P2P Databases

1
P2P Databases
2
Overview

• 0. Data objects, pointers (URLs), and attributes
• 1. Freeform versus structured attribute data
• 2. Centralized indices for attribute data and
  pointers (ex Napster)

• 3. Query by flooding (ex Gnutella)
• 4. DHTs (ex Chord)
• 5. Problems with DHTs
• 6. Keyword queries in DHTs (Magnolia)
• 7. Popularity queries
• 8. Demo of system
• 9. (if time) Data transmission    - Overlay vs
  DHT Multicast    - Bittorrent / Splitstream

• 10. (if time) P2P file systems and versioning
  (precursor to undo/redo logging from later in the
  course)


3
P2P Today
edonkey
bittorrent
pastry
jxta
can
fiorana
napster
freenet
united devices
open cola
?
aim
ocean store
netmeeting
farsite
gnutella
icq
ebay
morpheus
limewire
seti_at_home
bearshare
uddi
grove
jabber
popular power
kazaa
folding_at_home
tapestry
mojo nation
process tree
chord
4
Object representation and storage
Objects
Attributes Name , Artist, Album , Genre
Pointer to object
5
P2P vs. Distributed DBMS
Traditional DDBMS Issues

• Transactions
• Distributed Query Optimization
• Interoperation of heterogeneous data sources
• Reliability/failure of nodes

Complex features do not scale
6
P2P vs. Distributed DBMS

• Example application file-sharing
• Simple data model and query language
• No complex query optimization
• Easy interoperation
• No guarantee on quality of results
• Individual site availability unimportant
• Local updates
• No transactions
• Network partitions OK

Simple Amenable to large-scale network of
PCs
7
Example file sharing

• Challenge 1 Performance
• Asking everyone is expensive!
• If I am smart, I only need to ask one peer
• How can I be smart?

File X?
8
Search in P2P

• System can control
• Connections made by users/topology
• Data placement
• Query type
• Tight control Structured
• Efficient, comprehensive
• Loose control Unstructured
• Inefficient, not comprehensive, simple,
  expressive

• Used in real life

9
Centralized

• Napster model
• Benefits
• Efficient search
• Limited bandwidth usage
• No per-node state
• Drawbacks
• Central point of failure
• Limited scale

Bob
Alice
Jane
Judy
10
http//www.snocap.com/
11
Unstructured Query Flooding
12
Problems with unstructured

• Inefficient
• Query messages are flooded
• Even if routing is intelligent, worst case load
  is still O(n), where n is nodes in system

• Not comprehensive
• If I do not get a result for my query, is it
  because none exists?

• (Of course, many optimizations are possible)

13
Distributed Hash Table (DHTs)

• Model
• Key/Object pair, the key is hashed to get an ID
• Example
• Objects are files
• The key is the content of the file
• The ID is the hash of the file contents
• Single operation Lookup(ID)
• Input integer ID
• Output the object with the corresponding ID

14
Identifiers

• IDs are m-bit integers
• Nodes are also assigned IDs
• Commonly assigned by hashing a nodes IP address,
  although many problems with this

• An object is stored on the node with the smallest
  ID greater than the objects ID

• This node is called the successor of the objects
  ID

• IDs are arranged on a circle, so 0 2m-1

15
Data Placement
0

• Nodes
• 0
• 1
• 3

m 3
7
1
1
6

• Data
• 1
• 2
• 6

6
2
2
3
5
4
16
Connections

• Distance
• 20
• 21
• .
• 2m-1

0
7
1
Finger pointers
6
2
3
5
4
17
Query

• Lookup(objectID)
• objectID is typically the ID of the object you
  are looking for, but not necessarily

• Approach
• Find the predecessor of the object
• I.e. the node with the largest ID that is smaller
  than the object ID

• Return the successor of the predecessor

18
Query Example

• Say node 0 wants to find the object with ID 7
• For simplicity, we will assume a node exists at
  every ID in the space


19
Query Example
0
Node 0 Lookup(7)
7
1
Node 0 FindPred (7)
6
2
3
5
4
20
Query Example
0
Node 4 FindPred(7)
7
1
6
2
3
5
4
21
Query Example
0
Node 6 FindPred(7)
7
1
Node 6 is predecessor Return successor node 7
6
2
3
5
4
22
Query characteristics

• With high probability, a query can be answered by
  contacting O(log N) nodes

• N total nodes in the network
• Efficient!
• Also notice if an object with the ID exists in
  the network, it will be found

• Comprehensive!
• State is also O(log N) in size

23
Query characteristics

• Note that finger pointers are not required for
  correct operation

• Only successor pointers are needed
• But then cost of query increases
• O(N) in worst case

24
Advantages of Structured?

• Scalability/Efficiency
• load grows with O(log N)
• Comprehensiveness

25
Disadvantages? (cont)

• Availability of Data
• If a node dies suddenly, what happens to the data
  it was storing?

• MUST replicate data across multiple nodes
• Query Language
• How can we express keyword queries efficiently?
• Many useful applications require different
  languages


26
Magnolia
27
Resulting Distribution
28
Prefix hashing
29
Balancing
Innovation
Balanced over the sibling group
100
Sibling group ID100
All siblings in a group share the same prefix
30
Insert
Keyword hP? SiblingGroup ID
Random Sibling
Locate a sibling node via SIFT
31
Advantages

• Good Balancing Properties

32
Advantages

• Low Traffic Load on nodes for popular queries
• Quick Lookup
• Popularity Ranking of Objects
• Distributed Replication for resilience

33
Implementing Magnolia

• Developed on top of a chord clone written in
  Python

• If youre going to write a peer-to-peer app, why
  not leverage existing modules and libraries?

• Challenge How do we implement group-based stores
  and queries without requiring additional network
  maintenance?


34
Chords Finger Table

• A chord node maintains a finger table of M IPs
  pointing to nodes ahead of it in the ring.

• A pointer at index i is the successor of node id
  (2i-1). This lets us reach any node in the
  network in O(log M) hops

• We use the M most significant bits in a nodes
  id to indicate its group. We want to reach any
  group in O(log M) hops.

• Do we need another table?
• Nope. The last M entries in our finger table
  provide this.

35
Talking to Siblings

• How do we propagate queries through the group?
• Naïve solution send to our predecessor and
  successor.

• A better solution We can send a query throughout
  the group by treating the sibling group as a tree.

36
Sibling Tree
N/N 16 M/M 4
0 1 2 3 4 5
6 7 8 9 10 11 12
13 14 15
0
023
01
8
1
822
122
81
11
2
12
9
5
221
21
521
921
1221
51
91
121
10
11
3
4
6
7
13
14
Every edge can be found in the finger table!
1420
15
37
Sibling Tree Problems

• Problems
• Not every possible node will exist
• Not every node will have results to report
• The query maker needs to know when the search is
  done

• But were okay!
• Nodes can determine if a child sub-tree is dead
• Even if a child node in our sibling table is of a
  higher ID than expected

• its sub-tree contains all existing descendents of
  the expected id

• we can predict when a child is in a sibling our
  ancestors tree


38
Bigger Problems

• What if a pointer in our finger table fails?
• We either have to find the successor to its id
  or fail to query the sub-tree

• What if the lowest ID node isnt the root of our
  tree?

• Some of our edges wont be in our finger table

39
Popularity queries
40
Yulania , Demo
41
BitTorrent
42
SplitStream
