Open Frame Inverters

• Single or Multiple Lamp Designs
• Mating I/O connectors
• Standard 5v and 12v Models
• Designed for Plug-n-Play
• Custom Variations Available
• (Input Voltages, Input Connectors)

3
Encapsulated Inverters

• Board Mountable Design
• Standard and Custom Models Available
• Excellent Resistance to Shock, Vibration, and
  Humidity
• Great for Medical Applications

4
High Power Inverters

• Open Frame Design with Encapsulated Transformers
• Multiple Lamp Designs
• High Power
• Excellent for Industrial and High Bright
  Applications

5
ERG Product Platforms
6
8m Series
7
S Series
8
SE Series
9
E200 Series
10
P44 Series
11
K Series
12
8mA Series
13
L Series
14
LD Series
15
DmA Series

• High Efficiency
• Up to 12 Watts of Output Power
• Direct Display Connection
• Connectors on same end

16
DmC Series
17
DmD Series
18
8mF Series

• Low Profile
• High Efficiency
• Optimized Form Factor
• 6 Lamp Inverter
• Direct Display Connection
• Onboard PWM Dimming

19
8mD Series

• Single Lamp Inverter
• Wide Range Dimming
• Mounting hole compatible with 8m Series
• Up to 5W of Output Power

20
SE2 Series

• Dual Lamp Inverter
• PCB Mountable
• External PWM Dimming
• Up to 5 Watts of Output Power
• Fully Encapsulated for Resistance to Shock,
  Vibration, and Humidity

21
8mAD Series

• Low Cost
• Dual Lamp Inverter
• High Efficiency
• Up to 5 Watts Typical Output Power
• 8mm High
• Integrated PWM Dimming with Analog Control

22
P44W Series

• PCB Mountable
• Up to 15 Watts of Output Power
• 1 or 2 Lamps
• Boost Current Available
• Starting Voltage up to 2400V
• Operating Range of -30 to 85C

23
P44WD Series

• One or Two Lamp Inverter
• Up to 15 Watts of Output Power
• Wide Temperature Operation
• Available with Boost Current
• Onboard PWM Dimming
• Up to 2400v Start
• One Year Warranty

24
MS Series

• Six lamp Inverter
• For Large LCD Modules
• Up to 45 Watts of Output Power
• Fully Encapsulated Transformers
• Multi-Transformer Design for Reliable Lamp
  Ignition
• Custom Designs Available
• One Year Warranty

25
MD Series

• Up to 16 Lamps
• Up to 80 Watts of Output Power
• Encapsulated Transformers
• On Board PWM Dimming
• Mating Input and Output Harnesses Available

26
8m Kit Series

• Space saving layout
• World Class Support

27
Whats New?
28
Smart Force CCFL Inverters

• ERG Generic Series of CCFL Inverters
• Designed for Production Applications
• Covers a wide range of displays
• Drop in replacements for TDK
• Production quantities in stock

29
Smart Force LED Solutions

• Drivers for OEM backlit LCD Panels
• Drop in replacements for CCFL Rails
• Designed for Production Applications
• Covers most LCD Manufacturers
• Samples quantities in stock

30
