexity O(nm)
• You can reduce message complexity to polynomial
  by increasing time

104
Atomic Actions and Commit Protocols

• An action may have multiple subactions executed
  by different processes at different nodes of a
  distributed system
• Atomic action either all subactions are done or
  none are done (all-or-nothing property/ global
  atomicity property) as far as system state is
  concerned
• Commit protocols protocols for enforcing global
  atomicity property

105
Two-Phase Commit

• Assumes the presence of write-ahead log at each
  process to recover from local crashes
• One process acts as coordinator
• Phase 1
• coordinator sends COMMIT_REQUEST to all processes
• waits for replies from all processes
• on receiving a COMMIT_REQUEST, a process, if the
  local transaction is successful, writes Undo/redo
  logs in stable storage, and sends an AGREED
  message to the coordinator. Otherwise, sends an
  ABORT

106

• Phase 2
• If all processes reply AGREED, coordinator writes
  COMMIT record into the log, then sends COMMIT to
  all processes. If at least one process has
  replied ABORT, coordinator sends ABORT to all.
  Coordinator then waits for ACK from all
  processes. If ACK is not received within timeout
  period, resend. If all ACKs are received,
  coordinator writes COMPLETE to log
• On receiving a COMMIT, a process releases all
  resources/locks, and sends an ACK to coordinator
• On receiving an ABORT, a process undoes the
  transaction using Undo log, releases all
  resources/locks, and sends an ACK

107

• Ensures global atomicity either all processes
  commit or all of them aborts
• Resilient to crash failures (see text for
  different scenarios of failure)
• Blocking protocol crash of coordinator can
  block all processes
• Non-blocking protocols possible ex., Three-Phase
  Commit protocol we will not discuss in this class

108
Checkpointing Rollback Recovery

• Error recovery
• Forward error recovery assess damage due to
  faults exactly and repair the erroneous part of
  the system state
• less overhead but hard to assess effect of faults
  exactly in general
• Backward error recovery on a fault, restore
  system state to a previous error-free state and
  restart from there
• costlier, but more general, application-independen
  t technique

109

• Checkpoint and Rollback Recovery a form of
  backward error recovery
• Checkpoint
• local checkpoint local state of a process saved
  in stable storage for possible rollback on a
  fault
• global checkpoint collection of local
  checkpoints, one from each process
• Consistent and Strongly Consistent Global
  Checkpoint similar to consistent and strongly
  consistent global state respectively (Also called
  recovery line)

110

• Orphan message a message whose receive is
  recorded in some local checkpoint of a global
  checkpoint but send is not recorded in any local
  checkpoint in that global checkpoint ( Note A
  consistent global checkpoint cannot have an
  orphan message)
• Lost message a message whose send is recorded
  but receive is not in a global checkpoint
• Is lost messages a problem??
• not if unreliable channels assumed (since
  messages can be lost anyway)
• if reliable channels assumed, need to handle this
  properly! Cannot lose messages !
• We will assume unreliable channels for simplicity

111
Performance measures for a checkpointing and
recovery algorithm

• during fault-free operation
• checkpointing time
• space for storing checkpoints and messages (if
  needed)
• in case of a fault
• recovery time (time to establish recovery line)
• extent of rollback (how far in the past did we
  roll back? how much computation is lost?)
• is output commit problem handled? (if an output
  was sent out before the fault, say cash dispensed
  at a teller m/c, it should not be resent after
  restarting after the fault)

112
Some parameters that affect performance

• Checkpoint interval (time between two successive
  checkpoints)
• Number of processes
• Communication pattern of the application
• Fault frequency
• Nature of stable storage

113
Classification of Checkpoint Recovery Algorithms

• Asynchronous/Uncoordinated
• every process takes local checkpoint
  independently
• to recover from a fault in one process, all
  processes coordinate to find a consistent global
  checkpoint from their local checkpoints
• very low fault-free overhead, recovery overhead
  is high
• Domino effect possible (no consistent global
  checkpoint exist, so all processes have to
  restart from scratch)
• higher space requirements, as all local
  checkpoints need to be kept
• Good for systems where fault is rare and
  inter-process communication is not too high (less
  chance of domino effect)

114

• Synchronous/Coordinated
• all processes coordinate to take a consistent
  global checkpoint
• during recovery, every process just rolls back to
  its last local checkpoint independently
• low recovery overhead, but high checkpointing
  overhead
• no domino effect possible
• low space requirement, since only last checkpoint
  needs to be stored at each process

115

• Communication Induced
• Synchronize checkpointing with communication,
  since message send/receive is the fundamental
  cause of inconsistency in global checkpoint
• Ex. take local checkpoint right after every
  send! Last local checkpoint at each process is
  always consistent. But too costly
• Many variations are there, more efficient than
  the above, we will not discuss them in this class.

116

• Message logging
• Take coordinated or uncoordinated checkpoint, and
  then log (in stable storage) all messages
  received since the last checkpoint
• On recovery, only the recovering process goes
  back to its last checkpoint, and then replays
  messages from the log appropriately until it
  reaches the state right before the fault
• Only class that can handle output commit problem!
• Details too complex to discuss in this class

117
Some Checkpointing Algorithms

• Asynchronous/Uncoordinated
• See Juang-Venkatesans algorithm in text, quite
  well-explained
• Synchronous/Coordinated
• Chandy-Lamports global state collection
  algorithm can be modified to handle recovery from
  faults
• See Koo-Touegs algorithm in text, quite
  well-explained

118
(No Transcript)
