System Network Administration

• Chapter 18 Networks
• By Chang-Sheng Chen (20080304)

2
Contents of Chapter 18

• 18.1 The Basics
• 18.1.1 The OSI Model
• 18.1.2 Clean Architecture
• 18.1.3 Network Topologies
• 18.1.4 Intermediate Distribution Frame
• 18.1.5 Main Distribution Frame
• 18.1.6 Demarcation Point
• 18.1.7 Documentation
• 18.1.8 Simple Host Routing
• 18.1.9 Use Network Devices
• 18.1.10 Overlay Network

• 18.1.11 Number of Vendors
• 18.1.12 Standard-based Protocols
• 18.1.13 Monitoring
• 18.1.14 Single Administrative Domain
• 18.2 The Icing
• 18.2.1 Leading-Edge vs. Reliability
• 18.2.2 Multiple Administrative Domains
• 18.3 Conclusion

3
The Closed Network (????)

• PSTN Public Switched Telephone Network

4
The Network Today
5
Internet ?Intranet Extranet

• Intranets differ from "Extranets" in that the
  former are generally restricted to employees of
  the organization while extranets can generally be
  accessed by customers, suppliers, or other
  approved parties.
• The Internet is a worldwide, publicly accessible
  series of interconnected computer networks that
  transmit data by packet switching using the
  standard Internet Protocol (IP). It is a "network
  of networks" that consists of millions of smaller
  domestic, academic, business, and government
  networks, which together carry various
  information and services, such as electronic
  mail, online chat, file transfer, etc.

6
Local-area Networks (LANs)
7
802.3 LAN Development Todays LANs
8
Wide-area Networks (WANs)
9
Metropolitan-Area Network (MANs)

• POP Point of Presence

10
Storage-Area Networks (SANS)
11
18.1.1 OSI Model
12
Network Protocols
13
Peer-to-Peer Communication
14
Devices Function at Layers
15
18.1.2 Clean Architecture

• A network architecture should be as simple and
  clean to understand as it can be.
• It should be possible to briefly describe the
  approach used in designing the network and to
  draw a few simple pictures to illustrate that
  design.
• A clean architecture makes debugging network
  problem much easier.
• You can tell what path traffic should take from
  point A to point B. You can tell which links
  affect which networks.
• Having a clear understanding of traffic flow on
  your network puts you in control of it.

16
Clean Architecture (cont.)

• A clean architecture encompasses both physical
  and logical network topologies and the network
  protocols that are used on both host and network
  equipments.
• It also has a clearly defined growth strategy,
  both for adding LAN segments and for connecting
  new remote offices.

17
Developing a LAN Topology
18
18.1.3 Network Topology

• Network topologies change as technologies and
  cost structures change.
• They also change as companies grow, set up large
  remote offices, or buy other companies.
• Typical Network Topologies
• Star topology
• Pro it is easy to understand, simple and often
  cost-effective to implement.
• Con it has an obvious single-point-of-failure
  problem.
• Extended star topology (multi-star)
• A common variant of the start topology,
  consisting of multiple stars, the centers of
  which are connected to each other with redundant
  high-speed links.

19
?????????????
20
Network Topology
21
Typical Network Topologies (cont.)

• Ring topology (i.e., redundant links)
• Most often used for particular low-level
  topologies such as SONET rings. They are often
  found in local area and campus networks and are
  sometimes useful for WANs.
• Any one link or network entity can fail without
  affecting connectivity between functioning
  members of the ring.
• Adding new members to the ring, particularly in a
  WAN, can involve reconfiguring connectivity at
  multiple sites, however.
• There are many other possible network topologies,
  as shown in the figures of the previous page.

22
Network Topology (cont.)- Logical Network
Topology

• The star, multistar, ring topologies described
  previously can appear in either physical or
  logical topology.
• In the following, we will describe some other
  common logical topologies.
• Flat topology (bus topology)
• In a flat topology, there are no layer 3 devices
  except at the egress point (????).
• E.g., all machines reside in the same address
  block with the same network number and network
  mask.
• Location-based topology
• Layer 2 networks are assigned based on physical
  location.
• Functional group-based topology (e.g., VLAN)
• Each member of a group that works as a functional
  unit is connected to the same (flat) network
  regardless of location (within reason).

23
VLANs and Physical Boundaries
24
18.1.4 Intermediate Distribution Frame (IDF)

• An Intermediate Distribution Frame (IDF) is a
  fancy name for a wiring closet (???/?).
• The distribution system is the set of network
  closets and wiring that brings network
  connectivity out to the desktops.
• The need for IDFs, and how to design them and lay
  them out, is not something that has changed
  dramatically over time.
• The technologies and wiring specifics are what
  change with time.

25
Extended Star Topology in a Multi-Building Campus
26
Intermediate Distribution Frame (cont.)

• New innovations in network hardware require
  high-quality copper or fiber wiring to operate at
  increase speeds.
• If you use the newest, highest-specification
  wiring available when you build your cable plant,
  it is reasonable to expect it to last for five
  years before network technologies outpaces it.
• However, if you try to save money by using older,
  cheaper, lower-specification wiring, you will
  need to go through the expense and disruption of
  an upgrade sooner than if you had selected better
  cabling.
• E.g., Category 3 (10M), Category 5 (fast
  ethernet), etc.

27
Cabling Standards (1/2) -- Unshielded and
shielded twisted pair cabling standards

• The listed information is from Wikipedia
• Cat 1 Previously used for POTS telephone
  communications, ISDN and doorbell wiring
  (Currently unrecognized by TIA/EIA).
• Cat 2 Previously was frequently used on 4
  Mbit/s token ring networks (Currently
  unrecognized by TIA/EIA).
• Cat 3 Currently defined in TIA/EIA-568-B, used
  for data networks using frequencies up to 16 MHz.
  Historically popular for 10 Mbit/s Ethernet
  networks.
• Cat 4 Provided performance of up to 20 MHz, and
  was frequently used on 16 Mbit/s token ring
  networks (Currently unrecognized by TIA/EIA).

28
Unshielded and shielded twisted pair cabling
standards (2/2)

• Cat 5 Provided performance of up to 100 MHz, and
  was frequently used on 100 Mbit/s ethernet
  networks. May be unsuitable for 1000BASE-T
  gigabit ethernet (Currently unrecognized by
  TIA/EIA).
• Cat 5e Currently defined in TIA/EIA-568-B.
  Provides performance of up to 100 MHz, and is
  frequently used for both 100 Mbit/s and gigabit
  ethernet networks.
• Cat 6 Currently defined in TIA/EIA-568-B. It
  provides performance of up to 250 MHz, more than
  double category 5 and 5e.
• Cat 6a Future specification for 10 Gbit/s
  applications.
• Cat 7 An informal name applied to ISO/IEC 11801
  Class F cabling. This standard specifies four
  individually-shielded pairs (STP) inside an
  overall shield. Designed for transmission at
  frequencies up to 600 MHz.

29
Intermediate Distribution Frame (cont.)

• There are two ways to make a connection between
  two IDFs.
• One is to run bundles of cables between IDFs
  within a building.
• However, if there are large number of IDFs, the
  number of links can make this very expensive and
  complicated to maintain.
• The other is to have a central location (i.e.,
  MDF, Main Distribution Frame) and only run
  bundles from IDFs to this central location.
• Then, to connect any two IDFs, one simply creates
  a cross-connect in the MDF.

30
Intermediate Distribution Frame (cont.)

• You generally only get a chance to lay out and
  allocate space for your IDFs before moving into a
  building.
• It is difficult and expensive to change at a
  later date if you decide that you did the wrong
  thing.
• You should have one IDF per floor, more if the
  floor is large.
• You should align those IDFs vertically within the
  building (in other words, located in the same
  place on each floor, so that they stack on each
  other through the building).
• Vertical alignment means that cabling between the
  IDFs and the MDF is simpler and cheaper to
  install and it is easier to add extra cabling
  between the IDFs at a later date.
• The IDFs should be numbered with the building
  number, floor number, and closet number.

31
Intermediate Distribution Frame (cont.)

• IDF should be locked and subject to restricted
  access.
• Wiring closet should also be on protected power.
• IDF closets should have special cooling beyond
  what the building air-conditioning can supply.
• Network equipment is compact, so you will have
  hot-generating devices packed into a small area.
  A small IDF closet can get very hot without extra
  cooling.
• You should also provide remote console access to
  all the devices located in the IDFs that support
  the functionality.

32
Intermediate Distribution Frame (cont.)- Wiring
to the Desktop (1/2)

• It is less expensive to install jacks at
  construction time rather than add them one at a
  time afterward as needed.
• It is reasonable to install one or two more jacks
  at every desktop than you think any of your
  customer will add later.
• Extra wiring to the closet is very expensive and
  disruptive to add later.
• The same is true when running fiber to the
  desktop.
• Fiber cable is cheap compared with the cost of
  terminating the fiber itself.
• Some sites run fiber to the desktop but only
  terminate what they actually planning on using
  (plus 5 to 10 percent in case of failure).

33
Intermediate Distribution Frame (cont.)- Wiring
to the Desktop (2/2)

• Another thing to consider about installing
  network jacks is their orientation (??/??).
• Jacks are installed in some kind of termination
  box or face-plate, which determines which way the
  jacks face (e.g., Up, Down, Right, Left).
• If the jacks are on the side of the box they can
  face up, down, right, or left.
• Face right or left (good), Face Up or down (not
  good)

34
18.1.5 Main Distribution Frame (MDF)

• The Main Distribution Frame (MDF) is what connect
  the IDFs together and to the data center.
• There should always be plenty of cabling between
  the MDF and the IDFs.
• It is common for part of the data center to be
  the MDF.
• In a data center, the MDF is often referred to as
  the network row or network racks.
• Patch panels in these racks connect to a patch
  panel (???) at the top of each rack in the data
  center.

35
Main Distribution Frame (cont.)

• The MDF must have protected power because it
  connects all the server networks that are on
  protected power to each other. It also needs
  adequate cooling.
• It often connects the Internet, WANS, and remote
  access customers to the data center.
• It connects the IDFs to each other and everything
  else.
• Typically, there is a single MDF per campus.
• A large campus, or one that is particularly
  concerned about redundancy, may have more than
  one.
• An MDF should have the same level of restrict
  access as the data center.
• Only the network administrator team should need
  access to it.

36
18.1.6 Demarcation Point

• A demarcation point(???????) is the boundary
  between your organization and a utility company,
  such as telephone company or network provider.
• It can be a fiber cabinet, a set of punch down
  blocks, a board in a rack, a piece of network
  hardware or a small plastic box on the wall with
  a jack or socket for plugging in a cable.
• The telephone company is only responsible for the
  wiring up to its demarcation points (demarc).
• If you have a fault with a line, you need to be
  able to show the service engineer where the
  correct demarc is, so that he does not end up
  trying to test and fix another operational line.
• The main thing to know about your demarcation
  points is where they are.
• Make sure they are properly labeled.

37
Example HiNet ADSL????????????
38
18.1.7 Documentation

• Network documentation takes on many forms, the
  most fundamental of which is labeling.
• Maps of the physical and logical networks should
  be part of the network documentation.
• The physical network map should show where the
  wires go and the end points or ranges of wireless
  networks.
• If redundancy was part of the physical network
  design, it should clearly indicate and document
  the physical diverse paths.
• The amount and type of connectivity available for
  each link should be indicated.

39
Documentation (cont.)

• The logical map should show the logical network
  topology, with network numbers, names, and
  speeds.
• It should also show routing protocols and
  administrative domains if those vary across the
  network.
• Both the physical and logical network maps should
  reach to the perimeter of the organizations
  network and identify its outer boundaries.

40
Documentation Logical Diagram
41
Documentation (cont.)

• Labeling is the single most important component
  of the network documentation.
• Clear, consistent labeling on patch panels and
  long distance connections is particularly
  important.
• A patch panel (???)
• should clearly indicate the physical location of
  the corresponding patch panel or jacks, and each
  of the connections on the patch panel should be
  clearly and consistently labeled at both ends.

42
Documentation (cont.)

• Long distance connections
• should clearly indicate where the circuit goes,
  who to report problems to, and what information
  will be required when reporting a problem, such
  as the circuit ID and where it terminates.
• Network cables are often hard to label.
• One of the most effective is to use a cable tie
  with a protruding flat tab, to which standard
  sticky labels can be affixed.

43
Documentation (cont.)

• less-permanent connections, such as the network
  connection for each host connection, should also
  be labeled.
• You should only attempt to do this level of
  labeling if you can maintain it. Or, incorrect
  labels are worse than none at all.
• The other key location for documentation is
  online, as part of the configuration of the
  network devices themselves.
• Wherever possible, comment fields and device
  names should be used to provide documentation for
  the network administrators.
• Routers (and switches) usually permit a text
  comment to be recorded with each interface.

44
Server Placement
45
18.1.8 Simple Host Routing

• The routing within a site should be simple,
  deterministic, predictable, and easy to
  understand and diagnose.
• Using simple routing techniques on hosts.
• Making routing on hosts simple makes it possible
  to have the same configuration on all host
  devices and know that they will behave in the
  same deterministic way.
• Redundancy for such hosts should be taken care of
  by the network devices and should be transparent
  to the hosts.

46
Simple Host Routing (cont.)

• If a host is simple-homed, it should have a
  single default route.
• it should not listen to any dynamic routing
  information.
• If a host is multi-homed, it should not route
  packets from other sites.
• It should only accept packets that are addressed
  to it.
• It should have a static routing table and not
  listen to any dynamic routing information.
• Simple host routing makes debugging network
  problems easier and more predictable.
• There is also a performance problem with
  requiring hosts to perform routing.

47
18.1.9 Use Network Devices

• The building blocks of any modern networks should
  be dedicated network devices, such as routers and
  switches, rather than general-purpose hosts that
  have been configured to do routing.
• They should be designed to perform only tasks
  directly related to pushing packets, managing the
  traffic and the device itself.
• They should not be all-purpose devices that are
  configured to handle just network traffic, and
  they should most definitely not be devices that
  are also trying to perform other tasks or to
  perform additional services.

48
Networking Devices
49
18.1.10 Overlay Networks

• An overlay network is a logical topology that
  rides on top of a physical topology.
• Examples include VLAN (virtual LAN), Frame Relay,
  ATM, etc.
• This lets us design simple physical architectures
  that can support whatever complexity we require
  in the logical overlay, yet maintain simplicity
  on the physical layer.

50
Overlay Networks (cont.)

• One the WAN level, this could mean that all sites
  have a single connection to the ATM or
  Frame-Relay cloud.
• The Frame-Relay or ATM switches are then
  configured to provide virtual connections
  (circuits) between them.
• Another WAN example is the use of encrypted
  tunnels (virtual private network, VPNs) across
  the Internet.
• On the LAN level, an overlay network usually
  means
• creating a simple, flat physical topology and
  using IEEE 802.1q VLAN protocols to overlay
  subnetworks that are needed by the customers.

51
Virtual Private Networks (VPNs)
52
VPN Scenario Multiple Internet Access Methods
Headquarter
53
Benefits of VPNs
54
VLANs
VLANs logically segment switched networks based
on an organization's functions, project teams, or
applications as opposed to a physical or
geographical basis.
55
18.1.11 Number of vendors

• Using equipment from many vendors can add
  unnecessary complexity.
• The more vendors whose equipment is on the
  network, the more interoperability problems you
  are likely to experience.
• In addition, there is extra overhead for the
  network administrative staff in learning the
  configurations and quirks of the diverse
  equipment and in tracking software upgrades and
  bugs.
• Minimize the number of the vendors makes the
  network more reliable and easier to maintain.

56
Number of vendors (cont.)

• However, exclusive use of a single vendor has its
  own problems.
• A single vendor cannot possibly make the best
  product in every area.
• Exclusive use of a vendor also leaves your
  protocol interoperability untested, which can
  lead to a surprise the first time a new vendor is
  introduced.
• Somewhere between the extremes is a reasonable
  balance.
• Some sites find choosing a single vendor for each
  protocol layer (e.g., layer1/2/3/7, etc) or each
  tier of the network works well.

57
18.1.12 Standards-based Protocols

• An organizations network should be built using
  standards-based protocols.
• Vendor-proprietary protocols lock you into a
  single vendor by making it difficult to integrate
  equipment from competing vendors.
• Being locked into a particular vendor makes it
  difficult to negotiate for better prices and
  prevent you from adopting another companys
  products to take advantage of their improvements.
• It also leaves you vulnerable to that vendors
  business problems.

58
18.1.13 Monitoring

• You dont know how your network is performing or
  how reliable it is until you monitor it.
• There are two primary types of network
  monitoring.
• One is real-time availability monitoring (e.g.,
  MRTG of routers/switches) and alerting.
• The other is gathering data to do trend analysis
  to predict future demand or for usage-based
  billing purpose.

59
18.1.14 Single Administrative Domain

• A single administrative domain
• having a single, closely tied network
  administrative team with a single management
  structure.
• A network should be a single organism that moves
  traffic around in a coherent, coordinated
  fashion.
• It should be governed by a single set of policies
  and practices that are implemented consistently
  across the entire network.
• Properly designing networks, maintaining them,
  and debugging problems across multiple
  organizations are always difficult.

60
Single Administrative Domain (cont.)

• There are security issues associated with not
  having a single administrative domain.
• When different groups have control over different
  parts of the network, they probably will also
  have different policies with respect to
  connecting other networks to their piece of
  network and the security that should surround
  those connections.
• This results in an unknown level of security for
  the network because it is a single entity and
  only as secure as the weakest link.

61
Single Administrative Domain (cont.)

• Having a single administrative domain does not
  exclude the possibility of having regional or
  divisional network teams that
• all report to the same management structure
• and all are governed by the same set of policies
  and practices.
• The network will still act as a single organism
  if multiple teams work closely together in a
  coordinated fashion.

62
18.2.1 Leading-Edge vs. Reliability

• Typically, the most important quality people seek
  in their networks is reliability.
• Older products that have gone through many
  firmware and hardware revisions tend to be more
  reliable.
• The bugs have been shaken out.
• On the other hand, new features and faster
  connectivity are often only available in new
  products, which may not be field tested.

63
Leading-Edge vs. Reliability (cont.)

• There are different ways to manage this risk.
• You might perform your own certification of new
  products in a lab before they are put into
  product situations and then only slowly deploy
  them to establish confidence before beginning a
  major installation.
• You might have separate customer groups that
  differ in the amount of risk they are willing to
  accept.

64
Leading-Edge vs. Reliability (cont.)

• Some may be willing to accept slightly lower
  reliability in exchange for having access to
  newer features.
• Even then, such equipment should be tested in the
  lab first. People who want cutting edge
  performance still want reliability.
• Sometimes, the customer groups that are willing
  to take the risks are in a different SA teams
  domain of control.
• They may have customer groups with business
  requirements that mean they must use some of the
  new technologies when they become available.
• Let them suffer through the teething problems, if
  you can, and take advantage of your chance to let
  others work out the bugs for you.

65
Leading-Edge vs. Reliability (cont.)

• If you use leading-edge gear, make sure that each
  person who is going to be affected by its early
  problems knows that he is likely to suffer
  outages because the technology is so new.
• If you do not do that in advance, your customer
  will be unhappy and the reputation of your
  network as a whole will be adversely affected.
• If a high-level manager approves the risk, make
  sure the end-users and their direct managers are
  aware of this decision,
• so that outages are not blamed on you.

66
18.2.2 Multiple Administrative Domains

• For political, practical, or security reasons, it
  is sometimes impossible to have a single
  administrative domain.
• If different organizations manage different parts
  of the network and are not governed by the same
  set of policies or managed by the same management
  chain, the network needs a different model.
• The various pieces of the network should have
  explicit borders between them, making use of
  border routing protocols (e.g., BGP) and security
  mechanism (e.g., firewalls) to provide routing
  stability and known levels of security in each of
  the administrative domains, independent of the
  others.

67
Multiple Administrative Domains (cont.)

• If you have multiple administrative domains, you
  should do it the right way.
• The choices and actions of one network
  administrative team should be completely
  independent of what the other teams are doing and
  unable to affect the operations or reliability of
  other networks.

68
Discussion

• Cutting edge
• Windows Vista ???
• KMS authentication
• Routers vs. firewall
• All-in-one servers (e.g., DNS, mail, web, etc.)
• Wireless LAN
• 802.11n vs. 802.11 abg
• Thin client
• Features Mesh ID, controller
• Backbone (wired, wireless)

69
?????????BetaSite??????

• (??,????????????)

70
?????????
??10G??
?????
?????
?????
71
????????

• ????????????,??????? router
• ? 1G ?? TANet ??????
• ? 2G ?? TWAREN ?? POP
• ? 10G ?? HCIX ? 12 ? 1G ? ISP ??
• ? 1.6G/2.5G ?? TWgate ???
• ? 10G ????3G/10G,??1.25G/10G,??1.5G/10G,??1.25G/10
  G,??1.25G/10G,??1.25G/10G,??????1G/1G,TWIX625M/1G,
  TPIX625M/1G ,????620M/1G,????500M/1G,????300M/1G,?
  ???200M/1G,????120M/1G ???????

72
????????

• ?????????????? 96 ??? (single-mode)???????(???????
  ?)?
• ???????????????????????????????,???????? router?

73
??????????

• ??????? 68 Gbits/sec
• lt 128 Bytes/packet ? 91
• ??????, 90 ?? TCP?UDP unknown (e.g., P2P ??),10
  ?? well known (e.g., Mail, DNS, HTTP, etc.)?
• 70 ??? ISP ??,20 ?????????,10 ??? ISP ???
• Top 200 ??? 40?
• Top 200 ????????,?????????
• NO.1 ????? 1,NO.200 ??? 0.1 ?????

74
????????????

• ??? Cisco 7609 ??? 144 port ??? Giga bits
  Ethernet
• ?? 144 port SM mini GBIC?12 port TX mini GBIX
• ?? port mirror ????
• ?? pass through ????
• ???? router pass ??
• ?? Buffer rs232 out bound control ??
• ????????
• ????????
• ??????
• ?? 7 ? 24 ??????
• ?????? IP ????
• ??????????
• ??????

75
???????
?????
?????
2G
2G
Switch 12
Switch 48
PC 2500
76
?????????

• ?????????????????
• ???????????????
• ??? TOP200 ??? 90 ??????
• ????????????
• ?? Real IP
• ???????? 2500 ???
• ???????? 250 ???????
• ???? 144 ? 1G

77
?????????

• ??????????
• ??????????????
• ?????????
• ?????????
• ?????????????
• ???????????spam?open proxy ??????
• ????????,??????
• ??????? ISP ?????,??????????????,?????????
• ????????????????????,?????????????
• ????????????????,??????
• ???????????????,????
• ???????????????????
