Title: System Design Concepts


1
System Design Concepts
  • By Gus Roumeliotis

2
System Design Concepts
  • Antenna Combining Systems
  • Allow multiple transmitters and receivers to
    share an antenna system
  • Provide adequate isolation to permit simultaneous
    operation of all frequencies
  • May consist of several antenna systems (multiple
    Tx Rx antennas)
  • Terminology
  • Multicoupling
  • Refers to the combining of multiple transmitters
    and receivers onto a single antenna.
  • Combiner
  • Transmit multicoupler with ferrite isolators

3
System Design Concepts
  • Advantages
  • Maximize tower utilization
  • Reduces tower loading by minimizing the number of
    antennas feedlines
  • Expandable systems avoid need for tower climb
  • Premium antenna location can be utilized by many
    users
  • Minimize interference risk
  • Proper multicoupler system is designed to avoid
    all transmitter noise, receiver desense, and
    intermod problems
  • Bandpass filters commonly used in multicoupler
    systems to provide carrier suppression against
    other transmitters and noise suppression to avoid
    causing problems for receivers.
  • Bandpass filters also inherently notch the second
    harmonic of the pass frequency

4
System Design Concepts
  • VHF systems
  • Virtually no band plan
  • Potential for extremely close Tx-Rx spacings
  • Most Tx combiner and Rx Multicoupler systems are
    custom designs
  • Lower frequency means separation must be greater
    between antennas
  • 30-40 feet tip-to-bottom to gives approx. 55 dB
  • Greater cavity efficiency in this frequency band.
  • 7 bandpass cavity set at 1.0 dB insertion loss
    will provide 20 dB isolation 1.0 MHz from f0
  • UHF Systems
  • Paired services mean standard spacings
  • Watch for close minimum spacings
  • E.g. 461 Tx and 459 Rx
  • Higher frequency means separation can be less
    between antennas
  • 20 feet tip-to-bottom to get 55 dB
  • Lower cavity efficiency at this higher frequency
    band.
  • 7 bandpass cavity set at 1.0 dB insertion loss
    will provide 12 dB isolation 1.0 MHz from f0

5
System Design Concepts
  • 800 900 MHz systems
  • Paired services mean standard spacings
  • Watch for cell sites and paging transmitters
  • 894 MHz is 2MHz from 900 MHz SMR Rx band
  • Higher frequency means separation can be less
    between antennas
  • 10 feet tip-to-bottom to get 55 dB
  • Use of ¾ wavelength cavities required
  • 7 ¾ wave bandpass cavity set at 1.0 dB insertion
    loss will provide 11 dB isolation 1.0 MHz from f0

6
System Design Concepts
  • The Antenna Combining System Design Objectives
  • Provide sufficient isolation between transmitters
    (Txs) and Receivers (Rxs) to prevent RF
    interference in each receiver
  • Tx/Rx (Transmitter noise)
  • Rx/Tx (Receiver desensitization or Tx carrier)
  • Tx/Tx (Transmitter to transmitter isolation)
  • Rx/Rx (Receiver to receiver isolation)
  • Maintain proper impedance match with radios
    (Z050 OHMS)
  • Minimize insertion losses

7
System Design Concepts
  • The Antenna Combining System Design Constraints
  • Number of Transmitters (Txs) and Receivers
    (Rxs)
  • Frequency of Txs and Rxs (MHz)
  • Tx power levels (Watts)
  • Radio manufacturers (Motorola, GE, Kenwood)
  • Number of antennas (Gain of antennas in dBd)
  • Horizontal or Vertical antenna separation (Feet)
  • Future expansion needs
  • Packaging
  • Other operating frequencies on site
  • Combine or mate with existing equipment
  • Desired Price and availability

8
System Design Concepts
  • The Antenna Combining System Design Process
  • Obtain design constraint information
  • Txs Rxs frequencies, power levels, antennas,
    etc.
  • Perform intermodulation study
  • Examine frequency separations
  • Tx/Rx, Rx/Tx, Tx/Tx, Rx/Rx
  • Determine isolation requirements
  • Duplex operation curves (TNRD Curves)
  • Select type(s) of components and/or combiners to
    be utilized
  • Sketch design configuration using Visio
  • (Electrical and Mechanical)
  • Verify all design constraints incorporated and
    objectives met
  • Price system up, and check system availability
  • Finalize system diagram/quotation

9
System Design Concepts
  • Sinclair Capabilities
  • Custom combining and multicoupling systems
    available
  • Complete line of components for embedding into
    OEM systems
  • Cavity filters
  • Duplexers
  • Preselectors
  • Isolators
  • Preamplifiers
  • Splitters

10
System Design Concepts
  • Custom Special Requirements
  • Simplex, half-duplex, full duplex radio combining
  • High power transmitters
  • High isolation/low loss
  • Small packaging
  • Cabinet systems
  • Various power supply configurations
  • Large channel capacity combiners
  • Intermod analysis prevention
  • Isolation analysis design
  • Retuning expansion capabilities
  • Expansion/modification of existing antenna system
  • Environmental protection
  • Customized products (NPRs, RD, etc.)
