Characterizing Embedded Applications for InstructionSet Extensible Processors

1
Characterizing Embedded Applications for
Instruction-Set Extensible Processors

• By Pan Yu at embedded system seminar
• Mar. 11th, 2004

2
Overview

• What is the limit of potential performance
  speedup using instruction-set extensible
  processors?
• How different constraints will restrict
  performance potential?
• By relaxing control flow, can we gain much?

3
Agenda

• Background introduction about custom architecture
• Aim and motivation of this work
• Methodology and results interpretation
• Implications and conclusion

4
Background Introduction about Custom Architecture
5
The efficiency of HW

• 8 years ago
• When CPU is not sufficient, use HW
• Efficiency of HW

In the age of 486 processors
200 MPEG-I decompression card!
6
Energy Efficiency

• The same amount of energy
• HW Read data from memory, do computation, store
  data back
• SW the same as the above, plus...
• Read instruction from the memory,
• decode instruction,
• schedule and issue instruction,
• prefetch instruction,
• pipeline flushing

4 hours of mpeg2 decoding on 900mAh battery
using dedicate decoding HW
2 hours of mpeg2 decoding on 3800mAh battery
OR
7
Comparison between HW and SW

• SW
• Highly adaptive
• Suitable for control oriented computation
• Lower throughput, higher energy consumption
• HW
• Highly specialized (not adaptive)
• Suitable for computation intensive computation
• Higher throughput, lower energy consumption
• Custom architecture
• Easy to design (adaptive, flexible)
• Higher performance, lower energy consumption

8
Typical Instruction-set extensible processor

• A fragment of the programs data dependence graph
  mapped to CFU (Custom Functional Unit)
• Higher performance, lower energy consumption
• Release the use of temporary registers
• Reduce code size
• CFUs interface to the software as ISA Extension

9
Aim and Motivation of This Work
10
Sub questions of custom instruction
identification automation

• What topology of sub data dependency graph will
  be formed as custom instruction?
• How to identify all potential subgraphs
  efficiently?
• How to evaluate and pick out the ones that are
  most useful in terms of performance speedup or
  energy efficiency, under difference design
  constraints?

Multiple InputSingle Output (MISO)
Multiple InputMultiple Output (MIMO)
Simultaneously schedulable
11
A Limit Study

• Questions about custom instruction identification
  should include how limiting are the different
  constraints
• Number of operands
• Number of custom instructions
• Area for custom logic
• Control flow constraint
• Control flow constraint
• Previous works identifies and evaluates custom
  instructions within individual basic blocks.
  Thus, simplify compiler support, but restrict
  potential performance improvement
• We use trace based method to break control flow
  constraint

12
Three questions to answer

• What is the limit of potential performance
  speedup using instruction-set extensible
  processors?
• How different constraints will restrict
  performance potential?
• By relaxing control flow, can we gain much?

13
Methodology and Results Interpretation
14
Pattern Identification

• Enumerate all the MIMO subgraphs of the DDG
• Contain only arithmetic operations
• Number of input/output constraints
• Convexity condition
• An exhaustive enumeration of existence/non-existen
  ce of each node
• Number all the nodes by a reverse topological
  sort
• Enumeration is from lower numbering nodes to
  higher numbering ones
• The searching space can be viewed as a N level
  binary tree (where N is the total number of node
  on the DDG)

Non-convex subgraph
15
Pattern Identification (contd)

• Prune the search space when violating convexity
  condition or No. of output constraint

Example of identifying patterns contain less
than 2 outputs
6
Non-convex.Conflict.Prune subsearching space.
3 outputs. Conflict. Prune sub searching space
16
Pattern evaluation and selection

• Objective
• Cover the original instructions in the code with
  zero/one custom instruction, that
• 1. Achieve best program acceleration
• 2. In case multiple patterns are partially
  overlapped, select only one
• 3. Under different design constraints

17
Pattern evaluation and selection ILP formulation

• Isomorphic subgraphs are instances of the same
  pattern, which can use the same CFU
• Objective function
• Maximize total performance gain
• Covering exclusion constraint
• Area constraint
• Number of custom instructions constraint

18
Heuristic selection methods

• ILP is intractable when variables and constraints
  are too many
• Heuristic methods
• Ranking each pattern instance with priority
  function
• Scan the rank list once, greedily select current
  highest ranked pattern instance if not violating
  constraints
• If selected, throw out those have collision with
  the current one
• 3 Priority functions
• 1. Performance/Cost ratio2. Software execution
  time3. Performance gain
• 3 heuristic methods using 3 priority functions
  will be used, the result with highest total
  performance gain will be used, which is nearest
  to optimal solution given by ILP method

19
Number of output operand MISO vs MIMO

• Significant improvement MISO?MIMO
• Usually, 2 output is good enough

20
Number of input operand

• 45 input is quite good for both MISO and MIMO

21
Resource Constraint

• 25 adders resource is good for most benchmarks
• (jpeg the biggest benchmark, 200 adders
  resource will suffice)

22
Total No. of custom instructions

• Usually, 5 custom instructions will be quite good

23
Breaking Basic Block Boundary Using Compact
Trace

• Break Basic Block Boundaries (4B)
• Need execution order among basic blocks
• Control Flow Graph with profiling
• Accumulative information can only partially
  deduce programs dynamic behavior
• Program Trace
• Marnix Arnords PhD thesis
• Huge in space
• Traversing the same program region multiple times
• Compact Trace
• Reduce both space and time complexity considerably

24
Whole Program Path (WPP) using SEQUITUR compressor

• SEQUITUR a on-the-fly string compressor
• Input a string (the trace) over the alphabet of
  basic blocks
• Output context free grammar representing the
  trace
• The repeated sequence of sub strings are
  represented by the same non-terminal symbol of
  grammar rules
• An example of a short trace 232324245

A DAG, in which leave nodes represent single
basic blocks, interior nodes represent a sequence
of consecutively executed basic blocks
25
Traversing WPP

• Hierarchically walk on the WPP
• Starting from WPP leaf node, identify all
  patterns within each single basic block
• Walk upwards to the next higher level, identify
  all patterns within each interior node (a
  sequence of consecutively executed basic blocks)
• To avoid producing large number of low frequency
  patterns, only walk through hot leaves and hot
  interior nodes
• Walk up at most 34 levels, because useful
  computation usually wont expand among many basic
  blocks, also wide expanded computation will be
  hard to implement by the compiler

WPP
26
Control flow constraint (Across basic block)

• Significant speedup (up to 148) using across
  basic block patterns
• MIMO has more chance to improve performance

27
Across basic block Crossing if/loop branch

• Either of 2 cases can contribute considerably
• Using Predicate execution, Loop Unrolling to help
  explore

28
Conclusion and implication
29
Conclusion

• A reasonable resource and No. of custom
  instructions constraint wont affect performance
  much
• Under 4-input 2-output, we can achieve most
  performance speedup
• Significant improvement by relaxing control flow
  constraints (using across basic block pattern)

30
Implication

• The resource offered by moderate custom logic
  hardware is almost enough for single embedded
  application
• Research for multi-tasking custom architecture
  are needed

31
Summary

• A feasible approach to identify computation
  patterns on program trace
• Patterns across basic block boundaries
• Evaluating and selecting most valuable patterns
  by ILP or heuristic methods
• A limit study on the potential benefit of
  instruction-set extensible processors
