Columbia Verizon Research Security: SIP Application Layer Gateway

1
Columbia Verizon Research SecuritySIP
Application Layer Gateway

• Eilon Yardeni
• Columbia University
• Gaston Ormazabal
• Verizon Labs

2
Agenda

• Team
• Project Overview
• Background
• What is the Problem
• Goals
• Technical Overview
• Hardware Platform
• Software Developed at Columbia
• Integrated Testing and Analysis Tool
• Large Scale Testing Environment
• Conclusions

3
Team

• Verizon
• Stu Elby, VP Architecture
• Jim Sylvester, VP Systems Integration and Testing
• Gaston Ormazabal

• Columbia
• Prof. Henning Schulzrinne
• Jonathan Lennox
• Kundan Singh
• Eilon Yardeni

4
Background

• Columbia likes to work in real life problems and
  analyze large data sets with the goal of
  improving generic architectures and testing
  methodologies
• Columbia has world-renowned expertise in SIP
• Verizon needs to solve a perimeter protection
  problem for security of VoIP Services
• Protocol Aware Application Layer Gateway
• Verizon needs to build a high powered test tool
  to verify performance and scalability of these
  security solutions at carrier class rates
• Security and Performance are a zero sum game

5
What is Dynamic Pinhole Filtering

• SIP calls are stateful
• RTP media ports are negotiated during signaling,
  assigned dynamically, and taken down
• SIP signaling is done over a static port5060
• INVITE message contains an SDP message indicating
  the callers incoming media port (e.g., 43564 )
• Response 200OK has SDP with the callees incoming
  media port
• Each port creates a pinhole in firewall
• Pinholes are kept open only until a BYE message
  signals closing of both pinholes
• Firewall must keep a state table with all active
  pinholes to check if an arriving RTP packet can
  enter through an open pinhole, otherwise drop
  packet

6
Example of Dynamic Pinhole Filtering
SIPUA User1
SIPUA User2
CAM Table
128.59.19.16343564
128.59.19.16356432
7
Project Goals

• Program SIP based dynamic pinhole filtering in a
  parallel processing hardware platform
• Build an integrated testing and analysis tool
  that will validate functionality and performance
  of above device at carrier-class rates
• Tool will provide automation of testing (script
  based)
• Apply testing tool to evaluate several Session
  Border Controllers on behalf of Verizon
• Perform comparative analysis of architectural
  models and develop architectural improvements
• Generalize testing methodology

8
Applicability to Columbia

• Hands on experience with SIP Application Layer
  Gateways
• Experience some SIP security related challenges
• Experiment with carrier class traffic and scale
  models
• Hands on experience with a state-of-the-art
  programmable packet processing hardware
• Enhance Columbias SIP Proxy with Firewall
  Control Proxy capabilities
• Formalize security benchmarking methodology for
  SIP ALGs

9
Applicability to Verizon

• Verizon needs this functionality to perform at
  high rates for use
• In the protection of highly valued network assets

• Session Border Controllers for Packet Telephony
• In the provision of security services to
  Enterprise customers for revenue
• VADS (SIP Application Layer Gateway)
• Verizon needs to verify in the lab the
  performance and scalability of this technology
  prior to introduction in the network

10
CS-2000 Physical Architecture
11
CloudShield Application Platform

• Applications written in RAVE and pushed to DPPM
• Dynamic Pinhole Implementation
• RAVE based
• Complex logic such as SIP call processing is
  difficult to implement in Regular Expressions
  (Regex)
• Support only a thin SIP functionality
• SIP Proxy controlling the DPPM (Midcom-like
  solution)
• Introduce SIP Proxy - DDPM data exchange problem
• Solved by using a Firewall Control Protocol
• Columbia developed a breakthrough solution that
  allowed to use SIP Proxy with performance equal
  to the thin SIP-RAVE
• Maximized the use of RAVE
• Use full SIP proxy functionality

12
CS-2000 System with Dual DPPMs
System Level Port Distribution
Application Server Module Pentium 1GHz
13
Columbia Developed Modules

• Software Modules
• Static Filtering
• Filtering of pre-defined ports (e.g., SIP, ssh)
• Dynamic Filtering
• Filtering of dynamically opened ports (e.g., RTP)
• Switching Layer
• Perform switching between the input ports
• Firewall Control Module
• Intercept SIP call setup messages
• Get RTP ports from the SDP
• Maintain call state
• Firewall Control Protocol
• The way the Firewall Control Module talks with
  the CloudShield
• Push dynamic table updates to the data plane
• Could be used by multiple SIP Proxies that
  control one or more
• CloudShield firewalls

14
Columbia Modules Diagram

Linux server
sipd
Firewall Control Module
Control Messages Proxy
CAM
CPOS
Dynamic
Static
Table
Table
Lookup
Switch
Drop
15
Integrated Testing and Analysis Tool

• Intelligent Integrated End Point Tool Components
• SIPUA Test Suite
• Loader
• Handler
• Scanning Probes
• nmap
• Automated Script based Control Software
• Timing Devices
• Data Analysis Module
• Analyze handlers file for initial and teardown
  call delays,
• Number of packets dropped before pinhole opening
• Number of packets crossing after pinhole closing
• Scan results for pinhole coverage
• Protocol Analyzer
• SNORT
• Graphical Displays

16
Integrated Intelligent End Point
Trusted
Untrusted
Control and Analysis
SUT
IIEP
IIEP
Traffic Analyzer
Traffic Generator
Port Scanning
SNORT
Probes
Traffic Passed
Media Port
through Pinholes
4
Scanning/Probing Traffic
SIPUA Loader
Signaling and Media Generation
Timing Synchronization
17
SIPUA Methodology

• Loader/Handler
• Establishes calls using SIP
• Sends 160 byte RTP packets every 20ms
• Settable to shorter interval if needed for
  granularity
• Starts RTP sequence numbers from zero
• Dumps call number, sequence number, current
  timestamp and port numbers to a file

18
SIPUA Traffic Generator
SIPUA Handler
SIPUA Loader
SIP Proxy
19
Large Scale Integrated Testing and Analysis
Environment

• Pair of Intelligent Integrated End Points
• Generate traffic for detailed analysis
• External Traffic Generator
• Supplies external stress on SUT
• SIPUA in Array Form supplies traffic from an
  array of 6 computer pairs
• Controller
• Automated Script based Control Software
• Connects to the External Traffic Generation and
  the IIEP over ssh
• Invokes traffic generation
• Gathers, analyzes and correlates results
• Analyzes handler/loaders files for initial and
  teardown call delays
• Matches port scanning results with handlers file

20
Testbed Architecture
GigE Switch
GigE Switch
SIP Proxy
21
Problem Definition

• Problem parameterized along two independent
  vectors
• Call Rate (calls/sec)
• Related to performance of SIP Proxy in Pentium
• Concurrent Calls
• Related to performance of table lookup in IXP 2800

22
Testing And Analysis Methodology

• Generate external load on the firewall
• SIPUA Loader/Handler in external load mode
• Generates thousands of concurrent RTP sessions
• For 30K concurrent calls have 120K open pinholes
• CAM table length is 120K entries
• Search algorithm finds match in one cycle
• When external load is established, run the IIEP
  analysis
• SIPUA Loader/Handler in internal load mode
• Port scanning and Protocol analyzer
• Increment calls/sec rate
• Measure pinhole opening and closing delays
• Opening delay data provided in units of 20 ms
  packets
• Closing delay data provided in units of 10 ms
  packets
• Detect pinholes extraneously open

23
Data Results
24
Data Results (2)
25
Benefits to Verizon and Columbia

• Technology Transfer to Verizon Labs
• Set up a replica of Columbia testbed in Silver
  Spring VoIP lab for rapid SBC evaluation
• Licensing Agreement with CloudShield
• Currently negotiating a Royalty Agreement to take
  technology to market
• Intellectual Property
• Patents and Publications

26
Technology Transfer

• Silver Spring VoIP Lab testbed
• Have 12 computer in parallel running SIPUA,
  SNORT, nmap, protocol analyzers
• Set up Controller software
• Interoperability testing with local SIP proxy
  (Broadsoft)
• SIPUA can be used for other SIP performance
  testing with modifications

27
Intellectual Property

• Pending Patent Applications
• Fine Granularity Scalability and Performance of
  SIP Aware Border Gateways Methodology and
  Architecture for Measurements
• Inventors Henning Schulzrinne, Kundan Singh,
  Eilon Yardeni (Columbia), Gaston Ormazabal
  (Verizon)
• Architectural Design of a High Performance
  SIP-aware Application Layer Gateway
• Inventors Henning Schulzrinne, Jonathan Lennox,
  Eilon Yardeni (Columbia), Gaston Ormazabal
  (Verizon)
• Paper submitted to MASCOTS 2006
• Large Scale SIP-aware Application Layer
  Firewall.
• Authors Henning Schulzrinne, Eilon Yardeni
  (Columbia), Gaston Ormazabal (Verizon)

28
Conclusions

• Have implemented for the first time a SIP ALG
  that scales up to 30K concurrent calls with 300
  calls/sec
• This performance should satisfy Verizon
  carrier-class requirements at a reasonable cost
• Have proved hypothesis that cpu exhaustion will
  limit scalability because of degradation in
  performance
• Have constructed a SIP Proxy based model that
  will permit modularization,
• Hence increasing scalability of future
  architectures
• Have built a one of a kind high-powered black
  box testing environment
• Will permit Verizon verify this technology for
  other vendors

29
Back up slides
30
Verizon Future Security Architecture
Verizon Packet Telephony Access/Aggregation
Network
Call Server Network
SIP
NGSS
Media Proxy
H.248
H.248
Shielded CallP VLAN
MPCP
