Radio Applications
2
Cablefree Radio Solutions
Flexible H/W and Router OS enables many
applications

• Point-to-Point links Best-in-class radio
  throughput
• Point-to-Multipoint Enhanced features Dual
  Radio
• Hotspot Applications Many features Dual radio
• Wireless CCTV High quality secure
• Wireless Broadband Many features support
• Transportation Moving vehicles e.g. Trains
• Aerial CCTV video Air-to-ground video links

3
(No Transcript)
4
(No Transcript)
5
(No Transcript)
6
Cablefree Wireless Hotspot
Hotspot Applications Features, dual radios
b/w controls
2.4GHz Omnidirectional antenna
Standards-based 802.11 b/g WiFi coverage
Client laptops or PDAs with WiFi cards
gt20 Mbps Total throughput
Cablefree 802.11 Radio
Outdoor grade 2/4/5.3/5.8GHz Tri-band
Dual- Radio Router
5.8GHz 23dBi Directional antenna
Backhaul link 5.8GHz up to 72Mbps
In-building Power supply
Range depends on antennas RF background

• Benefits
• High throughput high quality radio units
• Nstreme protocol - throughput security
• 1 or 2 radio design
• Per-user bandwidth controls
• Walled Garden and authentication

Cablefree 802.11 Radio
Core IP Network
Outdoor grade 5.8GHz Backhaul Radio Router
7
Cablefree Wireless CCTV
Wireless CCTV High quality pictures with b/w
controls
1
Legacy Analogue CCTV Camera
1 or 2x 2.4/5.8GHz Sectored or Omnidirectional an
tennas
Pan Tilt unit
Cablefree 802.11 Radio
gt20 or gt72Mbps Total throughput
Outdoor grade 2/4/5.3/5.8GHz Tri-band
Dual- Radio Router
Cablefree 802.11 Radio
Video-over-IP converter
Range depends on antennas RF background


Total number of cameras depends on Bandwidth,
quality system design
Video Monitors
1

• Benefits
• High throughput
• Tri-band radio units
• Nstreme protocol improves throughput security
• Fully manageable
• 1 or 2 radio design
• Flexible architecture

Modern Digital IP camera

Customer IP Network
N
Cablefree 802.11 Radio
N
8
Cablefree Wireless Broadband
BWA/WISP Many features, dual radios b/w
controls
2.4GHz Omnidirectional Or Sectored antenna
Standards-based 802.11 a/b/g WiFi coverage
Subscriber sites
gt72 Mbps Total throughput Per sector
Outdoor grade 2/4/5.3/5.8GHz Tri-band
Dual- Radio Router
Cablefree 802.11 Radio
5.8GHz 23dBi Directional antenna
Base Station Power supply
Backhaul link 5.8GHz up to gt72Mbps
Cablefree 802.11 Radio
Core IP Network
Outdoor grade 5.8GHz Backhaul Radio Router
Base Station Tower or building
9
Cablefree in Transportation
Transportation Applications Backhaul Hotspot
in 1 unit
Outdoor grade 5.8GHz Backhaul Radio Router
Sectored antennas
Trackside Tower or station infrastructure
5.8GHz 23dBi Omnidirectional Backhaul antenna
Backhaul link 5.8GHz up to gt72Mbps
Cablefree 802.11 Radio
Core IP Network
Cablefree 802.11 Radio
In-carriage 2.4GHz WiFi 802.11 b/g coverage
with onboard RADIUS authentication
Client laptops or PDAs with WiFi cards
Railway grade 2/4/5.3/5.8GHz Tri-band
Dual- Radio Router
2.4GHz internal Omnidirectional antenna
In-train Power supply
Railway carriage
10
Cablefree Airborne Video Links
Wireless Video telemetry for airborne
applications
Wind speed direction sensors
Video-over-IP converter
Pan Tilt unit
Custom Telemetry -to-Ethernet converter
Strain Gauge sensor
Cablefree 802.11 Radio
5.8GHz antenna
Ethernet Switch
gt72Mbps Total throughput
Analogue CCTV Camera
Video Monitor
Video-over-IP converter
Outdoor grade 2/4/5.3/5.8GHz Radio Router
Cablefree 802.11 Radio
Laptop PC
Outdoor grade 2/4/5.3/5.8GHz Radio Router
Ethernet Switch
11
Cablefree Radio Solutions
Radio Features Highlights
64Mbyte Flash ROM contains RouterOS powerful
L2 L3 features easy remote upgrades
Slots for 1x or 2x 802.11a/b/g radios
Tri-band 2.4/5.3/5.8GHz Atheros Radios offer
108Mbps Turbo mode using OFDM, excellent ACR
and sensitivity
Powerful 133 or 266MHz 586-class CPU Low heat
dissipation
16Mbyte SDRAM
Designed to mount in external-grade IP67 enclosure
RF uplink connectors to 1 or 2 antennas (1 shown)
10/100 Ethernet port with 48V Power-over-Ethernet
RS232 Console port for configuration
12
Cablefree Radio Solutions
RouterOS Features Highlights
Windows GUI or Command-line Interface over RS232
or Telnet
Comprehensive stats for radio and
Ethernet interfaces
Comprehensive L1/2/3 networking IP
routing features
Multiple wireless features include WDS, AP, DFS,
virtual-AP and full-duplex links using 2 radio
cards
SNMP, CLI proprietary Management options
Full diagnostic toolset
Control of each interface, bridge routing
functions
Advanced routing includes VRRP for high
availability
Powerful carrier-grade router at no extra cost!
Windows API operates over Ethernet LAN/WAN
13
Cablefree Radio Solutions
RouterOS Security Features Highlights

• 64/128-bit WEP
• WPA
• On-board Radius Server
• Hidden SSID option
• Allow only known MAC addresses
• Proprietary packet protocol significantly
  improves both throughput and security

14
Cablefree Radio Solutions
Summary

• Flexible 2.4 / 5.3 / 5.8GHz dual-radio platform
• Best-in-class radio technology (sensitivity
  throughput)
• High quality Router hardware platform
• Carrier-Class RouterOS software
• Outdoor Radio unit case for wall/pole/tower
  mounting
• Wide choice of antennas
• Power-over-Ethernet at 48V
• Suited to P2P, PMP, Hotspot, WLAN and BWA
  applications
