FUSE: Lightweight Guaranteed Distributed Failure Notification

1
FUSE Lightweight Guaranteed Distributed Failure
Notification

• Mukil Kesavan
• Original Author Sangeetha Seshadri Spring
  2007. This presentation is an augmented version
  of the original one.

2
Agenda

• Problem Considered
• Background
• What is (/is not) FUSE?
• How FUSE works
• FUSE Semantics
• Implementation
• Evaluation
• Discussion

3
Problem considered

• Failure management in distributed systems
• How do you notify a failure to all relevant
  members of a group of systems with the following
  goals
• Guaranteed delivery of failure notification
• Delivery of failure notification within bounded
  time
• Be lightweight, scalable and flexible

4
Background

• Managing failures in distributed systems is
  important and complex
• Lots of cases and need to maintain a lot of
  state.
• Complexity of applications increase.
• Known techniques (before this paper)
• Weakly/strongly consistent membership services
  maintain a list of each component and whether
  up or down
• () Can be used to implement consensus
• (-) Bound to process or machine. Does not allow
  application components to have failed with
  respect to one operation but not another.
• Unreliable failure detectors
• Solves consensus and atomic broadcast problems in
  partially synchronous distributed systems.
• Can make mistakes and provides weak guarantees.

5
What is (/is not) FUSE?

• A programming model for failure management that
  helps DS nodes agree whether a failure has
  occurred or not handles many corner cases.
• Provides
• Distributed one-way agreement
• Guaranteed failure notification to all group
  members
• Tracks individual app communication paths
• Scalable when apps use overlay network
• Handles arbitrary and intransitive network
  failures (whole group fails)
• Enables fate-sharing of related dist. data
  items
• It is NOT a failure detection service -
  Responsibility of detecting failures shared
  between FUSE and application.
• Does NOT promise efficiency for large groups of
  systems
• Applications Wide-area internet applications
  such as content delivery networks, peer-to-peer
  applications, web-services and grid computing.

6
How FUSE works

• Every node in the system runs a FUSE layer.
• Can create multiple FUSE groups between same set
  of nodes.
• Application invokes the
• FuseId CreateGroup(NodeId set)
• API to create a FUSE group. A unique Group
  FuseID returned to creator.
• FUSE layer on every node contacted (possibly
  concurrently) and initialized.
• Application passes on FuseId to every node in the
  set.
• Each node registers a failure callback
  associated with the Group FuseId using the
• void RegisterFailureHandler(Callback handler,
  FuseId id)

7
How FUSE works (contd)

• Nodes periodically ping each other.
• If a node initiates a ping that is missed, the
  node itself stops responding to future pings
  ensures that individual observation of a failure
  converted into a group notification.
• Nodes notified of failure through callback
• Failure notification can be triggered
• explicitly, by application
• or implicitly when FUSE detects communication
  failure among group members.

8
Fuse Semantics

• Group Creation
• If any group node is unreachable then failure is
  returned to creator and other nodes whose state
  was established.
• Notification for unknown FUSE group ignored.
• Attempt to associate callback with non-existent
  FUSE group results in callback being executed
  immediately.
• Alternative design?
• Guarantees for Notification Delivery
• When a notification is triggered every live node
  in the system hears it within a small multiple of
  failure timeout period. In practice, authors
  claim a single failure timeout is enough is it
  per node?
• False positives possible during transient
  failures.

9
Fuse Semantics (contd)

• Fail-on-Send
• Explicit application failure signaling required
  as FUSE just guarantees failure notification
  delivery.
• Failed comm. Path and intransitive failures cause
  a Fail-on-Send.
• Crash recovery
• A recovering node does not know if a failure
  notification was triggered.
• FUSE handles this by nodes actively comparing the
  live FUSE groups during liveness checking.
• FUSE does not use stable storage, but can be used
  for masking transient failures.

10
Liveness Checking

• FUSE piggybacks on existing overlay maintenance
  pings.
• Per-group spanning trees on an overlay network
  used.
• Terminology
• Members Group members
• Delegates Nodes of overlay that are not part of
  the FUSE group but still aid in liveness
  checking.
• Required to notify neighbors in case of a
  connectivity failure.
• Overlapping liveness checking trees between
  multiple FUSE groups result in all of them being
  monitored during each ping.

11
Security-Scalability trade-offs

• Two kinds of security attacks
• Violation of FUSE semantics Dropped
  notifications
• handled using multiple dissemination trees
  (redundancy)
• Can use all-to-all pinging but high overhead.
• Delegates attack
• use per-group spanning trees without using
  overlay nodes
• Increases the amount of liveness checking
  traffic.
• DoS attacks malicious node causing frequent
  unnecessary failure notifications.
• Delegates cannot cause DoS because they can only
  trigger soft notifications (explained later).

12
Implementation

• Implemented on top of SkipNet
• SkipNet features
• Messages routed through the overlay result in a
  client upcall on every intermediate overlay hop.
• Overlay routing table is visible to the client.
• Route directly between members during creation
  and failure notifications reduces false
  positives.

13
Implementation Group Creation

• Group creation
• Creation request/response directly between root
  and member nodes
• Members simultaneously route InstallChecking
  messages through the overlay towards root. This
  prepares overlay nodes for future liveness
  forwarding

14
Implementation Steady State Notifications

• Steady-State
• Piggyback a hash containing all FUSE groups that
  use a particular overlay link on the SkipNet ping
  messages.
• reuse overlay routing table maintenance traffic
  for liveness checking
• Notifications
• Hard notifications used to dismantle the group
• Direct communication. Reduces latency.
• Soft notifications used to clear state on the
  liveness checking tree.
• Member receiving soft notifications initiates
  repair directly with the root (group creator).
• Provides resilience to delegate failures.

15
Implementation Group Repair

• Repair
• NeedRepair msg Sent by members to root. (In
  order to reduce latency)
• SoftNotification Sent by delegates to root.
• Otherwise repair mostly similar to group
  creation.

16
Experiments

• Latency of group creation As group size
  increases, latency increases since although nodes
  contacted in parallel, probability of
  encountering a slow link is increased.
• Note Groups created by direct messages and hence
  unaffected by the size of the network.

17
Experiments

• Latency of Failure notification
• Explicit notification- Lower than creation due
  to
• cached TCP connections
• One-way message
• Non-blocking.
• Crash failures with ping interval of 1 min and
  timeout of 30 secs. TCP connection timeout
  dominates.

18
Experiments (contd)

• At steady state, no additional traffic
  introduced. (However, message size increased by
  20 bytes due to hash)
• With churn with average network size of 300 and
  an additional 100 nodes churn, FUSE soft
  notifications result in a 33 increase in
  messages (good? Bad?)
• Price paid for reusing overlay liveness..

19
Experiments

• False positives
• Unreliable communication links
• Under high loss rates more groups failed
  (obvious)
• Larger the group size, greater the probability of
  encountering an unreliable link.
• Delegate failures Never generated false
  positives (due to soft notifications and repair)

20
Summary

• Can scale with the number of groups
• Multiple FUSE groups can share liveness checking
  messages
• Designed to support large number of small and
  medium sized groups.
• If application already uses a scalable overlay,
  FUSE can reuse existing liveness checking.
  Otherwise can implement its own overlay or
  alternative liveness checking topology.
• Allows applications to declare failures even when
  application level constraints are violated.
• FAILURE could mean system failure, violation of
  application constraints, invalidation of shared
  data etc.

21
Discussion

• Is the scalable claim true?
• Scalable IF implemented on an overlay. Otherwise
  FUSE does introduce liveness checking traffic
  overhead.
• FUSE just tells you whether or not theres a
  failure. Theres very little info for the app to
  use during repair. The repair here is more of a
  re-establish.
• Reports failure even if one process in the group
  fails they recommend smaller groups
• App semantics might not be conducive to that.
• How to model other failure paradigms like say
  group alive as long as quorum exists?
• Cannot handle Byzantine failures (arbitrary o/p,
  collusion non-determinism are bad for FUSE)

22
Thank you!!
