TCP and UDP

1
TCP and UDP
2
The Internet Transport Layer

• Two transport layer protocols supported by the
  Internet
• Reliable
• The Transport Control Protocol (TCP)
• Unreliable
• The Unreliable Datagram Protocol (UDP)

3
UDP

• UDP is an unreliable transport protocol that can
  be used in the Internet
• UDP does not provide
• connection management
• flow or error control
• guaranteed in-order packet delivery
• UDP is almost a null transport layer

4
Why UDP?

• No connection needs to be set up
• Throughput may be higher because UDP packets are
  easier to process, especially at the source
• The user doesnt care if the data is transmitted
  reliably
• The user wants to implement his or her own
  transport protocol

5
UDP Usage

• often used for streaming multimedia apps
• loss tolerant
• rate sensitive
• other UDP uses
• DNS
• SNMP
• reliable transfer over UDP add reliability at
  application layer
• application-specific error recovery!

6
UDP Frame Format
32 bits
Source Port
Destination Port
UDP length
UDP checksum (optional)
Data
7
UDP checksum

• Goal detect errors (e.g., flipped bits) in
  transmitted segment

• Sender
• treat segment contents as sequence of 16-bit
  integers
• checksum 1s complement of (1s complement sum
  of segment contents)
• sender puts checksum value into UDP checksum
  field

• Receiver
• compute checksum of received segment
• check if computed checksum equals checksum field
  value
• NO - error detected
• YES - no error detected. But maybe errors
  nonetheless? More later .

8
Internet Checksum Example

• Note
• When adding numbers, a carryout from the most
  significant bit needs to be added to the result
• Example add two 16-bit integers

1 1 1 1 0 0 1 1 0 0 1 1 0 0 1 1
0 1 1 1 0 1 0 1 0 1 0 1 0 1 0 1 0
1 1 1 0 1 1 1 0 1 1 1 0 1 1 1 0 1
1 1 1 0 1 1 1 0 1 1 1 0 1 1 1 1
0 0 1 0 1 0 0 0 1 0 0 0 1 0 0 0 0
1 1
Wraparound the carry
sum
Checksum (complement)
9
TCP

• TCP provides the end-to-end reliable connection
  that IP alone cannot support
• The protocol
• Connection management
• Retransmission
• Flow control
• Congestion control
• Frame format

10
Connection Management
11
TCP Connection Establishment

• Three-way Handshake

Host A
Host B
SYN (seqx)
SYN (seqy, ACKx1)
SYN (seqx1, ACKy1)
12
TCP Connection Tear-down

• Two double handshakes

Host A
Host B
FIN (seqx)
ACK (ACKx1)
A-gtB torn down
FIN (seqy)
ACK (ACKy1)
B-gtA torn down
13
Retransmission
14
TCP Retransmission

• When a packet remains unacknowledged for a period
  of time, TCP assumes it is lost and retransmits
  it
• TCP tries to calculate the round trip time (RTT)
  for a packet and its acknowledgement
• From the RTT, TCP can guess how long it should
  wait before timing out

15
Round Trip Time (RTT)
Time for data to arrive
Network
Time for ACK to return
RTT Time for packet to arrive at destination
Time for ACK to return from
destination
16
RTT Calculation
Receiver
Sender
0.9 sec
RTT
ACK 2048
2.2 sec
RTT 2.2 sec - 0.9 sec. 1.3 sec
17
Smoothing the RTT measurement

• First, we must smooth the round trip time due to
  variations in delay within the network
• SRTT a SRTT (1-a) RTTarriving ACK
• The smoothed round trip time (SRTT) weights
  previously received RTTs by the a parameter
• a is typically equal to 0.875

18
Retransmission Timeout Interval (RTO)

• The timeout value is then calculated by
  multiplying the smoothed RTT by some factor
  (greater than 1) called b
• Timeout b SRTT
• This coefficient of b is included to allow for
  some variation in the round trip times.

19
Example
Initial SRTT 1.50 a 0.875, b 4.0
RTT Meas.
SRTT
Timeout
1.5 s
1.50
b1.50 6.00
1.0 s
1.50a 1.0(1- a) 1.44
b1.44 5.76
2.2 s
1.44a 2.2(1- a) 1.54
b1.54 6.16
1.0 s
1.54a 1.0(1- a) 1.47
b1.47 5.88
0.8 s
1.47a 0.8(1- a) 1.39
b1.39 5.56
3.1 s
2.0 s
20
Problem with RTT Calculation
Receiver
Sender
Sender Timeout
RTT?
ACK 2048
RTT?
21
Karns Algorithm

• Retransmission ambiguity
• Measure RTT from original data segment
• Measure RTT from most recent segment
• Either way there is a problem in RTT estimate
• One solution
• Never update RTT measurements based on
  acknowledgements from retransmitted packets
• Problem Sudden change in RTT can cause system
  never to update RTT
• Primary path failure leads to a slower secondary
  path

22
Karns algorithm

• Use back-off as part of RTT computation
• Whenever packet loss, RTO is increased by a
  factor
• Use this increased RTO as RTO estimate for the
  next segment (not from SRTT)
• Only after an acknowledgment received for a
  successful transmission is the timer set to new
  RTT obtained from SRTT

23
Another Problem with RTT Calculation

• RTT measurements can sometimes fluctuate severely
• smoothed RTT (SRTT) is not a good reflection of
  round-trip time in these cases
• Solution Use Jacobson/Karels algorithm
• Error RTT - SRTT
• SRTT SRTT (a Error)
• Dev Dev h(Error - Dev)
• Timeout SRTT (b Dev)

24
Jacobson/Karels AlgorithmExample
Error RTT - SRTT SRTT SRTT (a Error) Dev
Dev d (Error - Dev) Timeout SRTT (b
Dev)
Initial SRTT 1.50, Dev 0 a 0.125, d 0.25,
b 4.0
RTT Meas.
SRTT
Error
Dev.
Timeout
1.5 s
1.50
0.0
0.00
1.50
1.0 s
1.44
-0.50
0.13
1.94
2.2 s
1.54
0.76
0.28
2.67
1.0 s
1.47
-0.54
0.35
2.85
0.8 s
1.39
-0.67
0.43
3.09
3.1 s
2.0 s
25
Flow Control
26
TCP Flow Control

• TCP uses a modified version of the sliding window
• In acknowledgements, TCP uses the Window size
  field to tell the sender how many bytes it may
  transmit
• TCP uses bytes, not packets, as sequence numbers

27
TCP Flow Control (contd)
Important information in TCP/IP packet headers
Number of bytes in packet (N)
Sequence number of first data byte in packet (SEQ)
N
SEQ
Send
Window size at the receiver (WIN)
Sequence number of next expected byte (ACK)
ACK bit set
ACK
WIN
Recv
Contained in TCP header
Contained in IP header
28
Example TCP session

• (1)remus tcpdump -S host scullyKernel
  filter, protocol ALL, datagram packet
  sockettcpdump listening on all devices
• 151522.152339 eth0 gt remus.4706 gt
  scully.echo S 12642965041264296504(0) win 32120
  ltmss 1460,sack OK,timestamp 71253512 0,nop,wscale
  0gt
• 151522.153865 eth0 lt scully.echo gt
  remus.4706 S 875676030875676030(0) ack
  1264296505 win 8760 ltmss 1460gt
• 151522.153912 eth0 gt remus.4706 gt
  scully.echo . 12642965051264296505(0) ack
  875676031 win 32120

remus telnet scully 7 A ltreturngt A
29
Example TCP session
Timestamp
Source IP/port
Dest IP/port
Packet 1 151522.152339 eth0 gt remus.4706 gt
scully.echo S 12642965041264296504(0) win 32120
ltmss 1460,sackOK,timestamp 71253512 0,nop,wscale
0gt (DF)
Flags
Packet 2 151522.153865 eth0 lt scully.echo gt
remus.4706 S 875676030875676030(0) ack
1264296505 win 8760 ltmss 1460)
Options
Packet 3 151522.153912 eth0 gt remus.4706 gt
scully.echo . 12642965051264296505(0) ack
875676031 win 32120
Window
Start Sequence Number
Acknowledgement Number
End Sequence Number
30
TCP data transfer
Packet 4151528.591716 eth0 gt remus.4706 gt
scully.echo P 12642965051264296508(3) ack
875676031 win 32120
data
Packet 5 151528.593255 eth0 lt scully.echo gt
remus.4706 P 875676031875676034(3) ack
1264296508 win 8760
bytes
31
TCP Flow Control (contd)
Receivers buffer
Receiver
Sender
Application does a 2K write
0
4K
Empty
ACK 2048 WIN 2048
Application does a 3K write
Full
Sender is blocked
Application reads 2K
ACK 4096 WIN 0
ACK 4096 WIN 2048
Sender may send up to 2K
32
TCP Flow Control (contd)
Piggybacking Allows more efficient
bidirectional communication
Data from A to B
ACK for data from B to A
N
SEQ
ACK
WIN
A
B
N
SEQ
ACK
WIN
Data from B to A
ACK for data from A to B
33
Congestion Control
34
Principles of Congestion Control

• Congestion
• informally too many sources sending too much
  data too fast for network to handle
• different from flow control!
• manifestations
• lost packets (buffer overflow at routers)
• long delays (queueing in router buffers)
• a top-10 problem!

35
TCP Congestion Control

• Recall Network layer is responsible for
  congestion control
• However, TCP/IP blurs the distinction
• In TCP/IP
• the network layer (IP) simply handles routing and
  packet forwarding
• congestion control is done end-to-end by TCP

36
TCP Congestion Control

• Goal fully (fairly) utilize the resource
  (bandwidth)
• Dont over use - congestion
• Dont under use - waste
• Goal achieve self-clocking state
• Even if dont know bandwidth of bottleneck
• Bottleneck may change over time

37
Self-Clocking Model
Bottleneck link
Pr
Fast link
Pb
1. Send Burst
2. Receive data packet
5. Send a data packet
Data
Receiver
Sender
Acks
4. Receive Acknowledgement
3. Send Acknowledgement
Ab
Ar
Ar
Given Pb Pr Ar Ab Ar (in units of time)
Sending a packet on each ACK keeps the
bottleneck link busy
38
TCP Congestion Window

• TCP introduces a second window, called the
  congestion window
• This window maintains TCPs best estimate of
  amount of outstanding data to allow in the
  network to achieve self-clocking
• Sending size min(congestion control window,
  flow control window)

39
TCP Congestion Control

• Two phases to keep bottleneck busy (fully utilize
  the resource)
• Increase the usage (window size) to keep probing
  the network
• Decrease the usage when congestion is detected

40
TCP Slow Start

• When connection begins, CongWin 1 MSS
• Example MSS 500 bytes
• available bandwidth may be gtgt MSS/RTT
• desirable to quickly ramp up to respectable rate
• Increase exponentially until first loss

• MSS - maximum segment size,
• the maximum size a TCP packet
• can be (including header)

41
TCP Slow Start (more)

• incrementing CongWin for every ACK received
• double CongWin every RTT
• initial rate is slow but ramps up
  exponentially fast

Host A
Host B
one segment
RTT
two segments
four segments
42
TCP Slow Start (contd)

• Congestion detection
• Packet losses
• Sender side Timeout
• Timeout
• the congestion window is reduced to 1 MSS
• everything starts over

43
TCP Slow Start (contd)
Timed out Transmissions
Congestion window
Inefficient, Low throughput
Transmission Number
1 MSS
44
TCP Linear Increase

• Dont push the network too fast
• Slow start (exponential)
• -gt Threshold -gt linear increase

45
TCP Linear Increase Algorithm

• Algorithm
• Start the threshold at 64K
• Slow start
• Once the threshold is passed
• For each ack received, cwnd cwnd
  (mssmss)/cwnd
• 1 MSS for each congestion window of data
  transmitted
• Timeout
• reset the congestion window size to 1 MSS
• Set threshold to max(2mss,1/2 of MIN(sliding
  window, congestion window))

46
TCP Linear Increase Threshold Phase
Example Maximum segment size 1K Assume
thresh32K
Timeout occurs when MIN(sliding window,
congestion window) 40K
Congestion window
Thresholds
40K
32K
20K
1K
Transmission Number
47
TCP Congestion Control

• Can we do better at detecting congestion than
  using timeout?
• Receiver send duplicate ack for out-of-order
  packets
• Possible loss?

48
TCP Fast Retransmit

• Idea When sender sees 3 duplicate ACKs, it
  assumes something went wrong
• The packet is immediately retransmitted instead
  of waiting for it to timeout

49
TCP Fast RetransmitExample
Receiver
Sender
MSS 1K
ACK of new data
ACK 2048 WIN 31K
Duplicate ACK 1
ACK 2048 WIN 30K
Duplicate ACK 2
ACK 2048 WIN 29K
Fast Retransmit occurs (2nd packet is
now retransmitted w/o waiting for it to timeout)
Duplicate ACK 3
ACK 2048 WIN 28K
ACK 2048 WIN 27K
ACK 7168 WIN 26K
50
TCP fast recovery

• Duplicate Acks are better than Timeouts
• Data are still getting across
• Too conservative for CW to go back to 1 MSS for
  duplicate Acks?

51
TCP Fast Recovery

• Idea Dont do a slow start after a fast
  retransmit
• Instead
• threshold -gt max(2mss,1/2 of MIN(sliding window,
  congestion window))
• congestion window -gt threshold 3 MSS
• For each duplicate ACK (after the fast
  retransmit) -gt increment congestion window by MSS
• When next non-duplicate ACK arrives -gt set
  congestion window equal to the threshold, start
  linear increase

52
TCP Fast RecoveryExample
Sender
SW29K,TH15K, CW20K
Continuing with the Fast Retransmit Example...
SW28K,TH15K, CW20K
ACK 2048 WIN 28K
Fast Retransmit Occurs
MSS1K Sliding Window (SW) Congestion Threshold
(TH) Congestion Window (CW)
SW28K, TH10K, CW13K
ACK 2048 WIN 27K
SW27K, TH10K, CW14K
ACK 7168 WIN 26K
SW26K, TH10K, CW10K
53
Resulting TCP Sawtooth
In steady state, window oscillates around the
bottlenecks capacity (I.e. number of
outstanding bytes in transit)
Congestion window
Slow Start
Bottleneck Capacity
Linear Mode
40K
Sawtooth
32K
20K
1K
Transmission Number
54
TCP Recap

• Timeout Computation
• Timeout is a function of 2 values
• the weighted average of sampled RTTs
• The sampled variance of each RTT
• Congestion control
• Goal Keep the self-clocking pipe full in spite
  of changing network conditions
• 3 key Variables
• Sliding window (Receiver flow control)
• Congestion window (Sender flow control)
• Threshold (Senders slow start vs. linear mode
  line)

55
TCP Recap (cont)

• Slow start
• Add 1 segment for each ACK to the congestion
  window
• -Doubles the congestion windows volume each
  RTT
• Linear mode (Congestion Avoidance)
• Add 1 segments worth of data to each congestion
  window
• Adds 1 segment per RTT

56
Algorithm Summary TCP Congestion Control

• When CongWin is below Threshold, sender in
  slow-start phase, window grows exponentially.
• When CongWin is above Threshold, sender is in
  congestion-avoidance phase, window grows
  linearly.
• When a triple duplicate ACK occurs, Threshold set
  to max(FlightSize/2,2mss) and CongWin set to
  Threshold3mss. (Fast retransmit, Fast recovery)
• When timeout occurs, Threshold set to
  max(FlightSize/2,2mss) and CongWin is set to 1
  MSS.
• FlightSize The amount of data that has been
  sent but not yet acknowledged.

57
TCP sender congestion control
58
TCP Fairness

• Fairness goal if K TCP sessions share same
  bottleneck link of bandwidth R, each should have
  average rate of R/K

59
Why is TCP fair?

• Two competing sessions
• Additive increase gives slope of 1, as throughout
  increases
• multiplicative decrease decreases throughput
  proportionally

R
equal bandwidth share
loss decrease window by factor of 2
Connection 2 throughput
congestion avoidance additive increase
Connection 1 throughput
R
60
Fairness (more)

• Fairness and UDP
• Multimedia apps often do not use TCP
• do not want rate throttled by congestion control
• Instead use UDP
• pump audio/video at constant rate, tolerate
  packet loss
• Research area TCP friendly

• Fairness and parallel TCP connections
• nothing prevents app from opening parallel
  connections between 2 hosts.
• Web browsers do this
• Example link of rate R supporting 9 connections

• new app asks for 1 TCP, gets rate R/10
• new app asks for 11 TCPs, gets R/2 !

61
TCP Frame Format
32 bits
Source Port
Destination Port
Sequence Number
Acknowledgement number
Window Size
HL
F I N
S Y N
R S T
P S H
A C K
U R G
Checksum
Urgent Pointer
Options (0 or more 32-bit words)
Data
62
TCP Frame Fields

• Source Destination Ports
• 16 bit port identifiers for each packet
• Sequence number
• The packets unique sequence ID
• Acknowledgement number
• The sequence number of the next packet expected
  by the receiver

63
TCP Frame Fields (contd)

• Window size
• Specifies how many bytes may be sent after the
  first acknowledged byte
• Checksum
• Checksums the TCP header and IP address fields
• Urgent Pointer
• Points to urgent data in the TCP data field

64
TCP Frame Fields (contd)

• Header bits
• URG Urgent pointer field in use
• ACK Indicates whether frame contains
  acknowledgement
• PSH Data has been pushed. It should be
  delivered to higher layers right away.
• RST Indicates that the connection should be
  reset
• SYN Used to establish connections
• FIN Used to release a connection

65
Delay modeling

• Q How long does it take to receive an object
  from a Web server after sending a request?
• Ignoring congestion, delay is influenced by
• TCP connection establishment
• data transmission delay
• slow start

• Notation, assumptions
• Assume one link between client and server of rate
  R
• S MSS (bits)
• O object size (bits)
• no retransmissions (no loss, no corruption)
• Window size
• First assume fixed congestion window, W segments
• Then dynamic window, modeling slow start

66
Fixed congestion window (1)

• First case
• WS/R gt RTT S/R ACK for first segment in window
  returns before windows worth of data sent

delay 2RTT O/R
67
Fixed congestion window (2)

• Second case
• WS/R lt RTT S/R wait for ACK after sending
  windows worth of data sent

delay 2RTT O/R (K-1)S/R RTT - WS/R
68
TCP Delay Modeling Slow Start (1)

• Now suppose window grows according to slow start

• Will show that the delay for one object is

where P is the number of times TCP idles at
server
- where Q is the number of times the server
idles if the object were of infinite size. -
and K is the number of windows that cover the
object.
69
TCP Delay Modeling Slow Start (2)

• Delay components
• 2 RTT for connection estab and request
• O/R to transmit object
• time server idles due to slow start
• Server idles P minK-1,Q times

• Example
• O/S 15 segments
• K 4 windows
• Q 2
• P minK-1,Q 2
• Server idles P2 times

70
TCP Delay Modeling (3)
71
TCP Delay Modeling (4)
Recall K number of windows that cover
object How do we calculate K ?
Calculation of Q, number of idles for
infinite-size object, is similar (see HW).
