Experience in Black-box OSPF Measurement

1
Experience in Black-box OSPF Measurement

• Aman Shaikh, UCSC
• Albert Greenberg, ATT Labs-Research
• Sigcomm IMW November 2001

2
Why Measure OSPF?

• OSPF behavior in large ISPs not well understood,
  yet
• any meaningful performance assurance depends on
  routing stability
• an internal network change (OSPF event) can have
  major impact on flows and customers, during which

• intra-domain routing reconverges
• inter-domain routing reconverges (BGP uses OSPF
  metrics)
• Internal OSPF processing delays matter!
• message processing, routing calculation, table
  update
• add up to impact convergence, instabilities
• OSPF measurements also needed for
• guidance in tuning configurable parameters
• head to head vendor comparisons

3
How to Measure OSPF?

• Problem Instrumenting routing code for measuring
  delays is challenging
• commercial implementations are proprietary
• may involve grappling with
• numerous code versions, hardware platforms, and
  developers
• Solution black-box measurements
• measure the timing delays using external
  observations
• Contribution black-box measurements for internal
  OSPF delays
• applied to Cisco and GateD OSPF implementations
• Key prior work
• IS-IS measurements by Packet Design
  draft-alaettinoglu-ISIS-convergence-00

4
Black-box Techniques are Effective

• Works across wide range of timing delays
• 100 ?sec for packet processing
• 10s of msec for routing calculation
• Works even for the purely CPU bound tasks
• packet processing subtasks, Dijkstras shortest
  path calculation
• Captures scaling
• O(n2) time for shortest path calculation, for
  full n ? n mesh topologies

5
OSPF Background

• Link-state routing protocol
• all routers in the domain come to a consistent
  view of the topology by exchange of Link State
  Advertisements (LSAs)
• set of LSAs (self-originated received) at a
  router topology
• SPF Calculation
• each router calculates a single source shortest
  path tree
• Forwarding Information Base (FIB)
• each router uses the tree to build its FIB, which
  governs packet forwarding

6
Link-state Advertisement (LSA)

• LSA propagation each router
• describes local connectivity in an LSA
• floods LSA to other routers in the domain
• acknowledges LSA in an LS Ack packet
• Duplicate LSAs each router
• can receive multiple copies of a given LSA
• first copy received is termed new
• copies received later are termed duplicate
• Duplicate LSAs MUST be acknowledged immediately
  (RFC2328)
• allows us to build a timestamp

7
Router Model
LSA Processing
Route Processor (CPU)
OSPF Process
LSA Flooding
Topology View
SPF Calculation
FIB Update
FIB
Forwarding
Forwarding
Switching Fabric
Interface card
Interface card
8
Methodology
Target router
TopTracker
Testbed

• Load emulated topology on target router

• Initiate task of interest

• Measure the time for task

9
Measuring Task Time

• Use a black-box method to bracket task start and
  finish times
• Subtract out intervals that precede and exceed
  these times

top bracket event
task start time
task finish time
bottom bracket event
X A - (BC)
10
Methodology for SPF Calculation
Initiator LSA arrives
SPF calculation starts
time
SPF calculation ends
Ack for duplicate LSA arrives

• X A (B C D E)
• Estimate the overhead B C D E

11
Estimating the Overhead

• Remove SPF calculation from bracket
• spf_delay 60 seconds

Initiator LSA arrives
Duplicate LSA arrives
time
Initiator LSA processing done
Ack for duplicate LSA arrives
SPF calculation starts
overhead B C D E
12
Results

• Results for Cisco GSR, 7513 and GateD
• for GateD, comparison of black-box results with
  those obtained using instrumentation (white-box)
• route processors
• Cisco 200 MHz R5000 processor
• GateD 500 MHz AMD-K6 processor
• Topology used is a full n ? n mesh with random
  OSPF edge weights
• vary n in the range 10, 20, , 100

13
Results for Cisco Routers

• Similar results for two models
• SPF calculation time is O(n2)

14
Results for GateD

• Black-box over-estimates white-box measurement
• Black-box captures the characteristics very well

15
OSPF Task Delays (Cisco)

• LSA Processing
• 100-800 microseconds
• LSA flooding
• 30-40 milliseconds
• pacing timer is the determining factor
• SPF calculation
• 1-40 milliseconds
• O(n2) behavior for full n x n mesh
• FIB update time
• 100-300 milliseconds
• no dependence on the size of the topology

16
Toolkit

• Use of topology emulator
• loads topologies
• generates specific patterns of LSAs
• Use of protocol dynamics mandated by standards
• duplicate LSA mechanism OSPF is required to ack
  a duplicate LSA immediately
• useful for estimating end-point of tasks like SPF
  calculation
• Use of vendor-specific parameters
• spf_delay
• spf_holdtime
• Pacing timer

17
Conclusions

• Black-box methods for estimating OSPF processing
  delays
• LSA processing and flooding
• SPF calculation and FIB Update
• Applied techniques to Cisco GSR and 7513 routers
  as well as GateD
• Black-box methods worked
• Future work
• develop techniques for other protocols, in
  particular BGP

18
Backup
19
OSPF Overview Example
A
A
1
1
B
B
1
1
1
1
1
E
D
D
E
C
C
1
1
1
2
1
1
1
G
3
F
F
G
2
1
2
1
I
H
I
H
1
1
1
J
J
SPT at G
OSPF Domain (single area)
20
LSA Processing
Receive an LSA
New/duplicate?
paced by hold-down timer (spf_delay)
21
SPF Calculation
LSA Processing over
22
Internal OSPF Tasks to Measure

• Processing Link State Advertisements (LSAs)
• Flooding LSAs
• Performing SPF calculation
• described in this talk
• Updating the Forwarding Information Base (FIB)
