WORLD LEADERS IN WIRELESS INSTRUMENTS

1

• WORLD LEADERS IN WIRELESS INSTRUMENTS

Micronet mn100-2Instrument Range
wired to wireless

better performance greater freedom
2
Setting up and Operating Tacktick Digital Display

• Note This presentation is to be used in
  conjunction with the user manual and in no way
  replaces the manual.

3
T110 - Digital Display

• Shows any single data type
• Fully programmable with 7 chapter settings giving
  up to 32 pages of information.
• Super large digits 38mm (1.5) high

4
Solar Power

• All Tacktick displays use solar power.
• The integrated solar panel charges the
  instruments lithium battery, which supplies
  power to the unit for life.
• Power consumption is so efficient that, when
  fully charged, units can run autonomously for up
  to 300 hours without any recharge. When using
  back lighting at night this will be reduced by
  about 1/3.

5
Solar charging
6
Display Information
7
Switching on and off.
The whole system will switch On and Off with the
one button press.
8
Backlighting.
Switching backlighting on and off.
9
Chapter Page
Access to information pages within the display
using the chapter and page format. Only
information on the bus will be available. There
are 32 pages. Pages not required can be turned
off.
10
Chapter Page
11
Chapter Page Format.
12
Race Timer
13
Race Performance Pages
14
Setting up Calibrating
15
Setting up Calibrating Pages
16
Setting up Calibrating Depth
17
Setting up Calibrating Speed
18
Setting up Calibrating Wind
19
Micronet Display pack contents

• All Supplied with
• Soft carrying case.
• 2 x dove tail brackets.
• 1 x mounting horse shoe bracket.
• Fixing screws for rear and front mount.
• Templates.
• Instructions.

20
Mounting the Displays

• Three mounting options
• Option 1
• 2 x Clip mounting brackets and 1 x Horseshoe
  bracket are supplied with each instrument. This
  allows for two mounting points enabling the
  instrument to be moved to alternate positions
  (e.g. above / below decks) or removed for winter
  storage.
• Template is provided for the mounting of the
  bracket.

21
Clip Mounting - Installation
22
Mounting the displays

• Option 2
• From the front
• Simple three screw fixing
• Bezel removal required
• DO NOT Over tighten
• Option3
• From the rear
• Three studs and thumb nuts provided
• Check for access
• DO NOT Over tighten

23
Digital Display Operation

• END.
• Note This presentation is a quick guide and is
  to be used in conjunction with the user manual
  and in no way replaces the manual.
• If in doubt read the manual!
